HD IR Waterproof Fixed Network Camera User’s Manual
Version 1.2.0
Zhejiang Dahua Technology CO.,LTD
bezpeka-shop.com

i
Welcome
Thank you for purchasing our network camera!
This user’s manual is designed to be a reference tool for your system.
Please read the following safeguard and warnings carefully before you use this series product!
Please keep this user’s manual well for future reference!
bezpeka-shop.com

ii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited
power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction) Please
note: Do not connect two power supplying sources to the device at the same time; it may result
in device damage!
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling
or installation.
We are not liable for any problems caused by unauthorized modification or attempted repair.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Do not apply power to the camera before completing installation.
Please install the proper power cut-off device during the installation connection.
Always follow the instruction guide the manufacturer recommended.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
This series network camera should be installed in a cool, dry place away from direct sunlight,
inflammable, explosive substances and etc.
Please keep it away from the electromagnetic radiation object and environment.
Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.
Otherwise it may result in CCD (CMOS) optical component damage.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the camera.
Thunder-proof device is recommended to be adopted to better prevent thunder.
The grounding studs of the product are recommended to be grounded to further enhance the reliability
of the camera.
6. Daily Maintenance
Please shut down the device and then unplug the power cable before you begin daily maintenance
work.
bezpeka-shop.com

iii
Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens
surface.
Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to
dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the
device.
Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.
Dome enclosure is the optical component, do not touch the enclosure when you are installing the
device or clean the enclosure when you are doing maintenance work. Please use professional optical
clean method to clean the enclosure. Improper enclosure clean method (such as use cloth) may result
in poor IR effect of camera with IR function.
7. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
Accessory Name
Amount
Network Camera Unit
1
Quick Start Guide
1
Installation Accessories Bag
1
CD
1
Warranty Card and Certificate
1
bezpeka-shop.com

iv
Table of Contents
1General Introduction..............................................................................................................1
1.1 Overview ...................................................................................................................1
1.2 Features....................................................................................................................1
1.3 Specifications ...........................................................................................................2
1.3.1 Performance ......................................................................................................2
2Structure .................................................................................................................................6
2.1 Multiple-function Combination Cable .....................................................................6
2.2 Framework and Dimension .....................................................................................6
3Device Installation .................................................................................................................8
4Quick Configuration Tool ....................................................................................................10
4.1 Overview.................................................................................................................10
4.2 Operation ................................................................................................................10
5Web Operation.....................................................................................................................12
5.1 Network Connection...............................................................................................12
5.2 Login and Main Interface.......................................................................................12
6FAQ.......................................................................................................................................15
Appendix Toxic or Hazardous Materials or Elements.............................................................16
bezpeka-shop.com

1
1General Introduction
1.1 Overview
This series network camera integrates the traditional camera and network video technology. It adopts
video data collection, transmission together. It can connect to the network directly without any auxiliary
device.
This series network camera uses standard H.264 video compression technology, which maximally
guarantees the video quality.
It supports the IR night vision function. In the night environments, the device can use the IR light to
highlight the object which is suitable for the surveillance function in the low illumination environments.
The waterproof design conforms to the IP 66 level. It has the sound waterproof function suitable for
use in the outdoor environments.
It can be used alone or used in a network area. When it is used lonely, you can connect it to the
network and then use a network client-end. Due to its multiple functions and various uses, this series
network camera is widely used in many environments such office, bank, road monitor and etc.
1.2 Features
User
Management
Different user rights for each group, one user belongs to one group.
The user right shall not exceed the group right.
Storage
Function
Support central server backup function in accordance with your configuration
and setup in alarm or schedule setting
Support record via Web and the recorded file are storage in the client-end
PC.
Support network storage function such as FTP.
Data
Transmission
Data transmission via PoE.
Network
Monitor
It supports one-channel video data transmit to network terminal and then
decode. Delaying time is within 270ms (network bandwidth support needed)
Max supports 20 connections and output bandwidth is 32Mbps. System
refuses new connection request once it exceeds the bandwidth threshold.
Adopt the following video transmission protocol: HTTP, TCP, UDP,
MULTICAST, RTP/RTCP, RTSP and etc.
Support web access.
Network
Management
Realize network camera configuration and management via Ethernet.
Support device management via web or client-end.
Support various protocols.
Power
External power adapter DC 12V.
Support PoE. (Please refer to specifications.)
Warning！
Do not connect these two power supplying sources to the device at the
same time; it may result in device damage!
Assistant
Function
Log function
Support system resource information and running status real-time display.
Day/Night mode auto switch.
Support picture parameter setup such as electronic shutter and gain setup.
Backlight compensation: screen auto split to realize backlight compensation
to adjust the bright.
Support digital WDR.
bezpeka-shop.com

2
Support video watermark function to avoid vicious video modification.
Support dual bit streams, ACF.
1.3 Specifications
1.3.1 Performance
Please refer to the following sheet for network camera performance specification.
Model
Parameter
IPC-HFW3200SP/N Series
IPC-HFW2100S
System
Main Processor
TI Davinci high performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/2.8" CMOS
1/3 " CMOS
Pixel
1920(H)*1080(V)
1280 (H)*960 (V)
Day/Night Mode
Support day/night switch
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
On/Off
Exposure Mode
Manual/Auto
It ranges from 1/3 to 1/10000
Video
Compression
Standard
H264/ H.264B/H.264H/MJPEG
Note: Some versions may not support H.264H.
Video Frame
Rate
PAL:
Main
stream(1920*1080@25fps)，
extra stream (704*576@25fps)
NTSC:
Main
stream(1920*1080@30fps)，
extra stream(704*480@30fps)
PAL:
Main stream(1280*960@15fps)，
extra stream (704*576@15fps)
Main stream(1280*720@25fps)，
extra stream (704*576@25fps)
NTSC:
Main stream(1280*960@15fps)，
extra stream(704*480@15fps)
Main stream(1280*720@30fps)，
extra stream(704*480@30fps)
Video Bit Rate
H.264: 56Kbps-8192Kbps.
MJPEG is adjustable and bit rate
is adjustable.
Support customized setup.
H.264: 56Kbps-6144Kbps.
MJPEG is adjustable and bit rate
is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, camera masking.
Lens
3.6mm, 6mm, 8mm. Fixed focus.
Lens Interface
M12. Lens is the default accessories
bezpeka-shop.com

3
Video
Motion Detect
396 (18*22) detection zones；sensitivity level ranges from 1 to 6 (The
6th level has the highest sensitivity)
Activation event: video storage, image snapshot, log, email function
and etc.
Record and Backup
Storage
Management
Support display local storage status
Network
Wire Network
1- channel wire Ethernet port, 10/100 Base-T Ethernet
Network Protocol
Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP,
SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,
SNMP.
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
Restore Default
Setup
Reset button (on LED panel)
IR light
IR light 20-30M.
General Parameter
Power
DC 12V power and PoE.
Power
Consumption
DC 12V
6.5 W MAX
DC 12V
6W MAX
Working
Temperature
-20℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
70*66*160
Weight
0.5Kg（Excluding box）
Installation
Bracket installation
Model
Parameter
IPC-HFW4100S
IPC-HFW4200S
IPC-HFW4300S
System
Main Processor
High performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3 " CMOS
1/2.8" CMOS
1/3 " CMOS
Pixel
1280(H) ×960(V)
1920(H) ×1080(V)
2048(H) ×1536(V)
Day/Night Mode
Support day/night switch
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
On/Off
Exposure Mode
Auto/Low noise/Low motion blur/Manual
It ranges from 1/3 to 1/100000.
Video
Compression
Standard
H264/H.264H/MJPEG
bezpeka-shop.com

4
Video Frame
Rate
PAL:
Main
stream(1280*960@25
fps)，
extra stream
(704*576@25fps)
NTSC:
Main
stream(1280*960@30
fps)，
extra
stream(704*480@30f
ps)
PAL:
Main
stream(1920*1080@2
5fps)，
extra stream
(704*576@25fps)
NTSC:
Main
stream(1920*1080@3
0fps)，
extra
stream(704*480@30f
ps)
PAL:
Main
stream(2048*1536@2
0fps)，
extra stream
(704*576@20fps)
Main
stream(1920*1080@2
5fps)，
extra stream
(704*576@25fps)
NTSC:
Main
stream(2048*1536@2
0fps)，
extra
stream(704*480@20f
ps)
Video Bit Rate
H.264: 16Kbps-8192Kbps.
MJPEG is adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, camera masking.
Lens
3.6mm, 6mm, 8mm. Fixed focus.
Lens Interface
M12. Lens is the default accessories
Video
Motion Detect
396 (18*22) detection zones；sensitivity level ranges from 1 to 6 (The
6th level has the highest sensitivity)
Activation event: video storage, image snapshot, log, email function
and etc.
Record and Backup
Record Priority
Manual>video detect>schedule
Storage
Management
Support display local storage status
Network
Wire Network
1-channel wire Ethernet port, 10/100 Base-T Ethernet
Network Protocol
Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP,
SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,
SNMP.
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
Restore Default
Setup
Reset button
IR light
IR light 20-30M.
Gene ral Para mete r
Power
DC 12V power and PoE.
Power
Consumption
DC 12V
5 W MAX
DC 12V
5.5 W MAX
bezpeka-shop.com

5
Working
Temperature
-20℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
70*66*160
Weight
500g（Excluding box）
Installation
Bracket installation
bezpeka-shop.com

6
2Structure
2.1 Multiple-function Combination Cable
You can refer to the following figure for multiple-function combination cable information. See Figure
2-1.
Figure 2-1 Multiple-function combination cable
Please refer to the following sheet for detailed information.
SN
Port Name
Function
Connection
Note
1.
LAN
Network port
Ethernet
port
Connect to standard Ethernet cable.
2
DC12V
Power input
port
/
Power input port. Input DC 12V.
2.2 Framework and Dimension
Please refer to the following two figures for dimension information. The unit is mm. See Figure 2-2 and
Figure 2-3.
bezpeka-shop.com

7
Figure 2-2 Dimension illustration 1
Figure 2-3 Dimension illustration 2
bezpeka-shop.com

8
3Device Installation
Important
The installation wall shall min sustain 3X weight of the bracket and camera.
Please follow the steps listed below to install the device. Please refer to Figure 3-1 and Figure 3-2 for
reference.
Step 1
Paste the installation map on the surface of the wall or the ceiling.
Step 2
Dig the installation holes according to the installation map.
Figure 3-1 Device installation 1
Step 3
Open the accessories bag and then take the expansion bolt out. Insert the expansion bolt into the
installation holes.
Step 4
Take the screws from the accessories bag and then use them to secure the device on the installation
surface of the wall or the ceiling. The sun shield of the device can move forward or backward. Please
secure the set screw of the sun shield after you fixed the device.
Step 5
Connect the corresponding cables.
Step 6
Use the cross-head screwdriver to loosen the adjust screw.
Step 7
Turn the device in different directions to make it suitable for the monitor position.
Step 8
Use the cross-head screwdriver to fix the adjust screw firmly.
bezpeka-shop.com

9
Figure 3-2 Device installation 2
bezpeka-shop.com

10
4Quick Configuration Tool
4.1Overview
Quick configuration tool can search current IP address, modify IP address. At the same time, you can
use it to upgrade the device.
Please note the tool only applies to the IP addresses in the same segment.
4.2Operation
Double click the “ConfigTools.exe” icon, you can see an interface is shown as in Figure 4-1.
In the device list interface, you can view device IP address, port number, subnet mask, default
gateway, MAC address and etc.
Figure 4-1 Search interface
Select one IP address and then right click mouse, you can see an interface is shown as in Figure 4-2.
Select the “Open Device Web” item; you can go to the corresponding web login interface.
Figure 4-2 Search interface 2
If you want to modify the device IP address without logging in the device web interface, you can go to
the configuration tool main interface to set.
bezpeka-shop.com

11
In the configuration tool search interface (Figure 4-1), please select a device IP address and then
double click it to open the login interface. Or you can select an IP address and then click the Login
button to go to the login interface. See Figure 4-3.
In Figure 4-3, you can view device IP address, user name, password and port. Please modify the
corresponding information to login.
Please note the port information here shall be identical with the port value you set in TCP port in Web
Network interface. Otherwise, you cannot login the device.
If you are using device background upgrade port 3800 to login, other setups are all invalid.
Figure 4-3 Login prompt
After you logged in, the configuration tool main interface is shown as below. See Figure 4-4.
Figure 4-4 Main interface
For detailed information and operation instruction of the quick configuration tool, please refer
to the Quick Configuration Tool User’s Manual included in the resources CD.
bezpeka-shop.com

12
5Web Operation
This series network camera products support the Web access and management via PC.
Web includes several modules: Monitor channel preview, system configuration, alarm and etc.
5.1Network Connection
Please follow the steps listed below for network connection.
Make sure the network camera has connected to the network properly.
Please set the IP address, subnet mask and gateway of the PC and the network camera
respectively. Network camera default IP address is 192.168.1.108. Subnet mask is 255.255.255.0.
Gateway is 192.168.1.1
Use order ping ***.***.***.***(* network camera address) to check connection is OK or not.
5.2Login and Main Interface
Open IE and input network camera address in the address bar. See Figure 5- 1.
Figure 5- 1 IP address
The login interface is shown as below. See Figure 5- 2.
Please input your user name and password.
Default factory name is admin and password is admin.
Note: For security reasons, please modify your password after you first login.
Input your IP
address here
bezpeka-shop.com

13
Figure 5- 2 Web login
If it is your first time to log in, system pops up warning information to ask you whether install web plug-
in or not after you logged in for one minute. For detailed plug-in installation, please refer to the Web
Operation Manual included in the resource CD.
After you logged in, you can see the main window. See Figure 5- 3.
Figure 5- 3 Web monitoring window
bezpeka-shop.com

14
Please refer to the Web Operation Manual included in the resource CD for detailed operation
instruction.
bezpeka-shop.com

15
6FAQ
Bug
I can not boot up
the device or
operate properly.
Please click RESET button for at least five seconds to restore
factory default setup.
The water leakage
occurred.
The unauthorized front or rear cap remove many result in water
leakage.
The glass front cap has sustained heavy push or strike.
The waterproof plug of the rear cap becomes loosen.
IR video is poor.
Do not use the proper supplying power. The IR light can not turn on
completely.
The object is out of the IR distance range of current device.
IR-CUT does not turn to the night mode. The photosensitive chip of
the front-end can not sense the IR light.
I can not upgrade
the device via
network.
When network upgrade operation failed, you can use port 3800 to
continue upgrade.
I can not login the
client-end or the
WEB.
For Windows OS 98 or Windows ME user, if you can not install
the client-end or can not view after the installation. We
recommend the win2000sp4 OS or install the client-end of the
low version.
The Active X control is blocked.
The display card version shall be dx8.1 or higher.
Network connection error occurred.
Invalid network setup.
Invalid user name or password.
I can not play the
download file.
There is no player.
There is no DX8.1 or higher.
For the MEDIA PLAYER, there shall be Div X503Bundle.exe
plugin if you play the .AVI file.
For Windows XP user, you need to install the plugin
DivX503Bundle.exe and ffdsho-2004 1012.exe.
To guarantee
setup update
After you modified the important setup, please reboot the device via
the software to make sure the setup has been updated to the
storage medium.
Power adapter
The general power adapter can work ranging from 0℃to 40 ℃.
The device may result in unstable power supply when the
temperature exceeds the working temperature.
Please replace an industry-level power adapter if you are using
in the harsh environments.
bezpeka-shop.com
