Danby DAS120BAHWDB User manual

DANBY PRODUCTS LIMITED, ONTARIO, CANADA N1H 6Z9
DANBY PRODUCTS INC., FINDLAY, OHIO, USA 45840
OWNER’S MANUAL
MANUEL DU PROPRIÉTAIRE
MANUAL DEL PROPIETARIO
www.Danby.com 2019.12.11
DAS090BAHWDB
DAS120BAHWDB
DAS180BAHWDB
DAS180DBAHWDB
DAS240BAHWDB
FOR ANY QUESTIONS OR CONCERNS REGARDING INSTALLATION OR SERVICING OF THIS
APPLIANCE, PLEASE CONTACT THE DEALER OR BUILDER WHO SOLD THE APPLIANCE.
_____________________________________________________________________
POUR TOUTE QUESTION OU PRÉOCCUPATION CONCERNANT L’INSTALLATION OU L’ENTRETIEN
DE CET APPAREIL, VEUILLEZ CONTACTER LE REVENDEUR OU LE CONSTRUCTEUR QUI A VENDU
L’APPAREIL.
__________________________________________________________________
PARA CUALQUIER PREGUNTA O INQUIETUD RELACIONADA CON LA INSTALACIÓN O SERVICIO DE
ESTA UNIDAD, PÓNGASE EN CONTACTO CON EL DISTRIBUIDOR O CONSTRUCTOR QUE VENDIÓ LA
UNIDAD.
SPLIT AIR CONDITIONER
Owner’s Use and Care Guide ................................... 1 - 12
CLIMATISEUR DIVISÉ
Guide d’utilisation et d’entretien du propriétaire....... 13 - 24
AIRE ACONDICIONADO DIVIDIDO
Guía de utilización y cuidado para el propietario..... 25 - 36

SAFETY REQUIREMENTS
To avoid installation or operation difficulties, read
these instructions before first use of the product.
• Use this appliance only for its intended use, as
described in this manual.
• Never allow children to operate, play with, or
crawl inside the appliance.
• Never clean appliance parts with flammable
fluids. The fumes can create a fire hazard or
explosion.
• Do not store or use flammable vapors or liquids
in the vicinity of this or any other appliance. The
fumes can create a fire hazard or explosion.
• Do not use this product near water, e.g. in a wet
basement, laundry room or near a sink.
• Do not cover or block any openings on the
appliance.
• This appliance should be serviced only by a
qualified HVAC technician. Contact the dealer at
the location where the appliance was purchased
for information on servicing the appliance.
• Disposal of this appliance should be in
accordance with federal and local regulations.
• This appliance is not intended for use by persons
(including children) whose physical, sensory or
mental capabilities may be different or reduced,
or who lack experience or knowledge, unless
such persons receive supervision or training to
operate the appliance by a person responsible
for their safety.
• Do not climb onto or place objects on top of the
outdoor appliance.
• Do not operate this appliance with wet hands as
this can cause electric shock.
• Do not insert fingers or other objects into the
air inlet or outlet as the fan rotates at very high
speed and can cause serious injury or damage.
• Do not allow the appliance to operate for long
periods of time with doors or windows open or if
the humidity is very high.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the
electric current. The serial rating plate indicates the
voltage and frequency the appliance is designed for.
WARNING - Improper use of the grounding plug can
result in a risk of electric shock. Consult a qualified
electrician or service technician if the grounding
instructions are not completely understood, or if
doubt exists as to whether the appliance is properly
grounded.
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1
SAVE THESE INSTRUCTIONS!

2
FEATURES
will display for 3 seconds when:
• TIMER ON is set
• SWING, TURBO or SLEEP features are turned on
will display for 3 seconds when:
• TIMER OFF is set
• SWING, TURBO or SLEEP features are turned off
will display when anti-cold air feature is turned on
will display when the appliance is defrosting
• In fan mode, the appliance will display the room temperature
• In other modes, the appliance will display the temperature setting
DISPLAY CODE MEANINGS
OPERATING INSTRUCTIONS

OPERATING TEMPERATURE
Optimal performance for the COOL, HEAT and DRY
modes can be achieved in the following temperature
ranges. When the air conditioner is used outside of
these temperature ranges, certain safety protection
features will activate and cause the appliance to
perform less efficiently.
COOL mode HEAT mode DRY mode
Room temperature 17°C - 32°C
(63°F - 90°F) 0°C - 30°C (32°F - 86°F) 10°C - 32°C (50°F - 90°F)
Outdoor temperature 0°C - 50°C
(32°F - 122°F) -15°C - 30°C (5°F - 86°F) 0°C - 50°C (32°F - 122°F)
OPERATION WITHOUT THE REMOTE CONTROL
Note: The manual button is intended for testing
purposes and emergency operation only. Do not
use this function unless absolutely necessary. To
restore regular operation, use the remote control to
activate the appliance.
Operational functioning can be access through the
remote control. In the event that the remote control
fails to work, the appliance can be operated
manually with the manual control button located on
the indoor appliance. Note that manual operation
is not an efficient long-term solution and that
operating the appliance with the remote control is
recommended.
The appliance must be turned off before manual
operation. To operate the appliance manually:
1. Open the front panel of the indoor appliance.
2. The manual control button is located on the right
side hand side of the appliance.
3. Press the manual control button one time to
activate forced AUTO mode.
4. Press the manual control button a second time to
activate forced COOL mode.
5. Press the manual control button a third time to turn
the appliance off.
6. Ensure the front panel is closed when finished.
To optimize the performance of the appliance:
• Keep doors and windows closed
• Do not block air inlets or outlets
• Regularly inspect and clean all air filters
• Limit energy usage by using the timer function
Note: When the outside temperature is below 0°C
(32°F), keep the appliance plugged in at all times
to ensure smooth ongoing performance.
OPERATING INSTRUCTIONS
3

4
OPERATION WITH THE REMOTE CONTROL
• The air conditioner will not operate if curtains, doors or other materials block the signal from the remote
control to the indoor appliance.
• Do not expose the remote control to water, direct sunlight or excessive heat.
• Do not allow direct sunlight to fall on the infrared receiver on the indoor appliance as this can impede
the signal from the remote control.
• Remote signal reception is confirmed with a beep.
OPERATING INSTRUCTIONS
ON/OFF: Turns the appliance
on or off
MODE: Selects mode
operation in the following
order:
Auto --> Cool --> Dry --> Heat
--> Fan
FAN: Selects fan speed in the
following order:
Auto --> Low --> Med --> High
SLEEP: Conserves energy
during sleeping hours
TURBO: Starts and stops the
turbo function, which will run
the appliance continuously to
reach the preset temperature
in the shortest amount of time;
after running for 30 minutes
turbo mode will stop
Symbol will flash
to indicate that the
appliance has received
the signal from the
remote control.
UP AND DOWN BUTTONS:
Used to increase or decrease
the temperature setting in 1°
increments. Press and hold
the up and down buttons for
three seconds to change the
temperature scale between
°C and °F
SHORTCUT: Used to restore
the current settings or resume
previous settings
TIMER ON: Used to set
automatic on function
TIMER OFF: Used to set
automatic off function
DIRECT: Used to change the
louver movement and set the up
or down air flow direction
SWING: Used to start or
stop the horizontal louver
swing feature
LED: Turns the LED
display on or off
Remote Control Specifications
Model RG57B/BGEU1
Rated Voltage 3.0V (dry batteries R03/LR03x2)
Signal Receiving Range 8m (26 feet)
Environment -5°C to 60°C (23°F to 140°F)

OPERATING MODES
AUTO mode
• Press the MODE button to select AUTO mode.
• The appliance will automatically select cooling,
or fan only operation depending on what
temperature has been set and the ambient room
temperature.
DRY (dehumidifying) mode
• Press the MODE button to select the DRY mode.
• The fan speed cannot be adjusted in this mode.
The fan operates at LOW speed.
• Keep windows and doors closed for the best
dehumidifying effect.
• Condensed water will automatically drain
through the drain hose.
Note: The fan speed cannot be adjusted in AUTO
and DRY mode.
COOL mode / HEAT mode / FAN operation
• Press the MODE button to select the desired
mode; COOL, HEAT or FAN.
• Press the UP or DOWN buttons to select your
desired room temperature. The temperature can
be set within a range of 17°C - 30°C (62°F -
86°F).
• Press the FAN button to choose the fan speed:
Auto, Low, Med or High.
SHORTCUT function (only available on remote):
• Used to save a favourite setting
• Set the unit to the temperature and fan speed that
you would like to set as a favourite
• Press and hold the SHORTCUT button for 2
seconds
• Press the SHORTCUT button at any point in future
to return to the favourite setting
• If no favourite is set, pressing the SHORTCUT
button will cause the unit to run in AUTO mode at
26°C (79°F), with fan speed set to AUTO
Anti-Cold Air Feature
• The fan speed and the louver angle adjust
according to the ambient temperature. The
manual control button and remote control cannot
adjust fan speed or louver angle in this setting.
SLEEP function
• The SLEEP function is used to decrease energy
use during sleeping hours. This function can only
be activated by pressing the SLEEP button on the
remote control.
• When in COOL mode, the temperature will
increase by 1°C (2°F) in the first hour and
will increase an additional 1°C (2°F) in the
second hour. The appliance will then hold this
new temperature for 5 hours. At the end of the
SLEEP cycle, the appliance will resume normal
operation.
• When in HEAT mode, the temperature will
decrease by 1°C (2°F) in the first hour and
will decrease an additional 1°C (2°F) in the
second hour. The appliance will then hold this
new temperature for 5 hours. At the end of the
SLEEP cycle, the appliance will resume normal
operation.
Note: The sleep feature is not available in FAN and
DRY mode.
AUTOMATIC FEATURES
Auto-Restart
If the appliance loses power, it will automatically
restart with the previous settings once power is
restored.
Louver Angle Memory
When turning on the appliance, the louver will
automatically resume the previous angle setting.
Refrigerant Leakage Detection
The indoor appliance will automatically display
“EC” when it detects a refrigerant leakage and the
appliance will shut off.
OPERATING INSTRUCTIONS
5

6
TIMER OPERATION
To set the Auto-off timer:
• Ensure the appliance is turned on
• Press the TIMER OFF button and the Timer Off
indicator will illuminate
• Press the TIMER OFF button to select the desired
amount of hours before the appliance turns off
To set the Auto-on timer:
• Ensure the appliance is turned on
• Press the TIMER ON button and the Timer On
indicator will illuminate
• Press the TIMER ON button to select the desired
amount of hours before the appliance turns on
Notes:
• The TIMER ON and TIMER OFF buttons will
increase the time in 0.5 hour increments up to
10 hours and then in 1 hour increments up to 24
hours
• The display will revert back to showing the
previous temperature setting if the appliance does
not receive a signal within a 5 second period
during programming
• Turning the appliance on or off at any time or
adjusting the timer setting to 0.0 hours will cancel
the TIMER settings
Using the TIMER ON and TIMER OFF feature at the
same time
The appliance can be set to turn on and run for a
set period of time and then turn off again by using
the TIMER ON and TIMER OFF features at the same
time. Keep in mind that the hours displayed on the
appliance refer to the number of hours that will pass
from the current time before the action is taken.
For example:
• First, set the Auto-off timer
• Ensure the appliance is turned on
• Press the TIMER OFF button and the Timer Off
indicator light will illuminate
• Press the TIMER OFF button to select the desired
amount of hours before the appliance turns off
• Press the TIMER ON button within 5 seconds and
the Timer On indicator light will illuminate
• Press the TIMER ON button to select the amount
of hours before the appliance turns back on
Note: If the TIMER OFF function and the SLEEP
function are used at the same time, the appliance
will only implement the setting whose duration is
shorter.
If the TIMER OFF function is set for less than seven
hours, the TIMER OFF will turn the appliance off
before the SLEEP function can complete its cycle.
If the TIMER OFF function is set for more than seven
hours, the SLEEP function will turn the appliance off
before the TIMER OFF can complete its cycle.
OPERATING INSTRUCTIONS

SETTING VERTICAL ANGLE OF AIR FLOW
While the appliance is on, use the SWING/DIRECT
button to set the vertical angle of the air flow.
1. Press the SWING/DIRECT button once to
activate the louver. Each press of the button will
adjust the louver by 6°.
2. To make the louver swing up and down
continuously, press and hold the SWING/
DIRECT button for 3 seconds. Press it again to
stop the continuous swing.
SETTING HORIZONTAL ANGLE OF AIR
FLOW
The horizontal angle of the air flow must be set
manually. Grip the deflector rod and manually adjust
it to the preferred direction.
NOTE ON LOUVER ANGLES
When using COOL or DRY mode, do not set the
louver at an extreme vertical angle for a long period
of time. Water can condense on the louver blade
which can then drip on the floor or furnishings.
When using COOL or HEAT mode, do not set the
louver at an extreme vertical angle for a long period
of time. This can cause reduced performance due to
restricted air flow.
Do not force the louver to move or adjust the louver
by hand. This will cause the louver to be out of sync
and it will not function correctly. If this occurs, turn off
the appliance and unplug it for a few seconds and
then restart the appliance. This will reset the louver
position.
CAUTION
Do not put fingers in or near the blower
and suction side of the appliance. The
high-speed fan inside the appliance can
cause serious harm or injury.
OPERATING INSTRUCTIONS
7

8
OPERATING INSTRUCTIONS
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
1. Reorient or relocate the receiving antenna
2. Increase the separation between the equipment and receiver
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
4. Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not approved by the party responsible for FCC compliance could void the user’s
authority to operate the equipment. This appliance complies with Part 15 of the FCC Rules and Industry
Canada’s license-exempt RSS.
Operation is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operation.
This device complies with Canadian CAN ICES-3 (B) / NMB-3 (B)
REPLACING THE REMOTE BATTERIES
The appliance comes with two AAA batteries. Place the batteries in the
remote control before use.
1. Slide the back cover from the remote downward to expose the battery
compartment.
2. Insert the batteries, ensure to match the (+) and (-) symbols on the ends of
the batteries with the symbols inside the battery compartment.
3. Slide the battery cover back into place.
• Do not mix old and new batteries or batteries of different types.
• Do not leave the batteries in the remote control if it is not going to be
used for more than 2 months.
• Do not dispose of batteries as unsorted municipal waste. Collection of
such waste separately for special treatment is necessary.
Note: Removing the batteries from the remote will erase all previous
programming. After inserting new batteries, the settings on the appliance must
be reprogrammed.

CLEANING THE INDOOR APPLIANCE
Note: Always turn off the air conditioner and
disconnect the power source before cleaning the
appliance or removing the filter.
• Use a soft, dry cloth to clean the outside of the
appliance. If the appliance is especially dirty,
use a cloth soaked in warm water to clean the
outside of the appliance.
• Do not use water to clean the inside of the
appliance as this can destroy the insulation and
cause electric shock.
• Do not use chemicals or chemically treated cloths
to clean the appliance.
• Do not use benzene, paint thinner or other
solvents to clean the appliance. They can cause
the plastic surface to crack or deform.
• Do not use water hotter than 40°C (104°F) to
clean the front panel. This can cause the panel to
deform or become discoloured.
CLEANING THE AIR FILTER
A clogged air filter can reduce the efficiency of the
air conditioner. It is advisable to clean the air filter
every two weeks or after 240 hours of operation,
whichever comes first. When removing the filter, do
not touch any metal parts inside the appliance as the
sharp metal edges can cause injury.
1. Lift the front panel of the indoor appliance.
2. Grip the tab on the end of the filter, lift it up and
pull it outwards to remove it from the appliance.
3. If the filter has a small air freshening filter, unclip if
from the larger filter. Clean the air freshening filter
with a soft brush or hand-held vacuum cleaner.
4. Clean the large filter with warm, soapy water.
Use mild detergent.
5. Rinse the filter with clean water. Ensure all soap
is removed from the filter and shake off excess
water.
6. Dry the filter in a cool, dry place. Do not expose
the filter to direct sunlight as this can warp or
shrink the filter.
7. When the filter is dry, replace the air freshening
filter and then slide the larger filter back into the
appliance.
8. Close the front panel of the indoor appliance.
Note: Do not touch the air freshening (plasma) filter
for at least 10 minutes after turning off the appliance
to allow it to cool.
CARE & MAINTENANCE
9
