Daikin FT35CV1A9 Quick start guide

• Indoor Units • R-22 • FT-C
1
1
• Split Sky Air • Indoor Units
1
IndoorSplitFT-CR-22 1 Features
• Easy to clean flat suction grille
• Quiet operation: down to 28 dBA sound pressure level
• Vertical auto-swing function moves the discharge flaps up and down
for efficient air distribution throughout the room
• Wide angle louvers provide a comfortable air flow throughout the
entire room
• You have the choice out of 5 fan speeds to select
• Daikin’s special dry programme reduces humidity in the room without
variation in room temperature
• Powerful mode can be selected for rapid cooling
• Night set mode saves energy by preventing overcooling or
overheating during night time
• Air purification filter with photocatalytic deodorising function:
deodorises the air, powerfully decomposes cigarette and pet odours,
removes house dust and pollen, deactivates bacteria and viruses
• Daikin remote controls give you easy control at your fingertips.
optional 5 steps
standard

3
1
2
• Split Sky Air • Indoor Units 2
• Indoor Units • R-22 • FT-C
2 Specifications
2-1 TECHNICAL SPECIFICATIONS FT25CV1A9 FT35CV1A9 FT50CV1A9 FT60CV1A9
Casing Colour White
Dimensions Packing Height mm 325 325 366 366
Width mm 834 834 1147 1147
Depth mm 258 258 337 337
Unit Height mm 273 273 290 290
Width mm 784 784 1050 1050
Depth mm 195 195 238 238
Weight Machine Weight kg 8.0 8.0 12.0 12.0
Gross Weight kg 11.0 11.0 17.0 17.0
Heat
Exchanger Dimensions Length mm 577 577 863 863
Nr of Rows 2 2 2 2
Fin Pitch mm 1.40 1.40 1.40 1.40
NrofPasses2244
Nr of Stages 12 12 16 16
Tube type Hi-XA (7)
Fin Type ML fin (Multi louver)
Fan Type Cross flow fan
Quantity 1 1 1 1
Air Flow Rate Cooling High m³/min 8.3 8.4 16.2 17.5
Medium m³/min 6.7 7.0 14.0 15.0
Low m³/min 5.0 5.5 11.9 12.5
Fan Motor Quantity 1 1 1 1
Model 18F-22 18F-22 D43C-31 D43C-31
Number of steps 5 steps and auto
Motor Speed
(cooling) High rpm 1360 1390 1260 1340
Medium rpm 1150 1200 1110 1170
Low rpm 940 1010 960 1000
Fan Motor Output
(high) W18 18 43 43
Cooling Sound
Pressure High dBA 38.0 39.0 43.0 46.0
Medium dBA 34.0 35.0 39.0 41.0
Low dBA 28.0 31.0 35.0 36.0
Refrigerant Type R22
Piping
connections Liquid (OD) Diameter (OD) mm 6.4 6.35 6.4 6.4
Gas Diameter
(OD) mm 9.5 12.7 15.9 15.9
Drain Diameter
(OD) mm 18 18 18 18
Heat Insulation Both liquid and gas pipes
Air Filter Removable/washable/Mildew proof
Air direction control Left, right, up and downwards
Temperature control Microcomputer control

• Indoor Units • R-22 • FT-C
1
2
• Split Sky Air • Indoor Units
3
Standard
Accessories Item Installation manual
Quantity 2 pcs
Item Operation manual
Quantity 1 pc
Item Infrared remote control
Quantity 1 pc
Item Screws
Quantity 1 set
Item Batteries
Quantity 2 pcs
Item Mounting plate
Quantity 1 pc
Item Insulation tape Insulation tape Insulation tape Insulation tape
Quantity 1 pc
Item - Remote controller
mounting plate Remote controller mounting plate Remote controller mounting plate
Quantity - 1 pc
Item Remote control holder - - -
Quantity 1 pc - - -
Item Air purification filter with photocatalytic function
Quantity 2 pcs
Notes Sound values are measured in an anechoic room.
Sound pressure level is a relative value, depending on the distance and acoustic environment. For more details,
please refer to sound level drawings of this chapter.
The sound power level is an absolute value indicating the power which a sound source generates.
2-1 TECHNICAL SPECIFICATIONS FT25CV1A9 FT35CV1A9 FT50CV1A9 FT60CV1A9

3
1
2
• Split Sky Air • Indoor Units 4
• Indoor Units • R-22 • FT-C
2-2 ELECTRICAL SPECIFICATIONS FT25CV1A9 FT35CV1A9 FT50CV1A9 FT60CV1A9
Power Supply Name V1 V1 V1 V1
Phase 1111
Frequency Hz 50 50 50 50
Voltage V 220-240
Current Nominal
runningcurrent
(RLA)
Cooling A 0.22 0.22 0.18 0.20
Wiring
connections For Power Supply Quantity 3 3 3 3
Remark 4 for interunit wiring (included earth wiring)
Voltage range Minimum -10%
Maximum +10%
Power Supply Intake Outdoor unit only
NOTES

• Indoor Units • R-22 • FT-C
1
3
• Split Sky Air • Indoor Units
5
3 Dimensional drawing & centre of gravity
3 - 1 Dimensional drawing
FT25,35CV1A9
3D045893
Up/down (automatic)
cooling, dry
Right/left (manual)
Blow
BLADE ANGLE
WIRELESS REMOTE
CONTROLLER
(ARC423A18)
Signal transmitter
Flaps
Front panel fixed screws (inside)
Bottom
Left Right
Rear
Signal receiver
Room temp. thermistor
Timer indicator lamp
Operation indicator lamp
Operation switch
Air flow (indoor)
REQUIRED SPACE
Terminal block with
earth terminal
Name plate
50 min.
(space for performance)
50 min.
(space for performance)
30 min.
(space for performance)
Drain hose
(connecting part I.D. ø 14.0,
O.D. ø 18.0)
(the hose length of outside
the unit is approx. 410)
Gas pipe 9.5 CuT (FT25C--) or
12.7 CuT (FT35C--)
(the length of pipe outside the
unit: about 340)
Liquid pipe 6.4 CuT
(the length of pipe outside
the unit: about 390)
Wall hole
ø 65 hole
Wall hole for
embedded piping
ø 65 hole
STANDARD LOCATIONS OF WALL HOLES
(for performance and maintenance)
(including mounting
plate)

3
1
3
• Split Sky Air • Indoor Units 6
• Indoor Units • R-22 • FT-C
3 - 2 Centre of gravity
FT50,60CV1A9
3D045893
Horizontal blade
(automatic)
cooling
Vertical blade
(manual)
Dry
BLADE ANGLE
WIRELESS REMOTE
CONTROLLER
(ARC433A24)
Signal transmitter
Flaps
Front grille fixing screws (inside)
Bottom
Left Right
Rear
Operation lamp
Signal receiver
Indoor unit on/off
Room temp. thermistor
(inside)
Timer lamp
Air flow (indoor)
REQUIRED SPACE
Terminal block with
earth terminal
(inside)
Model name plate
50 min.
(space for maintenance)
50 min.
(space for performance)
30 min.
(space for performance)
Drain hose for VP13
(connecting part I.D. ø 14.0,
O.D. ø 18.0)
(the hose length of outside
the unit: about 530)
Gas pipe 15.9 CuT
(the length of pipe outside
the unit: about 430)
Liquid pipe 6.4 CuT
(the length of pipe outside
the unit: about 480)
Wall hole
ø 80 hole
Wall hole for
embedded piping
ø 80 hole
STANDARD LOCATIONS OF WALL HOLES
Fan
(including installation plate)
(For performance and maintenance)
Rear
FT25,35CV1A9
4D020686N

• Indoor Units • R-22 • FT-C
1
3
• Split Sky Air • Indoor Units
7
FT50,60CV1A9
4D040313H

3
1
4
• Split Sky Air • Indoor Units 8
• Indoor Units • R-22 • FT-C
4 Piping diagram
FT25,35CV1A9
4D023507H
NOTE
1 Field piping specifications are as shown below.
Model
name A
FT25-- 9.5 CuT
FT35-- 12.7 CuT
Field piping
(6.4 CuT)
Indoor unit
9.5 CuT
Heat exchanger
Thermistor on heat
exchanger
Cross flow fan
Fan motor
Field piping
(specifications see note 1)
7.0 CuT
7.0 CuT
7.0 CuT
7.0 CuT
7.9 CuT

• Indoor Units • R-22 • FT-C
1
4
• Split Sky Air • Indoor Units
9
FT50,60CV1A9
4D040082F
Field piping
(6.4 CuT)
Indoor unit
12.7 CuT
Heat exchanger
Thermistor on heat
exchanger
Cross flow fan
Fan motor
Field piping
(15.9 CuT)
7.9 CuT
Refrigerant flow
Cooling
Heating

3
1
5
• Split Sky Air • Indoor Units 10
• Indoor Units • R-22 • FT-C
5 Wiring diagram
5 - 1 Wiring diagram
FT25,35CV1A9
3D027406C
Signal receiver
To outdoor unit
Wireless remote
controller
LEGEND
C70 Running capacitor
FU Fuse
H1P, H2P Pilot lamp
M1F Fan motor
M1S Swing motor
MR2 Magnetic relay
PCB1, PCB2 Printed circuit board
R1T, R2T Thermistor
S1~S32 Connector
SW7 Operation switch
SA1 Surge arrester
V1, V2 Varistor
X1M Terminal strip
Protective earth
NOTES
1 Wiring diagram nameplate size: width 110 x length 65.
2 Material: wood free tack paper. Coat the reverse side with pressure sensitive adhesive. Refer to AS(Y)303002 unless otherwise specified.
3 This drawing was drawn on CAD system.
4 Make a slit on separate liner in vertical direction.

• Indoor Units • R-22 • FT-C
1
5
• Split Sky Air • Indoor Units
11
FT50,60CV1A9
3D038655C
To outdoor unit
Wireless remote
controller
Signal
receiver
Field wiring
Rectifier
Indoor
LEGEND
FG Frame ground
Fu Fuse
H1H3 Harness
H1P, H2P Pilot lamp
M1F Fan motor
M1S Swing motor
MR2 Magnetic relay
PCB1~PCB4 Printed circuit board
R1T, R2T Thermistor
S1~S38 Connector
S1W Operation switch
SA1 Surge arrester
V1, V2 Varistor
X1M Terminal strip
Protective earth
NOTES
1 Size: length 70 x width 120.
2 Nameplate material: wood free tack paper
3 Coat the reverse side with pressure sensitive adhesive.
4 Refer to purchasing specification AS303002, unless otherwise specified.
5 This drawing was drawn on CAD system.
6 Make a split on separate liner in vertical direction.

3
1
6
• Split Sky Air • Indoor Units 12
• Indoor Units • R-22 • FT-C
6 Sound data
6 - 1 Sound pressure spectrum
FT25CV1A9
4D045896
Octave band center frequency (Hz)
Octave band sound pressure level (dB) (0 dB = 0.0002 µbar)
Location of
microphone
NOTES
1 Measurement was taken in an anechoic room.
2 The operation noise measuring method is in accordance
with JISC9612.
3 Operating conditions:
Power source = 220-240 V, 50 Hz
o------o H (A = 38) and o- - - -o L (A = 28)
4 Operation noise differs with operation and ambient
conditions.
Approximate
threshold hearing
for continuous
noise
FT35CV1A9
4D029147B
Octave band center frequency (Hz)
Octave band sound pressure level (dB) (0 dB = 0.0002 µbar)
Location of
microphone
NOTES
1 Measurement was taken in an anechoic room.
2 The operation noise measuring method is in accordance
with JISC9612.
3 Operating conditions:
Power source = 220-240 V, 50 Hz
o------o H (A = 39) and o- - - -o L (A = 31)
4 Operation noise differs with operation and ambient
conditions.
Approximate
threshold hearing
for continuous
noise
FT50CV1A9
4D045894
Octave band center frequency (Hz)
Octave band sound pressure level (dB) (0 dB = 0.0002 µbar)
Location of
microphone
NOTES
1 Measurement was taken in an anechoic room.
2 The operation noise measuring method is in accordance
with JISC9612.
3 Operating conditions:
Power source = 220-240 V, 50 Hz
o------o H (A = 43) and o- - - -o L (A = 35)
4 Operation noise differs with operation and ambient
conditions.
Approximate
threshold hearing
for continuous
noise
FT60CV1A9
4D045895
Octave band center frequency (Hz)
Octave band sound pressure level (dB) (0 dB = 0.0002 µbar)
Location of
microphone
NOTES
1 Measurement was taken in an anechoic room.
2 The operation noise measuring method is in accordance
with JISC9612.
3 Operating conditions:
Power source = 220-240 V, 50 Hz
o------o H (A = 46) and o- - - -o L (A = 36)
4 Operation noise differs with operation and ambient
conditions.
Approximate
threshold hearing
for continuous
noise
