Danfoss iC7 Series User manual

1 Overview
1.1 Description
The in-bottom/out-back cooling kit fits FA11 and FA12 frequency converters mounted in Rittal TS8 cabinets with widths of 600 mm
(24 in) or 800 mm (32 in). When the kit is installed, air flows into the bottom duct and out through the back duct of the frequency
converter. See Illustration 1.
6
3
5
1
4
2
e30be922.10
Illustration 1: Direction of Airflow with Kit Installed
1
Top cover
2
Frequency converter
3
Bottom duct assembly
4
Back channel airflow (intake)
5
Back channel airflow (exhaust)
6
Mounting plate
1.2 Kit Numbers
Use these instructions with the following kits.
Table 1: In-bottom/Out-back Cooling Kits
Number
Kit description
176F4059
In-bottom/out-back cooling kit for FA11 in 600 mm (24 in) cabinet
176F4193
In-bottom/out-back cooling kit for FA11 in 800 mm (32 in) cabinet
176F4060
In-bottom/out-back cooling kit for FA12 in 800 mm (32 in) cabinet
1.3 Items Supplied
The following parts are contained in the kit.
AN361429392581en-000201 / 136R0253 | 1Danfoss A/S © 2022.12
Installation Guide
In-bottom/Out-back Cooling Kit for FA11-FA12
iC7 Series Frequency Converters

Table 2: Items Supplied in In-bottom/Out-back Cooling Kits
Item
Quantity
Top cover
1
Top gasket
1
Duct support bracket
1
Duct support gasket
1
Telescopic bottom duct
1
Ribbed EPDM rubber seal
1
Base plate (with opening for duct)
1
Back duct
1
6-hole back gasket
2
8-hole back gasket
2
M5x18 screw
12
M5x14 screw
8
M5 hex nut
6
M6x12 screw
6
M5 clip-on nut
8
AN361429392581en-000201 / 136R02532 | Danfoss A/S © 2022.12
Overview
In-bottom/Out-back Cooling Kit for FA11-FA12
Installation Guide

-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
2 Installation
2.1 Safety Information
NOTICE
QUALIFIED PERSONNEL
Only qualified, Danfoss authorized personnel are allowed to install the parts described in these installation instructions.
Disassembly and reassembly of the frequency converter must be done in accordance with the service guide.
Use the standard fastener torque values from the service guide, unless the torque value is specified in these instructions.
WARNING
DISCHARGE TIME (40 MINUTES)
The frequency converter contains DC-link capacitors, which can remain charged even when the frequency converter is not pow-
ered. High voltage can be present even when the warning LED indicator lights are off. Failure to wait 40 minutes after power has
been removed before performing service or repair work can result in death or serious injury.
Stop the motor.
Disconnect AC mains and remote DC-link power supplies, including battery back-ups, UPS, and DC-link connections to other
frequency converters.
Disconnect or lock the motor.
Disconnect any brake option.
Disconnect any DC connector option.
Wait 40 minutes for the DC-link capacitors to discharge fully.
Before performing any service or repair work, measure the voltage level to verify that the capacitors are fully discharged.
WARNING
ELECTRICAL SHOCK HAZARD
The frequency converter contains dangerous voltages when connected to mains voltage. Improper installation, and installing or
servicing with power connected, can cause death, serious injury, or equipment failure.
Only use qualified electricians for the installation.
Disconnect the frequency converter from all power sources before installation or service.
Treat the frequency converter as live whenever the mains voltage is connected.
Follow the guidelines in these instructions and local electrical safety codes.
NOTICE
ELECTROSTATIC DISCHARGE
Electrostatic discharge can damage components.
Ensure electrostatic discharge before touching internal frequency converter components, for example by touching a groun-
ded, conductive surface or by wearing a grounded armband.
2.2 Installation Overview
NOTICE
APPLYING GASKETS
This kit contains self-adhesive gaskets to ensure a proper seal between metal parts.
Before affixing a gasket, check that the part matches the gasket and that no holes are covered.
AN361429392581en-000201 / 136R0253 | 3Danfoss A/S © 2022.12
Installation
In-bottom/Out-back Cooling Kit for FA11-FA12
Installation Guide

1
2
3
4
5
6
7
5
11
8
9
e30bg105.10
10
Illustration 2: Overview of In-bottom/Out-back Cooling Kit
1
Duct support gasket
2
Duct support bracket
3
M5x14 screw
4
M5x18 screw
5
Bottom duct assembly
6
M5 hex nut
7
Base plate
8
Top cover
9
Top gasket
10
Back duct assembly
11
Opening for duct
AN361429392581en-000201 / 136R02534 | Danfoss A/S © 2022.12
Installation
In-bottom/Out-back Cooling Kit for FA11-FA12
Installation Guide

1.
2.
3.
4.
2.3 Creating Vent Opening in the Mounting Plate
To create mounting holes and a back vent opening in the mounting plate, use the following steps. Use the dimensions in Illustration
3for FA11 frequency converters in 600 mm (24 in) cabinets, and Illustration 4 for FA11 frequency converters in 800 mm (32 in)
cabinets. Use the dimensions in Illustration 5 for FA12 frequency converters in 800 mm (32 in) cabinets.
Procedure
Drill 6 mounting holes in the back of the frequency converter using the dimensions in the template.
Insert 6 M10 pem self-clinching nuts (not supplied) in the mounting holes.
Cut out the vent opening in the mounting plate using the dimensions in the template.
The opening must match the frequency converter vent opening.
Drill 6 screw holes around the vent opening using the dimensions in the template.
The holes must match the holes in the inner flange of the back duct.
e30bg107.10
499 (19.7)
246 (9.7)
230 (9.1)
206 (8.1)
201 (7.9)
6X S-M10-2Z1
0.0
201 (7.9) 206 (8.1)
230 (9.1)
246 (9.7)
23 (0.9)
0.0
100 (3.9)
2X 137 (5.3)
158 (6.2)
169 (6.7)
314 (12.3)
326 (12.8)
2X 347 (13.7)
1645 (64.7)
215 (8.5)
0.0
7 (0.3)
3 (0.1)
215 (8.5)
Illustration 3: Vent Dimensions for FA11 Mounting Plate in 600 mm (24 in) Cabinet
AN361429392581en-000201 / 136R0253 | 5Danfoss A/S © 2022.12
Installation
In-bottom/Out-back Cooling Kit for FA11-FA12
Installation Guide

699 (27.5)
246 (9.7)
230 (9.1) 206 (8.1) 201 (7.9)
6X S-M10-2Z1
0.0
201 (7.9) 206 (8.1)
230 (9.1)
246 (9.7)
23 (0.9)
0.0
100 (3.9)
2X 137 (5.3)
158 (6.2)
169 (6.7)
314 (12.3)
326 (12.8)
2X 347 (13.7)
1645 (64.7)
215 (8.5)
0.0
7 (0.3)
3 (0.1)
e30bg108.10
215 (8.5)
Illustration 4: Vent Dimensions for FA11 Mounting Plate in 800 mm (32 in) Cabinet
AN361429392581en-000201 / 136R02536 | Danfoss A/S © 2022.12
Installation
In-bottom/Out-back Cooling Kit for FA11-FA12
Installation Guide

1.
2.
699 (27.5)
230 (9.1)
254 (10.0)
201 (7.9)
6X S-M10-2Z1
0.0
201 (7.9)
230 (9.1)
23 (0.9)
0.0
100 (3.9)
2X 137 (5.3)
158 (6.2)
169 (6.7)
314 (12.3)
326 (12.8)
2X 347 (13.7)
1645 (64.7)
0.0
7 (0.3)
3 (0.1)
e30bg265.10
263 (10.4)
254 (10.0)
263 (10.4)
Illustration 5: Vent Dimensions for FA12 Mounting Plate in 800 mm (32 in) Cabinet
2.4 Creating Vent Opening in the Backplate
To create a vent opening in the cabinet backplate, use the following steps. Use the dimensions in Illustration 6 for 600 mm (24 in)
cabinets, and Illustration 7 for 800 mm (32 in) cabinets.
Procedure
Cut out the vent opening in the cabinet backplate using the template dimensions.
The opening must match the frequency converter vent opening.
Drill 8 screw holes (6 mm) around the vent opening using the template dimensions.
The holes must match the holes in the outer flange of the back duct.
AN361429392581en-000201 / 136R0253 | 7Danfoss A/S © 2022.12
Installation
In-bottom/Out-back Cooling Kit for FA11-FA12
Installation Guide

e30bg109.10
244 (9.6)
2X 232 (9.1)
8X Ø 6 (0.2)
225 (8.9)
2X 218 (8.6)
2X 82 (3.2)
75 (3.0) 2X 68 (2.7) 244 (9.6) 2X 218 (8.6)
225 (8.9) 2X 232 (9.1) 2X 68 (2.7)
75 (3.0) 2X 82 (3.2)
0.0
18 (0.7)
0.0
185 (7.3)
4X 196 (7.7)
198 (7.8)
392 (15.4)
4X 394 (15.5)
405 (15.9)
0.0
592 (23.3)
Illustration 6: Vent Template for Backplate in 600 mm (24 in) Cabinet
AN361429392581en-000201 / 136R02538 | Danfoss A/S © 2022.12
Installation
In-bottom/Out-back Cooling Kit for FA11-FA12
Installation Guide

1.
2.
3.
4.
5.
6.
e30bg110.10
244 (9.6)
2X 232 (9.1)
8X Ø 6 (0.2)
225 (8.9)
2X 218 (8.6)
2X 82 (3.2)
75 (3.0) 2X 68 (2.7) 244 (9.6) 2X 218 (8.6)
225 (8.9) 2X 232 (9.1) 2X 68 (2.7)
75 (3.0) 2X 82 (3.2)
0.0
18 (0.7)
0.0
185 (7.3)
4X 196 (7.7)
198 (7.8)
392 (15.4)
4X 394 (15.5)
405 (15.9)
0.0
792 (31.2)
Illustration 7: Vent Template for Backplate in 800 mm (32 in) Cabinet
2.5 Installing the Top Cover
To install the top cover, use the following steps. See Illustration 8.
Procedure
Remove paper backing from the top gasket to expose the adhesive.
Adhere the top gasket to the underside of the top cover.
Remove the M5x14 screws (T25) surrounding the sides and back of the vent in the top of the frequency converter.
Retain the screws. Fx11 converters have 6 screws; Fx12 converters have 7 screws.
Loosen 3 M5x12 screws (T25) at the front of the vent in the top surface of the frequency converter.
Slide the edge of the top cover plate under the 3 loosened screws, positioning the plate over the vent in the top of the
frequency converter.
Secure the top cover plate with the M5x14 screws (T25) removed previously in step 3.
Torque all screws to 2.3 Nm (20 in-lb).
AN361429392581en-000201 / 136R0253 | 9Danfoss A/S © 2022.12
Installation
In-bottom/Out-back Cooling Kit for FA11-FA12
Installation Guide

1.
2.
1
2
3
e30bk192.10
6
4
5
Illustration 8: Installation of Top Cover
1
M5x14 screw
2
Top cover
3
Top gasket
4
Top vent
5
M5x12 screw (loosened, not removed)
6
Top of frequency converter
2.6 Assembling the Bottom Duct
The bottom duct is a telescopic duct that collapses to simplify installation. To assemble the duct before installation, use the follow-
ing steps. Refer to Illustration 9.
Procedure
Cut the strip of ribbed EPDM rubber seal into 2 pieces of 990 mm (39.0 in).
Peel the paper off the self-adhesive seals. Place 1 strip on the outside bottom edge of the inner sleeve of the duct, and
1 strip on the upper inside edge of the outer sleeve of the duct.
AN361429392581en-000201 / 136R025310 | Danfoss A/S © 2022.12
Installation
In-bottom/Out-back Cooling Kit for FA11-FA12
Installation Guide
