Danby DAS120GAHWDB User manual

DANBY PRODUCTS LIMITED, ONTARIO, CANADA N1H 6Z9
DANBY PRODUCTS INC., FINDLAY, OHIO, USA 45840
OWNER’S MANUAL
MANUEL DU PROPRIÉTAIRE
MANUAL DEL PROPIETARIO
www.Danby.com
*
*
2020.12.07
DAS120GAHWDB
DAS170GAHWDB
DAS220GAHWDB
FOR ANY QUESTIONS OR CONCERNS REGARDING INSTALLATION OR SERVICING OF THIS
APPLIANCE, PLEASE CONTACT THE DEALER OR BUILDER WHO SOLD THE APPLIANCE.
_____________________________________________________________________
POUR TOUTE QUESTION OU PRÉOCCUPATION CONCERNANT L’INSTALLATION OU L’ENTRETIEN
DE CET APPAREIL, VEUILLEZ CONTACTER LE REVENDEUR OU LE CONSTRUCTEUR QUI A VENDU
L’APPAREIL.
__________________________________________________________________
PARA CUALQUIER PREGUNTA O INQUIETUD RELACIONADA CON LA INSTALACIÓN O SERVICIO DE
ESTA UNIDAD, PÓNGASE EN CONTACTO CON EL DISTRIBUIDOR O CONSTRUCTOR QUE VENDIÓ LA
UNIDAD.
SPLIT AIR CONDITIONER
Owner’s Use and Care Guide ................................... 1 - 12
CLIMATISEUR DIVISÉ
Guide d’utilisation et d’entretien du propriétaire....... 13 - 24
AIRE ACONDICIONADO DIVIDIDO
Guía de utilización y cuidado para el propietario..... 25 - 36

SAFETY REQUIREMENTS
To avoid installation or operation difficulties, read
these instructions before first use of the product.
• Use this appliance only for its intended use, as
described in this manual.
• Never allow children to operate, play with, or
crawl inside the appliance.
• Never clean appliance parts with flammable
fluids. The fumes can create a fire hazard or
explosion.
• Do not store or use flammable vapors or liquids
in the vicinity of this or any other appliance. The
fumes can create a fire hazard or explosion.
• Do not use this product near water, e.g. in a wet
basement, laundry room or near a sink.
• Do not cover or block any openings on the
appliance.
• This appliance should be serviced only by a
qualified HVAC technician. Contact the dealer at
the location where the appliance was purchased
for information on servicing the appliance.
• Disposal of this appliance should be in
accordance with federal and local regulations.
• This appliance is not intended for use by persons
(including children) whose physical, sensory or
mental capabilities may be different or reduced,
or who lack experience or knowledge, unless
such persons receive supervision or training to
operate the appliance by a person responsible
for their safety.
• Do not climb onto or place objects on top of the
outdoor appliance.
• Do not operate this appliance with wet hands as
this can cause electric shock.
• Do not insert fingers or other objects into the
air inlet or outlet as the fan rotates at very high
speed and can cause serious injury or damage.
• Do not allow the appliance to operate for long
periods of time with doors or windows open or
if the humidity is very high.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the
electric current. The serial rating plate indicates the
voltage and frequency the appliance is designed for.
WARNING - Improper use of the grounding
plug can result in a risk of electric shock. Consult
a qualified electrician or service technician if
the grounding instructions are not completely
understood, or if doubt exists as to whether the
appliance is properly grounded.
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1
SAVE THESE INSTRUCTIONS!

2
FEATURES
OPERATING INSTRUCTIONS
DISPLAY CODE MEANINGS
CL: will display when the iCLEAN feature is active.

OPERATING TEMPERATURE
Optimal performance for the cool, heat and dry
modes can be achieved in the following temperature
ranges. When the air conditioner is used outside of
these temperature ranges, certain safety protection
features will activate and cause the appliance to
perform less efficiently.
COOL mode HEAT mode DRY mode
Room temperature 16°C - 32°C
(61°F - 90°F) 0°C - 32°C (32°F - 90°F) 16°C - 32°C (61°F - 90°F)
Outdoor temperature 0°C - 43°C
(32°F - 109°F) -7°C - 32°C (19°F - 90°F) 0°C - 43°C (32°F - 109°F)
OPERATION WITHOUT THE REMOTE CONTROL
Operational functioning can be access through the remote
control. In the event that the remote control fails to work,
the appliance can be operated manually with the manual
control button located on the indoor appliance. Note that
manual operation is not an efficient long-term solution
and that operating the appliance with the remote control is
recommended.
If the manual control button is pressed when the appliance
is turned off, the air conditioner will operate in auto mode.
If the manual control button is pressed when the appliance
is turned on, the air conditioner will turn off.
Note: The manual button is intended for testing purposes
and emergency operation only. Do not use this function
unless absolutely necessary. To restore regular operation,
use the remote control to activate the appliance.
To optimize the performance of the appliance:
• Keep doors and windows closed
• Do not block air inlets or outlets
• Regularly inspect and clean all air filters
• Limit energy usage by using the timer function
Note: When the outside temperature is below 0°C
(32°F), keep the appliance plugged in at all times
to ensure smooth ongoing performance.
OPERATING INSTRUCTIONS
3

4
OPERATION WITH THE REMOTE CONTROL
• The air conditioner will not operate if curtains, doors or other materials block the signal from the
remote control to the indoor appliance.
• Do not expose the remote control to water, direct sunlight or excessive heat.
• Do not allow direct sunlight to fall on the infrared receiver on the indoor appliance as this can impede
the signal from the remote control.
• Remote signal reception is confirmed with a beep.
OPERATING INSTRUCTIONS
Remote Control Specifications
Model YKR-H/101E
Rated Voltage 3.0V (dry batteries
R03/LR03x2)
Signal Receiving
Range 8m (26 feet)
Environment -5°C to 60°C (23°F
to 140°F)
SET: Used to increase or decrease the temperature setting in 1°
increments. Pressing and holding these buttons can reach the
desired temperature faster.
ON/OFF: Press to turn the appliance on or off.
MODE: Press to select the desired operating mode.
TURBO: Press to activate the turbo function, which will run the
appliance continuously to reach the preset temperature in the
shortest amount of time.
SPEED: Press to set the desired fan speed.
SLEEP: Press to activate sleep mode which conserves energy
during sleeping hours.
°C/°F: Press to change the temperature scale between °C and
°F.
DISPLAY: Press to turn the display on or off.
SWING: Press to start or stop the horizontal and vertical louver
swing feature. The direction of the arrow indicates which louver
is being controlled.
iFEEL: Press to activate iFEEL mode which will adjust the set
temperature automatically.
ANTI-F: Press to set the anti-F feature which will run the fan for
a short period after the appliance turns off to ensure the interior
of the appliance is dry and does not produce a musty smell.
iCLEAN: Press when the appliance is turned off to activate
iCLEAN.
TIMER: Press to set the automatic timer.

OPERATING INSTRUCTIONS
5
OPERATING MODES
AUTO mode
• Press the mode button to select auto mode.
• The appliance will automatically select cooling,
heating or fan only operation depending on
what temperature has been set and the ambient
room temperature.
DRY
• Press the mode button to select the dry mode.
• Keep windows and doors closed for the best
dehumidifying effect.
• Condensed water will automatically drain
through the drain hose.
COOL / HEAT / FAN
• Press the mode button to select the desired
mode; cool, heat or fan.
• Press the temperature control buttons to select
your desired room temperature. The temperature
can be set within a range of 16°C - 32°C (61°F
- 90°F).
• Press the speed button to choose the fan speed.
AUTOMATIC FEATURES
Auto-Restart
If the appliance loses power, it will automatically
restart with the previous settings once power is
restored.
Louver Angle Memory
When turning on the appliance, the louver will
automatically resume the previous angle setting.
Refrigerant Leakage Detection
The indoor appliance will automatically display
“P3” when it detects a refrigerant leakage and the
appliance will shut off.
SLEEP
• The sleep feature is used to decrease energy use
during sleeping hours. This feature can only be
activated by pressing the sleep button on the
remote control.
• When in cool mode, the temperature will
increase by 1°C (2°F) in the first hour and will
increase an additional 1°C (2°F) in the second
hour. The temperature will decrease by 1°C (2°F)
in 7 hour and another 1°C (2°F) in 10 hour.
• When in heat mode, the temperature will
decrease by 1°C (2°F) in the first hour and will
decrease an additional 1°C (2°F) in the second
hour. The temperature will increase by 1°C (2°F)
in 7 hour and another 1°C (2°F) in 10 hour.
• At the end of sleep cycle, the appliance will
resume normal operation.
Note: The sleep feature is not available in fan and
dry mode.
ANTI-F
The Anti-F feature will run the fan at a very low
speed for 3 minutes to ensure that the interior of the
appliance is dry. This can prevent the formation of
odors inside the appliance.
Ensure the appliance is off. Press the Anti-F button
with the appliance turned off to activate this feature.
A buzzer will sound 10 times to indicate that Anti-F
is active. If the appliance is turned on during this
period, Anti-F will be deactivated.
To cancel the Anti-F feature, press the Anti-F button
while the unit is off but Anti-F is running. The unit
will sound 8 times to confirm that Anti-F has been
turned off.

6
OPERATING INSTRUCTIONS
TIMER
To set the Auto-off timer:
• Ensure the appliance is turned on.
• Press the timer button to set the timer to turn the
appliance off.
• Press the temperature control buttons to
select the desired amount of hours before the
appliance turns off.
To set the Auto-on timer:
• Ensure the appliance is turned off.
• Press the timer button to set the timer to turn the
appliance on.
• Press the temperature control buttons to
select the desired amount of hours before the
appliance turns off.
Notes:
• The temperature control buttons will increase the
time in 0.5 hour increments up to 10 hours and
then in 1 hour increments up to 24 hours
• The display will revert back to showing the
previous temperature setting if the appliance
does not receive a signal within a 5 second
period during programming
• Turning the appliance on or off at any time
or adjusting the timer setting to 0.0 hours will
cancel the TIMER settings
ANTI-COLD AIR
The fan speed and the louver angle adjust
according to the ambient temperature. The manual
control button and remote control cannot adjust fan
speed or louver angle in this setting.
iFEEL
There is a temperature sensor built into the remote
control that will continuously collect the current
room temperature. Keep the remote control with
you and the appliance will automatically adjust the
set temperature based on the current temperature
where you are located to reach the most
comfortable condition.
Press the iFEEL button to activate this feature. The
remote will display the current temperature at its
location. The remote will send a signal to the air
conditioner every 3 minutes, so long as you remain
within range of the appliance.
The iFEEL light on the control panel of the appliance
will illuminate for 5 seconds every three minutes
to indicate that it has received a signal from the
remote. If the appliance does not receive a signal
from the remote during any 10 minute interval,
it will beep to indicate that the iFEEL feature has
deactivated.
The maximum distance for the iFEEL feature is 8
meters (26 feet). This feature is available in cool and
auto modes.
iCLEAN
The iCLEAN feature can be used to remove dust
from the interior of the appliance and ensure that
the evaporator is dry. Press the iCLEAN button when
the appliance is turned off to activate this features.
The iCLEAN feature will run for approximately 30
minutes and then turn off. If the appliance is turned
on during this period, iCLEAN will be deactivated.

LOUVERS
While the appliance is on, use the swing button to
set the vertical angle of the air flow.
Press the swing to begin the louver movement. Press
the swing button again to stop the louver at the
desired angle.
Note that there are two swing buttons on the remote
control. One controls the up and down louver and
the other controls the side to side louver. The arrows
on the button will indicate which louver is being set.
NOTE ON LOUVER ANGLES
When using cool or dry mode, do not set the louver
at an extreme vertical angle for a long period of
time. Water can condense on the louver blade
which can then drip on the floor or furnishings.
When using cool or heat mode, do not set the
louver at an extreme vertical angle for a long period
of time. This can cause reduced performance due to
restricted air flow.
Do not force the louver to move or adjust the louver
by hand. This will cause the louver to be out of sync
and it will not function correctly. If this occurs, turn
off the appliance and unplug it for a few seconds
and then restart the appliance. This will reset the
louver position.
CAUTION
Do not put fingers in or near the blower
and suction side of the appliance. The
high-speed fan inside the appliance can
cause serious harm or injury.
OPERATING INSTRUCTIONS
7

8
OPERATING INSTRUCTIONS
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
1. Reorient or relocate the receiving antenna
2. Increase the separation between the equipment and receiver
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
4. Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not approved by the party responsible for FCC compliance could void the user’s
authority to operate the equipment. This appliance complies with Part 15 of the FCC Rules and Industry
Canada’s license-exempt RSS.
Operation is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operation.
This device complies with Canadian CAN ICES-3 (B) / NMB-3 (B)
REPLACING THE REMOTE BATTERIES
The appliance comes with two AAA batteries. Place the batteries in the
remote control before use.
1. Slide the back cover from the remote downward to expose the battery
compartment.
2. Insert the batteries, ensure to match the (+) and (-) symbols on the ends
of the batteries with the symbols inside the battery compartment.
3. Slide the battery cover back into place.
• Do not mix old and new batteries or batteries of different types.
• Do not leave the batteries in the remote control if it is not going to be
used for more than 2 months.
• Do not dispose of batteries as unsorted municipal waste. Collection of
such waste separately for special treatment is necessary.
• Removing the batteries from the remote will erase all previous
programming. After inserting new batteries, the settings on the
appliance must be reprogrammed.

CLEANING THE AIR FILTER
A clogged air filter can reduce the efficiency of the
air conditioner. It is advisable to clean the air filter
every two weeks or after 240 hours of operation,
whichever comes first. When removing the filter, do
not touch any metal parts inside the appliance as
the sharp metal edges can cause injury.
1. Lift the front panel of the indoor appliance.
2. Grip the tab on the end of the filter, lift it up and
pull it outwards to remove it from the appliance.
3. If the filter has a small air freshening filter, unclip
if from the larger filter. Clean the air freshening
filter with a soft brush or hand-held vacuum
cleaner.
4. Clean the large filter with warm, soapy water.
Use mild detergent.
5. Rinse the filter with clean water. Ensure all soap
is removed from the filter and shake off excess
water.
6. Dry the filter in a cool, dry place. Do not expose
the filter to direct sunlight as this can warp or
shrink the filter.
7. When the filter is dry, replace the air freshening
filter and then slide the larger filter back into the
appliance.
8. Close the front panel of the indoor appliance.
Note: Do not touch the air freshening (plasma)
filter for at least 10 minutes after turning off the
appliance to allow it to cool.
CARE & MAINTENANCE
9
