Welcome
Thank you for purchasing our speed dome!
Please read the following safeguards and warnings carefully before you install or use the
product!

v
Important Safeguards and Warnings
Safety Measures
1. Qualified Engineer Needed
The installation engineer or maintenance engineer shall have corresponding CCTV system
installation certificate or maintenance qualification certificate.
The installation engineer or maintenance engineer shall have qualification certificate for work
at height.
The installation engineer or maintenance engineer shall have the basic knowledge and
operation technique for low-voltage cable layout and low-voltage electronic cable connection.
Please read the installation manual carefully and keep it well for future reference,
We are not liable for any problems caused by unauthorized modifications or attempted repair.
2. Lifting Appliance Requirement
Please select the proper speed dome installation mode and use the lifting appliances at the
safety environment.
The lifting appliances shall have the enough capacity to reach the installation height.
The lifting appliances shall have safe performance.
The precaution measures include two types: Warning and Note.
Warning: It is to alert you there is an optional risk of death or series injury!
Note: It is to alert you there is an optional risk of damage or property loss!
Warning
1. All installation and operation here should conform to your local electrical safety codes. We
assume no liability or responsibility for all the fires or electrical shock caused by improper
handling or installation.
2. Be sure to use all the accessories (such as power adapter) recommended by manufacturer.
3. Do not connect several speed domes to one power adapter. It may result in overheat or fire
if it exceeds the rated load.
4. Before you connect the cable, install or uninstall, or begin the daily maintenance work,
please turn off the power and unplug the power cable.
5. Please make sure the produce is secure firmly on the wall or the ceiling.
6. Please turn off the power and unplug the power cable, If there is any smoke, disgusting
smell, or noise. Please contact your local retailer or customer service centre for help.

vi
7. All the examination and repair work should be done by the qualified service engineers. We
are not liable for any problems caused by unauthorized modifications or attempted repair.
Note
1. Safety Transportation
Heavy stress, violent vibration or water splash are not allowed during transportation, storage
and installation.
This series product must use split type package during the transportation.
We are not liable for any damage or problem resulting from the integrated package during
the transportation.
2. When device is malfunction
Shut down the device and disconnect the power cable immediately if there is smoke, abnormal
smell or abnormal function. Please contact your local retailer ASAP.
3. Do not try to dismantle or modify the device
There is risk of personal injury or device damage resulting from opening the shell.
Please contact your local retailer if there is internal setup or maintenance requirement.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
4. Do not allow other object falling into the device
Please make sure there is no metal or inflammable, explosive substance in the speed dome.
The above mentioned objects in the device may result in fire, short-circuit or damage.
Please shut down the device and disconnect the power cable if there is water or liquid falling
into the camera. Please contact your local retailer ASAP.
Please pay attention to the camera. Avoid the sea water or rain to erode the camera.
5. Handle carefully
Do not allow this series product fall down to the ground.
Avoid heavy vibration.
6. Installation Environment Requirement
This series speed dome should be installed in a cool, dry place away from direct sunlight,
inflammable, explosive substances and etc.
This series product shall be away from the strong electromagnetism radiant, please keep it
away from wireless power, TV transmitter, transformer and etc.
7. Daily Maintenance
Please use the soft cloth to clean dust on the shell, or you can use soft cloth with cleaning
liquid to clean the shell and then use soft cloth to make it dry.

vii
Do not use gasoline, dope thinner or other chemical material to clean the shell. It may result
in shell transfiguration or paint flake.
Do not allow the plastic or rubber material to touch the shell for a long time. It may result in
paint flake.

1
1INTELLIGENT SPEED DOME INSTALLATION
1.1 Installation Environments
Basic Requirement
All installation and operation here should conform to your local electrical safety codes.
Before installation, please open the package and check all the components are included.
Please make sure the speed dome installation environment and installation mode can meet
your requirement. If there is special requirement, please contact your local retailer for more
information.
We assume no liability or responsibility for all the fires or electrical shock caused by
improper handling or installation.
1.2 Check installation space and installation location intension
Please make sure the installation environment has enough space to install the speed dome and
its corresponding bracket.
Please make sure the ceiling, wall and the bracket can support the speed dome and its
corresponding installation component. It shall sustain the 8X weight of the speed dome.
1.3 About cable
Please select the cable according to your transmission distance.
The minimum video coaxial-cable requirement is:
75 ohm.
Full cable with copper conductor
95% knitted copper shield
Please refer to Appendix 2 for RS485 communication cable information.
International Model
Max Transmission Distance
(Ft\M)
RG59/U
750Ft (229M)
RG6/U
1,000Ft (305M)
RG11/U
1,500Ft (457M)
Note: The above can be applied to analog speed dome and network speed dome
International Mode
Max Transmission Distance
(M\Ft)
SYV-75-3
720P（25fps\30fps)：500M/1640Ft
720P（50fps\60fps)：300M/984Ft
1080P（25fps\30fps)：300M/984Ft
Note: The above can be applied to HDCVI speed dome
Select eclectic wire according to your transmission distance:
For 24V AC series product, please refer to Appendix 3.
For 12V DC series product, please refer to Appendix 4.
1.4 Please keep all package material well for future use

2
Please keep speed dome package material well in case you need to send it back to your local
retailer or manufacturer for maintenance work.
Non-original package material may result in device damage during the transportation.

3
2SETUP BEFORE INSTALLATION
2.1 Check Accessories
Before the installation, please check the accessories one by one according to the packing list.
Please make sure all the components listed are included.
2.2 Open Device
This section is for intelligent analog speed dome, intelligent network speed dome, and intelligent
tracking speed dome.
Remove the package and then take out the device. Open the transparent cover and take out the
packing material EPE around the speed dome drive. Please remove the paster from the pedestal.
See Figure 2-1.
Figure 2-1
2.3 Initial Setup
The default setup is:
Address: 1
Baud rate: 9600
Parity: None
120Ωresistance: OFF

4
2.4 Dial Switch Setup (Analog Speed Dome)
The following operation is based on the ceiling mount speed dome. Here we are going to set
speed dome address, baud rate and etc. There are two dial switches on the PTZ for you to set
address, baud rate and etc. See Figure 2-2.
Figure 2-2
2.4.1 Dial Switch Setup for Intelligent Speed Dome
Before you control speed dome, please set the speed dome address, baud rate, parity.
Otherwise, you cannot control the device! See Figure 2-3.
Open speed dome transparent enclosure, you can view the dial switch buttons on the PTZ main
board. You can follow the steps listed below to set the speed dome address, baud rate, and
parity. Please note you need to restart the device to activate the new setup!
For wall mount speed dome, you need to take out the packing material EPE, set the dial switch
buttons and then put it back to the transparent enclosure module.
Figure 2-3

5
There are two dial switch buttons on the PTZ. You can use them to set speed dome address,
baud rate, and parity respectively. It is 1 when you set the button as ON. 1 is the lowest bit for
address setup dial, 8 is the highest bit; 1 is the lowest bit for the baud rate and parity setup dial, 4
is the highest bit.
Please note the intelligent speed dome self-adapt PELCO-D. PELCO-P and industrial
standard protocol, the control protocol doesn’t have to be set via dial.
2.4.2 Baud Rate and Parity Setup
Figure 2-4
For the dial switch button from 1 to 4, 1 and 2 bit is used to set baud rate, 3 and 4 bit is used to
set parity. Please refer to the following figure for detailed information.
Please refer to the baud rate sheet for detailed information.
1
2
Baud Rate
OFF
OFF
9600bps
ON
OFF
4800bps
OFF
ON
2400bps
ON
ON
1200bps
Please refer to the parity setup sheet for detailed information.
3
4
Parity
OFF
OFF
NONE
ON
OFF
EVEN
OFF
ON
ODD
ON
ON
NONE
2.4.3 Speed Dome Address Setup
The address interface is shown as in Figure 2-5.
Figure 2-5
The encode mode adopts binary system. 1 to 8 is valid bit. The highest address bit is 255. You
can refer to the following sheet for more information.
Address
1
2
3
4
5
6
7
8
1
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF

6
3
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
4
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
5
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
6
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
7
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
8
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
……
…………………………………………………………………
254
OFF
ON
ON
ON
ON
ON
ON
ON
255
ON
ON
ON
ON
ON
ON
ON
ON
2.4.4 Terminal Matching Resistance Setup
There is terminal resistance 120Ω on the main board. There are two modes: See
Figure 2-6.
Figure 2-6
The factory default setup is shown as in Figure 2-7. Right now, the jumper (Connection board) is
on the pin 2 and pin 3. The 120Ω resistance does not connect to the device.
Figure 2-7
If you want to connect the 120Ω resistance, please remove the jumper from the pin 2 and pin 3
and connect to pin 1 and pin 2. Now the 120Ω is connected to the circuit. See Figure 2-8.
1-2
2-3
120Ω
ON
OFF

7
Figure 2-8
2.5 Dial Switch Setup (HDCVI Speed Dome)
The following operation is based on the ceiling mount speed dome. Here we are going to set
speed dome address, baud rate and etc. There are two dial switches on the PTZ for you to set
address, baud rate and etc. See Figure 2-9.
Figure 2-9
2.5.1 Dial Switch Setup for Intelligent Speed Dome
Before you control speed dome, please set the speed dome address, baud rate and HD/SD
video format. Otherwise, you cannot control the device! See Figure 2-10.
Open speed dome transparent enclosure, you can view the dial switch buttons on the PTZ main
board. You can follow the steps listed below to set the speed dome address, baud rate, and
HD/SD video format setup. Please note you need to restart the device to activate the new
setup!
For wall mount speed dome, you need to take out the packing material EPE, set the dial switch
buttons and then put it back to the transparent enclosure module.
Figure 2-10

8
There are two dial switch buttons on the PTZ. You can use them to set speed dome address,
baud rate and HD/SD video format respectively. It is 1 when you set the button as ON. 1 is the
lowest bit for address setup dial, 8 is the highest bit; 1 is the lowest bit for the baud rate and
HD/SD video format setup dial, 4 is the highest bit.
Please note the intelligent speed dome self-adapt PELCO-D. PELCO-P and industrial
standard protocol, the control protocol doesn’t have to be set via dial.
2.5.2 Baud Rate and Parity Setup
Figure 2-11
For the dial switch button from 1 to 4, 1 and 2 bit is used to set baud rate, 3 and 4 bit is used to
set HD/SD video format. Please refer to the following figure for detailed information.
Please refer to the baud rate sheet for detailed information.
1
2
Baud Rate
OFF
OFF
9600bps
ON
OFF
4800bps
OFF
ON
2400bps
ON
ON
1200bps
Please refer to the HD/SD video format setup sheet for detailed information.
3
4
HD/SD video format
OFF
OFF
HD
ON
OFF
SD
OFF
ON
Self-adapt
ON
ON
HD
2.5.3 Speed Dome Address Setup
The address interface is shown as in Figure 2-5.
Figure 2-12
The encode mode adopts binary system. 1 to 8 is valid bit. The highest address bit is 255. You
can refer to the following sheet for more information.
Address
1
2
3
4
5
6
7
8
1
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF

9
3
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
4
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
5
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
6
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
7
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
8
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
……
…………………………………………………………………
254
OFF
ON
ON
ON
ON
ON
ON
ON
255
ON
ON
ON
ON
ON
ON
ON
ON
2.5.4 Terminal Matching Resistance Setup
There is terminal resistance 120Ω on the main board. There are two modes: See Figure 2-13.
Figure 2-13
The factory default setup is shown as in Figure 2-14. Right now, the jumper (Connection board)
is on the pin 2 and pin 3. The 120Ω resistance does not connect to the device.
Figure 2-14
If you want to connect the 120Ω resistance, please remove the jumper from the pin 2 and pin 3
and connect to pin 1 and pin 2. Now the 120Ω is connected to the circuit. See Figure 2-15.
Figure 2-15
1-2
2-3
120Ω
ON
OFF

10
3CEILING MOUNT
3.1 Installation Components
The ceiling mount installation component is shown as in Figure 3-1.
Figure 3-1
3.2 Ceiling Mount Installation Steps
3.2.1 Installation Environments
The ceiling mount speed dome can be installed in the hard construction wall in the indoor
environments. Before the installation, please make sure:
The wall is thick enough to install the expansion bolt.
The ceiling can at least sustain the 8x weight of the speed dome, bracket and the
accessories.
3.2.2 Installation Steps
1) The ceiling installation has two cable exit modes: One is to pull the cable through the
side cable exit of the speed dome without dig holes on the ceiling. The other is to dig
holes on the ceiling and pull the cable through the ceiling.
2) Confirm installation position and cable exit mode. Use the ceiling installation position
map to dig holes on the ceiling and then put the four plastic expansion bolts firmly.

11
3) In Figure 3-2, pull the cable according to your cable exit mode. And then use four
screws (working with insulated sleeve) to secure the pedestal of ceiling mount speed
dome on the ceiling. Turn the screws to the plastic expansion bolts.
Figure 3-2
4) In Figure 3-3, line up the arrow symbol on the speed dome external enclosure to the bar
symbol of the pedestal. Use three screws (provided) to secure the external enclosure
on the pedestal and fix firmly.
Figure 3-3

12
3.2.3 Cable Connection
The step listed below is for ceiling, in-ceiling or wall mount series product.
Please connect the power cable, video output cable, RS485 control cable, alarm input/output pin
of the intelligent speed dome composite cable according to your actual requirements. Pleas use
insulation tape to seal the cable connection ports to do proper waterproof work.
Note
The video port is covered the heat shrink tube of high shrinking ratio. After the video
connection, please heat the tube to make sure the video port is damp proof and water
proof.
