Dahua OTS102T User manual

HDSDI Fiber Transceiver
User’s Manual
V1.0.0

i
Important Safeguards and Warnings
Please read the following safeguards and warnings carefully before using the product in order to
avoid damages and losses.
Note:
Do not expose the device to lampblack, steam or dust. Otherwise it may cause fire or electric
shock.
Do not install the device at position exposed to sunlight or in high temperature. Temperature
rise in device may cause fire.
Do not expose the device to humid environment. Otherwise it may cause fire.
The device must be installed on solid and flat surface in order to guarantee safety under load
and earthquake. Otherwise, it may cause device to fall off or turnover.
Do not place the device on carpet or quilt.
Do not block air vent of the device or ventilation around the device. Otherwise, temperature in
device will rise and may cause fire.
Do not place any object on the device.
Do not disassemble the device without professional instruction.
Warning:
Please use battery properly to avoid fire, explosion and other dangers.
Please replace used battery with battery of the same type.
Do not use power line other than the one specified. Please use it properly. Otherwise, it may
cause fire or electric shock.
Special Announcement
This manual is for reference only.
All the designs and software here are subject to change without prior written notice.

If there is any uncertainty or controversy, please refer to the final explanation of us.


ii
Table of Contents
1Product Overview............................................................................................. - 1 -
1.1 Introduction............................................................................................................................- 1 -
1.2 Features ................................................................................................................................- 1 -
1.3 Typical Application.................................................................................................................- 1 -
2 Device Structure.................................................................................................. - 3 -
2.1 Front Panel............................................................................................................................- 3 -
2.2 Rear Panel.............................................................................................................................- 3 -
2.3 Indicator and Other Ports......................................................................................................- 4 -
3 Technical Standard ............................................................................................. - 6 -
4 FAQ....................................................................................................................... - 7 -
Appendix A Toxic or Hazardous Materials or Elements...................................... - 8 -

- 1 -
1 Product Overview
1.1 Introduction
SDI fiber transceiver adopts the advanced non-compression digital HD video and high-speed digital
optical fiber transmission technology which converts SDI digital signal to optical signal via
fiber-optical and it can transmit up to 20 km. It is used in public security, school, residence and office
environments.
1.2 Features
Digital non-compression encoding technology.
Auto recognition of video input format.
Support 1-ch SDI and RS485 control data transmission on single fiber.
RS485 speed support 115200bit/s and below.
Support DC12V power supply.
Support video format of 720p/25, 720p/30, 720p/50, 720p/60, 1080p/25, 1080p/30 and 1080i/60.
LED status indicator display fiber transceiver’s working status.
1.3 Typical Application
The typical application of SDI fiber transceiver is shown in Figure 1- 1

- 2 -
Figure 1- 1

- 3 -
2 Device Structure
2.1 Front Panel
The front panel is shown in Figure 2- 1.
Figure 2- 1
2.2 Rear Panel
The rear panel is shown in Figure 2- 2.

- 4 -
Figure 2- 2
2.3 Indicator and Other Ports
For indicator, please refer to Chart 2- 1. For other ports, please refer to Chart 2- 2
Indicator
Description
Color
Status
PWR
Power status
indicator
Green
Means power connection is
normal
LOS
Fiber status
indicator
Green
Means fiber connection is
normal
VIDEO
BNC video
output indicator
Green
Means video input is normal
DATA
RS485 data
transmission
indicator
Flashing green
Means transmitting data
Chart 2- 1

- 5 -
Port
Description
DC12V
Power port, DC12V 1A
IN
Video input port
OUT
Video output port
OPT
Fiber port
RS485
RS485 data port
Chart 2- 2

- 6 -
3 Technical Standard
Parameter
Description
Model
OTS102T
OTS102R
Optical
Standard
Fiber type
Single fiber
Fiber port
FC port
Transmission distance
0km～20km
Send/Receive
wavelength
Sending end: 1310nm send, 1550nm receive
Receiving end: 1550nm send, 1310nm receive
SDI
Standard
(sending
end)
Input electrical level
＞380 mVp-p
Input/output impedance
75 ohm
SDI
Standard
(receiving
end)
Receiving end output
electrical level
800mVp-p ±10%
Receiving end up and
down time
＜0.8ns
Receiving end max
jitter
＜0.2 UI
Input/output impedance
75 ohm
Data
Standard
Input/output port
number
1
Baud rate
≤115200bit/s
Bit error rate
≤10-9
Working mode
Half-duplex auto-negotiation
Data format
RS485
Indicator
Optical link indicator, power indicator, data indicator,
video source indicator
MTBF
>100,000 hours
General
Power supply
DC12V 1A
Working temperature
-40℃～75℃
Power consumption
≤6W
Working humidity
10%～90%
Dimension
104.6mm×96.2mm×29.5mm

- 7 -
4 FAQ
Problem
Possible Cause
Solution
Video signal blanking
Fiber cable, video line
connection are abnormal.
Properly connect fiber cable, and
may judge according to device
indicator.
Video line is too long.
Use better cable, and make 75-5
line > 100m
Sending end and receiving end
are connected inversely.
Make sure sending end is
OTS102T and receiving end is
OTS102R.
RS485 does not work
Connecting terminal’s positive
and negative ends are
connected inversely.
Switch them.

- 8 -
Appendix A Toxic or Hazardous Materials or Elements
Component
Name
Toxic or Hazardous Materials or Elements
Pb
Hg
Cd
Cr VI
PBB
PBDE
Circuit
Board
Component
○
○
○
○
○
○
Device Case
○
○
○
○
○
○
Wire and
Cable
○
○
○
○
○
○
Packing
Components
○
○
○
○
○
○
Accessories
○
○
○
○
○
○
O: Indicates that the concentration of the hazardous substance in all homogeneous materials in the
parts is below the relevant threshold of the SJ/T11363-2006 standard.
X: Indicates that the concentration of the hazardous substance of at least one of all homogeneous
materials in the parts is above the relevant threshold of the SJ/T11363-2006 standard. During the
environmental-friendly use period (EFUP) period, the toxic or hazardous substance or elements
contained in products will not leak or mutate so that the use of these (substances or elements) will
not result in any severe environmental pollution, any bodily injury or damage to any assets. The
consumer is not authorized to process such kind of substances or elements, please return to the
corresponding local authorities to process according to your local government statutes

- 9 -
Note
This user’s manual is for reference only.
Slight difference may be found in user interface.
All the designs and software here are subject to change without prior written notice.
All trademarks and registered trademarks are the properties of their respective owners.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website for more information.
