Danfoss ECtemp 532 User manual

Danfoss ECtemp 532
Electronic Thermostat
Installation Guide
electricheating.danfoss.com

Danfoss ECtemp 532
3Installation Guide
1 Introduction
ECtemp 532 is an electronic thermostat provided with a
2-pole switch, a room sensor to control the room tempera-
ture, and an additional oor sensor to limit the maximum
oor temperature. It can be either ush-mounted or
surface-mounted.
The thermostat has a button for adjusting the temperature
setting with a scale from ( ) 5-35°C. Furthermore, it has
a LED indicator showing standby periods (green light) and
heating periods (red light).
More information on this product can also be found at:
ectemp.danfoss.com
Table of Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Technical Specications . . . . . . . . . . . . 4
1.2 Safety Instructions . . . . . . . . . . . . . . . . 5
2 Mounting Instructions . . . . . . . . . . . . . . . . . 6
3 Settings . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 Warranty. . . . . . . . . . . . . . . . . . . . . . . . . 12
4 Disposal Instruction . . . . . . . . . . . . . . . . . 14

Danfoss ECtemp 532
Installation Guide4
1.1 Technical Specications
Operation voltage 220-240 V~, 50 Hz
Standby power consump-
tion Max 0.25 W
Relay:
Resistive load
Inductive load
Max 15 A / 3450 W @ 230 V
cos φ= 0.3 max 1A
Sensing units NTC 15kOhm at 25°C
Sensing values:
0 °C
25 °C
50 °C
42 kOhm
15 kOhm
6 kOhm
Hysteresis ± 0.4 °C
Ambient temperature -10 to +30 °C
Frost protection tempera-
ture 5 °C -
Temperature range
5-35°C room temperature
20-50°C oor temperature
limiter - default 35°C
Cable specication max 1x4 mm² or 2x2,5 mm²
Ball pressure temperature 75 °C
Pollution degree 2 (domestic use)

Danfoss ECtemp 532
5Installation Guide
Type 1C
Storage temperature -20 to +65 °C
IP class 31
Protection class Class II -
Dimensions 85 x 85 x 36 mm
Weight 90 g
The product complies with the EN/IEC Standard“Automatic
electrical controls for household and similar use”:
• EN/IEC 60730-1 (general)
• EN/IEC 60730-2-9 (thermostat)
1.2 Safety Instructions
Make sure the mains supply to the thermostat is turned o
before installation.
IMPORTANT: When the thermostat is used to control a
oor heating element in connection with a wooden oor or
similar material, always use a oor sensor and never set the
maximum oor temperature to more than 35°C.

Danfoss ECtemp 532
Installation Guide6
Please also note the following:
• The installation of the thermostat must be done by an
authorized and qualied installer according to local
regulations.
• The thermostat must be connected to a power supply
via an all-pole disconnection switch.
• The sensor is to be considered as live voltage. Have
this in mind if the sensor must be extended.
• Always connect the thermostat to continuous power
supply.
• Do not expose the thermostat to moisture, water,
dust, and excessive heat.
2 Mounting Instructions
Please observe the following placement guidelines:
Place the thermostat at a suitable height on
the wall (typically 80-170cm.).
In wet rooms, always place the thermostat
according to local regulation on IP classes.

Danfoss ECtemp 532
7Installation Guide
Do not place the thermostat on the inner
side of an exterior wall.
Always install the thermostat at least 50 cm.
from windows and doors.
Do not place the thermostat in a way that it
will be exposed to direct sunlight.
Note: A oor sensor enables a more
accurate temperature control and is recom-
mended in all oor heating applications
and mandatory under wooden oors to
reduce the risk of over-heating the oor.
• Place the oor sensor in a conduit in an appropriate
place where it is not exposed to sunlight or draft from
door openings.
• Equally distant and >2cm from two heating cables.
• The conduit should be ush with the oor surface -
countersink the conduit if necessary.
• Route the conduit to the connection box.
• The bending radius of the conduit must be min 50mm.

Danfoss ECtemp 532
Installation Guide8
Follow the steps below to mount the thermostat:
1. Open the thermostat:
devireg™550
3
5
6
24
20
30
40
50
• Press the release tab in the bottom of the ther-
mostat using a at object.
• Carefully detach the front cover.
• Carefully detach the frame.

Danfoss ECtemp 532
9Installation Guide
2. Connect the thermostat according to the connection
diagram.
IP31
-10T30
D532
Mains
220-240V~
Max. Load
15 (1) A
Sensor
NL NTC
N
LOAD
L
LOAD
The screen of the heating cable must be connected
to the earth conductor of the power supply cable by
using a separate connector.
Note: Always install the oor sensor in a conduit in
the oor.
3. Set the maximum oor temperature between 20° and
50°C by turning the screw with temperature indica-
tions in the upper left corner.
4. Mount and reassemble the thermostat:
• Fasten the thermostat to a ush-mounting box
or a surface-mounting box by driving the screws
through the holes in each side of the thermostat.
• Install the frame and front cover in the reverse
order of disassembly.
5. Turn on the power supply.

Danfoss ECtemp 532
Installation Guide10
3 Settings
How to change the minimum and maximum oor
temperatures
1. Remove the adjust-
ment button.
2. Move the pins to the
desired positions.
3. Put the adjustment
button back in place.
devireg™550
3
5
6
24
20
30
40
50
Note: Please be aware of the following:
• The oor temperature is measured where the oor
sensor is placed.
• The temperature of the bottom of a wooden oor can
be up to 10 degrees higher than the top.
• Floor manufactures often specify the max tempera-
ture on the top surface of the oor (usually 27-28˚C).
• By default, the maximum oor temperature is set to
35°C.
• Always use a oor sensor or a room + oor sensor
combination to control oor heating. Without a oor
sensor, the temperature control may be less accurate
and you risk overheating the oor.

Danfoss ECtemp 532
11Installation Guide
Thermal
resist-
ance
[m²K/W]
Examples of
ooring
Details Approximate
setting for
25 °C on top
surface of
oor
0,05 8 mm HDF based
laminate
> 800
kg/m³
28 °C
0,10 14 mm beech
parquet
650 -
800 kg/m³
31 °C
0,13 22 mm solid oak
plank
> 800
kg/m³
32 °C
< 0,17 Max. carpet thick-
ness suitable for
oor heating
acc. to
EN/IEC
1307
34 °C
0,18 22 mm solid r
planks
450 - 650
kg/m³
35 °C

Danfoss ECtemp 532
Installation Guide12
4 Warranty
A 2-year product warranty is valid for:
• thermostats: ECtemp 532.
Should you, against all expectations, experience a problem with your Danfoss
product, you will nd that Danfoss oers Danfoss warranty valid from the date
of purchase on the following conditions: During the warranty period Danfoss
shall oer a new comparable product or repair the product if the product is
found to be faulty by reason of defective design, materials or workmanship. The
repair or replacement.
The decision to either repair or replace will be solely at the discretion of Dan-
foss. Danfoss shall not be liable for any consequential or incidental damages
including, but not limited to, damages to property or extra utility expenses. No
extension of the warranty period following repairs undertaken is granted.
The warranty shall be valid only if the WARRANTY CERTIFICATE is completed
correctly and in accordance with the instructions, the fault is submitted to the
installer or the seller without undue delay and proof of purchase is provided.
Please note that the WARRANTY CERTIFICATE must be lled in, stamped and
signed by the authorized installer performing the installation (Installation
date must be indicated). After the installation is performed, store and keep the
WARRANTY CERTIFICATE and purchase documents (invoice, receipt or similar)
during the whole warranty period.
Danfoss warranty shall not cover any damage caused by incorrect conditions of
use, incorrect installation or if installation has been carried out by non-author-
ized electricians. All work will be invoiced in full if Danfoss is required to inspect
or repair faults that have arisen as a result of any of the above. The Danfoss
warranty shall not extend to products which have not been paid in full. Danfoss
will, at all times, provide a rapid and eective response to
all complaints and inquiries from our customers.
The warranty explicitly excludes all claims exceeding the
above conditions.
For full warranty text please use QR code

Danfoss ECtemp 532
13Installation Guide
WARRANTY CERTIFICATE
The Danfoss warranty is granted to:
Address Stamp
Purchase date
Serial number
of the product
Product Art. No.
*Connected
output [W]
Installation Date
& Signature
Connection Date
& Signature
*Not mandatory

Danfoss ECtemp 532
Installation Guide14
YEAR
WARRANTY
5 Disposal Instruction

Danfoss ECtemp 532
08091241 & AQ059186456572en-010102 Produced by Danfoss © 07/2022
Danfoss A/S
Nordborgvej 81
6430 Nordborg, Syddanmark
Denmark

ECtemp 532 ELKO
088L0035
Product documentation
Designed in Denmark for Danfoss A/S
*08091241*
5 703466 209004
dk
Thermostat
Floor/Room Sensor
220-240V~
50-60Hz~
+5 to +35°C
15A/3450W@230V~
IP 31
