Dali OBERON C SOUND HUB COMPACT User manual

SOUND HUB COMPACT
Diagnostics Mode and Manual Channel Selection
The DALI wireless speaker systems are designed to work seamlessly out the box, and for the majori of cases the default
factory seings will ensure a plug and play experience.
However, In homes and environments busy with technology it is sometimes possible for the DALI SOUND HUB COMPACT
temporarily to lose the connection with the speakers when the wireless channel in use becomes congested. You may notice
your music repeatedly drops-out for a moment as the wireless connection automatically switches to an alternative channel.
The first potential solution to this problem is to ensure that any unused wireless equipment nearby is switched o. Even
when in standby or sleep mode, some wireless equipment will still broadcast a signal and consume bandwidth, so if it is
unused, it is best fully Switched o.
If however you still experience occasional drop-outs, you can reconfigure your SOUND HUB COMPACT to remain
connected via a fixed Wireless channel rather than switching channels automatically. This will prompt other wireless
equipment in your home automatically to switch to alternative channels and release more bandwidth for your wireless DALI
system.
To manually configure your SOUND HUB COMPACT to use a fixed wireless channel, follow the Steps described on the
folowing pages.
1

Print color: MOTIP 51077
Print color: MOTIP 51077
2
3
4
56
1
9
108
>10
sec.
Use volume
UP/DOWN buons
on remote control
to toggle and select
channel.
5.8GHz Ch.3
LED 6+ 9
5.8GHz Ch.2
LED 5+ 9
5.8GHz Ch.1
LED 4+ 9
5.2GHz Ch.3
LED 3+ 9
5.2GHz Ch.2
LED 2+ 9
5.2GHz Ch.1
LED 1+ 9
Auto Channel:
LED 9turns o
Press the LINK & CONNECT
buon on the SOUND HUB
COMPACT >10 seconds.
LED 8& 10 turned
ON indicates wireless
Diagnostics mode
selected.
LED 9: Indicates
fixed channel select
enabled.
SOUND HUB COMPACT Diagnostics Mode and Manual Channel Selection
2

SOUND HUB COMPACT Diagnostics Mode and Manual Channel Selection
Wireless Diagnostic mode:
1. With the music still playing, press and hold the SOUND HUB
COMPACT Link & Connect buon for 10 seconds then release it.
This will launch the SOUND HUB COMPACT wireless diagnostic
mode, where it is possible to read the wireless channel and
manually select a channel.
2. The SOUND HUB COMPACT top panel LED indicators 8 and 10
will now illuminate as will one of indicators 1 to 6.
Indicators 8 + 10 indicates the wireless diagnostics mode
whereas Indicators 1 to 6 indicate which of the six possible
wireless channels is in use.
If the Indicator 1 to 6 changes every few seconds, this reveals
that the wireless environment is congested and the SOUND
HUB COMPACT is jumping channels.
3. A fixed wireless channel can now be selected by using the
SOUND HUB COMPACT remote control Volume Up and Volume
Down buons. The selected channel indicator, 1 to 6 ,will flash for
a short time then switch to continuous illumination. Indicator 9 will
also illuminate to indicate “fixed channel mode”
4. Exit the wireless diagnostic mode again by pressing the SOUND
HUB COMPACT Link & Connect buon.
NOTES:
In order to identi the best channel, select each one in turn and leave
the music playing for a couple of minutes. Nearby wireless equipment
with auto channel switching enabled will vacate the selected SOUND
HUB COMPACT channel. Once you have tried each channel for a minute
or two you will have an idea which one is the least prone to interference.
If you wish to return the SOUND HUB COMPACT to auto channel
selection, press the Link & Connect buon for 10 seconds to re-enter
wireless Diagnostic mode. Now press the SOUND HUB COMPACT
remote control Volume Up/down buon until indicators 1 to 6 all flash
and indicator 9 switched o, this indicates Auto mode.
Press the Link & Connect buon to exit wireless channel setup mode.
Reseing the SOUND HUB COMPACT using its rear panel pin-hole
buon will also return it to auto channel selection mode.

The SOUND HUB COMPACT rear panel Band Selection switch is
inactive when the unit is configured with a fixed wireless channel.
Manual channel selection requires FW ver 3.3 or later in your
SOUND HUB COMPACT. For latest FW and instructions please go to
www.dali-speakers.com/products/oberon-c/sound-hub-compact/
