Dahua TAS100 User manual

PoE Splitter
Quick Start Guide
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.0

Quick Start Guide
I
Foreword
General
This manual mainly introduces the hardware, installation, and wiring steps of the PoE splitter
(hereinafter referred to as "the device"). Read carefully before using the device, and keep the manual
safe for future reference.
Safety Instructions
The following categorized signal words with defined meaning might appear in the manual.
Signal Words Meaning
Indicates a high potential hazard which, if not avoided, will result in death or
serious injury.
Indicates a medium or low potential hazard which, if not avoided, could result
in slight or moderate injury.
Indicates a potential risk which, if not avoided, could result in property
damage, data loss, lower performance, or unpredictable result.
Provides methods to help you solve a problem or save you time.
Provides additional information as the emphasis and supplement to the text.
Revision History
Version Revision Content Release Time
V1.0.0 First release. June 2023
Privacy Protection Notice
As the device user or data controller, you might collect the personal data of others such as their face,
fingerprints, and license plate number. You need to be in compliance with your local privacy
protection laws and regulations to protect the legitimate rights and interests of other people by
implementing measures which include but are not limited: Providing clear and visible identification
to inform people of the existence of the surveillance area and provide required contact information.
About the Manual
●The manual is for reference only. Slight differences might be found between the manual and the
product.
●We are not liable for losses incurred due to operating the product in ways that are not in
compliance with the manual.
●The manual will be updated according to the latest laws and regulations of related jurisdictions.
For detailed information, see the paper user’s manual, use our CD-ROM, scan the QR code or visit
our official website. The manual is for reference only. Slight differences might be found between
the electronic version and the paper version.
●All designs and software are subject to change without prior written notice. Product updates
might result in some differences appearing between the actual product and the manual. Please

Quick Start Guide
II
contact customer service for the latest program and supplementary documentation.
●There might be errors in the print or deviations in the description of the functions, operations
and technical data. If there is any doubt or dispute, we reserve the right of final explanation.
●Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
●All trademarks, registered trademarks and company names in the manual are properties of their
respective owners.
●Please visit our website, contact the supplier or customer service if any problems occur while
using the device.
●If there is any uncertainty or controversy, we reserve the right of final explanation.

Quick Start Guide
III
Important Safeguards and Warnings
This section introduces content covering the proper handling of the device, hazard prevention, and
prevention of property damage. Read carefully before using the device, and comply with the
guidelines when using it.
Transportation Requirements
Transport the device under allowed humidity and temperature conditions.
Storage Requirements
Store the device under allowed humidity and temperature conditions.
Installation Requirements
●Do not connect the power adapter to the device while the adapter is powered on.
●Strictly comply with the local electrical safety code and standards. Make sure that the ambient
voltage is stable and meets the power supply requirements of the device.
●Personnel working at heights must take all necessary measures to ensure personal safety
including wearing a helmet and safety belts.
●Do not place the device in a place exposed to sunlight or near heat sources.
●Keep the device away from dampness, dust, and soot.
●Put the device in a well-ventilated place, and do not block its ventilation.
●Use an adapter or cabinet power supply provided by the manufacturer.
●The power supply must conform to the requirements of ES1 in IEC 62368-1 standard and be no
higher than PS2. Please note that the power supply requirements are subject to the device label.
●Do not connect the device to two or more kinds of power supplies, to avoid damage to the
device.
●The device is a class I electrical appliance. Make sure that the power supply of the device is
connected to a power socket with protective earthing.
●The device must be grounded by a copper wire with a cross-sectional area of 2.5 mm2and a
ground resistance no more than 4 Ω.
●Voltage stabilizer and lightning surge protector are optional depending on the actual power
supply on site and the ambient environment.
●To ensure heat dissipation, the gap between the device and the surrounding area should not be
less than 10 cm on the sides and 10 cm on top of the device.
●When installing the device, make sure that the power plug and appliance coupler can be easily
reached to cut off power.

Quick Start Guide
IV
Operation Requirements
●Do not disassemble the device without professional instruction.
●Operate the device within the rated range of power input and output.
●Make sure that the power supply is correct before use.
●Make sure the device is powered off before disassembling wires to avoid personal injury.
●Do not unplug the power cord on the side of the device while the adapter is powered on.
●Use the device under allowed humidity and temperature conditions.
●Do not drop or splash liquid onto the device, and make sure that there is no object filled with
liquid on the device to prevent liquid from flowing into it.
●This is a class A product. In a domestic environment this may cause radio interference in which
case you may be required to take adequate measures.
●Do not block the ventilator of the device with objects, such as a newspaper, table cloth or curtain.
●Do not place an open flame on the device, such as a lit candle.
Maintenance Requirements
●Power off the device before maintenance.
●Mark key components on the maintenance circuit diagram with warning signs.

Quick Start Guide
V
Table of Contents
Foreword ........................................................................................................................................................................................................I
Important Safeguards and Warnings............................................................................................................................................ III
1 Overview...................................................................................................................................................................................................1
1.1 Introduction .................................................................................................................................................................................1
1.2 Application Scenarios..............................................................................................................................................................1
1.3 Features..........................................................................................................................................................................................1
1.4 Specifications ..............................................................................................................................................................................1
2 Structure ...................................................................................................................................................................................................3
Appendix 1 Cybersecurity Recommendations..........................................................................................................................4

Quick Start Guide
1
1 Overview
1.1 Introduction
TAS 100 is a PoE splitter to supply power for devices of IEEE802.3af standard. It can supply 12 VDC,
1.15 A power for network terminal devices that are under 14 W, with the transmission broadband of
10/100 Mbps, and is used together with power supplies, including PoE switches, PoE injectors and
PoE converters that meet IEEE802.3af standard. The splitter separates power from data signals. In
this way, it supplies power and feeds it to a separate input that a non-PoE compliant device can
access.
1.2 Application Scenarios
●Intelligent traffic surveillance system.
●Expressway surveillance system, electronic road surveillance system, and electronic snapshot
system.
●Large mine factories surveillance system, and network multifunction system.
●Remote multimedia teaching system/school surveillance system, and video conference system.
●Building intercom and video surveillance system.
1.3 Features
●Supports IEEE802.3af Ethernet power standard.
●Supports 10/100 Mbps data transmission.
●12 VDC, 1.15 A power output, applicable for all kinds small network devices.
●Circuit isolation protection for wired devices.
●High quality design, effectively protects the steady and reliable operation of the devices.
●Supports uses in all-metal environment.
●Built-in transformer and snubber circuit for lower heat and more stable voltage.
1.4 Specifications
Table 1-1 Port description
No. Description
1 Network connector (RJ-45 connector, 10/100 Mbps)
2 DC power connector (12 V, 1.15 A)
3 Powered port (RJ-45 connector, 10/100 Mbps)

Quick Start Guide
2
Table 1-2 Environment requirement
No. Name Requirement
1 Working temperature -10 °C to +55 °C (14 °F to +131 °F)10%–90% (RH),
non-condensing
2 Storage temperature -40 °C to +80 °C (-40 °F to +176 °F)5%–95% (RH), non-
condensing
Table 1-3 Electricity features
Model Name Requirement
TAS100
Input voltage 48–52 VDC
Output voltage 12 VDC
Output current 1–1.15 A
Dimensions and Package
●Dimensions for device: 205 mm × 27 mm × 22 mm (8.07'' × 1.06'' × 0.87'')
●Dimensions for package: 125 mm × 90 mm × 28 mm (4.92'' × 3.54'' × 1.10'')
●Net weight: 45 g
●Gross weight: 80 g
●Package method: unit packaging

Quick Start Guide
3
2 Structure
Figure 2-1 Structure (unit: mm [inch])
Table 2-1 Port description
No. Name
1 Network connector
2 DC power connector
3 Powered port

Quick Start Guide
4
Appendix 1 Cybersecurity Recommendations
Mandatory actions to be taken for basic device network security:
1. Use Strong Passwords
Please refer to the following suggestions to set passwords:
●The length should not be less than 8 characters.
●Include at least two types of characters; character types include upper and lower case letters,
numbers and symbols.
●Do not contain the account name or the account name in reverse order.
●Do not use continuous characters, such as 123, abc, etc.
●Do not use overlapped characters, such as 111, aaa, etc.
2. Update Firmware and Client Software in Time
●According to the standard procedure in Tech-industry, we recommend to keep your device
(such as NVR, DVR, IP camera, etc.) firmware up-to-date to ensure the system is equipped with
the latest security patches and fixes. When the device is connected to the public network, it is
recommended to enable the “auto-check for updates” function to obtain timely information
of firmware updates released by the manufacturer.
●We suggest that you download and use the latest version of client software.
"Nice to have" recommendations to improve your device network security:
1. Physical Protection
We suggest that you perform physical protection to device, especially storage devices. For
example, place the device in a special computer room and cabinet, and implement well-done
access control permission and key management to prevent unauthorized personnel from
carrying out physical contacts such as damaging hardware, unauthorized connection of
removable device (such as USB flash disk, serial port), etc.
2. Change Passwords Regularly
We suggest that you change passwords regularly to reduce the risk of being guessed or cracked.
3. Set and Update Passwords Reset Information Timely
The device supports password reset function. Please set up related information for password
reset in time, including the end user’s mailbox and password protection questions. If the
information changes, please modify it in time. When setting password protection questions, it is
suggested not to use those that can be easily guessed.
4. Enable Account Lock
The account lock feature is enabled by default, and we recommend you to keep it on to
guarantee the account security. If an attacker attempts to log in with the wrong password several
times, the corresponding account and the source IP address will be locked.
5. Change Default HTTP and Other Service Ports
We suggest you to change default HTTP and other service ports into any set of numbers between
1024–65535, reducing the risk of outsiders being able to guess which ports you are using.
6. Enable HTTPS
We suggest you to enable HTTPS, so that you visit Web service through a secure communication
channel.
7. MAC Address Binding

Quick Start Guide
5
We recommend you to bind the IP and MAC address of the gateway to the device, thus reducing
the risk of ARP spoofing.
8. Assign Accounts and Privileges Reasonably
According to business and management requirements, reasonably add users and assign a
minimum set of permissions to them.
9. Disable Unnecessary Services and Choose Secure Modes
If not needed, it is recommended to turn off some services such as SNMP, SMTP, UPnP, etc., to
reduce risks.
If necessary, it is highly recommended that you use safe modes, including but not limited to the
following services:
●SNMP: Choose SNMP v3, and set up strong encryption passwords and authentication
passwords.
●SMTP: Choose TLS to access mailbox server.
●FTP: Choose SFTP, and set up strong passwords.
●AP hotspot: Choose WPA2-PSK encryption mode, and set up strong passwords.
10. Audio and Video Encrypted Transmission
If your audio and video data contents are very important or sensitive, we recommend that you
use encrypted transmission function, to reduce the risk of audio and video data being stolen
during transmission.
Reminder: encrypted transmission will cause some loss in transmission efficiency.
11. Secure Auditing
●Check online users: we suggest that you check online users regularly to see if the device is
logged in without authorization.
●Check device log: By viewing the logs, you can know the IP addresses that were used to log in
to your devices and their key operations.
12. Network Log
Due to the limited storage capacity of the device, the stored log is limited. If you need to save the
log for a long time, it is recommended that you enable the network log function to ensure that
the critical logs are synchronized to the network log server for tracing.
13. Construct a Safe Network Environment
In order to better ensure the safety of device and reduce potential cyber risks, we recommend:
●Disable the port mapping function of the router to avoid direct access to the intranet devices
from external network.
●The network should be partitioned and isolated according to the actual network needs. If
there are no communication requirements between two sub networks, it is suggested to use
VLAN, network GAP and other technologies to partition the network, so as to achieve the
network isolation effect.
●Establish the 802.1x access authentication system to reduce the risk of unauthorized access to
private networks.
●Enable IP/MAC address filtering function to limit the range of hosts allowed to access the
device.

Quick Start Guide
