Dahua DHI-ITC215-PW6M-IRLZF-B User manual

Access ANPR Camera
Web Operation Manual
V1.1.0

I
Foreword
General
This manual introduces the functions and operations of the access ANPR camera (hereinafter
referred to as "the Camera").
Safety Instructions
The following signal words might appear in the manual.
Signal Words Meaning
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, reductions in performance, or
unpredictable results.
Provides methods to help you solve a problem or save time.
Provides additional information as a supplement to the text.
Revision History
Revision Content Revision Content Release Time
V1.1.0 Updated functions under ITC. November 2021
V1.0.2 Updated the focal length of 437 and 415
models of camera. July 2021
V1.0.1 Added camera models. March 2021
V1.0.0 First release. November 2019
Privacy Protection Notice
As the device user or data controller, you might collect the personal data of others such as their face,
fingerprints, and license plate number. You need to be in compliance with your local privacy
protection laws and regulations to protect the legitimate rights and interests of other people by
implementing measures which include but are not limited: Providing clear and visible identification
to inform people of the existence of the surveillance area and provide required contact information.
About the Manual
●The manual is for reference only. Slight differences might be found between the manual and the
product.
●We are not liable for losses incurred due to operating the product in ways that are not in
compliance with the manual.
●The manual will be updated according to the latest laws and regulations of related jurisdictions.
For detailed information, see the paper user’s manual, use our CD-ROM, scan the QR code or visit

II
our official website. The manual is for reference only. Slight differences might be found between
the electronic version and the paper version.
●All designs and software are subject to change without prior written notice. Product updates
might result in some differences appearing between the actual product and the manual. Please
contact customer service for the latest program and supplementary documentation.
●There might be errors in the print or deviations in the description of the functions, operations
and technical data. If there is any doubt or dispute, we reserve the right of final explanation.
●Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
●All trademarks, registered trademarks and company names in the manual are properties of their
respective owners.
●Please visit our website, contact the supplier or customer service if any problems occur while
using the device.
●If there is any uncertainty or controversy, we reserve the right of final explanation.

III
Important Safeguards and Warnings
This section introduces content covering the proper handling of the device, hazard prevention, and
prevention of property damage. Read carefully before using the device, comply with the guidelines
when using it, and keep the manual safe for future reference.
Transportation Requirements
Transport the device under allowed humidity and temperature conditions.
Storage Requirements
Store the device under allowed humidity and temperature conditions.
Installation Requirements
●Do not connect the power adapter to the device while the adapter is powered on.
●Strictly comply with the local electric safety code and standards. Make sure the ambient voltage
is stable and meets the power supply requirements of the device.
●Do not connect the device to two or more kinds of power supplies, to avoid damage to the
device.
●Personnel working at heights must take all necessary measures to ensure personal safety
including wearing a helmet and safety belts.
●Do not place the device in a place exposed to sunlight or near heat sources.
●Keep the device away from dampness, dust, and soot.
●Put the device in a well-ventilated place, and do not block its ventilation.
●Use an adapter or cabinet power supply provided by the manufacturer.
●The power supply must conform to the requirements of ES1 in IEC 62368-1 standard and be no
higher than PS2. Please note that the power supply requirements are subject to the device label.
●The device is a class I electrical appliance. Make sure that the power supply of the device is
connected to a power socket with protective earthing.
Operation Requirements
●Check whether the power supply is correct before use.
●Do not unplug the power cord on the side of the device while the adapter is powered on.
●Operate the device within the rated range of power input and output.
●Use the device under allowed humidity and temperature conditions.
●Do not drop or splash liquid onto the device, and make sure that there is no object filled with
liquid on the device to prevent liquid from flowing into it.
●Do not disassemble the device without professional instruction.

IV
Table of Contents
Foreword ........................................................................................................................................................................................................I
Important Safeguards and Warnings............................................................................................................................................ III
1 Introduction ............................................................................................................................................................................................ 1
1.1 Overview........................................................................................................................................................................................ 1
1.2 Features.......................................................................................................................................................................................... 1
2 Web Configuration .............................................................................................................................................................................. 3
2.1 Web Login...................................................................................................................................................................................... 3
2.1.1 Recommended System Requirements................................................................................................................. 3
2.1.2 Device Initialization....................................................................................................................................................... 4
2.1.3 Login ..................................................................................................................................................................................... 6
2.1.4 Resetting Password ....................................................................................................................................................... 6
2.1.5 Web Functions.................................................................................................................................................................. 8
2.2 Guide................................................................................................................................................................................................ 8
2.3 Live.................................................................................................................................................................................................... 9
2.3.1 Video Stream...................................................................................................................................................................10
2.3.2 Live View ...........................................................................................................................................................................10
2.3.3 Recognized Plate Number........................................................................................................................................11
2.3.4 Plate Snapshot ...............................................................................................................................................................11
2.3.5 System Functions..........................................................................................................................................................11
2.3.6 Functions of the Live Page .......................................................................................................................................11
2.3.7 Vehicle Snapshot ..........................................................................................................................................................13
2.3.8 Event List...........................................................................................................................................................................13
2.4 Query .............................................................................................................................................................................................13
2.4.1 Image Search...................................................................................................................................................................13
2.4.1.1 SD Picture...............................................................................................................................................................13
2.4.1.2 PC Picture...............................................................................................................................................................14
2.4.2 Recording Search..........................................................................................................................................................15
2.4.2.1 Recording...............................................................................................................................................................15
2.4.2.2 Watermark.............................................................................................................................................................15
2.4.3 Capture Record Search...............................................................................................................................................16
2.4.4 Alarm Output Search ..................................................................................................................................................17
2.5 Setting...........................................................................................................................................................................................17
2.5.1 ITC.........................................................................................................................................................................................18
2.5.1.1 Setting Snapshot................................................................................................................................................18
2.5.1.2 Intelligence ...........................................................................................................................................................20

V
2.5.1.2.1 Configuring Intelligent Analysis .....................................................................................................20
2.5.1.2.2 Selecting Recognition Scene.............................................................................................................21
2.5.1.3 Configuring OSD ................................................................................................................................................21
2.5.1.3.1 Video OSD...................................................................................................................................................21
2.5.1.3.2 Snapshot OSD...........................................................................................................................................23
2.5.1.4 Configuring Cutout...........................................................................................................................................24
2.5.1.4.1 Snapshot Cutout......................................................................................................................................24
2.5.1.4.2 Plate Overlay.............................................................................................................................................25
2.5.1.5 Setting Blocklist and Allowlist ....................................................................................................................25
2.5.1.5.1 Allowlist.......................................................................................................................................................25
2.5.1.5.2 Blocklist........................................................................................................................................................27
2.5.1.6 Configuring Barrier Control..........................................................................................................................27
2.5.1.7 Configuring RS-485...........................................................................................................................................28
2.5.1.8 Configuring RS-485 External........................................................................................................................30
2.5.1.9 Setting Time Schedule.....................................................................................................................................31
2.5.1.10 Setting RS-485 LED Display........................................................................................................................32
2.5.1.11 Configuring Voice Broadcast ....................................................................................................................33
2.5.1.11.1 Broadcast Content...............................................................................................................................33
2.5.1.11.2 Volume/Encoding.................................................................................................................................34
2.5.1.12 Setting Device Test.........................................................................................................................................35
2.5.1.12.1 Device Test...............................................................................................................................................35
2.5.1.12.2 Capturing Commissioning...............................................................................................................36
2.5.1.12.3 Operation Log Collection .................................................................................................................36
2.5.2 Camera ...............................................................................................................................................................................36
2.5.2.1 Configuring Camera Attributes ..................................................................................................................37
2.5.2.1.1 General.........................................................................................................................................................37
2.5.2.1.2 Shutter..........................................................................................................................................................38
2.5.2.1.3 Metering Zone ..........................................................................................................................................39
2.5.2.2 Configuring Video Parameters ...................................................................................................................40
2.5.2.2.1 Video .............................................................................................................................................................40
2.5.2.2.2 Snapshot......................................................................................................................................................41
2.5.2.2.3 Interest Area..............................................................................................................................................42
2.5.3 Network.............................................................................................................................................................................42
2.5.3.1 Configuring TCP/IP............................................................................................................................................43
2.5.3.2 Configuring Port.................................................................................................................................................43
2.5.3.3 Configuring DDNS.............................................................................................................................................44
2.5.3.4 Configuring Auto Register ............................................................................................................................44
2.5.3.5 Configuring Multicast......................................................................................................................................45

VI
2.5.3.6 Configuring SMTP (Email)..............................................................................................................................45
2.5.3.7 Configuring SNMP.............................................................................................................................................47
2.5.3.8 Configuring IEEE802.........................................................................................................................................47
2.5.3.9 Configuring PPPoE............................................................................................................................................48
2.5.3.10 Configuring Platform ....................................................................................................................................49
2.5.3.10.1 ONVIF .........................................................................................................................................................49
2.5.3.10.2 Info Push Platform...............................................................................................................................49
2.5.4 Event ...................................................................................................................................................................................50
2.5.4.1 Alarm........................................................................................................................................................................50
2.5.4.1.1 Relay Activation.......................................................................................................................................50
2.5.4.1.2 Relay-out .....................................................................................................................................................51
2.5.4.2 Abnormality..........................................................................................................................................................52
2.5.5 Storage...............................................................................................................................................................................53
2.5.5.1 Point .........................................................................................................................................................................53
2.5.5.2 Local..........................................................................................................................................................................53
2.5.5.3 FTP.............................................................................................................................................................................54
2.5.5.4 Client........................................................................................................................................................................55
2.5.5.5 Save Path................................................................................................................................................................56
2.5.6 System................................................................................................................................................................................56
2.5.6.1 General....................................................................................................................................................................56
2.5.6.1.1 General Setup ...........................................................................................................................................56
2.5.6.1.2 Date & Time................................................................................................................................................57
2.5.6.2 Account...................................................................................................................................................................58
2.5.6.2.1 Account........................................................................................................................................................58
2.5.6.2.2 ONVIF User .................................................................................................................................................61
2.5.6.3 Safety .......................................................................................................................................................................62
2.5.6.3.1 System Service..........................................................................................................................................62
2.5.6.3.2 HTTPS............................................................................................................................................................63
2.5.6.3.3 Firewall.........................................................................................................................................................66
2.5.6.4 Default Settings..................................................................................................................................................66
2.5.6.5 Import/Export......................................................................................................................................................67
2.5.6.6 System Maintenance........................................................................................................................................67
2.5.6.7 System Upgrade .................................................................................................................................................67
2.5.7 Information......................................................................................................................................................................68
2.5.7.1 Version ....................................................................................................................................................................68
2.5.7.2 Log.............................................................................................................................................................................69
2.5.7.2.1 System Log.................................................................................................................................................69
2.5.7.2.2 Remote log .................................................................................................................................................69

VII
2.5.7.3 Online User............................................................................................................................................................70
2.5.7.4 Running Status....................................................................................................................................................70
2.6 Alarm..............................................................................................................................................................................................70
2.7 Logout ...........................................................................................................................................................................................71
3 FAQ ............................................................................................................................................................................................................72
Appendix 1 Cybersecurity Recommendations........................................................................................................................73

1
1 Introduction
1.1 Overview
The access ANPR camera adopts intelligent deep learning algorithm. It supports vehicle detection,
license plate recognition, logo recognition, model recognition, and color recognition, and encoding
mode such as H.265.
The Camera consists of protective housing, illuminator, and intelligent HD camera. The intelligent
HD camera adopts progressive scanning CMOS, which owns several features such as high definition,
low illuminance, high frame rate, and excellent color rendition.
The Camera is extensively applied to vehicle capture, and recognition of community road, parking
lot, and other entrance, and exit surveillance.
1.2 Features
The features are available on select modes, and might differ from the actual camera.
Permission Management
●Each user group owns permissions. Permissions of a user cannot exceed the permissions of its
group.
●2 user levels.
●Permission of opening barrier, and blocklist alarm function.
●Device configuration, and permission management through Ethernet.
Storage
●Stores corresponding video data onto the central server according to the configuration (such as
alarm, and timing settings).
●Users can record through web according to their requirements. The recorded video file will be
stored on the computer where client is located.
●Supports local hot swapping of storage card, and storage when network disconnected. It
overwrites stored pictures, and videos automatically when memory becomes insufficient.
●Stores 1024 log records, and user permission control.
●Supports FTP storage, and automatic network replenishment (ANR).
Alarm
●It can trigger alarm upon camera operation exceptions through network, such as memory card
damage.
●Some devices can connect to various alarm peripherals to respond to external alarm input in real
time (within 200 ms). It can correctly deal with various alarms according to the linkage
predefined by users, and generate corresponding voice prompt (users are allowed to record
voice in advance).

2
Network Monitoring
●Transmits video data of single channel compressed by device to network terminal, and make it
reappear after decompression through network. Keep delay within 500ms when bandwidth is
allowed.
●Supports maximum 10 users online at the same time.
●Supports system access, and device management through web.
●Video data transmission adopts HTTP, TCP, UDP, MULTICAST, and RTP/RTCP.
Capture, and Recognition
●Recognition of number plate, and other vehicle information, including vehicle color, logo, model,
and other vehicle features.
●Supports setting OSD information, and configuring location of channel, and picture.
●Supports picture capture, and encoding. Supports picture watermark encryption to prevent
pictures from being tampered.
●The captured pictures can automatically record vehicle time, location, license plate, vehicle color,
and more.
Peripheral Control
●Peripheral control: Supports setting various peripheral control protocols, and connection pages.
●Connects to external devices such as vehicle detector, signal detector, and more.
Auto Adjustment
●Auto iris: Automatically adjusts the iris opening to the changing light throughout the day.
●Auto white balance: Accurately displays the object color when light condition changes.
●Auto exposure: Automatically adjusts shutter speed according to the exposure value of the
image measured by the metering system, and according to shutter, and iris exposure set by
factory defaults.
●Auto gain: Automatically increases camera sensitivity when illuminance is very low, enhancing
image signal output so that the Camera can acquire clear, and bright image.

3
2 Web Configuration
It supports logging in to device web page through browser on PC, and realizes device configuration,
operation, and management.
The pages, and settings are for reference only, and might differ from the actual page.
2.1 Web Login
2.1.1 Recommended System Requirements
You can access the Camera through browsers which support plugin download and browsers without
plugin.
Browsers without plugin have limitations on certain functions.
●When using a browser which supports plugins, you can get a better and more complete
experience.
We recommend using IE browser.
Table 2-1 Recommended system requirements-with plugin
PC Component Recommended System Requirements
Operating System Windows 7, and later
CPU Intel core i3, and faster processor
Graphics Intel HD Graphics, and later
RAM 2 GB, and larger
Monitor 1024 × 768, and higher
Browser Internet Explorer 9/11, Chrome 33/41, Firefox 49
●If IE browser is not available, you can switch to Chrome. For Chrome, make sure the system
attributes meet the requirements included in the table below.
◇If you are using a system which is at a lower performance, we recommend you use substream
to eliminate video lags.
◇When using a 4 MP camera, adjust the video frame rate to 15 fps.
Table 2-2 Recommended system requirements-without plugin
PC Component Recommended System Requirements
Operating System Windows 7, and later
CPU Intel core i5 6500, and faster

4
PC Component Recommended System Requirements
Graphics Intel HD Graphics, and later
RAM 16 GB, and larger
Monitor 1024 × 768, and higher
Browser Chrome 92 and newer
Browsers that do not support plug-in might have trouble displaying certain videos and images, or
downloading data in batches. The Camera reminds you when that happens.
Figure 2-1 Reminder
2.1.2 Device Initialization
The Camera is delivered uninitialized by default. You need to initialize it, and change its password
before further operations.
Before initialization, make sure that both PC IP, and device IP are on the same network segment,
otherwise it might fail to enter the initialization page.
Step 1 Set IP address, subnet mask, and gateway of PC, and device respectively.
●If there is no router in the network, distribute IP address of the same segment.
●If there is router in the network, configure the corresponding gateway, and subnet
mask.
The IP address is 192.168.1.108 by default.
Step 2 Use ping x.x.x.x (device IP address) command to check whether network is connected.
Step 3 Open browser, enter the IP address of the Camera in the address bar, and then press the
Enter key.
Step 4 Enter and confirm the password.
●The new password must consist of 8 to 32 characters, and contain at least two types
from upper case, lower case, number, and special characters (excluding ' " ; :, and &).

5
●If you want to change your password again, go to Setting > System > Account >
Account.
Step 5 Select the Email Address checkbox, and then enter your email address (recommended to
set for resetting your password).
Step 6 Click Confirm.
Figure 2-2 Device Initialization
Step 7 Enter the username, and password, and then click Login.
Figure 2-3 Login
●The Camera prompts when the username or password is incorrect to reminds you of
remaining attempts.
●The account will be locked for 300 s if you enter incorrect username or password for 5
times consecutively.
Step 8 Click Please click here to download, and install the plug-in in the video window.
The system automatically downloads webplugin.exe, and installs it according to prompt.

6
Before installing plug-in, make sure that the associated plug-in option of active has been
modified as Enable or Prompt in Internet Option > Security > Settings .
Figure 2-4 Web page
The Camera prompts authorization failed when there is no operation on the web page for
a long time. In this case, you need to log in again.
2.1.3 Login
You can log in to the web page by following the steps below. For first-time login or login after
restoring factory default settings, see "2.1.2 Device Initialization".
Step 1 Enter the IP address of the Camera in the browser address bar, and then press Enter.
Step 2 Enter your login username, and password, and then click Login.
2.1.4 Resetting Password
Reset the password when you forget or want to change it.
●When scanning QR code to acquire the security code, one QR code supports up to 2 acquisition.
●the security code received through email is only valid for 24 hours.
●One device can generate up to 10 security codes in one day, so you can change the password 10
times at most in one day.
●Email address must be filled in during device initialization; otherwise you will not receive the
security code. The email address of admin can be modified under Setting > System > Account >
Account.
Step 1 Open the browser, enter the IP address of the Camera in the browser address bar, and then
press Enter.
Step 2 Click Forgot password?

7
Figure 2-5 Information
Step 3 Click OK.
If you use IE browser, the system might prompt Stop running the script, click No, and
continue to run the script.
Step 4 Scan the QR code according to the page prompt, and send the scanning result to
designated email to get the security code.
Figure 2-6 Reset password (1)
Scan the actual QR code.
Step 5 Enter the received security code.
Step 6 Click Next.
Figure 2-7 Reset password (2)
Step 7 Set Password, and enter your new password again in Confirm Password.
Step 8 Click Yes.

8
2.1.5 Web Functions
This section mainly introduces the following 6 functions on the web page.
Figure 2-8 Tab
Table 2-3 Tab function description
Tab Function
Guide Quick configuration of plate pixel, recognition region, and more.
Live View, and record live video, and image, adjust the video and image
window, set client image parameter, and more.
Query Search for different types of pictures and videos, and configure watermark
verification of videos.
Setting Set traffic event rules, basic attributes of the Camera , network, storage,
and system, and view system information.
Alarm Set alarm prompt.
Logout Log out of the web client.
The following buttons are very common on the web page.
Table 2-4 Common buttons description
Button Description
Restore all parameters to system defaults.
Refresh the parameters to the latest value.
Save the settings.
2.2 Guide
On the Guide page, you can configure capture scenarios, and get assistance with setting installation
scenario.
You can click at the upper-right corner of the Guide page to exit.
Step 1 Click the Guide tab.
Step 2 Select the basic date and time format and system time of the Camera, and then click
Confirm.
●You can manually enter the time, or click Sync PC to synchronize time from the server.
●Select Plate Algorithm based on the actual region to get better recognition effect.

9
Figure 2-9 Basic parameter
Step 3 Click Drawing to see whether the video image is properly zoomed, and focused by
checking the plate pixel.
Figure 2-10 Drawing
1) Drag zoom, and focus bar to adjust the video image until the image is clear.
2) Follow the tips on the figure on the right side, draw the capture area of entering
vehicles.
3) Click Add next to Shield Area to draw areas where the Camera does not recognize.
Click Delete to delete the area.
4) Realtime Display window in the middle displays the plate recognition result cutout at
the upper-left corner and vehicle image in real-time.
5) Click Save.
Step 4 Click Finish, and then click Finish in the middle to exit the Guide page.
You can always click Back to go back to the last step during the guide.
2.3 Live
Click the Live tab.

10
On this page, it can realize several functions such as live video, live picture, real-time capture, record,
and config (LPR), and more.
Figure 2-11 Live
Table 2-5 Live page description
No. Description No. Description
1 Video stream 5 System functions
2 Live view 6 Functions of the Live page
3 Recognized plate number 7 Vehicle snapshot
4 Plate snapshot 8 Event list
2.3.1 Video Stream
●Main Stream: Make sure that the Camera can record video, and carry out network surveillance
when the network is normal. You can configure main stream resolution within the supported
range of the Camera.
●Sub Stream: Replaces main stream to make network surveillance, and reduce the network
bandwidth possession when network bandwidth is insufficient.
●Protocol: Video surveillance protocol, currently it only supports TCP.
●Fluency: Fluency of viewing the live video. The fluency can be set to High, Middle, Low, and
Default (recommended).
2.3.2 Live View
Displays the live video captured by the Camera. You can also click the icons to change the display
mode of live view.
●: Adjust the image to original size or appropriate window.
●: Click it to switch to big window.

11
Figure 2-12 Big window
●: Click to enable smart track detection. Plate number, vehicle bounding box, and other smart
tracking information will be displayed on the video image.
●: Click to display the window in full screen; double-click or right-click to exit full screen.
2.3.3 Recognized Plate Number
Displays the plate number recognized by the Camera in real time when a vehicle passes.
2.3.4 Plate Snapshot
Displays the snapshot of the license plate when a vehicle passes.
2.3.5 System Functions
Click the tabs to set system functions, including playback, video recording, and snapshot query,
intelligent rules setting, alarm event setting, and system logout.
2.3.6 Functions of the Live Page
This section introduces operations such as image and video capture, zoom, record, and talk.
Figure 2-13 General function option column
Table 2-6 General function option
Icons Name Description
ANPR Receive
Select the checkbox, and the Camera automatically receives
vehicle snapshots, and detects event information triggered by
sources such as radar or video detection, and displays such
snapshots, and information at the lower part of the page.
The snapshots are saved in the storage path defined in
Setting > Storage > Destination > Save Path.

12
Icons Name Description
Record Type Select the format of video recordings (dav by default).
Talk Click Talk, and you can communicate with people on site
through the camera.
Manual
Snapshot
Click to take a snapshot when a vehicle passes. The snapshot is
saved in the storage path.
●Enable ANPR Receive first.
●To change the storage path of snapshots, go to Setting >
Storage > Destination > Save Path.
Digital Zoom
Drag to select any area in the video window, and then the area
will be zoomed in. In any area of the video window, click
or right-click to exit.
Video
Recording
Click it to start recording. Click again to stop recording.
You can set the storage path of video recordings in Setting >
Storage > Destination > Save Path.
Config (LPR) You can draw the area of plate detection, adjust camera’s focal
length, and set applicable region.
Step 1 Click to configure LPR.
Figure 2-14 Config (LPR)
Step 2 Set the focus and zoom mode, which is used to recognize vehicle.
Table 2-7 Focus parameter description
Parameter Description
Auto Focus Auto adjust camera lens, and make the scenario clearly focused.
Regional Click Regional, and then draw a box in the video image to focus the defined
region in the box.
