1General Introduction
1.1 Overview
This series analog camera adopts the high sensitivity CCD and advanced circuit design. It is
featuring the high quality video, the lowest distortion, low noise and etc. This series product is
suitable to be used in surveillance system and video process system.
1.2 Features
zHigh-performance SONY CCD, high resolution, 700TVL, vivid and impressive video.
zSupport auto white balance, ANTI CR (anti-color roll), manual control, push lock, and etc.
Restore high definition and vivid video.
zSupport privacy mask function. Set zone color, transparent, mosaic and etc.
zSupport motion detect function. Set zone sensitivity, block display and etc.
zSupport backlight compensation, high light compensation, close and etc according to the
actual environments.
zSupport ATR (digital WDR) function.
zSupport auto electronic gain control, self-adaptive brightness.
zSupport OSD (on-screen display), suitable for user self-defined setup.
zSupport various languages such as English.
zSupport IR function.
zSupport RS-485 communication protocol.
1.3 Functions
High Definition
700 TVL
540TVL 700TVL
ATR and ATR-EX
ATR (Adaptive Tone-curve Reproduction) function allows the camera to digitally calculate the
video color again and then adjust the brightness to enhance the video quality. This function
can effectively enhance the color and black zone of the video when there is sharp light contrast
in the environments.

2
General Camera ATR Camera
IR function
This series product can use the IR light to allow you to see the object or realize the monitor in
the low illumination environment.
General Camera IR Camera
1.4 Specifications
Please refer to the following sheet for specification.
700 TVL IR Vandal Proof Dome Camera
Model
Parameter CA-DBW480BP/N(-A) CA-DBW481BP/N(-A)
Video Processor 1/3" SONY EXview HAD CCD Ⅱ
Video Format PAL/NTSC
Effective Pixel
PAL:
976(H)*582（V）
NTSC:
976(H)×494（V）
Resolution 700TVL
Min Illumination Color: 0.005Lux/F1.4（0Lux IR light on.）

3
PAL
Auto: 1/50s~1/100,000s
Manual: 1/50s,1/120s,1/250s,1/500,1/1000s,1/2000s,
1/4000s,1/10,000s
Electronic Shutter
NTSC
Auto: 1/60s~1/100,000s
Manual: 1/60s,1/100s,1/250s,1/500,1/1000s,1/2000s,
1/4000s,1/10,000s
Lens Type φ14 port 2.8-12mm zoom auto aperture lens andφ14 port 4-9mm zoom auto
aperture lens.
Day/Night Switch Auto
Video Output 1Vp-p Composite Output (75 Ohm/BNC)
SNR Above 65 dB(AGC OFF)
Max IR Distance 20m.
OSD Menu Control Support
LENS Auto/Manual
SHUTTER/AGC Auto/Manual
BACKLIGHT
(BLC)
Off/BLC/HLC(High light compensation )
WHITE
BALANCE
ATW / ANTI CR /manual/push lock/push/user 1/user 2
DAY/NIGHT
MODE
Auto/black and white/color
ADJUST
Mirror/brightness/contrast/sharpness/hue/gain
ATR Off/luminance/contrast
MOTION
DETECT
Detect sensitivity/block display/area selection
PRIVACY
MASK
Area selection/color/transparent/mosaic
NR Level/Y level/C level
SYNC INT
Camera ID Character/position
OSD
Language English/Japanese and etc
Communication Port RS-485
Protection Level IP66
Working Temperature -30 ~+60℃℃
Power DC12V±10%

4
(-A) series product support AC24V±10% ⁄DC12V±10%.
Power Consumption 4W Max
Dimension(mm) φ160×118.5
Weight 980g(-A:1000g)

5
2Framework
2.1 Dimensions
Please refer to the following figure for the dimension information. The unit is mm. See Figure
2-1.
Figure 2-1
2.2 Structure
Please refer to the following figure for detailed information. See Figure 2-2.
Figure 2-2
Please refer to the following sheet for detailed information.
SN Component
Name Function
1 Device lens /
2 IR Light It is to send out the IR compensation light to enhance the
night vision.

6
SN Component
Name Function
3 Dome internal
Enclosure
/
4 X-Y-Z axis
module.
X-Y-Z axis module to realize 360° monitor.
5 Dome camera
enclosure
/
6 Dome camera
pedestal
/
7
5-direction
buttons
These five buttons are for OSD menu operation.
Please use the up/down button to select the item and use
the left/right button to select the option. The button in the
middle is to confirm current operation.
8 Power input port Connect to the DC 12V power to input the power.
9 RS-485 port Connect to devices such as DVR, keyboard to realize
remote control via this port.
10 Video output port
BNC port is to output analog video signal.
You can connect to the devices such as the DVR or the
NVR.

7
3Installation
The dome camera usually mainly uses the in-ceiling installation.
Important
Please make sure the installation surface can min support the 3X weight of the camera
and the bracket.
Figure 3-1
Figure 3-2

8
Figure 3-3

9
Figure 3-4
Step 1
Use the inner hexagonal wrench (provided) to loose the three inner hexagon screws in the
dome cover and then open the cover. See Figure 3-1.
Step 2
Use the inner hexagonal wrench (provided) to loose the three inner hexagon screws in the
dome and then remove the device installation pedestal. See Figure 3-2.
Step 3
Take out the installation location map from the accessories bag and then paste it on the ceiling
or the wall to identify the installation area. Draw out the cable exit and four plastic expansion
bolt holes in the installation position according to the device pedestal. Dig the four plastic
expansion bolt holes and cable exit. Insert the four plastic expansion bolts into the screw holes.
See Figure 3-3.
Step 4
Adjust the device installation pedestal to the proper position and then draw the cable through
the cable exit you just dug in the ceiling (wall). Line up the four screw holes in the device
pedestal to the four plastic expansion bolt holes in the installation position. Put the four self-
tapping screws in the four plastic expansion bolts firmly. See Figure 3-4.
Step 5

10
Adjust the device position and then line up the three inner hexagon screws of the device to the
three holes in the installation ceiling (wall). Put the three inner hexagon screws to the screw
holes of the device pedestal and then use the inner hexagonal wrench to secure firmly.
Step 6
Loose the trip bolt and then turn the X-Y-Z rotation module to adjust the camera lens to the
proper monitor angle.
Step 7
Use the inner hexagonal wrench to secure three hex screws at the top cover to complete the
installation.
Now you have completed dome camera installation and cable connection.
You can use the terminal devices such as the DVR, NVS and etc to view the monitor video.

11
4Menu
4.1 Main Menu List
Please refer to the following sheet for menu information.
THE 1st MENU THE 2
ND
MENU
TYPE DC、VIDEO
MODE AUTO.
ON,
OFF
AUTO
SPEED
LENS○
1
MANUAL
HIGH
LUMINANCE
MODE SHUTTER+AUTO
IRIS
AUTO IRIS
BRIGHTNESS 0~255
LOW
LUMINANCE
MODE AUTO GAIN
OFF
AUTO
BRIGHTNESS ×0.25~×1.00
MODE SHUTTER+AGC
SHUTTER 1/50~1/10,000
SHUTTER
AGC
MANUAL
AGC 6.00~44.80
B-GAIN 0~255
USER1 R-GAIN 0~255
B-GAIN 0~255
USER2 ○
2R-GAIN 0~255
ANTI CR
MANUAL LEVEL 018~040
PUSH
PUSH
LOCK
SPEED 0~255
DELAY CNT 0~255
ATW FRAME
×0.50~×2.00
WHITE
BALANCE
ATW
ENVIRON
MENT
INDOOR
OUTDOOR
OFF
BLC
BACKLIGH
T HLC
MIRROR ON,OFF
BRIGHTNESS 0~255
CONTRAST 0~255
SHARPNESS 0~255
HUE 0~255
PICT
ADJUST
GAIN 0~255
ATR ON LUMINANCE
LOW
MIDDLE
HIGH
THE 1st MENU THE 2ND MENU
ON CONTRAST
LOW
MIDLOW
MID
MIDHIGH
HIGH
ATR
OFF
DETECT
SENSE
000~127
BLOCK
DISPLAY ON/OFF/SET
MONITOR
AREA
ON
OFF
AREA SEL 1/4~4/4
TOP 000~288
BOTTOM 000~288
LEFT 000~468
ON
RIGHT 000~468
MOTION
DETECT
OFF
AREA SEL 1/4~4/4
TOP 000~288
BOTTOM 000~288
LEFT 000~468
RIGHT 000~468
COLOR 1~8
TRANSPARENT 0.00~1.00
ON
MOSAIC ON
OFF
PRIVACY
MASK
OFF
BURST ON
OFF
DELAY
CNT 000~255
DAY→NIGHT○
3000~255
AUTO
NIGHT→DAY○
4000~255
B/W
BURST ON
OFF
DAY/NIGH
T
COL
OR
NR
MODE OFF,Y/C,Y,C
Y LEVEL 000~015
NR
C LEVEL 000~015
ON
CAMERA
ID○
5OFF
SYNC INT
LANGUAG
E○6
ENGL
IISH
CAMERA
RESET
4.2 Menu Note
○1 : The different series products support various lens. Please refer to the specifications for
detailed information.

12
○2 : The user2 setup is the same with the user1.
○3○4：In day-night mode, the smaller the value is, and the hard for the camera to switch to the
black and white mode. In night-day mode, the larger the value is, and the hard for the camera
to switch to the color. Here we recommend the default value. If the system switches back and
forth when you are using, please set the value in night-day mode larger and the value in the
day-night mode smaller.
○5 ：CAMERA ID
CAMERA ID
0001
A B C D E F G H I J K L M N O P Q R S T U V
W X Y Z 0 1 2 3 4 5 6 7 8 9 —！”# $ % & ’
（）_‵，￥：；< = >?@﹨^*. ×＋⁄
CHR1 CHR2
←→↑↓ CLR POS
RETURN
CHR1: Library 1.
CHR2: Library 2.
←→↑↓: Select the character you want to modify.
CLR: Clear current character.
POS : Select it to go to the camera mask position interface.
○6：The parameter includes: English, French, German, Russian, Portuguese, Spanish,
Chinese and Japanese. The default setup is English.
Important
After you completed the setup, please click the “SAVE ALL” button to save current
setup and then exit the menu. It is to guarantee the camera setup after the power failure.

13
Appendix Toxic or Hazardous Materials or Elements
Toxic or Hazardous Materials or Elements
Component
Name Pb Hg Cd Cr VI PBB PBDE
Circuit Board
Component ○○○○○○
Device
Construction
Material
○
○○○○○
Wire and Cable ○ ○○○○○
Packing
Components ○○○○○○
Accessories ○○○○○○
O: Indicates that the concentration of the hazardous substance in all homogeneous materials
in the parts is below the relevant threshold of the SJ/T11363-2006 standard.
X: Indicates that the concentration of the hazardous substance of at least one of all
homogeneous materials in the parts is above the relevant threshold of the SJ/T11363-2006
standard. During the environmental-friendly use period (EFUP) period, the toxic or hazardous
substance or elements contained in products will not leak or mutate so that the use of these
(substances or elements) will not result in any severe environmental pollution, any bodily injury
or damage to any assets. The consumer is not authorized to process such kind of substances
or elements, please return to the corresponding local authorities to process according to your
local government statutes.
Note
•This manual is for reference only. Slight difference may be found in the user
interface.
•All the designs and software here are subject to change without prior written
notice.
•If there is any uncertainty or controversy, please refer to the final explanation of
us.
•Please visit our website or contact your local service engineer for more
information.
