Danfoss AK-UI55 User manual

084R8057
AN324530821966en-000104
Installation Guide
AK-UI55 Bluetooth
© Danfoss | DCS (vt) | 2020.09 AN324530821966en-000104 | 1
NEMA4
IP65
Identification Dimensions
Mounting
Connection
AK-UI cable, 3 m: 084B4078
AK-UI cable, 6 m: 084B4079
RJ 12
tamb = 0 – 55 °C
32 – 130 °F
Non condensing
L MAX.= 100 m
0.5 - 3.0 mm
L1+ L2 : MAX.= 100 m
L1
L2
AK-UI55 Bluetooth
Without configuration, the display
can show the same information as
the AK-UI55 Info version.
Loc
The operation is locked and cannot
be operated via Bluetooth.
Unlock from the system device.
Access to parameters via Bluetooth and app
1. App can be downloaded from App Store and Google Play
Name = AK-CC55 Connect
Start the app.
2. Click on the display’s Bluetooth button for 3 seconds.
The Bluetooth light will then flash while display is showing the controller’s address.
3. Connect to the controller from the app.
App Store Google Play

© Danfoss | DCS (vt) | 2020.09
2 | AN324530821966en-000104
Statements for the AK-UI55 Bluetooth display:
FCC COMPLIANCE STATEMENT
CAUTION: Changes or modifications not expressly approved could void your authority to use this equipment
This device complies with Part 15 of the FCC Rules. Operation to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired operation
INDUSTRY CANADA STATEMENT
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
NOTICE
FCC COMPLIANT NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modifications: Any modifications made to this device that are not approved by Danfoss may void the authority granted to the user by the FCC to
operate this equipment.
Danfoss Cooling
11655 Crossroads Circle
Baltimore, Maryland 21220
United States of America
www.danfoss.com
EU CONFORMITY NOTICE
Hereby, Danfoss A/S declares that the radio equipment type AK-UI55 Bluetooth is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: www.danfoss.com
Danfoss A/S
Nordborgvej 81
6430 Nordborg
Denmark
www.danfoss.com
China Commitment
Type Approval for Radio Transmitting Equipment
CMIIT ID: 2020DJ7408
