Danby DAC050MB3GDB Assembly instructions

Model • M odèle • Modelo
OWNER’S USE AND CARE GUIDE
GUIDE D’UTILISATION ET SOINS DE PROPRIÈTAIRE
GUÍA DE UTILIZACIÓN Y CUIDADO PARA EL PROPIETARIO
MODEL • MODÈLE • MODELO
DANBY PRODUCTS LIMITED, ONTARIO, CANADA N1H 6Z9
DANBY PRODUCTS INC., FINDLAY, OHIO, USA 45840 V1.2 .11.13
AIR CONDITIONER
CLIMATISEUR
AIRE ACONDICIONADO
DAC050MB3GDB
5

TO OBTAIN WARRANTY SERVICE YOU MUST PROVIDEA VALID PROOF OF
PURCHASE. PLEASE STAPLE YOUR RECEIPT TO THIS PAGE FOR FUTURE
REFERENCE.
-------------------------------------------------------------------------------------------------------------------
POUR OBTENIR LE SERVICE SUR GARANTIE VOUS DEVEZ FOURNIR UNE
PREUVE D’ACHAT VALIDE. VEUILLEZ AGRAFER VOTRE REÇU À CETTE PAGE
POUR RÉFÉRENCE FUTURE.
-------------------------------------------------------------------------------------------------------------------
PARA OBTENER SERVICIO DE GARANTÍA, DEBE PROVEER UN RECIBO
ORIGINAL. POR FAVOR ENGRAPE SU RECIBO A ÉSTA PÁGINA EN CASO QUE
NECESITE HACER UN RECLAMO.
This product is factory equipped with a power supply cord that has a three-pronged grounded plug. It must
be plugged into a mating grounding type receptacle in accordance with the National Electrical Code and
applicable local codes and ordinances. If the circuit does not have a grounding type receptacle, it is the
responsibility and obligation of the customer to exchange the existing receptacle in accordance with the
National Electrical Code and applicable local codes and ordinances. The third ground prong should not,
under any circumstances, be cut or removed.
IMPORTANT - GROUNDING METHOD
Ce produit arrive d’origine avec un cordon d’alimentation équipé d’une prise à trois fiches. Il doit être
branché dans une prise avec une fiche de mise à la terre en conformité avec le Code National de l’Électricité
et les codes et règles locales applicables. Si le prise murale n’a pas de mise à la de terre, il est de la
responsabilité et l’obligation du client de changer la prise existante pour la rendre conforme aux Codes
Nationaux de l’Électricité, aux codes et règles locaux applicables. La fiche de la mise à la terre ne doit pas,
en aucune circonstance, être coupée ou retirée.
IMPORTANT - MÉTHODE POUR LA MISE À LA TERRE
Este producto viene equipado con un cable eléctrico que tiene un enchufe de tres patas con conexión
a tierra. Este debe colocarse en una toma de corriente con conexión a tierra de acuerdo con el Código
nacional de electricidad y códigos y ordenanzas locales correspondientes. Si el circuito no cuenta con
una toma de corriente con conexión a tierra, es responsabilidad y obligación del cliente sustituir la toma
de corriente actual de acuerdo con el Código nacional de electricidad y códigos y ordenanzas locales
correspondientes. Bajo ninguna circunstancia se debe cortar o eliminar la tercera pata de conexión a tierra.
IMPORTANTE - MÉTODO DE CONEXIÓN A TIERRA

AIR CONDITIONER
Owner’s Use and Care Guide ................................1-10
• Welcome
• Important Safety Information
• Features
• Installation Instructions
• Operation Instructions
• Care and Maintenance
• Troubleshooting
• Warranty
CLIMATISEUR
Guide d’utilisation et d’entretien du propriétaire....11-20
• Bienvenue
• Consignes de sécurité importantes
• Caractéristiques
• Consignes d’installation
• Consignes d’utilisation
• Soins et entretien
• Dépannage
• Garantie
AIRE ACONDICIONADO
Guía de utilización y cuidado para el propietario..21-31
• Bienvenido
• Información importante sobre seguridad
• Características
• Instrucciones de instalación
• Instrucciones de funcionamiento
• Cuidado y mantenimiento
• Resolución de problemas
• Garantía
CONTENTS
Model • Modèle • Modelo
DAC050MB3GDB
CAUTION:
Read and follow all safety rules and operating
instructions before first use of this product.
PRÉCAUTION:
Veuillez lire attentivement les consignes de
sécurité et les instructions d’utilisation avant
l’utilisation initiale de ce produit.
PRECAUCIÓN:
Lea y observe todas las relgas de seguridad y
las instrucciones de operación antes de usar
este producto por la primera vez.

WELCOME
1
Welcome to the Danby family. We are proud of our quality products, and we believe in dependable service, like you will
find in this Owner’s Use and Care Guide, and like you will receive from our friendly customer service department. Best of
all, you will experience these values each and every time you use your Danby appliance. That is important, because your
new appliance will be a part of your family for a long time.
For easy reference, we suggest you attach a copy of your sales slip/receipt to this page, along with the following
information, located on the manufacturer’s nameplate on the right side of the unit above the powercord.
Note the information below; you will need this information to obtain service under warranty.
To receive service, you must provide the original receipt.
NOTE: THIS UNIT IS NOT DESIGNED FOR “THROUGH-THE-WALL” INSTALLATION.
Model No:
Serial No:
Date Purchased:
NEED HELP?
Before you call for service, here are a few things you can do to
help us serve you better:
Read this Owner’s Use and Care Guide:
It contains instructions to help you use and maintain your
appliance properly.
If you received a damaged appliance:
Immediately contact the retailer (or builder) that sold you the
appliance.
Save time and money:
Check the Troubleshooting section at the end of the guide
before calling. This section helps you solve common problems
that may occur.
If you do need service, you can relax, knowing help is only a
phone call away.
Tel: 1-800-26-
(1-800-263-2629)
WARNING
Improper connection of the grounding plug can result in risk of
fire, electric shock and/or injury to persons associated with the
appliance. Check with a qualified service representative if in doubt
that the appliance is properly grounded.

2
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. All wiring must comply with local and national electrical codes and must be installed by a qualified electrician. If you
have any questions regarding the following instructions, contact a qualified electrician.
2. Check available power supply and resolve any wiring problems BEFORE installing and operating this unit.
3. This 115V air conditioner uses 3.88 or less nameplate amps and may be used in any properly wired, general-purpose
household receptacle. See Table 1 for the specifications for the individual branch circuit.
4. For your safety and protection, this unit is grounded through the powercord plug when plugged into a matching wall
outlet. If you are not sure whether your wall outlet is properly grounded, please consult a qualified electrician.
5. The wall outlet must match the 3-prong plug on the service cord supplied with the unit. DO NOT use plug adapters.
See Table 2 for receptacle and fuse information. If it is necessary to use an extension cord to connect your air condi-
tioner, use an approved “air conditioner” extension cord only (available at most local hardware stores).
6. The rating plate on the unit contains electrical and other technical data. The rating plate is located on the right side of
the unit, above the powercord.
ELECTRICAL
REQUIREMENTS
TABLE 1
Suggested Individual Branch Circuit
Nameplate Amps
3.88 *AWG Wire Size 18
AWG-American Wire Gauge
*Based on copper wire at 60°C temperature rating
TABLE 2
Receptacle and Fuse Types
Rated Volts 125
Amps 15
Wall Outlet
Fuse Size 15
Time Delay Fuse Plug Type
(or Circuit Breaker)
FOR YOUR SAFETY: Read these instructions carefully before operating the unit.

FEATURES
Your Danby appliance is designed to be highly efficient in energy savings. Follow these recommendations for
greater efficiency.
1. Select a thermostat setting that suits your comfort needs and leave at that chosen setting.
2. The air filter is very efficient in removing airborne particles. Keep the air filter clean at all times. (Usually cleaned every
2 weeks depending on indoor air quality.)
3. Use drapes, curtains or shades to keep direct sunlight from penetrating and heating the room, but do not allow drapes
or curtains to obstruct the air flow around the unit.
4. Start your air conditioner before the outdoor air becomes hot, to avoid an initial period of discomfort while the unit is
cooling the room.
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
FOR YOUR SAFETY: Read these instructions carefully before operating the unit.
ENERGY
SAVING TIPS
Air Filter
Cabinet
Air Filter
Exterior
Air Inlet
Cabinet
Interior Air Inlet
Control Panel
Interior Air Outlet
3

INSTALLATION INSTRUCTIONS
TOOLS NEEDED FOR INSTALLATION:
• Screwdrivers: Phillips and flat head.
• Power Drill: 1/8” (3.2mm) diameter drill bit
• Pencil
• Measuring Tape
• Scissors
• Carpenter’s Level
NOTE: Save the shipping carton and packing materials for future storage or transportation. From
the carton, remove the plastic bag containing the installation hardware kit necessary for the instal-
lation of your air conditioner. Please check the contents of the hardware kit against the corre-
sponding model check list, prior to installation of the unit. See Fig. 1.
ELECTRIC SHOCK HAZARD
To avoid the possibility of personal
injury, disconnect power to the unit
before installing or servicing.
NOTE: Your RoomAir Conditioner is designed for easy
installation in a single or double-hung window. This unit
is NOTdesigned for vertical (slider type) windows and/or
through-the-wall applications.
Because the compressor is located on the controls side of the unit (left side), this side
will be heavier and more awkward to manipulate. Inadequate support on control side of
the unit can result in personal injury and damage to your unit and property. Therefore, it
is recommended that you have someone assist you during the installation of this unit.
CAUTION
INSTALLATION
HARDWARE
1/2in. (13 mm)
screws (7) Safety Lock (1)
3/8in. (9.5mm) screws
(4) *Factory installed
on some models
“L” Shaped
mounting
bracket (1)
* Factory installed
on some models
Sash bracket (2)
Adhesive
Foam Seal(1)
Side Curtain LH (1)
Side Curtain RH (1)
Regular
Foam Seal(1)
Fig. 1
4

1. This room air conditioner is designed to fit easily into a single or double hung window. However, since window designs
vary, it may be necessary to make some modifications for safe, proper installation.
2. Make sure window and frame are structurally sound and free from dry and rotted wood.
3. For maximum efficiency, install the air conditioner on a side of the house or building which favours more shade than
sunlight. If the unit is in direct sunlight, it is advisable to provide an awning over the unit.
4. Provide sufficient clearance around the cabinet to allow for ample air circulation through the unit (See Fig. 2). The
rear of the unit should be outdoors. It should not be in a garage, or inside a building. Keep unit as far away as possi-
ble from obstacles/obstructions and at least 30” above the floor or ground. Curtains and other objects within the room
should be prevented from blocking the air flow.
5. Be certain that the proper electrical outlet is within reach of the installation. Use only a single outlet circuit rated at 15
amps. All wiring should be in accordance with local and national electrical codes.
6. DO NOT install unit where leakage of combustible gas is suspected. Your air conditioner may fail to operate in air
containing oils (including machine oils), sulfide gas, near hot springs, etc.
NOTE: Your unit is designed to evaporate condensation under normal conditions. However, under extreme humidity con-
ditions, excess condensation may cause basepan to overflow to the outside. The unit should be installed where conden-
sation run-off cannot drip on pedestrians or neighbouring properties.
5
INSTALLATION INSTRUCTIONS
LOCATION
Awning
Fence,
wall, or
other
obstacle
Ground
Side
Obstruction
20”
Min
30”
Min
20”
Min
12” Min
Fig. 2

6
INSTALLATION INSTRUCTIONS
ASSEMBLY AND
INSTALLATION
1. Assembly of the upper channel to the cabinet (factory installed on some units).
•“L” Shaped Top Channel: install the “L” shaped channel to the top of the cabinet as shown in Fig. 3, using four (4) 3/8”
screws.
2. Assembly of the side curtains to the cabinet.
•Extend the shutter from the shutter frame and slide it into the shutter tabs on the side channel of the air conditioner,
as shown in Fig. 4.
•Slide the shutters into the top (“L” shaped) and bottom (“U” shaped) channels. The shutters are identified (on frame)
as left and right.
3/8” screws
“L” shaped mounting
bracket
“U” shaped Channel
(Factory Installed)
Fig. 3
Slide down into tabs
Shutter tabs
Shutter
Shutter frame
Fig. 4
3. Completing the installation.
•Carefully place the air conditioner into the window with the “L” shaped mounting bracket (on top) positioned in front
of the upper window sash. The bottom of the cabinet should be positioned on the “recessed” portion of the window
frame. Pull the window down until it rests just behind the front flange of the (top) “L” shaped mounting bracket (See
Fig. 5).
•Expand the shutter frames (fully) on each side and secure the top of the frames to the window sash using one 1/2”
screw on each side and one in the “L” shaped mounting bracket (Fig. 5).
•Secure the shutter clamp on each side of the lower part of the shutter, and secure to window sill using one 1/2” screw
on each side (Fig. 5).
•Place the second foam sealing strip to fit the opening between the inside and outside windows, then attach the safety
lock to the outside window frame using one 1/2” screw (See Fig. 6).
PLEASE NOTE: Window applications come in a variety of different styles. Therefore, it may be necessary to modify your
particular installation.
Window sash
“L” Shaped
Mounting
Bracket
Shutter clamps
1/2” screws
Safety Lock
1/2” screw
Foam Seal
(adhesive)
Fig. 6Fig. 5
•Cut the foam (non adhesive) sealing strip to fit the area of the window sill that the air conditioner will rest on.

OPERATING INSTRUCTIONS
CONTROLS
SELECTOR SWITCH: The selector switch controls cooling mode. Simply rotate the SELECTOR knob to one of the two
settings described below.
COOLING MODES:
• LOW COOL provides cooling with minimum air circulation. Recommended for night-time use.
• HIGH COOL provides cooling with maximum air circulation. Recommended for quick cooling or for extremely hot
days. Once room is cooled, reduce setting to LOW COOL.
• OFF shuts the unit down completely.
NOTE: Always allow 3 minutes before switching from one mode to another.
THERMOSTAT: The thermostat automatically controls the (compressor) cooling cycle and maintains the selected room
temperature. To set the thermostat, rotate the thermostat knob to the desired cooling setting (1 warmest - 7 coldest).
Turn the selector switch slowly, allowing the unit to adjust.
When using THERMOSTAT, be sure to allow three minutes
before changing the temperature. Adjusting too quickly may
cause compressor to overload.
IMPORTANT
Thermostat
OFF
arrêt
Selector
Switch
7
Check that the air conditioner is tilted downwards to the outside, about
3° to 4°, as shown in Fig. 7. After proper installation, condensed water
should not drain from the overflow drain hole during normal use. If you
notice water leaking out, check the angle of tilt, and make any neces-
sary adjustments. However, on a very humid day, water leakage can
occur – this is normal.
Measure the tilt angle from the cabinet’s edge. The distance H should
be approximately 5/8” to 3/4”.
ASSEMBLY AND INSTALLATION
Measure the tilt angle from the cabinet’s edge
WINDOW
: approximately
5/8” to 3/4”
Fig. 7
