Daikin VRV RXYQ5P7W1B Instruction manual

technical data
VRV heat pump
Small footprint combination
RXYQ5-54P7W1B
air conditioning systems
EEDEN08-200
2a

• VRV®Systems • Outdoor Units 1
• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
TABLE OF CONTENTS
RXYQ5-54P7W1B(A)
1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2 Electrical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4 Capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Combination table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Cooling capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Heating capacity tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
5 Dimensional drawing & centre of gravity . . . . . . . . . . . . . . . . . . . . . . 115
Dimensional drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Centre of gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
6 Piping diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
7 Wiring diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
External connection diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
8 Sound data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Sound pressure spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Sound power spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
9 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Service space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Fixation and foundation of units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
10 Operation range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
• VRV®Systems • Outdoor Units
2
1 Specifications
3
OutdoorUni VRVSystems RXYQ5-54P7W1B VRVHeatPum
p
1-1 TECHNICAL SPECIFICATIONS RXYQ5P7W1B RXYQ8P7W1B RXYQ10P7W1B RXYQ12P7W1B RXYQ14P7W1BA RXYQ16P7W1BA RXYQ18P7W1BA
Capacity Cooling kW 14.0 22.4 28.0 33.5 40.0 45.0 49.0
Heating kW 16.0 25.0 31.5 37.5 45.0 50.0 56.5
COP Cooling 3.98 4.03 3.77 3.48 3.23 3.17 3.02
Heating 4.00 4.27 4.09 3.97 3.98 3.88 3.69
Capacity range HP 5 8 10 12 14 16 18
Power input
(nominal)
Cooling kW 3.52 5.56 7.42 9.62 12.4 14.2 16.2
Heating kW 4.00 5.86 7.70 9.44 11.30 12.90 15.30
PED category Category II
Max n° of indoor units to be connected 813 16 19 23 26 29
Indoor index
connection
Minimum 62.5 100 125 150 175 200 225
Maximum 162.5 260 325 390 455 520 585
Casing Colour Daikin White
Material Painted galvanised steel
Dimensions Packing Height mm 1,855
Width mm 796 1,055 1,055 1,055 1,365 1,365 1,365
Depth mm 860 860 860 860 860 860 860
Unit Height mm 1,680
Width mm 635 930 930 930 1,240 1,240 1,240
Depth mm 765 765 765 765 765 765 765
Weight Unit kg 159 187 240 240 316 316 324
Packed Unit kg 182 217 273 273 356 356 364
Packing Material Carton
Weight kg 3.80 4.02 4.02 4.02 6.35 6.35 6.35
Material Wood
Weight kg 19.15 20.85 20.85 20.85 23.55 23.55 23.55
Material Plastic
Weight kg 0.215 0.265 0.265 0.265 0.330 0.330 0.330
Heat
Exchanger
Dimensions Length mm 1,483 1,778 1,778 1,778 2,088 2,088 2,088
Nr of Rows 54 54 54 54 54 54 54
Fin Pitch mm 2.00 2.00 2.00 2.00 2.00 2.00 2.00
Nr of Passes 818 18 18 21 21 21
Face Area m² 1.762 2.112 2.112 2.112 2.481 2.481 2.481
Nr of Stages 2222222
Tube type Hi-XSS (8)
Fin Fin type Non-symmetric waffle louvre
Treatment Hydrophylic and anti corrosion resistant
Fan Type Propeller
Quantity 1111222
Air Flow Rate
(nominal at
230V)
Cooling m³/min 95 171 185 196 233 233 239
Heating m³/min 95 171 185 196 233 233 239
External static pressure Pa 78 Pa in high static pressure
Discharge direction Vertical
Motor Quantity 1111222
Model Brushless DC
Output motor W350 750 750 750 2 x 350 2 x 350 2 x 750

• VRV®Systems • Outdoor Units 3
• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
1 Specifications
3
Compressor Quantity 1122333
Motor Quantity 1111111
Model Inverter
Type Hermetically sealed scroll compressor
Speed rpm 6,300 7,980 6,300 6,300 6,300 6,300 7,980
Motor Output kW 2.8 3.8 1.2 2.8 0.3 1.4 3.0
Crankcase
Heater
W33 33 33 33 33 33 33
Quantity 11222
Model ON - OFF ON - OFF ON - OFF ON - OFF ON - OFF
Type Hermetically
sealed scroll
compressor
Hermetically
sealed scroll
compressor
Hermetically
sealed scroll
compressor
Hermetically
sealed scroll
compressor
Hermetically
sealed scroll
compressor
Speed rpm 2,900 2,900 2,900 2,900 2,900
Motor Output kW 4.5 4.5 4.5 4.5 4.5
Crankcase
Heater
W33 33 33 33 33
Cooling Standard Min °CDB -5.0 -5.0 -5.0 -5.0 -5.0 -5.0 -5.0
Operation
Range
Cooling Max °CDB 43.0 43.0 43.0 43.0 43.0 43.0 43.0
Heating Min °CWB -20.0 -20.0 -20.0 -20.0 -20.0 -20.0 -20.0
Max °CWB 15.0 15.0 15.0 15.0 15.0 15.0 15.0
Sound level Cooling Sound Power
(Nominal)
dBA 72 78 78 80 80 80 83
Sound Pressure
(Nominal)
dBA 54 57 58 60 60 60 63
Refrigerant Name R-410A
Charge kg 6.2 7.7 8.4 8.6 11.3 11.5 11.7
Control Expansion valve (electronic type)
Nr of Circuits 1111111
Refrigerant Oil Name Synthetic (ether) oil
Charged Volume l1.7 2.1 4.3 4.3 6.6 6.6 6.7
Piping
connections
Liquid (OD) Type Braze connection
Diameter (OD) mm 9.52 9.52 9.52 12.7 12.7 12.7 15.9
Gas Type Braze connection
Diameter (OD) mm 15.9 19.1 22.2 28.6 28.6 28.6 28.6
Heat Insulation Both liquid and gas pipes
Max total length m1000 1000 1000 1000 1000 1000 1000
Defrost Method Reversed cycle
Defrost Control Sensor for outdoor heat exchanger temperature
Capacity Control Method Inverter controlled
Capacity Control ~ 100
Safety devices HPS
Fan motor driver overload protector
Over current relay
Inverter overload protector
PC board fuse
Standard
Accessories
Standard Accessories Installation and operation manual
Quantity 1111111
Standard Accessories Connection pipes
Quantity 4444444
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature :
35°CDB, equivalent refrigerant piping : 7.5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m, level difference : 0m
Sound pressure
Sound values
Sound values are measured in a semi-anechoic room.
1-1 TECHNICAL SPECIFICATIONS RXYQ5P7W1B RXYQ8P7W1B RXYQ10P7W1B RXYQ12P7W1B RXYQ14P7W1BA RXYQ16P7W1BA RXYQ18P7W1BA

• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
• VRV®Systems • Outdoor Units
4
1 Specifications
3
1-2 TECHNICAL SPECIFICATIONS RXYQ20P7W1B RXYQ22P7W1B RXYQ24P7W1B RXYQ26P7W1BA RXYQ28P7W1BA RXYQ30P7W1BA RXYQ32P7W1BA
Capacity Cooling kW 55.9 61.5 67.0 71.4 77.0 82.5 89.0
Heating kW 62.5 69.0 75.0 81.5 88.0 94.0 102.0
COP Cooling 3.68 3.62 3.49 3.28 3.26 3.20 3.11
Heating 4.08 4.04 3.97 3.84 3.83 3.81 3.83
Capacity range HP 20 22 24 26 28 30 32
Power input
(nominal)
Cooling kW 15.2 17.0 19.2 21.8 23.6 25.8 28.6
Heating kW 15.3 17.1 18.9 21.2 23.0 24.7 26.6
PED category Category II
Max n° of indoor units to be connected 32 35 39 42 45 49 52
Indoor index
connection
Minimum 250 275 300 325 350 375 400
Maximum 650 715 780 845 910 975 1040
Casing Colour Daikin White
Material Painted galvanised steel
Heat
Exchanger
Dimensions Length mm 1,778 + 1,778 1,778 + 1,778 1,778 + 1,778 1,778 + 2,088 1,778 + 2,088 1,778 + 2,088 2,088 + 2,088
Nr of Rows 54 + 54
Fin Pitch mm 2.00 2.00 2.00 2.00 2.00 2.00 2.00
Nr of Passes 18 + 18 18 + 18 18 + 18 18 + 21 18 + 21 18 + 21 21 + 21
Face Area m² 2.112 + 2.112 2.112 + 2.112 2.112 + 2.112 2.112 + 2.481 2.112 + 2.481 2.112 + 2.481 2.481 + 2.481
Nr of Stages 2 + 2
Tube type Hi-XSS (8)
Fin Fin type Non-symmetric waffle louvre
Treatment Hydrophylic and anti corrosion resistant
Fan Type Propeller
Quantity 1 + 1 1 + 1 1 + 1 1 + 2 1 + 2 1 + 2 2 + 2
Air Flow Rate
(nominal at
230V)
Cooling m³/min 171 + 196 185 + 196 196 + 196 171 + 239 185 + 239 196 + 239 233 + 239
Heating m³/min 171 + 196 185 + 196 196 + 196 171 + 239 185 + 239 196 + 239 233 + 239
External static pressure Pa 78 Pa in high static pressure
Discharge direction Vertical
Motor Quantity 1 + 1 1 + 1 1 + 1 1 + 2 1 + 2 1 + 2 2 + 2
Model Brushless DC
Output motor W750 + 750 750 + 750 750 + 750 750 + 2x750 750 + 2x750 750 + 2x750 2x350 + 2x750
Compressor Quantity 1 + 2 2 + 2 2 + 2 1 + 3 2 + 3 2 + 3 3 + 3
Motor Quantity 1 + 1
Model Inverter
Type Hermetically sealed scroll compressor
Speed rpm 7,980 + 6,300 6,300 + 6,300 6,300 + 6,300 7,980 + 7,980 6,300 + 7,980 6,300 + 7,980 6,300 + 7,980
Motor Output kW 3.8 + 2.8 1.2 + 2.8 2.8 + 2.8 3.8 + 3.0 1.2 + 3.0 2.8 + 3.0 0.3 + 3.0
Crankcase
Heater
W33 33 33 33 33 33 33
Quantity 1223334
Model ON-OFF
Type Hermetically sealed scroll compressor
Speed rpm 2,900
Motor Output kW 4.5 4.5 4.5 4.5 4.5 4.5 4.5
Crankcase
Heater
W33 33 33 33 33 33 33
Cooling Standard Min °CDB -5.0 -5.0 -5.0 -5.0 -5.0 -5.0 -5.0
Operation
Range
Cooling Max °CDB 43.0 43.0 43.0 43.0 43.0 43.0 43.0
Heating Min °CWB -20.0 -20.0 -20.0 -20.0 -20.0 -20.0 -20.0
Max °CWB 15.0 15.0 15.0 15.0 15.0 15.0 15.0
Refrigerant Name R-410A
Charge kg 7.7 + 8.6 8.4 + 8.6 8.6 + 8.6 7.7 + 11.7 8.4 + 11.7 8.6 + 11.7 11.3 + 11.7
Control Expansion valve (electronic type)
Nr of Circuits 1111111
Maximum total refrigerant charge in the system kg Less than 100 (calculated charge less than 95)
Refrigerant Oil Name Synthetic (ether) oil
Charged Volume l2.1 + 3.9 3.9 + 3.9 3.9 + 3.9 2.1 + 5.8 3.9 + 5.8 3.9 + 5.8 5.7 + 5.8

• VRV®Systems • Outdoor Units 5
• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
1 Specifications
3
Piping
connections
Liquid (OD) Type Braze connection
Diameter (OD) mm 15.9 15.9 15.9 19.1 19.1 19.1 19.1
Gas Type Braze connection
Diameter (OD) mm 28.6 28.6 34.9 34.9 34.9 34.9 34.9
Heat Insulation Both liquid and gas pipes
Max total length m1000 1000 1000 1000 1000 1000 1000
Defrost Method Reversed cycle
Defrost Control Sensor for outdoor heat exchanger temperature
Capacity Control Method Inverter controlled
Capacity Control ~ 100
Safety devices HPS
Fan motor driver overload protector
Over current relay
Inverter overload protector
PC board fuse
Standard
Accessories
Standard Accessories Installation and operation manual
Quantity 1111111
Standard Accessories Connection pipes
Quantity 4444444
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature :
35°CDB, equivalent refrigerant piping : 7.5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m, level difference : 0m
Sound level of a multi system is determined by the individual outdoor unit and installation condition
The refrigerant charge of the system must be less than 100 kg. This means that in case the calculated refrigerant
charge is equal to or more than 95 kg, you must divide your multiple outdoor system into smaller independent
systems, each containing less than 95 kg refrigerant charge. For factory charge, refer to the namplate of the unit.
1-2 TECHNICAL SPECIFICATIONS RXYQ20P7W1B RXYQ22P7W1B RXYQ24P7W1B RXYQ26P7W1BA RXYQ28P7W1BA RXYQ30P7W1BA RXYQ32P7W1BA

• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
• VRV®Systems • Outdoor Units
6
1 Specifications
3
1-2 TECHNICAL SPECIFICATIONS RXYQ34P7W1BA RXYQ36P7W1BA RXYQ38P7W1BA RXYQ40P7W1BA RXYQ42P7W1BA RXYQ44P7W1BA RXYQ46P7W1BA
Capacity Cooling kW 94.0 98.0 105.0 111.0 116.0 120.0 126.0
Heating kW 107.0 113.0 119.0 126.0 132.0 138.0 145.0
COP Cooling 3.09 3.02 3.34 3.34 3.28 3.16 3.17
Heating 3.79 3.69 3.89 3.89 3.86 3.78 3.79
Capacity range HP 34 36 38 40 42 44 46
Power input
(nominal)
Cooling kW 30.4 32.4 31.4 33.2 35.4 38.0 39.8
Heating kW 28.2 30.6 30.6 32.4 34.2 36.5 38.3
PED category Category II
Max n° of indoor units to be connected 55 58 61 64 64 64 64
Indoor index
connection
Minimum 425 450 475 500 525 550 575
Maximum 1105 1170 1,235 1,300 1,365 1,430 1,495
Casing Colour Daikin White
Material Painted galvanised steel
Heat
Exchanger
Dimensions Length mm 2,088 + 2,088 2,088 + 2,088 1,778 + 1,778
+ 2,088
1,778 + 1,778
+ 2,088
1,778 + 1,778
+ 2,088
1,778 + 2,088
+ 2,088
1,778 + 2,088
+ 2,088
Nr of Rows 54 + 54 54 + 54 54 + 54 + 54 54 + 54 + 54 54 + 54 + 54 54 + 54 + 54 54 + 54 + 54
Fin Pitch mm 2.00 2.00 2.00 2.00 2.00 2.00 2.00
Nr of Passes 21 + 21 21 + 21 18 + 18 + 21 18 + 18 + 21 18 + 18 + 21 18 + 21 + 21 18 + 21 + 21
Face Area m² 2.481 + 2.481 2.481 + 2.481 2.112 + 2.112
+ 2.481
2.112 + 2.112
+ 2.481
2.112 + 2.112
+ 2.481
2.112 + 2.481
+ 2.481
2.112 + 2.481
+ 2.481
Nr of Stages 2 + 2 2 + 2 2 2 2 2 2
Tube type Hi-XSS (8)
Fin Fin type Non-symmetric waffle louvre
Treatment Hydrophylic and anti corrosion resistant
Fan Type Propeller
Quantity 2 + 2 2 + 2 1 + 1 + 2 1 + 1 + 2 1 + 1 + 2 1 + 2 + 2 1 + 2 + 2
Air Flow Rate
(nominal at
230V)
Cooling m³/min 233 + 239 239 + 239 171 + 196 +
239
185 + 196 +
239
196 + 196 +
239
171 + 239 +
239
185 + 239 +
239
Heating m³/min 233 + 239 239 + 239 171 + 196 +
239
185 + 196 +
239
196 + 196 +
239
171 + 239 +
239
185 + 239 +
239
External static pressure Pa 78 Pa in high static pressure
Discharge direction Vertical
Motor Quantity 2 + 2 2 + 2 1 + 1 + 2 1 + 1 + 2 1 + 1 + 2 1 + 2 + 2 1 + 2 + 2
Model Brushless DC
Output motor W2x350 +
2x750
2x750 +
2x750
750 + 750 +
2x750
750 + 750 +
2x750
750 + 750 +
2x750
750 + 2x750 +
2x750
750 + 2x750 +
2x750
Compressor Quantity 3 + 3 3 + 3 6 7 7 7 8
Motor Quantity 1 + 1 1 + 1 1 + 1 + 1 1 + 1 + 1 1 + 1 + 1 1 + 1 + 1 1 + 1 + 1
Model Inverter
Type Hermetically sealed scroll compressor
Speed rpm 6,300 + 7,980 7,980 + 7,980 7,980 + 6,300
+ 7,980
6,300 + 6,300
+ 7,980
6,300 + 6,300
+ 7,980
7,980 + 7,980
+ 7,980
6,300 + 7,980
+ 7,980
Motor Output kW 1.4 + 3.0 3.0 + 3.0 3.8 + 2.8 + 3.0 1.2 + 2.8 + 3.0 2.8 + 2.8 + 3.0 3.8 + 3.0 + 3.0 1.2 + 3.0 + 3.0
Crankcase
Heater
W33 33 33 33 33 33 33
Quantity 4434445
Model ON-OFF
Type Hermetically sealed scroll compressor
Speed rpm 2,900
Motor Output kW 4.5 4.5 4.5 4.5 4.5 4.5 4.5
Crankcase
Heater
W33 33 33 33 33 33 33
Cooling Standard Min °CDB -5.0 -5.0 -5.0 -5.0 -5.0 -5.0 -5.0
Operation
Range
Cooling Max °CDB 43.0 43.0 43.0 43.0 43.0 43.0 43.0
Heating Min °CWB -20.0 -20.0 -20.0 -20.0 -20.0 -20.0 -20.0
Max °CWB 15.0 15.0 15.0 15.0 15.0 15.0 15.0

• VRV®Systems • Outdoor Units 7
• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
1 Specifications
3
Refrigerant Name R-410A
Charge kg 11.5 + 11.7 11.7 + 11.7 7.7 + 8.6 +
11.7
8.4 + 8.6 +
11.7
8.6 + 8.6 +
11.7
7.7 + 11.7 +
11.7
8.4 + 11.7 +
11.7
Control Expansion valve (electronic type)
Nr of Circuits 1111111
Maximum total refrigerant charge in the system kg Less than 100 (calculated charge less than 95)
Refrigerant Oil Name Synthetic (ether) oil
Charged Volume l5.7 + 5.8 5.8 + 5.8 2.1 + 3.9 + 5.8 3.9 + 3.9 + 5.8 3.9 + 3.9 + 5.8 2.1 + 5.8 + 5.8 3.9 + 5.8 + 5.8
Piping
connections
Liquid (OD) Type Braze connection
Diameter (OD) mm 19.1 19.1 19.1 19.1 19.1 19.1 19.1
Gas Type Braze connection
Diameter (OD) mm 34.9 41.3 41.3 41.3 41.3 41.3 41.3
Heat Insulation Both liquid and gas pipes
Max total length m1000 1000 1000 1000 1000 1000 1000
Defrost Method Reversed cycle
Defrost Control Sensor for outdoor heat exchanger temperature
Capacity Control Method Inverter controlled
Capacity Control ~ 100
Safety devices HPS
Fan motor driver overload protector
Over current relay
Inverter overload protector
PC board fuse
Standard
Accessories
Standard Accessories Installation and operation manual
Quantity 1111111
Standard Accessories Connection pipes
Quantity 4444444
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature :
35°CDB, equivalent refrigerant piping : 7.5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m, level difference : 0m
Sound level of a multi system is determined by the individual outdoor unit and installation condition
The refrigerant charge of the system must be less than 100 kg. This means that in case the calculated refrigerant
charge is equal to or more than 95 kg, you must divide your multiple outdoor system into smaller independent
systems, each containing less than 95 kg refrigerant charge. For factory charge, refer to the namplate of the unit.
1-2 TECHNICAL SPECIFICATIONS RXYQ34P7W1BA RXYQ36P7W1BA RXYQ38P7W1BA RXYQ40P7W1BA RXYQ42P7W1BA RXYQ44P7W1BA RXYQ46P7W1BA

• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
• VRV®Systems • Outdoor Units
8
1 Specifications
3
1-2 TECHNICAL SPECIFICATIONS RXYQ48P7W1BA RXYQ50P7W1BA RXYQ52P7W1BA RXYQ54P7W1BA
Capacity Cooling kW 132.0 138.0 143.0 147.0
Heating kW 151.0 158.0 163.0 170.0
COP Cooling 3.14 3.08 3.07 3.02
Heating 3.78 3.77 3.75 3.70
Capacity range HP 48 50 52 54
Power input
(nominal)
Cooling kW 42.0 44.8 46.6 48.6
Heating kW 40.0 41.9 43.5 45.9
PED category Category II
Max n° of indoor units to be connected 64 64 64 64
Indoor index
connection
Minimum 600 625 650 675
Maximum 1,560 1,625 1,690 1,755
Casing Colour Daikin White
Material Painted galvanised steel
Heat
Exchanger
Dimensions Length mm 1,778 + 2,088 + 2,088 2,088 + 2,088 + 2,088 2,088 + 2,088 + 2,088 2,088 + 2,088 + 2,088
Nr of Rows 54 + 54 + 54
Fin Pitch mm 2.00 2.00 2.00 2.00
Nr of Passes 18 + 21 + 21 21 + 21 + 21 21 + 21 + 21 21 + 21 + 21
Face Area m² 2.112 + 2.481 + 2.481 2.481 + 2.481 + 2.481 2.481 + 2.481 + 2.481 2.481 + 2.481 + 2.481
Nr of Stages 2222
Tube type Hi-XSS (8)
Fin Fin type Non-symmetric waffle louvre
Treatment Hydrophylic and anti corrosion resistant
Fan Type Propeller
Quantity 1 + 2 + 2 2 + 2 + 2 2 + 2 + 2 2 + 2 + 2
Air Flow Rate
(nominal at
230V)
Cooling m³/min 196 + 239 + 239 233 + 239 + 239 233 + 239 + 239 239 + 239 + 239
Heating m³/min 196 + 239 + 239 233 + 239 + 239 233 + 239 + 239 239 + 239 + 239
External static pressure Pa 78 Pa in high static pressure
Discharge direction Vertical
Motor Quantity 1 + 2 + 2 2 + 2 + 2 2 + 2 + 2 2 + 2 + 2
Model Brushless DC
Output motor W750 + 2x750 + 2x750 2x350 + 2x350 + 2x750 2x350 + 2x350 + 2x750 2x750 + 2x750 + 2x750
Compressor Quantity 8999
Motor Quantity 1 + 1 + 1
Model Inverter
Type Hermetically sealed scroll compressor
Speed rpm 6,300 + 7,980 + 7,980 6,300 + 7,980 + 7,980 6,300 + 7,980 + 7,980 7,980 + 7,980 + 7,980
Motor Output kW 2.8 + 3.0 + 3.0 0.3 + 3.0 + 3.0 1.4 + 3.0 + 3.0 3.0 + 3.0 + 3.0
Crankcase
Heater
W33 33 33 33
Quantity 5666
Model ON-OFF
Type Hermetically sealed scroll compressor
Speed rpm 2,900
Motor Output kW 4.5 4.5 4.5 4.5
Crankcase
Heater
W33 33 33 33
Cooling Standard Min °CDB -5.0 -5.0 -5.0 -5.0
Operation
Range
Cooling Max °CDB 43.0 43.0 43.0 43.0
Heating Min °CWB -20.0 -20.0 -20.0 -20.0
Max °CWB 15.0 15.0 15.0 15.0
Refrigerant Name R-410A
Charge kg 8.6 + 11.7 + 11.7 11.3 + 11.7 + 11.7 11.5 + 11.7 + 11.7 11.7 + 11.7 + 11.7
Control Expansion valve (electronic type)
Nr of Circuits 1111
Maximum total refrigerant charge in the system kg Less than 100 (calculated charge less than 95)
Refrigerant Oil Name Synthetic (ether) oil
Charged Volume l3.9 + 5.8 + 5.8 5.7 + 5.8 + 5.8 5.7 + 5.8 + 5.8 5.8 + 5.8 + 5.8

• VRV®Systems • Outdoor Units 9
• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
1 Specifications
3
Piping
connections
Liquid (OD) Type Braze connection
Diameter (OD) mm 19.1 19.1 19.1 19.1
Gas Type Braze connection
Diameter (OD) mm 41.3 41.3 41.3 41.3
Heat Insulation Both liquid and gas pipes
Max total length m1000 1000 1000 1000
Defrost Method Reversed cycle
Defrost Control Sensor for outdoor heat exchanger temperature
Capacity Control Method Inverter controlled
Capacity Control ~ 100
Safety devices HPS
Fan motor driver overload protector
Over current relay
Inverter overload protector
PC board fuse
Standard
Accessories
Standard Accessories Installation and operation manual
Quantity 1111
Standard Accessories Connection pipes
Quantity 4444
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature :
35°CDB, equivalent refrigerant piping : 7.5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m, level difference : 0m
Sound level of a multi system is determined by the individual outdoor unit and installation condition
The refrigerant charge of the system must be less than 100 kg. This means that in case the calculated refrigerant
charge is equal to or more than 95 kg, you must divide your multiple outdoor system into smaller independent
systems, each containing less than 95 kg refrigerant charge. For factory charge, refer to the namplate of the unit.
1-2 TECHNICAL SPECIFICATIONS RXYQ48P7W1BA RXYQ50P7W1BA RXYQ52P7W1BA RXYQ54P7W1BA

• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
• VRV®Systems • Outdoor Units
10
1 Specifications
3
1-3 ELECTRICAL SPECIFICATIONS RXYQ5P7W1B RXYQ8P7W1B RXYQ10P7W1B RXYQ12P7W1B RXYQ14P7W1BA RXYQ16P7W1BA RXYQ18P7W1BA
Power Supply Name W1
Phase 3N~
Frequency Hz 50 50 550 50 50 50
Voltage V400 400 400 400 400 400 400
Current Nominal
running current
(RLA)
Cooling A5.1 7.5 11.3 14.0 18.4 21.3 24.2
Heating A5.8 8.2 11.1 13.8 16.8 19.4 23.0
Starting current (MSC) A74 75 84 85 85
Minimum Ssc value kVa 1,218 928 944 1,114 1,114 1,171
Minimum circuit amps (MCA) A11.9 18.5 21.6 22.7 31.5 31.5 32.5
Maximum fuse amps (MFA) A16 25 25 25 40 40 40
Total overcurrent amps (TOCA) A15.6 16.5 31.5 31.5 46.4 46.4 48.3
Full load amps (FLA) A0.4 0.7 0.9 0.9 1.2 1.2 1.4
Voltage range Minimum V360 360 360 360 360 360 360
Maximum V440 440 440 440 440 440 440
Wiring
connections
For Power
Supply
Quantity 5555555
Remark Earth wire included
For connection
with indoor
Quantity 2222222
Remark F1 - F2
Power Supply Intake Both indoor and outdoor unit
Notes MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker)
MSC means the maximum current during start up of the compressor
Maximum allowable voltage range variation between phases is 2%
RLA is based on following conditions : indoor temperature : 27°CDB/19°CWB , outdoor temperature : 35°CDB
Select wire size based on the value of MCA or TOCA
TOCA means the total value of each OC set
Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminal is not below
or above listed range limits
1-3 ELECTRICAL SPECIFICATIONS RXYQ20P7W1B RXYQ22P7W1B RXYQ24P7W1B RXYQ26P7W1BA RXYQ28P7W1BA RXYQ30P7W1BA RXYQ32P7W1BA
Power Supply Name W1
Phase 3N~
Frequency Hz 50 50 50 50 50 50 50
Voltage V400 400 400 400 400 400 400
Current Nominal running
current (RLA)
Cooling A21.4 25.3 28.0 31.7 35.6 38.2 42.7
Heating A22.0 24.8 27.5 31.2 34.1 36.8 39.8
Starting current (MSC) A79 88 88 89 98 98 108
Minimum circuit amps (MCA) A41.2 44.3 45.4 51.0 54.1 55.2 64.0
Maximum fuse amps (MFA) A50 50 50 63 63 63 80
Total overcurrent amps (TOCA) A48.0 63.0 63.0 64.8 79.8 79.8 94.7
Full load amps (FLA) A1.6 1.8 1.8 2.1 2.3 2.3 2.6
Voltage range Minimum V360 360 360 360 360 360 360
Maximum V440 440 440 440 440 440 440
Wiring
connections
For Power
Supply
Quantity 5555555
Remark Earth wire included
For connection
with indoor
Quantity 2222222
Remark F1 - F2
Power Supply Intake Both indoor and outdoor unit
Notes MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker)
MSC means the maximum current during start up of the compressor
Maximum allowable voltage range variation between phases is 2%
RLA is based on following conditions : indoor temperature : 27°CDB/19°CWB , outdoor temperature : 35°CDB
Select wire size based on the value of MCA or TOCA
TOCA means the total value of each OC set
Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminal is not below
or above listed range limits

• VRV®Systems • Outdoor Units 11
• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
1 Specifications
3
1-3 ELECTRICAL SPECIFICATIONS RXYQ34P7W1BA RXYQ36P7W1BA RXYQ38P7W1BA RXYQ40P7W1BA RXYQ42P7W1BA RXYQ44P7W1BA RXYQ46P7W1BA
Power Supply Name W1
Phase 3N~
Frequency Hz 50 50 50 50 50 50 50
Voltage V400 400 400 400 400 400 400
Current Nominalrunning
current (RLA)
Cooling A45.5 48.5 45.7 49.5 52.2 55.9 59.8
Heating A42.4 46.0 45.0 47.8 50.5 54.2 57.1
Starting current (MSC) A109 109 102 111 111 113 122
Minimum circuit amps (MCA) A64.0 65.0 73.7 76.8 77.9 83.5 86.6
Maximum fuse amps (MFA) A80 80 100 100 100 100 100
Total overcurrent amps (TOCA) A94.7 96.6 96.3 111.3 111.3 113.1 128.1
Full load amps (FLA) A2.6 2.8 3.0 3.2 3.2 3.5 3.7
Voltage range Minimum V360 360 360 360 360 360 360
Maximum V440 440 440 440 440 440 440
Wiring
connections
For Power
Supply
Quantity 5555555
Remark Earth wire included
For connection
with indoor
Quantity 2222222
Remark F1 - F2
Power Supply Intake Both indoor and outdoor unit
Notes MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker)
MSC means the maximum current during start up of the compressor
Maximum allowable voltage range variation between phases is 2%
RLA is based on following conditions : indoor temperature : 27°CDB/19°CWB , outdoor temperature : 35°CDB
Select wire size based on the value of MCA or TOCA
TOCA means the total value of each OC set
Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminal is not below
or above listed range limits
1-3 ELECTRICAL SPECIFICATIONS RXYQ48P7W1BA RXYQ50P7W1BA RXYQ52P7W1BA RXYQ54P7W1BA
Power Supply Name W1
Phase 3N~
Frequency Hz 50 50 50 50
Voltage V400 400 400 400
Current Nominal
running current
(RLA)
Cooling A62.5 66.9 69.8 72.7
Heating A59.8 62.8 65.4 69.0
Starting current (MSC) A122 132 134 134
Minimum circuit amps (MCA) A87.7 96.5 96.5 97.5
Maximum fuse amps (MFA) A100 125 125 125
Total overcurrent amps (TOCA) A128.1 143.0 143.0 144.9
Full load amps (FLA) A3.7 3.6 3.6 4.2
Voltage range Minimum V360 360 360 360
Maximum V440 440 440 440
Wiring
connections
For Power
Supply
Quantity 5555
Remark Earth wire included
For connection
with indoor
Quantity 2222
Remark F1 - F2
Power Supply Intake Both indoor and outdoor unit
Notes MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker)
MSC means the maximum current during start up of the compressor
Maximum allowable voltage range variation between phases is 2%
RLA is based on following conditions : indoor temperature : 27°CDB/19°CWB , outdoor temperature : 35°CDB
Select wire size based on the value of MCA or TOCA
TOCA means the total value of each OC set
Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminal is not below
or above listed range limits

• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
• VRV®Systems • Outdoor Units
12
2 Electrical data
3
RXYQ8-54P(A)
4TW29411-4
COMBINATION OF Minimum S
sc
value
[kVA]
ZMAX
[Ω]
RXYQ8 RXYQ8 1218 -
RXYQ10 RXYQ10 928 0,27
RXYQ12 RXYQ12 944 0,27
RXYQ14 RXYQ14 1114 0,24
RXYQ16 RXYQ16 1114 0,24
RXYQ18 RXYQ18 1171 0,24
RXYQ20 RXYQ8 + RXYQ12 2162 0,27
RXYQ22 RXYQ10 + RXYQ12 1872 0,25
RXYQ24 RXYQ12 + RXYQ12 1888 0,25
RXYQ26 RXYQ8 + RXYQ12 2389 0,24
RXYQ28 RXYQ10 + RXYQ18 2099 0,23
RXYQ30 RXYQ12 + RXYQ18 2115 0,23
RXYQ32 RXYQ14 + RXYQ18 2284 0,22
RXYQ34 RXYQ16 + RXYQ18 2284 0,22
RXYQ36 RXYQ18 + RXYQ18 2342 0,22
RXYQ38 RXYQ8 + RXYQ12 + RXYQ18 3333 0,22
RXYQ40 RXYQ10 + RXYQ12 + RXYQ18 3043 0,22
RXYQ42 RXYQ12 + RXYQ12 + RXYQ18 3059 0,22
RXYQ44 RXYQ8 + RXYQ18 + RXYQ18 3560 0,22
RXYQ46 RXYQ10 + RXYQ18 + RXYQ18 3270 0,22
RXYQ48 RXYQ12 + RXYQ18 + RXYQ18 3286 0,22
RXYQ50 RXYQ14 + RXYQ18 + RXYQ18 3455 0,22
RXYQ52 RXYQ16 + RXYQ18 + RXYQ18 3455 0,22
RXYQ54 RXYQ18 + RXYQ18 + RXYQ18 3513 0,22
NOTES
1 In accordance with EN/IEC 61000-3-11 (1), respectively EN/IEC
61000-3-12 (2), it may be necessary to consult the distribution network
operator to ensure that the equipment is connected only to a supply
with ZSYS
(4) ⱕZMAX, respectively Ssc(3) ⱖminimum Ssc value
2(1) European/international technical standard setting the limits for
voltage changes, voltage fluctuations and flicker in public low-
voltage supply systems for equipment with rated ⱕ75A.
(2) European/international technical standard setting the limits for
harmonic currents produced by equipment connected to public
low-voltage system with input current ⬎ 16A and ⱕ 75A per phase.
(3) Short-circuit power
(4) System impendance

• VRV®Systems • Outdoor Units 13
• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
3 Options
3
RXYQ-P
NOTES
1 All options are kits.
2 Central drain pan kit shall be combined based on the outdoor mulit connection table.
3 Only 1 option per installation is needed.
4 1 Option per module is required.
5 The option should be installed inside the outdoor unit.
No. Item RXYQ5P RXYQ8P
RXYQ10P RXYQ12P
RXYQ14P
RXYQ16P
RXYQ18P
RXYQ20P
L
RXYQ54P
1 COOL/HEAT SELECTOR KRC19-26A6
2 FIXING BOX KJB111A
3 REFNET HEADER KHRQ22M29H
KHRQ22M64H
KHRQ22M75H
4REFNETJOINT KHRQ22M20T
KHRS22M29T9
KHRQ22M64T
KHRQ22M75T
5 OUTDOOR MULTI CONNECTION KIT FOR 2 OUTDOOR UNITS - - - - BHFQ22P1007
6 OUTDOOR MULTI CONNECTION KIT FOR 3 OUTDOOR UNITS - - - - BHFQ22P1517
7 CENTRAL DRAIN PAN KIT KWC26B160 KWC26B280 KWC26B450 See note 2
8 DIGITAL PRESSURE GAUGE KIT BJGP26A1 See note 3
9 INCREASE HEIGHT DIFFERENCE BETWEEN INDOOR &
OUTDOOR TO 90m (See note 5)
- EKLD90D12 EKLD90P18 See note 4
4TW27231-1C

• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
• VRV®Systems • Outdoor Units
14
4 Capacity tables
4 - 1 Combination table
3
RXYQ-P
4TW27239-2
RXQ5P7W1B RXQ8P7W1B
RXQ10P7W1B RXQ12P7W1B RXQ14P7W1B RXQ16P7W1B RXQ18P7W1B
RXYQ5P7W1B RXYQ8P7W1B
RXYQ10P7W1B RXYQ12P7W1B RXYQ14P7W1B RXYQ16P7W1B RXYQ18P7W1B
Cooling only
RXQ5P7W1B 1
RXQ8P7W1B 1
RXQ10P7W1B 1
RXQ12P7W1B 1
RXQ14P7W1B 1
RXQ16P7W1B 1
RXQ18P7W1B 1
Heat pump
RXYQ5P7W1B 1
RXYQ8P7W1B 1
RXYQ10P7W1B 1
RXYQ12P7W1B 1
RXYQ14P7W1B 1
RXYQ16P7W1B 1
RXYQ18P7W1B 1
Multi combination with 2 outdoor units
RXYQ20P7W1B 11
RXYQ22P7W1B 11
RXYQ24P7W1B 2
RXYQ26P7W1B 11
RXYQ28P7W1B 11
RXYQ30P7W1B 11
RXYQ32P7W1B 11
RXYQ34P7W1B 11
RXYQ36P7W1B 2
Multi combination with 3 outdoor units
RXYQ38P7W1B 11 1
RXYQ40P7W1B 11 1
RXYQ42P7W1B 21
RXYQ44P7W1B 12
RXYQ46P7W1B 12
RXYQ48P7W1B 12
RXYQ50P7W1B 12
RXYQ52P7W1B 12
RXYQ54P7W1B 3

• VRV®Systems • Outdoor Units 15
• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
4 Capacity tables
4 - 2 Cooling capacity tables
3
RXYQ5P
3TW27232-1C
NOTES
1 The above table shows the average value of conditions which may occur.
2 When indoor models FXFQ20M and FXFQ25M and VKM-models are connected, the maximum connection ratio is 130%.
TC: Total capacity: kW; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacitry
index (kW)
Outdoor
air temp.
Indoor air temperature: °CWB
14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
°CDBTCPITCPITCPITCPITCPITCPITCPI
130 163
(18.20)
10 12.3 1.62 14.6 1.98 17.0 2.36 17.6 2.41 17.9 2.36 18.3 2.26 18.7 2.16
12 12.3 1.65 14.6 2.02 17.0 2.40 17.4 2.40 17.6 2.35 18.1 2.25 18.5 2.21
14 12.3 1.68 14.6 2.06 17.0 2.43 17.2 2.38 17.4 2.33 17.8 2.32 18.3 2.34
16 12.3 1.71 14.6 2.10 16.7 2.42 16.9 2.41 17.2 2.42 17.6 2.44 18.1 2.46
18 12.3 1.75 14.6 2.14 16.5 2.52 16.7 2.53 16.9 2.54 17.4 2.57 17.8 2.59
20 12.3 1.78 14.6 2.28 16.3 2.64 16.5 2.65 16.7 2.66 17.2 2.69 17.6 2.72
21 12.3 1.83 14.6 2.36 16.2 2.70 16.4 2.71 16.6 2.73 17.0 2.75 17.5 2.78
23 12.3 1.96 14.6 2.53 15.9 2.82 16.2 2.84 16.4 2.85 16.8 2.88 17.3 2.91
25 12.3 2.10 14.6 2.71 15.7 2.95 15.9 2.96 16.1 2.98 16.6 3.01 17.0 3.04
27 12.3 2.24 14.6 2.90 15.5 3.07 15.7 3.09 15.9 3.10 16.4 3.14 16.8 3.17
29 12.3 2.39 14.6 3.10 15.2 3.19 15.5 3.21 15.7 3.23 16.1 3.26 16.6 3.30
31 12.3 2.55 14.6 3.28 15.0 3.32 15.2 3.34 15.5 3.36 15.9 3.39 16.3 3.43
33 12.3 2.72 14.3 3.41 14.8 3.45 15.0 3.46 15.2 3.48 15.7 3.52 16.1 3.56
35 12.3 2.90 14.1 3.53 14.6 3.57 14.8 3.59 15.0 3.61 15.5 3.65 15.9 3.69
37 12.3 3.08 13.9 3.66 14.3 3.70 14.6 3.72 14.8 3.74 15.2 3.78 15.7 3.83
39 12.3 3.28 13.7 3.78 14.1 3.83 14.3 3.85 14.6 3.87 15.0 3.92 15.4 3.96
120 150
(16.80)
10 11.3 1.48 13.5 1.81 15.7 2.15 16.8 2.33 17.6 2.42 18.0 2.33 18.4 2.24
12 11.3 1.51 13.5 1.84 15.7 2.19 16.8 2.37 17.3 2.41 17.8 2.32 18.2 2.22
14 11.3 1.54 13.5 1.88 15.7 2.23 16.8 2.41 17.1 2.40 17.5 2.30 17.9 2.32
16 11.3 1.57 13.5 1.91 15.7 2.28 16.7 2.43 16.9 2.40 17.3 2.42 17.7 2.44
18 11.3 1.60 13.5 1.95 15.7 2.36 16.5 2.51 16.7 2.52 17.1 2.55 17.5 2.57
20 11.3 1.63 13.5 2.03 15.7 2.53 16.2 2.64 16.4 2.65 16.8 2.67 17.3 2.70
21 11.3 1.64 13.5 2.10 15.7 2.62 16.1 2.70 16.3 2.71 16.7 2.73 17.1 2.76
23 11.3 1.75 13.5 2.25 15.7 2.81 15.9 2.82 16.1 2.83 16.5 2.86 16.9 2.89
25 11.3 1.88 13.5 2.41 15.5 2.93 15.7 2.94 15.9 2.96 16.3 2.99 16.7 3.01
27 11.3 2.00 13.5 2.58 15.2 3.05 15.4 3.07 15.6 3.08 16.0 3.11 16.5 3.14
29 11.3 2.14 13.5 2.75 15.0 3.18 15.2 3.19 15.4 3.21 15.8 3.24 16.2 3.27
31 11.3 2.28 13.5 2.94 14.8 3.30 15.0 3.32 15.2 3.33 15.6 3.37 16.0 3.40
33 11.3 2.42 13.5 3.13 14.5 3.42 14.8 3.44 15.0 3.46 15.4 3.49 15.8 3.53
35 11.3 2.58 13.5 3.34 14.3 3.55 14.5 3.57 14.7 3.59 15.1 3.62 15.5 3.66
37 11.3 2.75 13.5 3.56 14.1 3.67 14.3 3.69 14.5 3.71 14.9 3.75 15.3 3.79
39 11.3 2.92 13.5 3.76 13.9 3.80 14.1 3.82 14.3 3.84 14.7 3.88 15.1 3.93
110 138
(15.40)
10 10.4 1.34 12.4 1.64 14.4 1.94 15.4 2.10 16.4 2.26 17.7 2.40 18.0 2.32
12 10.4 1.37 12.4 1.67 14.4 1.98 15.4 2.14 16.4 2.30 17.4 2.39 17.8 2.30
14 10.4 1.39 12.4 1.70 14.4 2.02 15.4 2.18 16.4 2.35 17.2 2.38 17.6 2.30
16 10.4 1.42 12.4 1.73 14.4 2.06 15.4 2.23 16.4 2.39 17.0 2.41 17.4 2.43
18 10.4 1.45 12.4 1.77 14.4 2.10 15.4 2.29 16.4 2.51 16.8 2.53 17.1 2.55
20 10.4 1.47 12.4 1.80 14.4 2.22 15.4 2.46 16.2 2.63 16.5 2.65 16.9 2.68
21 10.4 1.49 12.4 1.86 14.4 2.30 15.4 2.55 16.0 2.69 16.4 2.72 16.8 2.74
23 10.4 1.56 12.4 1.99 14.4 2.47 15.4 2.73 15.8 2.82 16.2 2.84 16.6 2.86
25 10.4 1.67 12.4 2.13 14.4 2.64 15.4 2.93 15.6 2.94 16.0 2.96 16.3 2.99
27 10.4 1.78 12.4 2.27 14.4 2.83 15.2 3.05 15.4 3.06 15.7 3.09 16.1 3.12
29 10.4 1.89 12.4 2.42 14.4 3.02 14.9 3.17 15.1 3.19 15.5 3.21 15.9 3.24
31 10.4 2.02 12.4 2.59 14.4 3.23 14.7 3.30 14.9 3.31 15.3 3.34 15.7 3.37
33 10.4 2.15 12.4 2.76 14.3 3.40 14.5 3.42 14.7 3.44 15.1 3.47 15.4 3.50
35 10.4 2.28 12.4 2.94 14.1 3.53 14.3 3.54 14.4 3.56 14.8 3.60 15.2 3.63
37 10.4 2.43 12.4 3.13 13.8 3.65 14.0 3.67 14.2 3.69 14.6 3.72 15.0 3.76
39 10.4 2.58 12.4 3.33 13.6 3.78 13.8 3.80 14.0 3.81 14.4 3.85 14.7 3.89
100 125
(14.00)
10 9.45 1.21 11.3 1.47 13.1 1.74 14.0 1.88 14.9 2.02 16.7 2.31 17.7 2.39
12 9.45 1.23 11.3 1.50 13.1 1.78 14.0 1.92 14.9 2.06 16.7 2.36 17.5 2.38
14 9.45 1.26 11.3 1.53 13.1 1.81 14.0 1.95 14.9 2.10 16.7 2.40 17.2 2.37
16 9.45 1.28 11.3 1.55 13.1 1.84 14.0 1.99 14.9 2.14 16.7 2.43 17.0 2.41
18 9.45 1.30 11.3 1.58 13.1 1.88 14.0 2.03 14.9 2.19 16.4 2.51 16.8 2.53
20 9.45 1.33 11.3 1.62 13.1 1.94 14.0 2.13 14.9 2.34 16.2 2.64 16.6 2.66
21 9.45 1.34 11.3 1.63 13.1 2.01 14.0 2.21 14.9 2.43 16.1 2.70 16.4 2.72
23 9.45 1.38 11.3 1.74 13.1 2.15 14.0 2.37 14.9 2.60 15.9 2.82 16.2 2.84
25 9.45 1.47 11.3 1.86 13.1 2.30 14.0 2.54 14.9 2.79 15.6 2.94 16.0 2.97
27 9.45 1.56 11.3 1.98 13.1 2.46 14.0 2.71 14.9 2.98 15.4 3.07 15.8 3.09
29 9.45 1.67 11.3 2.12 13.1 2.62 14.0 2.90 14.9 3.16 15.2 3.19 15.5 3.22
31 9.45 1.77 11.3 2.26 13.1 2.80 14.0 3.09 14.6 3.29 15.0 3.32 15.3 3.34
33 9.45 1.89 11.3 2.40 13.1 2.99 14.0 3.30 14.4 3.41 14.7 3.44 15.1 3.47
35 9.45 2.00 11.3 2.56 13.1 3.18 14.0 3.52 14.2 3.54 14.5 3.57 14.9 3.60
37 9.45 2.13 11.3 2.72 13.1 3.39 13.8 3.64 13.9 3.66 14.3 3.69 14.6 3.73
39 9.45 2.26 11.3 2.90 13.1 3.61 13.5 3.77 13.7 3.79 14.1 3.82 14.4 3.85

• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
• VRV®Systems • Outdoor Units
16
4 Capacity tables
4 - 2 Cooling capacity tables
3
RXYQ5P
3TW27232-1C
TC: Total capacity: kW; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacitry
index (kW)
Outdoor
air temp.
Indoor air temperature: °CWB
14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
°CDBTCPITCPITCPITCPITCPITCPITCPI
90 113
(12.60)
10 8.50 1.09 10.1 1.31 11.8 1.55 12.6 1.67 13.4 1.79 15.1 2.05 16.7 2.31
12 8.50 1.10 10.1 1.33 11.8 1.57 12.6 1.70 13.4 1.83 15.1 2.09 16.7 2.35
14 8.50 1.12 10.1 1.36 11.8 1.60 12.6 1.73 13.4 1.86 15.1 2.13 16.7 2.40
16 8.50 1.14 10.1 1.38 11.8 1.63 12.6 1.76 13.4 1.90 15.1 2.17 16.7 2.44
18 8.50 1.16 10.1 1.41 11.8 1.67 12.6 1.80 13.4 1.94 15.1 2.21 16.4 2.51
20 8.50 1.18 10.1 1.44 11.8 1.70 12.6 1.84 13.4 2.01 15.1 2.38 16.2 2.63
21 8.50 1.20 10.1 1.45 11.8 1.73 12.6 1.90 13.4 2.08 15.1 2.46 16.1 2.70
23 8.50 1.22 10.1 1.51 11.8 1.85 12.6 2.03 13.4 2.23 15.1 2.64 15.9 2.82
25 8.50 1.28 10.1 1.61 11.8 1.98 12.6 2.18 13.4 2.38 15.1 2.83 15.6 2.94
27 8.50 1.37 10.1 1.72 11.8 2.11 12.6 2.32 13.4 2.55 15.1 3.03 15.4 3.07
29 8.50 1.45 10.1 1.83 11.8 2.25 12.6 2.48 13.4 2.72 14.9 3.17 15.2 3.19
31 8.50 1.55 10.1 1.95 11.8 2.40 12.6 2.65 13.4 2.90 14.7 3.29 15.0 3.31
33 8.50 1.64 10.1 2.07 11.8 2.56 12.6 2.82 13.4 3.10 14.4 3.41 14.7 3.44
35 8.50 1.74 10.1 2.21 11.8 2.73 12.6 3.01 13.4 3.30 14.2 3.54 14.5 3.57
37 8.50 1.85 10.1 2.35 11.8 2.90 12.6 3.20 13.4 3.52 14.0 3.66 14.3 3.69
39 8.50 1.96 10.1 2.49 11.8 3.09 12.6 3.41 13.4 3.75 13.7 3.79 14.0 3.82
80 100
(11.20)
10 7.56 0.96 9.02 1.15 10.5 1.36 11.2 1.46 11.9 1.57 13.4 1.79 14.8 2.01
12 7.56 0.98 9.02 1.17 10.5 1.38 11.2 1.49 11.9 1.60 13.4 1.82 14.8 2.05
14 7.56 1.00 9.02 1.19 10.5 1.41 11.2 1.51 11.9 1.63 13.4 1.86 14.8 2.09
16 7.56 1.01 9.02 1.22 10.5 1.43 11.2 1.54 11.9 1.66 13.4 1.89 14.8 2.13
18 7.56 1.03 9.02 1.24 10.5 1.46 11.2 1.57 11.9 1.69 13.4 1.93 14.8 2.17
20 7.56 1.05 9.02 1.26 10.5 1.49 11.2 1.60 11.9 1.72 13.4 2.00 14.8 2.33
21 7.56 1.06 9.02 1.27 10.5 1.50 11.2 1.62 11.9 1.76 13.4 2.07 14.8 2.41
23 7.56 1.08 9.02 1.30 10.5 1.58 11.2 1.73 11.9 1.88 13.4 2.22 14.8 2.58
25 7.56 1.11 9.02 1.38 10.5 1.68 11.2 1.84 11.9 2.01 13.4 2.37 14.8 2.77
27 7.56 1.18 9.02 1.47 10.5 1.79 11.2 1.97 11.9 2.15 13.4 2.54 14.8 2.96
29 7.56 1.26 9.02 1.57 10.5 1.91 11.2 2.10 11.9 2.29 13.4 2.71 14.8 3.16
31 7.56 1.33 9.02 1.67 10.5 2.04 11.2 2.24 11.9 2.45 13.4 2.89 14.6 3.29
33 7.56 1.42 9.02 1.77 10.5 2.17 11.2 2.38 11.9 2.61 13.4 3.09 14.4 3.41
35 7.56 1.50 9.02 1.88 10.5 2.31 11.2 2.54 11.9 2.78 13.4 3.29 14.2 3.53
37 7.56 1.59 9.02 2.00 10.5 2.45 11.2 2.70 11.9 2.96 13.4 3.51 13.9 3.66
39 7.56 1.69 9.02 2.12 10.5 2.61 11.2 2.87 11.9 3.15 13.4 3.73 13.7 3.78
70 88
(9.80)
10 6.61 0.85 7.89 1.01 9.16 1.17 9.80 1.26 10.4 1.35 11.7 1.54 13.0 1.73
12 6.61 0.86 7.89 1.02 9.16 1.19 9.80 1.28 10.4 1.38 11.7 1.56 13.0 1.76
14 6.61 0.87 7.89 1.04 9.16 1.22 9.80 1.31 10.4 1.40 11.7 1.59 13.0 1.79
16 6.61 0.89 7.89 1.06 9.16 1.24 9.80 1.33 10.4 1.43 11.7 1.62 13.0 1.83
18 6.61 0.90 7.89 1.08 9.16 1.26 9.80 1.36 10.4 1.45 11.7 1.66 13.0 1.86
20 6.61 0.92 7.89 1.10 9.16 1.28 9.80 1.38 10.4 1.48 11.7 1.69 13.0 1.92
21 6.61 0.93 7.89 1.11 9.16 1.30 9.80 1.40 10.4 1.50 11.7 1.71 13.0 1.98
23 6.61 0.94 7.89 1.13 9.16 1.32 9.80 1.44 10.4 1.57 11.7 1.84 13.0 2.12
25 6.61 0.96 7.89 1.17 9.16 1.41 9.80 1.54 10.4 1.67 11.7 1.96 13.0 2.27
27 6.61 1.01 7.89 1.25 9.16 1.50 9.80 1.64 10.4 1.79 11.7 2.09 13.0 2.43
29 6.61 1.08 7.89 1.32 9.16 1.60 9.80 1.75 10.4 1.90 11.7 2.23 13.0 2.59
31 6.61 1.14 7.89 1.41 9.16 1.70 9.80 1.86 10.4 2.03 11.7 2.38 13.0 2.77
33 6.61 1.21 7.89 1.49 9.16 1.81 9.80 1.98 10.4 2.16 11.7 2.54 13.0 2.95
35 6.61 1.28 7.89 1.58 9.16 1.92 9.80 2.11 10.4 2.30 11.7 2.70 13.0 3.14
37 6.61 1.35 7.89 1.68 9.16 2.04 9.80 2.24 10.4 2.44 11.7 2.88 13.0 3.35
39 6.61 1.43 7.89 1.78 9.16 2.17 9.80 2.38 10.4 2.60 11.7 3.06 13.0 3.57
60 75
(8.40)
10 5.67 0.74 6.76 0.87 7.85 1.00 8.40 1.07 8.95 1.14 10.0 1.29 11.1 1.45
12 5.67 0.75 6.76 0.88 7.85 1.02 8.40 1.09 8.95 1.16 10.0 1.32 11.1 1.48
14 5.67 0.76 6.76 0.89 7.85 1.03 8.40 1.11 8.95 1.18 10.0 1.34 11.1 1.50
16 5.67 0.77 6.76 0.91 7.85 1.05 8.40 1.13 8.95 1.21 10.0 1.37 11.1 1.53
18 5.67 0.78 6.76 0.92 7.85 1.07 8.40 1.15 8.95 1.23 10.0 1.39 11.1 1.56
20 5.67 0.79 6.76 0.94 7.85 1.09 8.40 1.17 8.95 1.25 10.0 1.42 11.1 1.59
21 5.67 0.80 6.76 0.95 7.85 1.10 8.40 1.18 8.95 1.26 10.0 1.43 11.1 1.61
23 5.67 0.81 6.76 0.96 7.85 1.12 8.40 1.20 8.95 1.29 10.0 1.49 11.1 1.71
25 5.67 0.83 6.76 0.98 7.85 1.16 8.40 1.26 8.95 1.37 10.0 1.59 11.1 1.83
27 5.67 0.86 6.76 1.04 7.85 1.24 8.40 1.35 8.95 1.46 10.0 1.70 11.1 1.95
29 5.67 0.91 6.76 1.10 7.85 1.32 8.40 1.43 8.95 1.55 10.0 1.81 11.1 2.08
31 5.67 0.96 6.76 1.17 7.85 1.40 8.40 1.52 8.95 1.65 10.0 1.92 11.1 2.22
33 5.67 1.02 6.76 1.24 7.85 1.48 8.40 1.62 8.95 1.75 10.0 2.05 11.1 2.36
35 5.67 1.08 6.76 1.31 7.85 1.58 8.40 1.72 8.95 1.86 10.0 2.18 11.1 2.51
37 5.67 1.14 6.76 1.39 7.85 1.67 8.40 1.82 8.95 1.98 10.0 2.31 11.1 2.67
39 5.67 1.20 6.76 1.47 7.85 1.77 8.40 1.93 8.95 2.10 10.0 2.46 11.1 2.84
50 63
(7.00)
10 4.72 0.63 5.63 0.73 6.54 0.84 7.00 0.89 7.46 0.95 8.37 1.07 9.28 1.19
12 4.72 0.64 5.63 0.74 6.54 0.85 7.00 0.91 7.46 0.97 8.37 1.09 9.28 1.21
14 4.72 0.65 5.63 0.75 6.54 0.87 7.00 0.92 7.46 0.98 8.37 1.10 9.28 1.23
16 4.72 0.66 5.63 0.77 6.54 0.88 7.00 0.94 7.46 1.00 8.37 1.12 9.28 1.25
18 4.72 0.67 5.63 0.78 6.54 0.89 7.00 0.95 7.46 1.02 8.37 1.14 9.28 1.28
20 4.72 0.68 5.63 0.79 6.54 0.91 7.00 0.97 7.46 1.03 8.37 1.16 9.28 1.30
21 4.72 0.68 5.63 0.80 6.54 0.92 7.00 0.98 7.46 1.04 8.37 1.18 9.28 1.31
23 4.72 0.69 5.63 0.81 6.54 0.93 7.00 1.00 7.46 1.06 8.37 1.20 9.28 1.34
25 4.72 0.70 5.63 0.82 6.54 0.95 7.00 1.02 7.46 1.09 8.37 1.26 9.28 1.43
27 4.72 0.71 5.63 0.85 6.54 1.00 7.00 1.08 7.46 1.16 8.37 1.34 9.28 1.53
29 4.72 0.76 5.63 0.90 6.54 1.06 7.00 1.15 7.46 1.24 8.37 1.42 9.28 1.63
31 4.72 0.80 5.63 0.96 6.54 1.13 7.00 1.22 7.46 1.31 8.37 1.51 9.28 1.73
33 4.72 0.84 5.63 1.01 6.54 1.19 7.00 1.29 7.46 1.39 8.37 1.61 9.28 1.84
35 4.72 0.89 5.63 1.07 6.54 1.26 7.00 1.37 7.46 1.48 8.37 1.71 9.28 1.95
37 4.72 0.94 5.63 1.13 6.54 1.34 7.00 1.45 7.46 1.57 8.37 1.81 9.28 2.08
39 4.72 0.99 5.63 1.19 6.54 1.42 7.00 1.53 7.46 1.66 8.37 1.92 9.28 2.20

• VRV®Systems • Outdoor Units 17
• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
4 Capacity tables
4 - 2 Cooling capacity tables
3
RXYQ8P
3TW27232-1C
NOTES
1 The above table shows the average value of conditions which may occur.
2 When indoor models FXFQ20M and FXFQ25M and VKM-models are connected, the maximum connection ratio is 130%.
TC: Total capacity: kW; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacitry
index (kW)
Outdoor
air temp.
Indoor air temperature: °CWB
14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
°CDBTCPITCPITCPITCPITCPITCPITCPI
130 260
(29.12)
10 19.7 2.56 23.4 3.13 27.2 3.73 28.2 3.81 28.6 3.73 29.3 3.57 30.0 3.41
12 19.7 2.61 23.4 3.19 27.2 3.80 27.8 3.79 28.2 3.71 28.9 3.55 29.6 3.49
14 19.7 2.66 23.4 3.25 27.1 3.85 27.5 3.77 27.8 3.69 28.5 3.66 29.3 3.69
16 19.7 2.71 23.4 3.32 26.8 3.83 27.1 3.80 27.5 3.82 28.2 3.85 28.9 3.89
18 19.7 2.76 23.4 3.38 26.4 3.97 26.8 3.99 27.1 4.01 27.8 4.05 28.5 4.09
20 19.7 2.82 23.4 3.60 26.0 4.17 26.4 4.19 26.7 4.21 27.5 4.25 28.2 4.29
21 19.7 2.89 23.4 3.73 25.9 4.26 26.2 4.29 26.6 4.31 27.3 4.35 28.0 4.39
23 19.7 3.10 23.4 4.00 25.5 4.46 25.8 4.48 26.2 4.50 26.9 4.55 27.6 4.60
25 19.7 3.31 23.4 4.29 25.1 4.65 25.5 4.68 25.8 4.70 26.5 4.75 27.3 4.80
27 19.7 3.54 23.4 4.58 24.8 4.85 25.1 4.88 25.5 4.90 26.2 4.95 26.9 5.00
29 19.7 3.78 23.4 4.90 24.4 5.05 24.8 5.07 25.1 5.10 25.8 5.15 26.5 5.21
31 19.7 4.03 23.3 5.19 24.0 5.24 24.4 5.27 24.7 5.30 25.4 5.36 26.2 5.42
33 19.7 4.30 23.0 5.38 23.7 5.44 24.0 5.47 24.4 5.50 25.1 5.56 25.8 5.62
35 19.7 4.58 22.6 5.58 23.3 5.64 23.7 5.67 24.0 5.71 24.7 5.77 25.4 5.83
37 19.7 4.87 22.2 5.77 22.9 5.84 23.3 5.88 23.6 5.91 24.4 5.98 25.1 6.04
39 19.7 5.19 21.9 5.97 22.6 6.04 22.9 6.08 23.3 6.11 24.0 6.19 24.7 6.26
120 240
(26.88)
10 18.1 2.34 21.6 2.86 25.1 3.40 26.9 3.67 28.1 3.83 28.8 3.68 29.4 3.54
12 18.1 2.38 21.6 2.91 25.1 3.46 26.9 3.74 27.8 3.81 28.4 3.66 29.1 3.51
14 18.1 2.43 21.6 2.97 25.1 3.53 26.9 3.81 27.4 3.79 28.0 3.64 28.7 3.66
16 18.1 2.47 21.6 3.02 25.1 3.60 26.7 3.84 27.0 3.79 27.7 3.83 28.3 3.86
18 18.1 2.52 21.6 3.08 25.1 3.72 26.3 3.97 26.7 3.99 27.3 4.02 28.0 4.06
20 18.1 2.57 21.6 3.21 25.1 4.00 26.0 4.16 26.3 4.18 27.0 4.22 27.6 4.26
21 18.1 2.60 21.6 3.32 25.1 4.14 25.8 4.26 26.1 4.28 26.8 4.32 27.4 4.36
23 18.1 2.77 21.6 3.56 25.1 4.43 25.4 4.45 25.8 4.48 26.4 4.52 27.1 4.56
25 18.1 2.96 21.6 3.81 24.7 4.63 25.1 4.65 25.4 4.67 26.0 4.72 26.7 4.76
27 18.1 3.16 21.6 4.07 24.4 4.82 24.7 4.84 25.0 4.87 25.7 4.92 26.3 4.96
29 18.1 3.37 21.6 4.35 24.0 5.02 24.3 5.04 24.7 5.07 25.3 5.12 26.0 5.17
31 18.1 3.59 21.6 4.64 23.6 5.21 24.0 5.24 24.3 5.26 24.9 5.32 25.6 5.37
33 18.1 3.83 21.6 4.95 23.3 5.41 23.6 5.44 23.9 5.46 24.6 5.52 25.2 5.58
35 18.1 4.08 21.6 5.28 22.9 5.61 23.2 5.64 23.6 5.67 24.2 5.72 24.9 5.78
37 18.1 4.34 21.6 5.62 22.5 5.80 22.9 5.84 23.2 5.87 23.9 5.93 24.5 5.99
39 18.1 4.61 21.5 5.94 22.2 6.00 22.5 6.04 22.8 6.07 23.5 6.13 24.1 6.20
110 220
(24.64)
10 16.6 2.12 19.8 2.59 23.0 3.07 24.6 3.32 26.2 3.57 28.3 3.79 28.9 3.66
12 16.6 2.16 19.8 2.63 23.0 3.13 24.6 3.38 26.2 3.64 27.9 3.77 28.5 3.64
14 16.6 2.20 19.8 2.68 23.0 3.19 24.6 3.45 26.2 3.71 27.5 3.75 28.1 3.64
16 16.6 2.24 19.8 2.74 23.0 3.25 24.6 3.52 26.2 3.78 27.2 3.80 27.8 3.83
18 16.6 2.29 19.8 2.79 23.0 3.32 24.6 3.61 26.2 3.96 26.8 4.00 27.4 4.03
20 16.6 2.33 19.8 2.85 23.0 3.51 24.6 3.88 25.9 4.16 26.5 4.19 27.1 4.23
21 16.6 2.35 19.8 2.93 23.0 3.64 24.6 4.02 25.7 4.25 26.3 4.29 26.9 4.33
23 16.6 2.46 19.8 3.14 23.0 3.90 24.6 4.31 25.3 4.45 25.9 4.49 26.5 4.52
25 16.6 2.63 19.8 3.36 23.0 4.18 24.6 4.62 24.9 4.64 25.5 4.68 26.1 4.72
27 16.6 2.81 19.8 3.59 23.0 4.47 24.3 4.81 24.6 4.84 25.2 4.88 25.8 4.92
29 16.6 2.99 19.8 3.83 23.0 4.77 23.9 5.01 24.2 5.03 24.8 5.08 25.4 5.12
31 16.6 3.18 19.8 4.08 23.0 5.10 23.5 5.20 23.8 5.23 24.4 5.28 25.0 5.33
33 16.6 3.39 19.8 4.35 22.9 5.38 23.2 5.40 23.5 5.43 24.1 5.48 24.7 5.53
35 16.6 3.61 19.8 4.64 22.5 5.57 22.8 5.60 23.1 5.62 23.7 5.68 24.3 5.73
37 16.6 3.83 19.8 4.94 22.2 5.77 22.5 5.80 22.8 5.82 23.4 5.88 24.0 5.94
39 16.6 4.08 19.8 5.26 21.8 5.96 22.1 5.99 22.4 6.02 23.0 6.08 23.6 6.14
100 200
(22.40)
10 15.1 1.92 18.0 2.32 20.9 2.75 22.4 2.97 23.9 3.20 26.8 3.66 28.3 3.78
12 15.1 1.95 18.0 2.37 20.9 2.80 22.4 3.03 23.9 3.26 26.8 3.72 28.0 3.76
14 15.1 1.98 18.0 2.41 20.9 2.86 22.4 3.09 23.9 3.32 26.8 3.80 27.6 3.74
16 15.1 2.02 18.0 2.46 20.9 2.91 22.4 3.15 23.9 3.39 26.7 3.85 27.2 3.80
18 15.1 2.06 18.0 2.50 20.9 2.97 22.4 3.21 23.9 3.45 26.3 3.97 26.9 4.00
20 15.1 2.10 18.0 2.55 20.9 3.06 22.4 3.37 23.9 3.70 26.0 4.16 26.5 4.19
21 15.1 2.12 18.0 2.58 20.9 3.17 22.4 3.49 23.9 3.83 25.8 4.26 26.3 4.29
23 15.1 2.17 18.0 2.75 20.9 3.39 22.4 3.74 23.9 4.11 25.4 4.45 25.9 4.49
25 15.1 2.32 18.0 2.94 20.9 3.63 22.4 4.01 23.9 4.40 25.0 4.65 25.6 4.69
27 15.1 2.47 18.0 3.14 20.9 3.88 22.4 4.28 23.9 4.71 24.7 4.84 25.2 4.88
29 15.1 2.63 18.0 3.34 20.9 4.14 22.4 4.58 23.8 5.00 24.3 5.04 24.9 5.08
31 15.1 2.80 18.0 3.56 20.9 4.42 22.4 4.89 23.4 5.19 23.9 5.24 24.5 5.28
33 15.1 2.98 18.0 3.80 20.9 4.72 22.4 5.21 23.0 5.39 23.6 5.43 24.1 5.48
35 15.1 3.16 18.0 4.04 20.9 5.03 22.4 5.56 22.7 5.58 23.2 5.63 23.8 5.68
37 15.1 3.36 18.0 4.30 20.9 5.35 22.0 5.76 22.3 5.78 22.9 5.83 23.4 5.89
39 15.1 3.57 18.0 4.57 20.9 5.70 21.7 5.95 21.9 5.98 22.5 6.03 23.0 6.09

• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
• VRV®Systems • Outdoor Units
18
4 Capacity tables
4 - 2 Cooling capacity tables
3
RXYQ8P
3TW27232-1C
TC: Total capacity: kW; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacitry
index (kW)
Outdoor
air temp.
Indoor air temperature: °CWB
14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
°CDBTCPITCPITCPITCPITCPITCPITCPI
90 180
(20.16)
10 13.6 1.72 16.2 2.07 18.8 2.44 20.2 2.64 21.5 2.83 24.1 3.24 26.7 3.65
12 13.6 1.74 16.2 2.10 18.8 2.49 20.2 2.68 21.5 2.89 24.1 3.30 26.7 3.72
14 13.6 1.77 16.2 2.14 18.8 2.53 20.2 2.74 21.5 2.94 24.1 3.36 26.7 3.79
16 13.6 1.81 16.2 2.18 18.8 2.58 20.2 2.79 21.5 3.00 24.1 3.43 26.7 3.85
18 13.6 1.84 16.2 2.22 18.8 2.63 20.2 2.84 21.5 3.06 24.1 3.49 26.3 3.97
20 13.6 1.87 16.2 2.27 18.8 2.68 20.2 2.90 21.5 3.17 24.1 3.75 25.9 4.16
21 13.6 1.89 16.2 2.29 18.8 2.73 20.2 3.00 21.5 3.28 24.1 3.89 25.8 4.26
23 13.6 1.93 16.2 2.38 18.8 2.92 20.2 3.21 21.5 3.52 24.1 4.17 25.4 4.45
25 13.6 2.03 16.2 2.55 18.8 3.12 20.2 3.44 21.5 3.76 24.1 4.47 25.0 4.65
27 13.6 2.16 16.2 2.71 18.8 3.34 20.2 3.67 21.5 4.02 24.1 4.78 24.7 4.84
29 13.6 2.30 16.2 2.89 18.8 3.56 20.2 3.92 21.5 4.30 23.8 5.00 24.3 5.04
31 13.6 2.44 16.2 3.08 18.8 3.80 20.2 4.18 21.5 4.59 23.4 5.20 23.9 5.24
33 13.6 2.59 16.2 3.28 18.8 4.04 20.2 4.46 21.5 4.89 23.1 5.39 23.6 5.43
35 13.6 2.75 16.2 3.49 18.8 4.31 20.2 4.75 21.5 5.22 22.7 5.59 23.2 5.63
37 13.6 2.92 16.2 3.71 18.8 4.58 20.2 5.06 21.5 5.56 22.4 5.79 22.8 5.83
39 13.6 3.10 16.2 3.94 18.8 4.88 20.2 5.39 21.5 5.92 22.0 5.98 22.5 6.03
80 160
(17.92)
10 12.1 1.52 14.4 1.82 16.8 2.14 17.9 2.31 19.1 2.48 21.4 2.82 23.7 3.18
12 12.1 1.55 14.4 1.85 16.8 2.18 17.9 2.35 19.1 2.52 21.4 2.88 23.7 3.24
14 12.1 1.57 14.4 1.89 16.8 2.22 17.9 2.39 19.1 2.57 21.4 2.93 23.7 3.30
16 12.1 1.60 14.4 1.92 16.8 2.26 17.9 2.44 19.1 2.62 21.4 2.99 23.7 3.37
18 12.1 1.63 14.4 1.96 16.8 2.30 17.9 2.49 19.1 2.67 21.4 3.05 23.7 3.43
20 12.1 1.66 14.4 1.99 16.8 2.35 17.9 2.53 19.1 2.72 21.4 3.16 23.7 3.67
21 12.1 1.67 14.4 2.01 16.8 2.37 17.9 2.56 19.1 2.78 21.4 3.27 23.7 3.81
23 12.1 1.70 14.4 2.05 16.8 2.49 17.9 2.73 19.1 2.97 21.4 3.51 23.7 4.08
25 12.1 1.76 14.4 2.18 16.8 2.66 17.9 2.91 19.1 3.18 21.4 3.75 23.7 4.37
27 12.1 1.87 14.4 2.33 16.8 2.83 17.9 3.11 19.1 3.40 21.4 4.01 23.7 4.68
29 12.1 1.99 14.4 2.48 16.8 3.02 17.9 3.32 19.1 3.62 21.4 4.28 23.7 5.00
31 12.1 2.11 14.4 2.63 16.8 3.22 17.9 3.53 19.1 3.86 21.4 4.57 23.4 5.19
33 12.1 2.24 14.4 2.80 16.8 3.42 17.9 3.76 19.1 4.12 21.4 4.87 23.0 5.39
35 12.1 2.37 14.4 2.97 16.8 3.64 17.9 4.01 19.1 4.38 21.4 5.20 22.7 5.58
37 12.1 2.51 14.4 3.16 16.8 3.87 17.9 4.26 19.1 4.67 21.4 5.54 22.3 5.78
39 12.1 2.67 14.4 3.35 16.8 4.12 17.9 4.53 19.1 4.97 21.4 5.90 21.9 5.98
70 140
(15.68)
10 10.6 1.34 12.6 1.59 14.7 1.85 15.7 1.99 16.7 2.13 18.7 2.43 20.8 2.73
12 10.6 1.36 12.6 1.61 14.7 1.89 15.7 2.03 16.7 2.17 18.7 2.47 20.8 2.78
14 10.6 1.38 12.6 1.64 14.7 1.92 15.7 2.06 16.7 2.21 18.7 2.52 20.8 2.83
16 10.6 1.40 12.6 1.67 14.7 1.95 15.7 2.10 16.7 2.25 18.7 2.56 20.8 2.89
18 10.6 1.43 12.6 1.70 14.7 1.99 15.7 2.14 16.7 2.30 18.7 2.61 20.8 2.94
20 10.6 1.45 12.6 1.73 14.7 2.03 15.7 2.18 16.7 2.34 18.7 2.67 20.8 3.03
21 10.6 1.46 12.6 1.75 14.7 2.05 15.7 2.20 16.7 2.36 18.7 2.71 20.8 3.13
23 10.6 1.49 12.6 1.78 14.7 2.09 15.7 2.28 16.7 2.48 18.7 2.90 20.8 3.36
25 10.6 1.51 12.6 1.85 14.7 2.23 15.7 2.43 16.7 2.65 18.7 3.10 20.8 3.59
27 10.6 1.60 12.6 1.97 14.7 2.37 15.7 2.59 16.7 2.82 18.7 3.31 20.8 3.84
29 10.6 1.70 12.6 2.09 14.7 2.53 15.7 2.76 16.7 3.01 18.7 3.53 20.8 4.10
31 10.6 1.80 12.6 2.22 14.7 2.69 15.7 2.94 16.7 3.20 18.7 3.76 20.8 4.37
33 10.6 1.91 12.6 2.36 14.7 2.86 15.7 3.13 16.7 3.41 18.7 4.01 20.8 4.66
35 10.6 2.02 12.6 2.50 14.7 3.04 15.7 3.33 16.7 3.63 18.7 4.27 20.8 4.97
37 10.6 2.14 12.6 2.65 14.7 3.23 15.7 3.53 16.7 3.86 18.7 4.55 20.8 5.29
39 10.6 2.26 12.6 2.81 14.7 3.43 15.7 3.75 16.7 4.10 18.7 4.84 20.8 5.64
60 120
(13.44)
10 9.1 1.1610.81.3712.61.5813.41.6914.31.8116.12.0517.82.29
12 9.1 1.1810.81.3912.61.6113.41.7214.31.8416.12.0817.82.33
14 9.1 1.2010.81.4112.61.6313.41.7514.31.8716.12.1217.82.38
16 9.1 1.2210.81.4312.61.6613.41.7814.31.9016.12.1617.82.42
18 9.1 1.2310.81.4612.61.6913.41.8114.31.9416.12.2017.82.47
20 9.1 1.2510.81.4812.61.7213.41.8514.31.9816.12.2417.82.52
21 9.1 1.2610.81.4912.61.7413.41.8614.31.9916.12.2617.82.54
23 9.1 1.2810.81.5212.61.7713.41.9014.32.0316.12.3517.82.70
25 9.1 1.3110.81.5512.61.8413.42.0014.32.1616.12.5117.82.89
27 9.1 1.3510.81.6412.61.9613.42.1314.32.3016.12.6817.83.08
29 9.1 1.4310.81.7412.62.0813.42.2614.32.4516.12.8517.83.29
31 9.1 1.5210.81.8512.62.2113.42.4014.32.6116.13.0417.83.50
33 9.1 1.6110.81.9612.62.3513.42.5514.32.7716.13.2317.83.73
35 9.1 1.7010.82.0712.62.4913.42.7114.32.9416.13.4417.83.97
37 9.1 1.8010.82.2012.62.6413.42.8814.33.1216.13.6517.84.22
39 9.1 1.9010.82.3212.62.8013.43.0514.33.3216.13.8817.84.49
50 100
(11.20)
10 7.561.00 9.0 1.1610.51.3311.21.4111.91.5013.41.6914.81.88
12 7.561.01 9.0 1.1710.51.3511.21.4311.91.5313.41.7114.81.91
14 7.561.03 9.0 1.1910.51.3711.21.4611.91.5513.41.7414.81.95
16 7.561.04 9.0 1.2110.51.3911.21.4811.91.5813.41.7714.81.98
18 7.561.06 9.0 1.2310.51.4111.21.5111.91.6013.41.8114.82.02
20 7.561.07 9.0 1.2510.51.4311.21.5311.91.6313.41.8414.82.06
21 7.561.08 9.0 1.2610.51.4511.21.5511.91.6513.41.8614.82.07
23 7.561.09 9.0 1.2810.51.4711.21.5711.91.6813.41.8914.82.12
25 7.561.11 9.0 1.3010.51.5011.21.6111.91.7313.41.9914.82.26
27 7.561.13 9.0 1.3510.51.5811.21.7111.91.8413.42.1214.82.41
29 7.561.19 9.0 1.4310.51.6811.21.8111.91.9513.42.2514.82.57
31 7.561.26 9.0 1.5110.51.7811.21.9211.92.0713.42.3914.82.73
33 7.561.33 9.0 1.6010.51.8911.22.0411.92.2013.42.5414.82.91
35 7.561.41 9.0 1.6910.52.0011.22.1611.92.3313.42.7014.83.09
37 7.561.48 9.0 1.7810.52.1111.22.2911.92.4713.42.8614.83.28
39 7.561.56 9.0 1.8810.52.2411.22.4211.92.6213.43.0414.83.48

• VRV®Systems • Outdoor Units 19
• Outdoor Units • VRV®Heat Pump • RXYQ5-54P7W1B(A)
4 Capacity tables
4 - 2 Cooling capacity tables
3
RXYQ10P
3TW27232-1C
NOTES
1 The above table shows the average value of conditions which may occur.
2 When indoor models FXFQ20M and FXFQ25M and VKM-models are connected, the maximum connection ratio is 130%.
TC: Total capacity: kW; PI: Power Input: kW (compressor + outdoor fan motor)
Combination
(%)
Capacitry
index (kW)
Outdoor
air temp.
Indoor air temperature: °CWB
14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB
20.0DB 23.0DB 26.0DB 27.0DB 28.0DB 30.0DB 32.0DB
°CDBTCPITCPITCPITCPITCPITCPITCPI
130 325
(36.40)
10 24.6 3.42 29.3 4.18 34.0 4.97 35.3 5.08 35.7 4.98 36.6 4.77 37.5 4.55
12 24.6 3.48 29.3 4.26 34.0 5.07 34.8 5.05 35.3 4.95 36.1 4.73 37.0 4.66
14 24.6 3.55 29.3 4.34 33.9 5.13 34.4 5.03 34.8 4.92 35.7 4.88 36.6 4.93
16 24.6 3.61 29.3 4.43 33.5 5.11 33.9 5.07 34.3 5.09 35.2 5.14 36.1 5.19
18 24.6 3.68 29.3 4.52 33.0 5.30 33.4 5.33 33.9 5.36 34.8 5.41 35.7 5.46
20 24.6 3.76 29.3 4.81 32.5 5.56 33.0 5.59 33.4 5.62 34.3 5.67 35.2 5.73
21 24.6 3.86 29.3 4.98 32.3 5.69 32.8 5.72 33.2 5.75 34.1 5.81 35.0 5.86
23 24.6 4.14 29.3 5.34 31.9 5.95 32.3 5.98 32.7 6.01 33.6 6.07 34.5 6.13
25 24.6 4.42 29.3 5.72 31.4 6.21 31.8 6.24 32.3 6.28 33.2 6.34 34.1 6.40
27 24.6 4.72 29.3 6.12 31.0 6.47 31.4 6.51 31.8 6.54 32.7 6.61 33.6 6.68
29 24.6 5.04 29.3 6.54 30.5 6.73 30.9 6.77 31.4 6.81 32.3 6.88 33.2 6.95
31 24.6 5.38 29.2 6.92 30.0 7.00 30.5 7.04 30.9 7.07 31.8 7.15 32.7 7.23
33 24.6 5.73 28.7 7.18 29.6 7.26 30.0 7.30 30.5 7.34 31.4 7.42 32.2 7.50
35 24.6 6.11 28.2 7.44 29.1 7.53 29.6 7.57 30.0 7.61 30.9 7.70 31.8 7.78
37 24.6 6.50 27.8 7.71 28.7 7.80 29.1 7.84 29.6 7.89 30.4 7.98 31.3 8.07
39 24.6 6.92 27.3 7.97 28.2 8.06 28.7 8.11 29.1 8.16 30.0 8.25 30.9 8.35
120 300
(33.60)
10 22.7 3.12 27.0 3.81 31.4 4.53 33.6 4.90 35.2 5.11 36.0 4.91 36.8 4.72
12 22.7 3.18 27.0 3.88 31.4 4.62 33.6 4.99 34.7 5.08 35.5 4.89 36.3 4.69
14 22.7 3.24 27.0 3.96 31.4 4.71 33.6 5.09 34.2 5.05 35.1 4.86 35.9 4.89
16 22.7 3.30 27.0 4.04 31.4 4.80 33.4 5.13 33.8 5.06 34.6 5.11 35.4 5.15
18 22.7 3.36 27.0 4.12 31.4 4.96 32.9 5.30 33.3 5.32 34.1 5.37 35.0 5.42
20 22.7 3.43 27.0 4.28 31.4 5.34 32.5 5.56 32.9 5.58 33.7 5.63 34.5 5.68
21 22.7 3.46 27.0 4.43 31.4 5.53 32.2 5.69 32.6 5.71 33.5 5.76 34.3 5.82
23 22.7 3.70 27.0 4.75 31.4 5.92 31.8 5.94 32.2 5.97 33.0 6.03 33.8 6.08
25 22.7 3.95 27.0 5.08 30.9 6.18 31.3 6.20 31.7 6.23 32.6 6.29 33.4 6.35
27 22.7 4.22 27.0 5.43 30.5 6.43 30.9 6.47 31.3 6.50 32.1 6.56 32.9 6.62
29 22.7 4.50 27.0 5.80 30.0 6.69 30.4 6.73 30.8 6.76 31.6 6.83 32.5 6.89
31 22.7 4.80 27.0 6.19 29.5 6.96 30.0 6.99 30.4 7.03 31.2 7.10 32.0 7.17
33 22.7 5.11 27.0 6.60 29.1 7.22 29.5 7.26 29.9 7.29 30.7 7.37 31.5 7.44
35 22.7 5.44 27.0 7.04 28.6 7.48 29.0 7.52 29.5 7.56 30.3 7.64 31.1 7.72
37 22.7 5.79 27.0 7.50 28.2 7.75 28.6 7.79 29.0 7.83 29.8 7.91 30.6 8.00
39 22.7 6.16 26.9 7.92 27.7 8.01 28.1 8.06 28.5 8.10 29.4 8.19 30.2 8.27
110 275
(30.80)
10 20.8 2.83 24.8 3.45 28.8 4.10 30.8 4.43 32.8 4.77 35.3 5.06 36.1 4.89
12 20.8 2.89 24.8 3.52 28.8 4.18 30.8 4.52 32.8 4.86 34.9 5.04 35.6 4.86
14 20.8 2.94 24.8 3.58 28.8 4.26 30.8 4.60 32.8 4.95 34.4 5.01 35.2 4.85
16 20.8 2.99 24.8 3.65 28.8 4.34 30.8 4.69 32.8 5.05 34.0 5.07 34.7 5.12
18 20.8 3.05 24.8 3.72 28.8 4.43 30.8 4.82 32.8 5.29 33.5 5.33 34.3 5.38
20 20.8 3.11 24.8 3.80 28.8 4.69 30.8 5.18 32.3 5.55 33.1 5.59 33.8 5.64
21 20.8 3.14 24.8 3.91 28.8 4.86 30.8 5.37 32.1 5.68 32.8 5.72 33.6 5.77
23 20.8 3.29 24.8 4.19 28.8 5.21 30.8 5.76 31.6 5.93 32.4 5.99 33.1 6.04
25 20.8 3.51 24.8 4.48 28.8 5.57 30.8 6.17 31.2 6.19 31.9 6.25 32.7 6.30
27 20.8 3.74 24.8 4.79 28.8 5.96 30.3 6.43 30.7 6.45 31.5 6.51 32.2 6.57
29 20.8 3.99 24.8 5.11 28.8 6.37 29.9 6.69 30.3 6.72 31.0 6.78 31.8 6.84
31 20.8 4.25 24.8 5.45 28.8 6.80 29.4 6.95 29.8 6.98 30.6 7.04 31.3 7.11
33 20.8 4.52 24.8 5.81 28.6 7.17 29.0 7.21 29.4 7.24 30.1 7.31 30.9 7.38
35 20.8 4.81 24.8 6.19 28.1 7.43 28.5 7.47 28.9 7.51 29.6 7.58 30.4 7.65
37 20.8 5.12 24.8 6.59 27.7 7.70 28.1 7.73 28.4 7.77 29.2 7.85 29.9 7.92
39 20.8 5.44 24.8 7.02 27.2 7.96 27.6 8.00 28.0 8.04 28.7 8.12 29.5 8.20
100 250
(28.00)
10 18.9 2.56 22.5 3.10 26.2 3.67 28.0 3.97 29.8 4.27 33.5 4.88 35.4 5.05
12 18.9 2.60 22.5 3.16 26.2 3.74 28.0 4.04 29.8 4.35 33.5 4.97 34.9 5.02
14 18.9 2.65 22.5 3.22 26.2 3.81 28.0 4.12 29.8 4.43 33.5 5.07 34.5 4.99
16 18.9 2.70 22.5 3.28 26.2 3.89 28.0 4.20 29.8 4.52 33.3 5.13 34.0 5.08
18 18.9 2.75 22.5 3.34 26.2 3.96 28.0 4.28 29.8 4.61 32.9 5.30 33.6 5.34
20 18.9 2.80 22.5 3.41 26.2 4.08 28.0 4.50 29.8 4.94 32.4 5.55 33.1 5.60
21 18.9 2.83 22.5 3.44 26.2 4.23 28.0 4.66 29.8 5.11 32.2 5.68 32.9 5.73
23 18.9 2.90 22.5 3.67 26.2 4.53 28.0 4.99 29.8 5.48 31.8 5.94 32.4 5.99
25 18.9 3.09 22.5 3.92 26.2 4.85 28.0 5.35 29.8 5.87 31.3 6.20 32.0 6.25
27 18.9 3.30 22.5 4.18 26.2 5.18 28.0 5.72 29.8 6.28 30.8 6.46 31.5 6.52
29 18.9 3.51 22.5 4.46 26.2 5.53 28.0 6.11 29.7 6.67 30.4 6.73 31.1 6.78
31 18.9 3.74 22.5 4.76 26.2 5.90 28.0 6.52 29.3 6.93 29.9 6.99 30.6 7.05
33 18.9 3.97 22.5 5.07 26.2 6.29 28.0 6.96 28.8 7.19 29.5 7.25 30.2 7.32
35 18.9 4.22 22.5 5.39 26.2 6.71 28.0 7.42 28.3 7.45 29.0 7.52 29.7 7.58
37 18.9 4.49 22.5 5.74 26.2 7.15 27.5 7.68 27.9 7.72 28.6 7.79 29.2 7.85
39 18.9 4.77 22.5 6.10 26.2 7.61 27.1 7.94 27.4 7.98 28.1 8.05 28.8 8.13
