Daktronics TI-2022 User manual

201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
TI-2022
PORTABLE LED TIMER
DISPLAY MANUAL
P1153
ED-13736
Rev 06
13 December 2019

Copyright © 2003-2019
All rights reserved. While every precaution has been taken in the preparation of this manual, the publisher assumes no
responsibility for errors or omissions. No part of this book covered by the copyrights hereon may be reproduced or copied
in any form or by any means—graphic, electronic, or mechanical, including photocopying, taping, or information
storage and retrieval systems—without written permission of the publisher.
Daktronics trademarks are property of Daktronics, Inc. All other trademarks are property of their respective companies.
FCC Statement
Supplier Declaration of Conformity (SDoC)
This product complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference when the equipment is operated
in a commercial environment. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications. Operation of
this equipment in a residential area is likely to cause
harmful interference in which case the user will be
required to correct the interference at their own
expense.
Warning: The user is cautioned that changes and
modications made to the equipment without the
approval of manufacturer could void the user’s
authority to operate this equipment.
Industry Canada Regulatory Information
This Class A digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe A est conforme à
la norme NMB-003 du Canada.
Inquiries
Contact Daktronics with any questions regarding our
product compliance.
Mail:
Daktronics
201 Daktronics Dr.
Brookings, SD 57006 USA
Phone:
800-325-8766
Website:
www.daktronics.com

– i –
Table of Contents
1 Introduction���������������������������������������������������������������������������������������������������������������������������1
Important Safety Instructions...............................................................................................................1
Specications Label .............................................................................................................................2
Resources ..............................................................................................................................................2
Daktronics Nomenclature ...................................................................................................................2
Display Overview ..................................................................................................................................3
Product Safety Approval .....................................................................................................................3
2 Mechanical Installation �������������������������������������������������������������������������������������������������������4
Wall Mounting .......................................................................................................................................4
Tripod Mounting....................................................................................................................................5
3 Electrical Installation ������������������������������������������������������������������������������������������������������������6
Power .....................................................................................................................................................6
Auto Off ���������������������������������������������������������������������������������������������������������������������������������������������6
Wired Signal Connection.....................................................................................................................7
Wireless Signal Connection .................................................................................................................7
Radio Settings �����������������������������������������������������������������������������������������������������������������������������������9
4 Controls & Timing Functions�����������������������������������������������������������������������������������������������10
System Setup.......................................................................................................................................10
Program Selection ..............................................................................................................................10
Program Operations...........................................................................................................................11
5 Display Maintenance���������������������������������������������������������������������������������������������������������13
Display Components..........................................................................................................................13
Replacing the Digit/Driver Printed Circuit Board ............................................................................14
Replacing Batteries ............................................................................................................................14
Schematics..........................................................................................................................................15
Replacement Parts.............................................................................................................................15
6 Daktronics Exchange and Repair & Return Programs ����������������������������������������������������16
Exchange Program ............................................................................................................................16
Repair & Return Program...................................................................................................................17
Daktronics Warranty & Limitation of Liability ...................................................................................17
A Reference Drawings �����������������������������������������������������������������������������������������������������������19
B Daktronics Warranty & Limitation of Liability��������������������������������������������������������������������23

This page intentionally left blank.

Introduction
1
1 Introduction
This manual explains the installation and maintenance of Daktronics TI-2022 portable
timing display. For additional information regarding safety, installation, operation, or
service, refer to the telephone numbers listed in Section 6: Daktronics Exchange and
Repair & Return Programs (p�16). This manual is not specic to a particular installation.
Project-specic information takes precedence over general information found in this
manual.
Important Safety Instructions
• Read and understand all instructions before using the display.
• Do not drop the device or immerse it in water.
• This device may be used outdoors temporarily, but it is not to be permanently
mounted outdoors or left in wet weather.
• This device shall not be exposed to dripping or splashing, and no objects lled with
liquid shall be placed upon it.
WARNING! To reduce the risk of re or electric shock, do not expose this device to rain
or moisture.
• Operate the device with the built-in rechargeable battery. A completely charged
battery will provide at least 10 hours of operation. Use 120 V power only when the
battery’s power is low.
CAUTION! DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED.
REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE.
WARNING! Do not expose batteries to excessive heat, such as direct sunlight or open
re.
• Do not run the display’s battery dead. Charge it for 24 hours before putting it away.
• Do not let the power cord touch hot surfaces or hang over the edge of a table,
which could damage or cut the cord.
• If an extension cord is necessary, use a three-pronged polarized cord. Arrange the
cord with care so that no one will trip over or pull it out.
• Before using an extension cord, inspect the cable thoroughly and verify its
compliance with the local electric codes.
• Always turn off and unplug the control equipment when it is not in use.
• Never yank the power cord to pull the plug from the outlet. Grasp the plug and pull
to disconnect.
• To avoid electrical shock, do not disassemble the control equipment or the driver
modules. Incorrect reassembly can cause electric shock and faulty operation or
permanent damage to the circuits.
WARNING! To prevent injury, the display must be securely attached to a wall in
accordance with installation instructions.

Introduction
2
Specications Label
Power specications as well as serial and model number information can be found on an
ID label on the display, similar to the one shown in Figure 1.
DAKTRONICS 201 DAKTRONICS DR. BROOKINGS, SD PHONE [phone]
SUITABLE FOR SERVICING ONLY WHEN DE-ENERGIZED
PUET FAIRE L'OBJET D'UN ENTRETIEN UNIQUEMENT S'IL EST HORS TENSION
LL-4284957
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION
Figure 1: Specications Label
Please have the assembly number, model number, and the date manufactured on hand
when calling Daktronics customer service to ensure the request is serviced as quickly as
possible. Knowing the facility name and/or job number will also be helpful.
Resources
Figure 2 illustrates a Daktronics drawing label.
This manual refers to drawings by listing the last
set of digits. In the example, the drawing would
be referred to as DWG-1007804. All references to
drawing numbers, appendices, gures, or other
manuals are presented in bold typeface.
Any drawings referenced in a section are listed
at the beginning of it as shown below:
Reference Drawing:
System Riser Diagram....................................................................................... DWG-1007804
Daktronics identies manuals by the DD or ED number located on the cover page.
Daktronics Nomenclature
Most display components have a white label that lists the part
number (Figure 3). Part numbers will also appear on certain drawings.
If a component is not found in the Replacement Parts (p�15), use
the label to order a replacement. Refer to Section 6: Daktronics
Exchange and Repair & Return Programs (p�16) if replacing or
repairing any display component.
Main Component Labels
Part Type Part Number
Individual circuit board 0P-XXXX-XXXX
Assembly; a collection of
circuit boards 0A-XXXX-XXXX
Wire or cable W-XXXX
Fuse F-XXXX
Transformer T-XXXX
Metal part 0M-XXXXXXX
Fabricated metal assembly 0S-XXXXXX
Specially ordered part PR-XXXXX-X
Drawing Number
Figure 2: Drawing Label
0P-1127-0024
SN: 2465
02/19/12 Rev. 1
Figure 3: Part Label
Accessory Labels
Component Label
Termination block for
power or signal cable TBXX
Grounding point EXX
Power or signal jack JXX
Power or signal plug for
the opposite jack PXX

Introduction
3
Display Overview
The TI-2022 is a portable timing system with 9 programmable functions. Though external
power and signal can be applied, the control and power systems are entirely self-
contained. Refer to Section 4: Controls & Timing Functions (p�10) for descriptions of the
TI-2022 control capabilities.
Manufactured in two models, the outdoor version of the timing display is designated as
TI-2022-11, while the indoor unit is designated TI-2022-13.
The timing display is powered by 12 V batteries. Detachable power cord/transformer
assemblies also permit operation of the TI-2022 with 120 or 240 VAC. The unit draws 1
Amp of power. The enclosed batteries (two in the outdoor model and one in the indoor
model) are rechargeable and have a built-in charger.
Product Safety Approval
Both models of the TI-2022 are ETL-listed and tested to CSA standards for indoor use.
Contact Daktronics with any questions regarding the testing procedures.

Mechanical Installation
4
2 Mechanical Installation
This section describes the mounting details of the TI-2022. Use this section when mounting
a display to a wall or on the tripod kit. Other mounting methods can be used, but
Daktronics engineers do not recommend those not documented here. Daktronics is not
responsible for mounting the display.
Note: Daktronics assumes no liability for any installation derived from the information
provided in this manual or installations designed and installed by others.
Wall Mounting
The TI-2022 mounts to a wall using an optional mounting bracket (Daktronics part #
0M-173125). This bracket then attaches to two wall anchors. A qualied engineer must
specify the anchor type according to national and local building codes.
Note: Do not attempt to permanently suspend the TI-2022 by its carrying handle.
Also, do not permanently mount outdoor displays or leave in wet weather.
Before beginning installation, place the bracket against the mounting surface, level it,
and then mark the surface through the anchor holes on the bracket with a marker or
heavy pencil. Drill holes in the wall and install anchors at the marked locations. Minimum
steel anchor size is 3/16" diameter (4.7 mm).
Note: Due to the variety of wall materials used in sports facilities, Daktronics cannot
anticipate every user’s installation needs or provide mounting hardware suitable
for every installation. Choose a method of installation that will safely support the
display’s weight.
Refer to Figure 4 for display mounting instructions:
Wall Mounting Bracket
(0M-173125)
1. Mount the bracket to
the wall.
2. Loosen 4 screws on
sides of display, slip
them into slots on
bracket, and re-tighten.
Figure 4: Wall Mounting Kit Installation

Mechanical Installation
5
Tripod Mounting
Mounting the display to a tripod requires the optional tripod mounting kit (Daktronics part
# 0A-1153-0325). A camera tripod is not sturdy enough to safely support the display and
will not attach to the display or adapter plate. An appropriate “speaker stand” tripod is
available from Daktronics (part # A-1580).
Refer to Figure 5 for instructions on preparing the display for mounting:
1. Remove rubber bumpers
from bottom of display.
2. Push in and discard 2
bottom knockouts.
3. Attach tripod adapter plate
using bumpers and screws.
4. Install knob, nut, and washer
on the tripod adaptor.
5. Attach tripod bracket to adaptor
plate using O-rings and T-bolts.
Bumper (HE-1080)
Tripod Adaptor Plate
(0S-1153-0036)
Screw (HC-1489)
Bumper (HE-1080)
Screw (HC-1489)
Tripod Bracket
(HS-1306)
T-bolt
(HS-1315)
Washer
Knob
O-ring Nut
Figure 5: Tripod Mounting Kit Installation

Electrical Installation
6
3 Electrical Installation
Power
The TI-2022 contains internal batteries for power but can receive external power through
a detachable transformer cord (Figure 6).
120 or
240 VAC
Power Supply Kit:
120 VAC (0A-1240-0071)
240 VAC (0A-1240-0072)
12 V IN
Figure 6: Transformer Connection
The primary purpose of the transformer is to charge the internal battery, but the display
can still be operated while the battery is charging. The transformer and cord can remain
plugged into the power source indenitely with no damage to the timer or its battery.
The indoor version (TI-2022-13) has one battery, while the outdoor version (TI-2022-11)
has two batteries. On a full charge, each battery should last approximately 10 hours
before recharge is necessary. To recharge the system, simply plug the power cable into
a grounded power receptacle. The recharging unit will not overcharge the batteries.
Indicator lights on the side control panel show when the unit is charging and when it is
fully charged (refer to Figure 11).
Auto Off
The TI-2022 features an Auto Off function, which will automatically turn the unit off in
response to two conditions:
1� Idle Timeout – If the display is not plugged into a transformer, and not in program
8 or 9 (time of day), and has been idle for 1 hour (not counting, no switch activity,
no signal input), the display will sound the horn and ash the digits 10 times before
turning itself off. Pressing any switch will reset the one hour timer.
2� Low Battery – This feature prevents the TI-2022 from running its battery completely
dead and damaging the battery. When the battery has dropped below a minimum
level, the unit will begin sounding the horn once per second as a warning. If the unit is
not plugged into the transformer for recharging within about one minute, the unit will
automatically turn off.
To turn the TI-2022 back on after an Auto Off has occurred, turn the power switch off,
wait a few minutes, and then turn it back on. In the case of a low battery, be sure to plug
the display into a charger before continuing use.

Electrical Installation
7
Wired Signal Connection
The TI-2022 is designed as a standalone timer with no need for signal cable from control
consoles. However, it is still possible to connect signal in from Daktronics All Sport®scoring
consoles and OmniSport®2000 timing consoles, and signal out to multiple displays. For
signal cable, Daktronics recommends, as a minimum, single-pair, shielded cable, 22
AWG (Daktronics part # W-1077). Two-pair shielded cable (part # W-1614) is preferred.
Wireless Signal Connection
The TI-2022 is capable of being controlled via wireless signal. The wireless radio system
requires a Daktronics All Sport®scoring console or OmniSport®2000 timing console
equipped with radio transmitter as well as a radio receiver mounted inside the display.
The optional radio receiver is installed on the left side of the display cabinet (as viewed
from the front).
1� Power off the display.
2� Turn the display around so that you are looking at the rear.
3� Using a Phillips screwdriver, remove the 10 outer screws to separate the front and rear
panels of the display.
4� CAREFULLY lay the front panel at to expose the internal components.
5� Connect the 6-pin power/signal cable from the radio receiver unit (A) into the mating
6-pin radio adapter cable (B) connected to the J2 RADIO JACK on the left side of the
driver printed circuit board (PCB). Refer to Figure 7.
Figure 7: Radio Connection

Electrical Installation
8
6� Remove the plastic strips from the adhesive-backed hook-and-loop fasteners on
the back of the radio receiver unit, and stick the unit to the inside right side of the
cabinet. Note that the radio receiver unit will be upside down. Refer to Figure 8.
Figure 8: Radio Mounting
7� Route the brass antenna connector through the “D” hole in the side of the display
cabinet. Slip on the washer and nut on the outside of the display, and then tighten
the nut using a 5/16 wrench. Screw the black antenna onto the brass connector.
Refer to Figure 9.
Figure 9: Radio Antenna
8� CAREFULLY close the front and rear panels. Ensure that no wires are pinched
between the metal panels.
9� Reinsert/tighten the 10 Phillips screws.
10� During operation, ensure the radio antenna stays pointed straight up.
For more information about the wireless radio control option, refer to the Gen VI Radio
Installation Manual (DD2362277), provided with the receiver unit and available online at
www.daktronics.com/manuals.

Electrical Installation
9
Radio Settings
With a radio receiver installed in the display, watch for the radio Broadcast settings (“b1”)
and Channel settings (“C1”) during the Power-On Self Test (POST).
These values must match the settings in the control console:
If the radio receiver channel and broadcast settings match those set in the console but
the console does not control the display, there may be radio interference. This can occur
when a nearby display also uses radio control. In this case, change the settings of the
wireless radio receiver inside the display and in the console as described in the radio
control manuals.
RADIO SETTINGS
BCAST 1 CHAN 01

Controls & Timing Functions
10
4 Controls & Timing Functions
System Setup
System setup information for each of the programs is shown in Figure 10. This chart is also
printed on a vinyl quick reference decal on the rear of the display case.
START
STOP
START START
START START/STOP
STOP
STOP
START START
STOP
STOP
SIGNAL IN
Optional All Sport
Control Console
Count Up With Pushbuttons1
Game Clock4 Qualifying Timer5 Flop Clock6
Lap Counter7
Time Of Day8 9
Count Up With Photocells2 Agility Timer3
Figure 10: TI-2022 Programs and System Connections
Program Selection
The TI-2022 display is programmable for 9 different timing
programs. The operator selects each program and
makes settings for the functions using the switches on
the right side of the display. Figure 11 shows the TI-2022
control panel and programming connections.
To select a program:
1� Press and hold <RESET> for 2 seconds. The display will
show PR## (program number) and then the preset
time.
2� While holding <RESET>, press and release <HORN>
to increment the program number by one. Program
numbers are as follows:
1) Count Up w/ Pushbuttons
2) Count Up w/ Photocells
3) Agility Timer
4) Game Clock
5) Qualifying Timer
6) Flop Clock
7) Lap Counter
8) 12-hour Time of Day
9) 24-hour Time of Day
Note: Refer to Program Operations (p�11) for more information about each program.
TI-2022
AUX.
POWER
RESET
(SHIFT)
HORN
(INCREMENT PROG. #)
STOP
(INCREMENT MINUTES)
(INCREMENT HOURS)
START
OFF
ON
12V IN
SIGNAL OUT
SIGNAL IN
STATUS
BATTERY
CHARGE
LOW
FULL
PORT
DAKTRONICS
R
Figure 11: Control Panel

Controls & Timing Functions
11
To modify the preset time for programs 1, 2, 4, and 6:
1� Press and hold <RESET> for 2 seconds. The display will show PR## (program number)
and then the preset time.
2� While holding <RESET>, press <START> to increment minutes and press <STOP> to
increment seconds.
3� Release <RESET> to save the time. The display will count up to or down from that time,
depending on the selected program.
To set the time of day for programs 8 and 9:
1� Press and hold <RESET> for 2 seconds. The display will show PR## (program number)
and then the preset time.
2� While holding <RESET>, press <START> to increment hours and press <STOP> to
increment minutes.
3� Release <RESET> to save the Time of Day.
Program Operations
1� Count Up with Pushbuttons� This program counts up from 0 to a programmed time
and sounds the horn. Operators can program the time from 0 to 99:59 (mn:sc) using
the switches on the side of the display. If the time is set to 0:00, the display will count
up to 59:59, roll over to 0:00, and continue counting.
In this program, the time can be started and stopped using the switches on the side,
or external, normally open contacts. If a stop input is received within 9.99 seconds
before the start, the display will show a -XX.X time on the digits for 10 seconds
following the start and then will resume counting. While the display is counting, a start
input will hold the elapsed time for 10 seconds and then go back to the running time.
2� Count Up with Photocells. This program counts up from 0 to a programmed time and
sounds the horn. The operator can program the time from 0 to 99:59 (mn:sc) using the
switches on the side of the display. If the time is set to 0:00, the display will count up to
59:59, roll over to 0:00, and continue counting.
In this program, the start and stop inputs are typically external, normally closed
contacts. If the stop input is received within 9.99 seconds before the start, the display
will show a -X.XX time on the digits for 10 seconds following the start and then will
resume counting. While the display is counting, a start input will hold the elapsed time
for 10 seconds and then go back to the running time.
3� Agility Timer. This program is used to time events with a unique start and stop. These
events typically last less than 99.99 seconds; if the timer reaches 99.99, it will roll over
to 0.00 and continue counting. Unlike programs 1 and 2, once the timer is stopped, a
start input will not cause it to begin counting again.
4� Game Clock. This program counts down to 0 from a programmed time and sounds a
horn. The operator can program the time using the switches on the side of the display
from 0 to 99:59 (mn:sc). If the time is set to 0:00, the display will count down to 0:00,
roll over to 59:59, and continue counting down.
5� Qualifying Timer. This program utilizes one photocell plugged into the START input to
qualify oval track. Timing range is from 0 to 99.99 seconds.
Pressing the <RESET> switch will set the display to 0.0 seconds and clear the best time.
With a photocell connected to the START input, the rst car that passes through the
photocell will start the clock counting. The timer will then ignore the photocell for 3
seconds to ensure that the car has completely passed through the Start/Finish line.

Controls & Timing Functions
12
The next time the car passes through the photocell, the clock will display the current
lap time for 10 seconds. Again, the clock will ignore the photocell for 3 seconds to
ensure that the car has passed completely through the Start/Finish line. The internal
clock also restarts at 0 and counts the time for the next lap. After the previous lap
has displayed for 10 seconds, the digits will show the new lap time. The next time a
car passes through the photocells, the time will freeze for 10 seconds and repeat the
cycle. This may be repeated for however many qualifying laps that a car will make.
When the car has completed its qualifying run, press the <STOP> switch on the side
of the display, and the best lap time will be displayed on the digits. The qualifying
sequence for the next driver will start the next time a car passes through the
photocells.
6� Flop Clock. This mode counts up in one-second increments to 9999, rolls over to 0,
and continues counting.
7� Lap Counter. This program uses the <START> switch to increment the display by one
from 1 to 9999. The <STOP> switch decrements the count by one.
8� 12-Hour Time of Day. This program displays the time of day in 12-hour format.
9� 24-Hour Time of Day. This program displays the time of day in 24-hour format.
Note: An All Sport control console or an OmniSport timing console can be connected
to the TI-2022 to control it, but the TI-2022 system is then limited to being an output
device rather than the self-contained timing system for which it was designed.

Display Maintenance
13
5 Display Maintenance
Disconnect power before doing any repair or maintenance work on the display�
Permit only qualied service personnel to access internal display electronics.
Disconnect power when not using the display�
Display Components
The TI-2022 uses a single printed circuit board (PCB) that contains all of the electronics
needed to make this system work: digit LEDs, control processors, power input connectors,
horn, and other components. All switches, power systems, and input/output terminations
are connected to the PCB.
As shown in Figure 12, the PCB is attached to the front panel of the display. Refer to
Replacing the Digit/Driver Printed Circuit Board (p.14) for instructions on accessing and
replacing the PCB.
Screw
(HC-1489)
Battery
(BT-1014)
8-32 Nut
(HC-1354)
Nut securing
signal jack
Printed Circuit Board
(Indoor: 0P-1153-0001)
(Outdoor: 0P-1153-0003)
Rear
Panel
Front Panel
Spacer
(HE-1357)
Printed Circuit Board
(Indoor: 0P-1153-0002)
(Outdoor: 0P-1153-0004)
Figure 12: TI-2022 Exploded View

Display Maintenance
14
Replacing the Digit/Driver Printed Circuit Board
1� To access the digit/driver PCB, remove the 10 outer screws to separate the front and
back panels of the display.
2� Disconnect all plugs from the PCB by squeezing together the locking tabs and pulling
the connectors free. It may be helpful to label the cables or take a picture to know
which plug goes to which jack when connecting the replacement PCB.
3� Remove the 8 nuts securing the PCB to the front panel of the display. Take note of
the orientation of the PCB for future reference.
4� Carefully remove the PCB from the studs and spacers on the front panel. Use an even
force to prevent any damage that might result from bending the LEDs or connector
pins on the board.
5� Position the new PCB over the studs, making sure there are spacers between the front
panel and circuit board.
6� Tighten the 8 nuts.
7� Reconnect all plugs to their mating jacks on the PCB. The connectors are keyed and
will attach in one way only. Do not force the connections.
8� Close and secure the back panel with 10 screws, then power on and test the display
to verify the issue has been resolved.
Replacing Batteries
CAUTION! DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED� REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE�
CAUTION: Do not allow any metal object, including jewelry, to contact the battery
terminal – a short-circuit on a battery can produce very high current, causing equipment
damage or severe burns!
To remove and replace a battery, refer to Figure 13 and follow these steps:
1� Remove the 10 outer screws to separate the front and back panels of the display.
2� Disconnect the power leads from the terminals.
3� Remove the 4 nuts securing the battery bracket.
4� Remove and replace the battery.
5� Reconnect the power leads to the terminals of the new battery exactly as follows:
RED to the POSITIVE terminal, BLACK to the NEGATIVE terminal.
6� Tighten the 4 nuts to secure the battery bracket.
7� Close and secure the back panel with 10 screws, then power on and test the display.
Do not throw old battery in trash. The battery contains lead and should be recycled.
WARNING! Do not expose batteries to excessive heat, such as direct sunlight or open re.

Display Maintenance
15
IMPORTANT
CONNECT RED WIRE TO POSITIVE (+) TERMINAL.
CONNECT BLACK WIRE TO NEGATIVE (-) TERMINAL.
IF CONNECTED OTHERWISE, THE DISPLAY W ILL NOT WORK PROPERLY AND MAY
DAMAGE COMPONENTS OR CAUSE INJURY.
IMPORTANT
CONNECT RED WIRE TO POSITIVE (+) TERMINAL.
CONNECT BLACK WIRE TO NEGATIVE (-) TERMINAL.
IF CONNECTED OTHERWISE, THE DISPLAY W ILL NOT WORK PROPERLY AND MAY
DAMAGE COMPONENTS OR CAUSE INJURY.
Terminals
Battery
(BT-1014) Bracket
Bracket
Nut
Side View Front View of Back Panel
(Indoor Model)
Front View of Back Panel
(Outdoor Model)
Figure 13: Battery Access
Schematics
For advanced troubleshooting and repair, it may be necessary to consult the schematic
drawing. DWG-177466 shows detailed power and signal wiring diagrams of internal
display components.
Replacement Parts
The following table contains display components that may require replacement. Many of
the other display components will have attached part number labels.
Description Part Number
Tripod Mounting Kit 0A-1153-0325
Power Supply Kit; 120VAC 0A-1240-0071
Power Supply Kit; 240VAC 0A-1240-0072
Wall Mounting Bracket 0M-173125
Indoor PCB 0P-1153-0002
Outdoor PCB 0P-1153-0004
Tripod, Speaker Stand Type A-1580
Battery, 12V 7.2 AH sealed lead-acid BT-1014
12 V Buzzer DS-1487
5-pin to 6-pin Radio Adapter W-2913
Refer to Section 6: Daktronics Exchange and Repair & Return Programs (p�16) for
information on exchanging or returning parts.

Daktronics Exchange and Repair & Return Programs
16
6 Daktronics Exchange and Repair & Return
Programs
Exchange Program
The Daktronics Exchange Program is a service for quickly replacing key components
in need of repair. If a component fails, Daktronics sends a replacement part to the
customer who, in turn, returns the failed component to Daktronics. This decreases
equipment downtime. Customers who follow the program guidelines explained below
will receive this service.
Before contacting Daktronics, identify these important numbers:
Display Serial Number: ________________________________________________________________
Display Model Number: _______________________________________________________________
Job/Contract Number: _______________________________________________________________
Date Manufactured/Installed: _________________________________________________________
Daktronics Customer ID Number: ______________________________________________________
To participate in the Exchange Program, follow these steps:
1� Call Daktronics Customer Service.
Market Description Customer Service Number
Schools (including community/junior colleges), religious
organizations, municipal clubs, and community centers
877-605-1115
Fax: [phone]
Universities and professional sporting events, live events for
auditoriums, and arenas
866-343-6018
Fax: [phone]
2� When the new exchange part is received, mail the old part to Daktronics.
If the replacement part xes the problem, send in the problem part being replaced.
a� Package the old part in the same shipping materials in which the replacement
part arrived.
b� Fill out and attach the enclosed UPS shipping document.
c� Ship the part to Daktronics.
3� The defective or unused parts must be returned to Daktronics within 5 weeks of initial
order shipment�
If any part is not returned within ve (5) weeks, a non-refundable invoice will be
presented to the customer for the costs of replenishing the exchange parts inventory
with a new part. Daktronics reserves the right to refuse parts that have been
damaged due to acts of nature or causes other than normal wear and tear.
