Daikin Quaternity H-Series Instruction Manual

EDUS04-906_b
H-Series
- Heat Pump -

EDUS04-906_b
Room Air Conditioners H-Series 1
Split-System
Room Air Conditioners
H-Series
1. Power Supply ..............................................................................................2
2. Functions.....................................................................................................3
3. Specifications ..............................................................................................4
4. Dimensions .................................................................................................6
5. Wiring Diagrams..........................................................................................7
6. Piping Diagrams..........................................................................................8
7. Capacity Tables ..........................................................................................9
7.1 Heat Pump ................................................................................................... 9
8. Operation Limit..........................................................................................15
9. Sound Level ..............................................................................................16
9.1 Measuring Location .................................................................................... 16
9.2 Octave Band Level ..................................................................................... 17
10.Electric Characteristics..............................................................................19
11.Installation Manual ....................................................................................20
11.1 Indoor Units ................................................................................................ 20
11.2 Outdoor Units ............................................................................................. 33
12.Operation Manual......................................................................................40
13.Optional Accessories ................................................................................71
13.1 Option List .................................................................................................. 71
13.2 Installation Manual ..................................................................................... 72
Heat Pump
Quaternity
FTXG09HVJU
FTXG12HVJU
FTXG15HVJU
RXG09HVJU
RXG12HVJU
RXG15HVJU

Power Supply EDUS04-906_b
2Room Air Conditioners H-Series
1. Power Supply
Note:
Power Supply Intake ; Outdoor Unit
Indoor Units Outdoor Units Power Supply
Quaternity
FTXG09HVJU RXG09HVJU
1φ, 208-230V, 60HzFTXG12HVJU RXG12HVJU
FTXG15HVJU RXG15HVJU

EDUS04-906_b Functions
Room Air Conditioners H-Series 3
2. Functions
(1) Inverter POWERFUL operation can be used for COOLING, DRY COOLING, and HEATING.
(2) The function setting is cancelled as it is restarted automatically.(3) Temperature display 16~99°F (–9°C~37°C)
Category Functions
FTXG09/12/15HVJU RXG09/12/15HVJU
Category Functions
FTXG09/12/15HVJU RXG09/12/15HVJU
Basic
Function
Inverter (with Inverter Power Control) Health &
Clean
Air-Purifying Filter —
Operation Limit for Cooling (°FDB) 14~
109 Photocatalytic Deodorizing Filter —
Operation Limit for Heating (°FWB) –4~
75
Air-Purifying Filter
with Photocatalytic Deodorizing Function —
PAM Control Titanium Apatite Photocatalytic
Air-Purifying Filter 
Energy Saving During Operation Standby —
Compressor Oval Scroll Compressor — Deodorizing Filter for Streamer 
Swing Compressor Flash Streamer Air-Purifying 
Rotary Compressor — Air Filter (Prefilter) 
Reluctance DC Motor Wipe-clean Flat Panel 
Comfortable
Airflow
Power-Airflow Flap — Washable Upper Grille 
Power-Airflow Dual Flaps Filter Cleaning Indicator (Remote Controller) 
Wide-Angle Louvers Mold Proof Operation —
Vertical Auto-Swing (Up and Down) Mold Shock Operation —
Horizontal Auto-Swing (Right and Left) Mold Proof Stick 
3-D Airflow Comfort Sleep Operation 2
Comfort Airflow Mode Fresh Air Supply Ventilation —
COOLING BREEZE Operation Home Leave Ventilation —
Comfort
Control
Auto Fan Speed Timer Weekly Timer —
Indoor Unit Quiet Operation 24-Hour ON/OFF Timer 
Night Quiet Mode (Automatic) — Count Up-down ON/OFF Timer
OFF only
Outdoor Unit Quiet Operation (Manual) — Night Set Mode 
INTELLIGENT EYE — Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) 
2-Area INTELLIGENT EYE — Self-Diagnosis (Remote Controller) Display 
Quick Warming Function Wiring Error Check —
Hot-Start Function Anticorrosion Treatment of Outdoor Heat
Exchanger 
Automatic Defrosting Flexibility Multi-Split / Split Compatible Indoor Unit —
Operation Automatic Operation H/P, C/O Compatible Indoor Unit —
Humidifying Operation — Chargeless 
Drying Operation Either Side Drain (Right or Left) 
DRY COOLING Operation Power Selection —
Programme Dry Function — Low Temperature Cooling Operation
(5°F / -15°C) —
Fan Only — °F/°C changeover R/C temperature display
(factory setting : °F) 3
Air-Purifying Operation 
Lifestyle
Convenience
New POWERFUL Operation (Non-Inverter) — Remote
Control
5-Rooms Centralized Controller (Option) 
Inverter POWERFUL Operation 1
2Remote Control Adaptor
(Normal Open-Pulse Contact) (Option) 
Dry Keep
JP set
Priority-Room Setting — Remote Control Adaptor
(Normal Open Contact) (Option) 
Cooling / Heating Mode Lock —
HOME LEAVE Operation — DIII-NET Compatible (Adaptor) (Option) 
ECONO Mode — Remote
Controller
Wireless 
Indoor Unit ON/OFF Switch Wired —
Signal Reception Indicator 
Multi-colored Indicator 
Monitor Brightness Setting 
Temperature & Humidity Level Information
Display (Remote Controller) 
Childproof Lock 
R/C with Back Light —
Note: : Included Functions
— : No Functions

Specifications 60Hz 230V EDUS04-906_b
4Room Air Conditioners H-Series
3. Specifications 60Hz 230V
Note:
The data are based on the conditions shown in the table below.
Models
Indoor Units FTXG09HVJU FTXG12HVJU
Outdoor Units RXG09HVJU RXG12HVJU
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.) Btu/h 9,000 (5,300~12,300) 12,000 (4,400~18,000) 12,000 (5,300~15,700) 16,000 (4,400~19,100)
Moisture Removal Pt/h 3.3 — 4.1 —
Running Current (Rated) A 3.10 4.04 4.30 5.64
Power Consumption Rated
(Min.~Max.) W 570 (250~900) 780 (220~1,900) 860 (260~1,300) 1,160 (220~2,100)
Power Factor % 80.0 84.0 87.0 89.5
EER (Rated)
Btu/h·W 15.8 — 14.0 —
COP (Rated) W/W — 4.51 — 4.04
Energy
Efficiency SEER/HSPF 26.1 11.0 24.2 10.6
Piping
Connections
Liquid inch (mm) φ 1/4” (6.4 mmm) φ 1/4” (6.4 mmm)
Gas inch (mm) φ3/8” (9.5 mm) φ3/8” (9.5 mm)
Drain inch (mm) φ 11/16” (17.5 mm) φ 11/16” (17.5 mm)
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length feet (m) 32 ft (10 m) 32 ft (10 m)
Max. Interunit Height Difference feet (m) 26 ft (8 m) 26 ft (8 m)
Chargeless feet (m) — —
Amount of Additional Charge of
Refrigerant oz/ft — —
Indoor Units FTXG09HVJU FTXG12HVJU
Front Panel Color White White
Airflow Rate cfm (m³/min)
H 420 (11.9) 438 (12.4) 459 (13.0) 470 (13.3)
M 325 (9.2) 346 (9.8) 346 (9.8) 367 (10.4)
L 230 (6.5) 258 (7.3) 240 (6.8) 272 (7.7)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 57 57
Speed Steps 5 Steps, Quiet and Auto 5 Steps, Quiet and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12 0.14 0.14 0.15
Power Consumption (Rated) W 24 26 29 31
Power Factor % 87 80.7 90.1 89.9
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) inch (mm) 12 × 35-1/16 × 8-1/4” (305 x 891 x 210 mm) 12 × 35-1/16 × 8-1/4” (305 x 891 x 210 mm)
Packaged Dimensions (H×W×D) inch (mm) 11 × 37-5/8 × 14-7/8” (279 x 956 x 378 mm) 11 × 37-5/8 × 14-7/8” (279 x 956 x 378 mm)
Weight Lbs (kg) 31 lbs (14 kg) 31 lbs (14 kg)
Gross Weight Lbs (kg) 38 lbs (17 kg) 38 lbs (17 kg)
Operation Sound H/M/L dBA 42 / 33 / 26 42 / 35 / 28 43 / 35 / 27 43 / 36 / 29
Outdoor Units RXG09HVJU RXG12HVJU
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36CXD 2YC36CXD
Motor Output W 1,100 1,100
Refrigerant
Oil
Type FVC50K FVC50K
Charge oz 13.5 13.5
Refrigerant Type R-410A R-410A
Charge Lbs 3.1 3.1
Airflow Rate cfm (m³/min) H 1,178 (33.4) 1,095 (31.0) 1,262 (35.7) 1,111 (31.5)
L————
Fan Type Propeller Propeller
Motor Output W 60 60
Running Current (Rated) A 2.98 3.9 4.16 5.49
Power Consumption (Rated) W 546 754 831 1,129
Power Factor % 79.7 84.1 86.9 89.4
Dimensions (H×W×D) inch (mm) 22-3/8 × 31-5/16 ×11-1/4”
(568 x 795 x 286 mm)
22-3/8 × 31-5/16 ×11-1/4”
(568 x 795 x 286 mm)
Packaged Dimensions (H×W×D) inch (mm) 25-3/16 ×36-7/16 ×14-7/8”
(568 x 795 x 286 mm
25-3/16 ×36-7/16 ×14-7/8”
(568 x 795 x 286 mm)
Weight Lbs(kg) 99 lbs (45 kg) 99 lbs (45 kg)
Gross Weight Lbs(kg) 104 lbs (32 kg) 104 lbs (32 kg)
Operation
Sound H / L dBA 46 / — 46 / — 49 / — 48 / —
Drawing No. 3D062857 3D062858
Cooling Heating Piping Length
Indoor ; 80°FDB/67°FWB
Outdoor ; 95°FDB/75°FWB
Indoor ; 70°FDB/60°FWB
Outdoor ; 47°FDB/43°FWB 25ft (7.5 m)
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3

EDUS04-906_b Specifications 60Hz 230V
Room Air Conditioners H-Series 5
60Hz 230V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Units FTXG15HVJU
Outdoor Units RXG15HVJU
Cooling Heating
Capacity
Rated (Min.~Max.) Btu/h 15,000 (5,300~18,000) 18,000 (4,400~21,200)
Moisture Removal Pt/h 4.8 —
Running Current (Rated) A 5.64 6.36
Power Consumption Rated
(Min.~Max.) W 1,160 (260~1,930) 1,320 (230~2,120)
Power Factor % 89.0 99.0
EER (Rated)
Btu/h·W 12.9 —
COP (Rated) W/W — 3.99
Energy
Efficiency SEER/HSPF 21.0 10.0
Piping
Connections
Liquid inch (mm) φ 1/4” (6.4 mmm)
Gas inch (mm) φ3/8” (9.5 mm)
Drain inch (mm) φ 11/16” (17.5 mm)
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length feet (m) 32’ (10 m)
Max. Interunit Height Difference feet (m) 26’ (8 m)
Chargeless feet (m) —
Amount of Additional Charge of Refrigerant oz/ft —
Indoor Unit FTXG15HVJU
Front Panel Color White
Airflow Rate cfm (m³/min)
H 487 (13.8) 494 (14.0)
M 371 (10.5) 392 (11.1)
L 258 (7.3) 293 (8.3)
Fan
Type Cross Flow Fan
Motor Output W 57
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.15 0.16
Power Consumption (Rated) W 33 35
Power Factor % 95.7 95.1
Temperature Control Microcomputer Control
Dimensions (H×W×D) inch (mm) 12 × 35-1/16 × 8-1/4” (305 x 891 x 210 mm)
Packaged Dimensions (H×W×D) inch (mm) 11 × 37-5/8 × 14-7/8” (279 x 956 x 378 mm)
Weight Lbs(kg) 31 lbs (14 kg)
Gross Weight Lbs(kg) 38 lbs (17 kg)
Operation
Sound H/M/L dBA 45 / 37 / 29 44 / 38 / 31
Outdoor Unit RXG15HVJU
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC36CXD
Motor Output W 1,100
Refrigerant
Oil
Model FVC50K
Charge oz 13.5
Refrigerant Model R-410A
Charge Lbs 3.1
Airflow Rate cfm (m³/min) H 1,262 (35.7) 1,195 (33.8)
L— —
Fan Type Propeller
Motor Output W 60
Running Current (Rated) A 5.49 6.2
Power Consumption (Rated) W 1,127 1,285
Power Factor % 89.3 90.1
Dimensions (H×W×D) inch (mm) 22-3/8 × 31-5/16 ×11-1/4”
(568 x 795 x 286 mm)
Packaged Dimensions (H×W×D) inch (mm)
25-3/16 ×36-7/16 ×14-7/8”
(568 x 795 x 286 mm)
Weight Lbs (kg) 99
Gross Weight Lbs(kg) 104
Operation
Sound H / L dBA 50 / — 50 / —
Drawing No. 3D062859
Cooling Heating Piping Length
Indoor ; 80°FDB/67°FWB
Outdoor ; 95°FDB/75°FWB
Indoor ; 70°FDB/60°FWB
Outdoor ; 47°FDB/43°FWB 25 ft (7.5 m)
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3

Dimensions EDUS04-906_b
6Room Air Conditioners H-Series
4. Dimensions
FTXG09/12/15HVJU
RXG09/12/15HVJU
35-1/16(890)
45°
45°
I.D. φ9/16(14)
CONNECTING PART
O.D. φ11/16(18)
TERMINAL BLOCK WITH EARTH TERMINAL
SIGNAL RECEIVER
55°
30°
25°
70°APPROX.23-9/16(598)
1-7/16(37)
8-1/4(209)
10-3/4(273)
OPERATING STATE
12 (305)
10-13/16(275)
7-1/8(180.5)
33(838)
STANDARD LOCATIONS OF WALL HOLES
APPROX.25-13/16(655)
1-15/16(50)MIN.
9/16(15)
1-3/4(44.5)
1-3/16(30)MIN.
2-5/16(59.5)
1-15/16(50)MIN.
1-1/16(26.8) 2-1/2(63)
15°
15°
70°55°
APPROX.21-9/16(548)
1-7/8(47)~2-3/8(60)
AIR FLOW (INDOOR)
1 - 3 / 4 (44.5)
9/16(14.5)
RIGHT/LEFT
(AUTOMATIC)
45°
55°
60°
20°
7-1/16(180)
(SPACE FOR
MAINTENANCE)
UP/DOWN (AUTOMATIC)
SIGNAL TRANSMITTER
WALL HOLE FOR
EMBEDDED PIPING
φ2-9/16(65) HOLE
COOLING
DRY COOLING
DRY
GAS PIPE φ3/8(9.5)Cut
WIRELESS REMOTE CONTROLLER
DRAIN HOSE
HEATING
ROOM TEMP.
THERMISTOR
RIGHT
REQUIRED SPACE
REAR
WALL HOLE
LIQUID PIPE φ1/4(6.4)Cut
AIR PURIFYING
(INDIVIDUAL OPERATION)
(SPACE FOR PERFORMANCE)
GEAR CASE UNIT FIXED SCREWS
(INSIDE PANEL)
INCLUDING
MOUNTING PLATE
LEFT
(SPACE FOR
PERFORMANCE)
THE MARK (→) SHOWS PIPING DIRECTION
BOTTOM
BLADE ANGLE
(ARC447A3)
φ2-9/16(65)
HOLE
FRONT GRILL FIXED SCREWS
(INSIDE PANEL)
NAME
PLATE
MULTI-COLORED INDICATOR LAMP/
INDOOR UNIT ON/OFF SWITCH
()
TIMER LAMP
3D061002
(φ3/8 (9.5) CuT)
GAS STOP VALVE
3-1/8 (79)
31-5/16 (795)
19-7/8 (505)
1/2 (13)
4-5/8 (118)
1-15/16 (50)
OUTDOOR AIR THERMISTOR
1-15/16 (50)
2-15/16 (75)
1-15/16 (50)
5-7/8 (150)
BRAND NAME LABEL
(M8 OR M10)
4-HOLES FOR ANCHOR BOLTS
12-1/4 (311)
22-5/8 (574)
1-3/16 (29.5)
22-3/8 (569)
PORT
SERVICE
5-7/8 (150)
3-15/16 (100)
(φ1/4 (6.4) CuT)
STOP VALVE
LIQUID
11-1/4 (285)
HOSE FOR CONNECTION)
(I.Dφ5/8 (15.9)
DRAIN OUTLET
HANDLE
9/16 (15)
NAME PLATE
2-1/2 (63)
13/16 (20)
11-13/16 (300)
3-3/4 (95.5)
5/8 (15.7)
11/16 (17)
1-15/16 (50)
7 (178)
3-15/16 (100)
= LESS THAN 47-3/16 (1200)
WALL HEIGHT ON AIR OUTLET SIDE
MINIMUM SPACE FOR AIR PASSAGE
STOP VALVE COVER
IN CASE OF REMOVING
UNIT=INCH (mm)
(BASE PITCH)
3D062671A

EDUS04-906_b Wiring Diagrams
Room Air Conditioners H-Series 7
5. Wiring Diagrams
FTXG09/12/15HVJU
RXG09/12/15HVJU
FIELD WIRING.
outdoor
R1T
t°
LED2
H2P
M
Y2S
indoor
TURNED OFF AND THENBACK
RESTART AUTOMATICALLY IF
NOTE THAT OPERATIONWILL
THE MAINPOWER SUPPLY IS
ONAGAIN.
CAUTION
SIGNAL
RECEIVER
MM
t°
R2T
Y1S
MULTI
MONITOR
H1P
SIGNAL
TRANSMITTER
LED3
H3P
M
6
RED
S51
5
+
1
BLK
S402
5
4
S1
7
M3S
BLK
JA Z1C N=4
M2S
GRN
1
1
13
A5P
RED
BLK
S2C
BLK
BLK
RED
BLK
S21
6
S401
H2
HUMIDITY
SENSOR
BLK
1
GRN
S1C
S32
7
BLK
S91
BLK
HIGH VOLTAGE
UNIT
M1F
BLK
1
(16PIN)
ORG
M
JA
A4P
2
YLW
3
BLK
JUMPER
BLK
BLK
ORG
FG
/
BLK
BLK
TRANSMISSION
CIRCUIT
BLK
ORG
A3P
4
BLK
BLU
BLK
R1V
1
CN1
S41
1
-
H1
BLK
PNK
A1P
PNK
BLK
YLW
H3
S43
BLK
BLK
BLU
A2P
ORG
S57
BLK
2
1
BLK
BLK
1
PNK
S52
S1W
YLW
YLW
BLK
BLK
RED
BLK
YLW RED
YLW
M1S
BLK
ANADDRESS SETUP OF REMOTECONTROLLER
WHT
BLK
X1M
(H250V,T3.15A)
S403
BLU
BLK
S48
ORG
YLW
13
RED
BLK
STREAMER PART
-
PNK
WHT
BLK
HA
S56
WHT
RED BLK
1
S46
BLK
M4S
WIRELESS
REMOTE
CONTROLLER
BLK
S58
1
BLU YLW ORG BLU YLW
BLK
BLU
BRN
BLK
BLK
GRN
: PROTECTIVE GROUND
3
F1U
: FLAME GROUND
: FUSE
: PILOT LAMP
: FANMOTOR
: PRINTED CIRCUIT BOARD
R1T, R2T
: CONNECTOR
: OPERATIONSWITCH
: TERMINAL STRIP
: SWING MOTORM1S~M4S
F1U
M1F
H2P, H3P
S1~S403, CN1
FG
X1M
S1W
: THERMISTOR
A1P~A5P
: MULTI MONITORH1P
: LIMIT SWITCH FOR PANELS1C
: LIMIT SWITCH FOR STREAMERS2C
: VARISTORR1V
: SOLENOID VALVE
Y1S, Y2S
: FERRITE COREZ1C
3D052768C
3
1
2
outdoor
L1R
DB1
NOTE
1. REFER TO THE NAMEPLATE FOR THE POWER REQUIREMENTS.
M
FIELD WIRING.
: PROTECTIVE GROUND
indoor
VW
IPM1
U
(CONDENSER)
BLU
FU1
W
R2T
V
BLK
E2
S70
WHT
X1M : TERMINAL STRIP
102°C
(OUTDOOR)
BLU
(DISCHARGE)
M1F
GRN/YLW
3MRM20
BLU
YLW
3.15A
WHT
X1A : CONNECTOR
ORG
GRN/
YLW
HL1
6
HR1
3
RED
YLW
Z2C
N=3
WHT
M
Y1R : REVERSING SOLENOIDE VALVE COIL
1
BLK
L1, L2: LIVE
Q1L
1
YLW
W
4
R1T
R1T, R2T, R3T : THERMISTOR
MR4, MRM10
MRM20 : MAGNETIC RELAY
BLK
YLW
S80
OL1
Z1C
N=4
ORG
2
1
M1F : FANMOTOR
U
BLU
PPL
2
PCB1 : PRINTED CIRCUIT BOARD
DB3
FU1, FU2, FU3 : FUSE
1
L2
1
Q1L : OVERLOAD PROTECTOR
X1M
S90
V1
3
M1C
WHT
YLW
S
BRN
3
1
GRN
Z3C
N=3
MRM10
3.15A
WHT
FU3
V2
U
1
RED
S45
MR4
SA1 : SURGE ARRESTER
FU2
Y1E
L1R : REACTOR
L
BLK
YLW
BLK
2HN1
RED
V1, V2:VARISTOR
Y1E : ELECTRONIC EXPANSIONVALVE COIL
RED
E1
DB1, DB2, DB3 : DIODE BRIDGE
7
BRN
Z4C
N=2
LDB2
RED
ORG
S20
M
PCB1
X1A
L1
R3T
IPM1 : INTELLIGENT POWER MODULE
V
M1C : COMPRESSOR MOTOR
YLW
30A
OL2
6
SA1
YLW
BLK
Z1C, Z2C, Z3C, Z4C : FERRITE CORE
HR2
Y1R
+
_
~
~
+
++
_
_
+
+
_
__
+
_
~
~
~
~
+
_
t°t°t°
1~
3D061486

Piping Diagrams EDUS04-906_b
8Room Air Conditioners H-Series
6. Piping Diagrams
FTXG09/12/15HVJU
RXG09/12/15HVJU
SV SV
M
(UNDER DEHUMIDIFICATION
OPERATION)
FIELD PIPING FAN MOTOR
HEATING
HEAT EXCHANGER
SINGLE UNION JOINT
HEAT EXCHANGER
REFRIGERANT FLOW
THERMISTOR
ON HEAT EXCH.
AT RATED VOLTAGE: CLOSED
SINGLE UNION JOINT
SOLENOID VALVE
1/ 4(6.4)CuT
FIELD PIPING
3/8(9.5)CuT
COOLING
1/4(6.4)CuT
CROSS FLOW FAN
INDOOR UNIT
3/8(9.5)CuT
4D061001
OUTDOOR TEMPERATURE
THERMISTOR
(7.9)CuT
FIELD PIPING
(7.9)CuT
COOLING
GAS STOP
VALVE
M
MOTOR
OPERATED
VALVE
OUTDOOR UNIT
FOUR WAY VALVE
ON : HEATING
1/2(12.7)CuT
(3/8(9.5)CuT)
HEAT EXCHANGER
3/8(9.5)CuT
(6.4)CuT
FILTER
(12.7)CuT
LIQUID STOP
VALVE
HEAT
EXCHANGER
THERMISTOR
HEATING
1/2(12.7)CuT
FAN MOTOR (6.4)CuT
PROPELLER FAN
MUFFLER
WITH
FILTER
FIELD PIPING
1/4(6.4)CuT
1/4(6.4)CuT
MUFFLER
COMPRESSOR
AUXILIARY
HEAT EXCHANGER
DISCHARGE PIPE
THERMISTOR
1/4(6.4)CuT
(7.9)CuT
(1/4(6.4)CuT)
MUFFLER
3/8(9.5)CuT
MUFFLER
FILTER
REFRIGERANT FLOW
1/2(12.7)CuT
1/2
5/16
5/16
9/32(7.0)CuT
9/32(7.0)
CuT
9/32(7.0)CuT
5/16
(7.9)CuT
5/16
UNIT=INCH(mm)
1/4
1/4
3D062171A

EDUS04-906_b Capacity Tables
Room Air Conditioners H-Series 9
7. Capacity Tables
7.1 Heat Pump
FTXG09HVJU + RXG09HVJU (60Hz 230V)
Cooling
Heating
AFR 11.9
BF 0.10
Temp: Celsius / TC, SHC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CDB)
EWB EDB 20.0 25.0 30.0 32.0 35.0 40.0
°C °C TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20 2.702.420.442.582.370.482.462.310.522.412.290.542.342.260.562.212.200.61
16.0 22 2.832.380.442.702.330.482.582.280.522.532.260.542.462.230.572.332.180.61
18.0 25 2.952.560.442.832.510.482.702.460.532.652.440.542.582.410.572.462.370.61
19.426.73.012.750.442.892.700.492.762.660.532.712.640.542.64 2.61 0.57 2.52 2.56 0.61
22.0 30 3.192.670.453.072.630.492.952.590.532.902.570.552.822.550.572.702.510.62
24.0 32 3.312.620.453.192.580.493.072.540.533.022.530.552.942.510.582.822.470.62
Temp: Fahrenheit / TC, SHC: kBtu / PI: kW
INDOOR OUTDOOR TEMPERATURE (°FDB)
EWB EDB 68.0 77.0 86.0 89.6 95.0 104.0
°F °F TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
57.268.09.238.270.448.818.080.488.397.890.528.227.810.547.977.700.567.557.520.61
60.871.69.648.140.449.227.960.488.807.780.528.647.710.548.397.610.577.977.440.61
64.4 77.0 10.06 8.72 0.44 9.64 8.56 0.48 9.22 8.39 0.53 9.05 8.33 0.54 8.80 8.23 0.57 8.38 8.07 0.61
67.0 80.0 10.27 9.37 0.44 9.85 9.22 0.49 9.43 9.06 0.53 9.26 9.00 0.54 9.01 8.90 0.57 8.59 8.75 0.61
71.6 86.0 10.89 9.11 0.45 10.47 8.97 0.49 10.05 8.83 0.53 9.88 8.78 0.55 9.63 8.70 0.57 9.21 8.56 0.62
75.2 89.6 11.30 8.93 0.45 10.88 8.81 0.49 10.46 8.68 0.53 10.30 8.63 0.55 10.05 8.56 0.58 9.63 8.43 0.62
AFR 12.4
Temp: Celsius / TC, SHC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CWB)
EDB -10.0 -5.0 0 6.1 10.0
°C TC PI TC PI TC PI TC PI TC PI
15.0 2.39 0.66 2.79 0.69 3.19 0.72 3.67 0.76 3.98 0.78
21.1 2.25 0.68 2.65 0.71 3.04 0.74 3.52 0.78 3.84 0.81
22.0 2.22 0.68 2.62 0.71 3.02 0.74 3.50 0.78 3.81 0.81
24.0 2.18 0.69 2.57 0.72 2.97 0.75 3.45 0.79 3.77 0.82
25.0 2.15 0.69 2.55 0.72 2.95 0.76 3.42 0.79 3.74 0.82
27.0 2.10 0.70 2.50 0.73 2.90 0.76 3.37 0.80 3.69 0.83
Temp: Fahrenheit / TC, SHC: kBtu / PI: kW
INDOOR OUTDOOR TEMPERATURE (°FWB)
EDB 14.0 23.0 32.0 43.0 50.0
°F TC PI TC PI TC PI TC PI TC PI
59.0 8.15 0.66 9.52 0.69 10.88 0.72 12.52 0.76 13.58 0.78
70.0 7.67 0.68 9.03 0.71 10.38 0.74 12.01 0.78 13.10 0.81
71.6 7.57 0.68 8.94 0.71 10.30 0.74 11.94 0.78 13.00 0.81
75.2 7.44 0.69 8.77 0.72 10.13 0.75 11.77 0.79 12.86 0.82
77.0 7.34 0.69 8.70 0.72 10.07 0.76 11.67 0.79 12.76 0.82
80.6 7.17 0.70 8.53 0.73 9.89 0.76 11.50 0.80 12.59 0.83

Capacity Tables EDUS04-906_b
10 Room Air Conditioners H-Series
3D063098A
Symbols Note:
AFR : Airflow rate (m3/min.) 1. Ratings shown are net capacities which include a deduction for indoor fan
motor heat.
2. shows nominal (rated) capacities and power input.
3. TC, PI and SHC must be calculated by interpolation using the figures in
the above tables. (Figures outof the tables should not be used for
calculation.)
4. About SHC which are not mentioned on the table, please calculate them
with around values in direct proportion.
5. Capacities are based on the following conditions.
Corresponding refrigerant piping length : 25ft (7.5 m)
Level difference : 0ft
6. Airflow rate (AFR) and Bypass factor (BF) are tabulated above table.
7. Cooling capacity at -10 degrees Celsius / 14 degrees Fahrenheit.
BF : Bypass factor
EWB : Entering wet bulb temp. (°C) / (°F)
EDB : Entering dry bulb temp. (°C) / (°F)
TC : Total capacity (kW) / (kBtu/h)
SHC : Sensible heating capacity (kW) / (kBtu/h)
PI : Power input (kW)
Temp: Celsius / TC, SHC, PI: kW
INDOOR OUTDOOR
EWB EDB -10 (°CDB)
°C °C TC SHC PI
14.0 20 3.44 2.77 0.31
Temp: Fahrenheit / TC, SHC: kBtu / PI: kW
INDOOR OUTDOOR
EWB EDB 14 (°FDB)
°F °F TC SHC PI
57.2 68.0 11.75 9.44 0.31

EDUS04-906_b Capacity Tables
Room Air Conditioners H-Series 11
FTXG12HVJU + RXG12HVJU (60Hz 230V)
Cooling
Heating
AFR 13.0
BF 0.14
Temp: Celsius / TC, SHC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CDB)
EWB EDB 20.0 25.0 30.0 32.0 35.0 40.0
°C °F TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20 3.612.860.663.442.780.723.282.710.793.212.680.813.112.630.852.952.550.91
16.0 22 3.772.810.663.602.740.733.442.670.793.382.640.823.282.600.853.112.530.92
18.0 25 3.932.980.673.772.910.733.602.840.793.542.810.823.442.770.863.282.710.92
19.426.74.013.160.673.853.100.733.683.030.803.623.010.823.52 2.97 0.86 3.36 2.91 0.92
22.0 30 4.253.060.674.093.000.743.932.950.803.862.920.833.762.890.873.602.830.93
24.0 32 4.422.990.684.252.940.744.092.880.814.022.860.833.932.830.873.762.780.93
Temp: Fahrenheit / TC, SHC: kBtu / PI: kW
INDOOR OUTDOOR TEMPERATURE (°FDB)
EWB EDB 68.0 77.0 86.0 89.6 95.0 104.0
°F °F TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
57.2 68.0 12.30 9.77 0.66 11.75 9.50 0.72 11.19 9.24 0.79 10.96 9.13 0.81 10.63 8.98 0.85 10.07 8.72 0.91
60.8 71.6 12.86 9.60 0.66 12.30 9.35 0.73 11.74 9.11 0.79 11.52 9.01 0.82 11.18 8.86 0.85 10.62 8.62 0.92
64.4 77.0 13.41 10.15 0.67 12.85 9.92 0.73 12.29 9.69 0.79 12.07 9.60 0.82 11.73 9.46 0.86 11.17 9.24 0.92
66.9 80.1 13.69 10.80 0.67 13.13 10.57 0.73 12.57 10.35 0.80 12.35 10.26 0.82 12.01 10.13 0.86 11.45 9.91 0.92
71.6 86.0 14.52 10.44 0.67 13.96 10.25 0.74 13.40 10.05 0.80 13.18 9.97 0.83 12.84 9.86 0.87 12.28 9.67 0.93
75.2 89.6 15.07 10.20 0.68 14.51 10.02 0.74 13.95 9.84 0.81 13.73 9.77 0.83 13.39 9.66 0.87 12.83 9.49 0.93
AFR 13.3
Temp: Celsius / TC, SHC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CWB)
EDB -10.0 -5.0 0 6.1 10.0
°C TC PI TC PI TC PI TC PI TC PI
15.0 3.19 0.98 3.72 1.02 4.25 1.07 4.88 1.13 5.31 1.17
21.1 3.00 1.01 3.52 1.05 4.05 1.10 4.69 1.16 5.11 1.20
22.0 2.96 1.01 3.49 1.06 4.02 1.11 4.66 1.17 5.08 1.20
24.0 2.90 1.02 3.43 1.07 3.96 1.12 4.59 1.18 4.72 1.18
25.0 2.87 1.03 3.40 1.08 3.92 1.12 4.52 1.17 4.52 1.16
27.0 2.80 1.04 3.33 1.09 3.86 1.13 4.11 1.13 4.11 1.12
Temp: Fahrenheit / TC, SHC: kBtu / PI: kW
INDOOR OUTDOOR TEMPERATURE (°FWB)
EDB 14.0 23.0 32.0 43.0 50.0
°F TC PI TC PI TC PI TC PI TC PI
59.0 10.88 0.98 12.69 1.02 14.50 1.07 16.65 1.13 18.12 1.17
70.0 10.22 1.01 12.03 1.05 13.83 1.10 16.00 1.16 17.45 1.20
71.6 10.10 1.01 11.91 1.06 13.72 1.11 15.90 1.17 17.33 1.20
75.2 9.89 1.02 11.70 1.07 13.51 1.12 15.66 1.18 16.11 1.18
77.0 9.79 1.03 11.60 1.08 13.38 1.12 15.41 1.17 15.41 1.16
80.6 9.55 1.04 11.36 1.09 13.17 1.13 14.01 1.13 14.01 1.12

Capacity Tables EDUS04-906_b
12 Room Air Conditioners H-Series
3D063099A
Symbols Note:
AFR : Airflow rate (m3/min.) 1. Ratings shown are net capacities which include a deduction for indoor fan
motor heat.
2. shows nominal (rated) capacities and power input.
3. TC, PI and SHC must be calculated by interpolation using the figures in
the above tables. (Figures out of the tables should not be used for
calculation.)
4. About SHC which are not mentioned on the table, please calculate them
with around values in direct proportion.
5. Capacities are based on the following conditions.
Corresponding refrigerant piping length : 25ft (7.5 m)
Level difference : 0ft
6. Airflow rate (AFR) and Bypass factor (BF) are tabulated above table.
7. Cooling capacity at -10 degrees Celsius / 14 degrees Fahrenheit.
BF : Bypass factor
EWB : Entering wet bulb temp. (°C) / (°F)
EDB : Entering dry bulb temp. (°C) / (°F)
TC : Total capacity (kW) / (kBtu/h)
SHC : Sensible heating capacity (kW) / (kBtu/h)
PI : Power input (kW)
Temp: Celsius / TC, SHC, PI: kW
INDOOR OUTDOOR
EWB EDB -10 (°CDB)
°C °C TC SHC PI
14.0 20 3.65 2.66 0.47
Temp: Fahrenheit / TC, SHC: kBtu / PI: kW
INDOOR OUTDOOR
EWB EDB 14 (°FDB)
°F °F TC SHC PI
57.2 68.0 12.45 9.08 0.47

EDUS04-906_b Capacity Tables
Room Air Conditioners H-Series 13
FTXG15HVJU + RXG15HVJU (60Hz 230V)
Cooling
Heating
AFR 13.8
BF 0.16
Temp: Celsius / TC, SHC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CDB)
EWB EDB 20.0 25.0 30.0 32.0 35.0 40.0
°C °C TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20 4.513.360.894.303.260.984.103.151.064.023.111.103.893.051.153.692.961.23
16.0 22 4.713.300.904.513.200.984.303.111.074.223.071.104.103.011.153.892.921.24
18.0 25 4.913.460.904.713.370.994.503.281.074.423.241.114.303.191.164.093.111.24
19.426.75.013.650.904.813.560.994.603.481.074.523.441.114.40 3.39 1.16 4.20 3.31 1.25
22.0 30 5.323.520.915.113.441.004.913.371.084.833.341.124.703.291.174.503.221.25
24.0 32 5.523.430.925.323.361.005.113.291.095.033.261.124.913.221.174.703.151.26
Temp: Fahrenheit / TC, SHC: kBtu / PI: kW
INDOOR OUTDOOR TEMPERATURE (°FDB)
EWB EDB 68.0 77.0 86.0 89.6 95.0 104.0
°F °F TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
57.2 68.0 15.38 11.46 0.89 14.68 11.11 0.98 13.98 10.76 1.06 13.70 10.62 1.10 13.28 10.42 1.15 12.58 10.08 1.23
60.8 71.6 16.07 11.26 0.90 15.37 10.93 0.98 14.67 10.60 1.07 14.39 10.48 1.10 13.98 10.28 1.15 13.28 9.97 1.24
64.4 77.0 16.76 11.80 0.90 16.07 11.49 0.99 15.37 11.19 1.07 15.09 11.07 1.11 14.67 10.89 1.16 13.97 10.60 1.24
67.0 80.0 17.11 12.45 0.90 16.41 12.15 0.99 15.71 11.86 1.07 15.43 11.75 1.11 15.01 11.58 1.16 14.31 11.29 1.25
71.6 86.0 18.15 12.00 0.91 17.45 11.75 1.00 16.75 11.49 1.08 16.47 11.39 1.12 16.05 11.24 1.17 15.35 10.98 1.25
75.2 89.6 18.84 11.69 0.92 18.14 11.45 1.00 17.44 11.22 1.09 17.16 11.13 1.12 16.74 10.99 1.17 16.04 10.76 1.26
AFR 14.0
Temp: Celsius / TC, SHC, PI: kW
INDOOR OUTDOOR TEMPERATURE (°CWB)
EDB -10.0 -5.0 0 6.1 10.0
°C TC PI TC PI TC PI TC PI TC PI
15.0 3.59 1.11 4.19 1.16 4.78 1.22 5.50 1.28 5.98 1.33
21.1 3.37 1.15 3.97 1.20 4.56 1.25 5.28 1.32 5.62 1.34
22.0 3.34 1.15 3.93 1.21 4.53 1.26 5.24 1.33 5.41 1.32
24.0 3.26 1.16 3.86 1.22 4.46 1.27 4.97 1.31 4.97 1.28
25.0 3.23 1.17 3.82 1.22 4.42 1.28 4.76 1.28 4.76 1.26
27.0 3.15 1.18 3.75 1.24 4.33 1.29 4.33 1.23 4.33 1.20
Temp: Fahrenheit / TC, SHC: kBtu / PI: kW
INDOOR OUTDOOR TEMPERATURE (°FWB)
EDB 14.0 23.0 32.0 43.0 50.0
°F TC PI TC PI TC PI TC PI TC PI
59.0 12.25 1.11 14.29 1.16 16.32 1.22 18.76 1.28 20.39 1.33
70.0 11.51 1.15 13.54 1.20 15.57 1.25 18.02 1.32 19.19 1.34
71.6 11.38 1.15 13.42 1.21 15.45 1.26 17.89 1.33 18.45 1.32
75.2 11.13 1.16 13.17 1.22 15.20 1.27 16.97 1.31 16.97 1.28
77.0 11.01 1.17 13.04 1.22 15.08 1.28 16.23 1.28 16.23 1.26
80.6 10.76 1.18 12.79 1.24 14.76 1.29 14.76 1.23 14.76 1.20

Capacity Tables EDUS04-906_b
14 Room Air Conditioners H-Series
3D063100A
Symbols Note:
AFR : Airflow rate (m3/min.) 1. Ratings shown are net capacities which include a deduction for indoor fan
motor heat.
2. shows nominal (rated) capacities and power input.
3. TC, PI and SHC must be calculated by interpolation using the figures in
the above tables. (Figures out of the tables should not be used for
calculation.)
4. About SHC which are not mentioned on the table, please calculate them
with around values in direct proportion.
5. Capacities are based on the following conditions.
Corresponding refrigerant piping length : 25ft (7.5 m)
Level difference : 0ft
6. Airflow rate (AFR) and Bypass factor (BF) are tabulated above table.
7. Cooling capacity at -10 degrees Celsius / 14 degrees Fahrenheit.
BF : Bypass factor
EWB : Entering wet bulb temp. (°C) / (°F)
EDB : Entering dry bulb temp. (°C) / (°F)
TC : Total capacity (kW) / (kBtu/h)
SHC : Sensible heating capacity (kW) / (kBtu/h)
PI : Power input (kW)
Temp: Celsius / TC, SHC, PI: kW
INDOOR OUTDOOR
EWB EDB -10 (°CDB)
°C °C TC SHC PI
14.0 20 3.66 2.70 0.46
Temp: Fahrenheit / TC, SHC: kBtu / PI: kW
INDOOR OUTDOOR
EWB EDB 14 (°FDB)
°F °F TC SHC PI
57.2 68.0 12.49 9.21 0.46

EDUS04-906_b Operation Limit
Room Air Conditioners H-Series 15
8. Operation Limit
RXG09/12/15HVJU
41
104
14
Heating
73.4
•Level difference
Continuous operation
-4
50
Outdoor temp. (°FWB)
68
50
68
(-4°FDB)
68
0ft
Outdoor temp. (°FDB)
• Air flow rate High
77
77
86
82.4 50
Cooling
5
75
32
Indoor temp. (°FDB)
Indoor temp. (°FWB)
25ft
14
32
109
86
Notes:
23
59
59
86
Pull-down period
Continuous operation
• Equivalent piping length
68
50
on the following conditions.
The graphs are based
3D063096

Sound Level EDUS04-906_b
16 Room Air Conditioners H-Series
9. Sound Level
9.1 Measuring Location
Note:
1. Operation sound is measured in an anechoic chamber.
2. The data are based on the conditions shown in the table below.
Indoor Unit
Outdoor Unit
Cooling Heating Piping Length
Indoor ; 80°FDB/67°FWB
Outdoor ; 95°FDB/75°FWB
Indoor ; 70°FDB/60°FWB
Outdoor ; 47°FDB/43°FWB 16.4ft (5 m)
3.3ft
2.6ft
(R5162)
3.3ft
(R4796)

EDUS04-906_b Sound Level
Room Air Conditioners H-Series 17
9.2 Octave Band Level
9.2.1 Indoor Units
FTXG09HVJU
FTXG12HVJU
FTXG15HVJU
POWER SOURCE
JIS STANDARD
OPERATING CONDITIONS
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
70
60
20
30
50
40
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
63 125
OCTAVE BAND CENTER FREQUENCY (Hz)
250 500 1000 2000 4000 8000
OVER ALL (dB )
A
(B.G.N IS ALREADY RECTIFIED )
70
60
20
30
50
40
63
OCTAVE BAND CENTER FREQUENCY (Hz)
125 250 500 1000 2000 4000 8000
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
POWER SOURCE
JIS STANDARD
OPERATING CONDITIONS
OVER ALL (dB )
(B.G.N IS ALREADY RECTIFIED )
COOLING HEATING
NC-60
NC-50
NC-40
NC-30
NC-20
60Hz 60Hz
208/230V 208/230V
SCALE
(H) (L)
42 26
60Hz 208/230V(H)
60Hz 208/230V(L)
STANDARD EXTERNAL STATIC PRESSURE
NC-60
NC-50
NC-40
NC-30
NC-20
60Hz
208/230V
SCALE
60Hz
208/230V
(H) (L)
A42 28
STANDARD EXTERNAL STATIC PRESSURE
60Hz 208/230V(H)
60Hz 208/230V(L)
208/230V 60Hz
208/230V 60Hz
Cooling Heating
3D063060
POWER SOURCE
JIS STANDARD
OPERATING CONDITIONS
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
70
60
20
30
50
40
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
63 125
OCTAVE BAND CENTER FREQUENCY (Hz)
250 500 1000 2000 4000 8000
OVER ALL (dB )
A
(B.G.N IS ALREADY RECTIFIED )
70
60
20
30
50
40
63
OCTAVE BAND CENTER FREQUENCY (Hz)
125 250 500 1000 2000 4000 8000
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
POWER SOURCE
JIS STANDARD
OPERATING CONDITIONS
OVER ALL (dB )
SCALE
(B.G.N IS ALREADY RECTIFIED )
COOLING HEATING
NC-40
NC-20
NC-30
NC-60
NC-50
208/230V 60Hz
60Hz
(L)
208/230V
(H)
208/230V
2743
60Hz
SCALE
STANDARD EXTERNAL STATIC PRESSURE
60Hz 208/230V(H)
60Hz 208/230V(L)
Cooling Heating
STANDARD EXTERNAL STATIC PRESSURE
60Hz 208/230V(L)
60Hz 208/230V(H)
208/230V 60Hz
(L)
208/230V
60Hz
(H)
208/230V
A43 29
60Hz
NC-60
NC-30
NC-20
NC-40
NC-50
3D063061
POWER SOURCE
JIS STANDARD
OPERATING CONDITIONS
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
70
60
20
30
50
40
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
63 125
OCTAVE BAND CENTER FREQUENCY (Hz)
250 500 1000 2000 4000 8000
OVER ALL (dB )
SCALE
A
(B.G.N IS ALREADY RECTIFIED )
70
60
20
30
50
40
63
OCTAVE BAND CENTER FREQUENCY (Hz)
125 250 500 1000 2000 4000 8000
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
POWER SOURCE
JIS STANDARD
OPERATING CONDITIONS
OVER ALL (dB )
SCALE
A
(B.G.N IS ALREADY RECTIFIED )
COOLING HEATING
NC-50
NC-60
NC-40
NC-30
NC-20
(L)
208/230V
2945
(H)
208/230V
60Hz 60Hz
208/230V 60Hz
60Hz 208/230V(L)
60Hz 208/230V(H)
Cooling
STANDARD EXTERNAL STATIC PRESSURE
NC-50
NC-30
NC-60
NC-40
NC-20
(H)
208/230V
31
60Hz
(L)
208/230V
60Hz
44
208/230V 60Hz
STANDARD EXTERNAL STATIC PRESSURE
60Hz 208/230V(L)
60Hz 208/230V(H)
Heating
3D063080

Sound Level EDUS04-906_b
18 Room Air Conditioners H-Series
9.2.2 Outdoor Units
RXG09HVJU
RXG12HVJU
RXG15HVJU
POWER SOURCE
JIS STANDARD (JIS9612)
OPERATING CONDITIONS
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
70
60
20
30
50
40
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
63 125
OCTAVE BAND CENTER FREQUENCY (Hz)
250 500 1000 2000 4000 8000
OVER ALL (dB )
(B.G.N IS ALREADY RECTIFIED )
70
60
20
30
50
40
63
OCTAVE BAND CENTER FREQUENCY (Hz)
125 250 500 1000 2000 4000 8000
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
POWER SOURCE
JIS STANDARD (JIS9612)
OPERATING CONDITIONS
OVER ALL (dB )
SCALE
A
SCALE
A
(B.G.N IS ALREADY RECTIFIED )
COOLING HEATING
NC-60
NC-30
NC-50
NC-20
NC-40
208-230V
60Hz
46
208-230V 60Hz
Cooling
NC-50
NC-40
NC-30
NC-20
NC-60
208-230V
60Hz
46
208-230V 60Hz
Heating
3D063010
POWER SOURCE
JIS STANDARD (JIS9612)
OPERATING CONDITIONS
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
70
60
20
30
50
40
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
63 125
OCTAVE BAND CENTER FREQUENCY (Hz)
250 500 1000 2000 4000 8000
OVER ALL (dB )
SCALE
A
(B.G.N IS ALREADY RECTIFIED )
70
60
20
30
50
40
63
OCTAVE BAND CENTER FREQUENCY (Hz)
125 250 500 1000 2000 4000 8000
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
POWER SOURCE
JIS STANDARD (JIS9612)
OPERATING CONDITIONS
OVER ALL (dB )
SCALE
A
(B.G.N IS ALREADY RECTIFIED )
COOLING HEATING
NC-60
NC-40
NC-50
NC-20
NC-30
60Hz
208-230V
49
208-230V 60Hz
Cooling
NC-20
NC-50
NC-60
NC-30
NC-40
48
60Hz
208-230V
208-230V 60Hz
Heating
3D063011
COOLING
NC-40
NC-30
NC-50
NC-60
NC-20
POWER SOURCE
JIS STANDARD
OPERATING CONDITIONS
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
70
60
20
30
50
40
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
63 125
OCTAVE BAND CENTER FREQUENCY (Hz)
250 500 1000 2000 4000 8000
OVER ALL (dB )
SCALE
A
(B.G.N IS ALREADY RECTIFIED )
70
60
20
30
50
40
63
OCTAVE BAND CENTER FREQUENCY (Hz)
125 250 500 1000 2000 4000 8000
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
POWER SOURCE
JIS STANDARD
OPERATING CONDITIONS
OVER ALL (dB )
SCALE
A
(B.G.N IS ALREADY RECTIFIED )
60Hz 208/230V
208/230V 60Hz
51
Cooling
208/230V
60Hz
NC-40
NC-30
NC-50
NC-60
NC-20
60Hz 208/230V
208/230V 60Hz
51
Heating
208/230V
60Hz
HEATING
3D047647A
POWER SOURCE
JIS STANDARD (JIS9612)
OPERATING CONDITIONS
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
70
60
20
30
50
40
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
63 125
OCTAVE BAND CENTER FREQUENCY (Hz)
250 500 1000 2000 4000 8000
OVER ALL (dB )
SCALE
A
(B.G.N IS ALREADY RECTIFIED )
70
60
20
30
50
40
63
OCTAVE BAND CENTER FREQUENCY (Hz)
125 250 500 1000 2000 4000 8000
OCTAVE BAND SOUND PRESSURE LEVEL
dB(0dB=0.0002μbar)
THRESHOLD HEARING
APPROXIMATE
FOR CONTINUOUS
NOISE
POWER SOURCE
JIS STANDARD (JIS9612)
OPERATING CONDITIONS
OVER ALL (dB )
SCALE
A
(B.G.N IS ALREADY RECTIFIED )
COOLING HEATING
NC-20
NC-50
NC-30
NC-60
NC-40
208-230V
50
60Hz
208-230V 60Hz
Cooling
NC-60
NC-30
NC-50
NC-20
NC-40
208-230V
60Hz
50
208-230V 60Hz
Heating
3D063012

EDUS04-906_b Electric Characteristics
Room Air Conditioners H-Series 19
10.Electric Characteristics
3D063013
Representative Unit Combination Power Supply COMP OFM IFM
Indoor Unit Outdoor Unit Hz-Volts Voltage Range MCA MOP RHz RLA W FLA W FLA
FTXG09HVJU RXG09HVJU 60-208 MAX. 60Hz 253V
MIN. 60Hz 187V 14.5 15 29 2.3 60 0.10 57 0.13
60-230 2.1 0.12
FTXG12HVJU RXG12HVJU 60-208 MAX. 60Hz 253V
MIN. 60Hz 187V 14.5 15 43 3.7 60 0.13 57 0.15
60-230 3.3 0.14
FTXG15HVJU RXG15HVJU 60-208 MAX. 60Hz 253V
MIN. 60Hz 187V 14.5 15 54 5.1 60 0.13 57 0.17
60-230 4.6 0.15
Symbols: Note:
MCA : MIN. CIRCUIT AMPS (A) 1. RLA is based on the following conditions.
Indoor temp. : 80°FDB / 67°FWB (26.7°CDB / 19.4°CWB)
Outdoor temp. : 95°FDB (35°CDB)
2. Maximum allowable voltage variation between phases is 2%.
3. Select wire size based on the larger value of MCA.
4. Instead of fuse, use circuit breaker.
5. Be sure to install a ground leak detector. (One that can handle
higher harmonics.)
(This unit uses an inverter, which means that it must be used a
ground leak detector capable handling high harmonics in order to
prevent malfunctioning of the ground leak detector itself.)
MOP : MAX. OVERCURRENT PROTECTION (A)
RLA : RATED LOAD AMPS (A)
OFM : OUTDOOR FAN MOTOR
IFM : INDOOR FAN MOTOR
FLA : FULL LOAD AMPS (A)
W : FAN MOTOR RATED OUTPUT (W)
RHz : RATED OPERATING FREQUENCY (Hz)
