Daniela DAN10MTP User manual

DAN10MTP
60CM BUILT IN FUNCTION
ELECTRIC OVEN
Appliance User Manual
danielaappliances.com.au
1

PAGE 2
P I02 9604 1226 E I [e-mail] W| danielaappliances.com.au
ACKNOWLEDGMENT
Thank you for purchasing our product. We hope you enjoy using the many features
and benefits it provides. Before using this product please study this entire Instruction
Manual carefully. Keep this manual in a safe place for future reference. Ensure that
other people using the product are familiar with these instructions as well.
WARNING
• When the oven is first switched on, it may give off an unpleasant smell. This is due to the
bonding agent used for the insulating panels within the oven. Please run up the new empty
product with the conventional cooking function, 250°C, 90 minutes to clean oil impurities
inside the cavity.
• During the first use, it is completely normal that there will be a slight smoke and odors. If it
does occur, you merely have wait for the smell to clear before putting food into the oven.
• Please use the product under the open environment.
• The appliance and its accessible parts become hot during use. Care should be taken to
avoid touching heating elements. Children less than 8 years of age shall be kept away unless
continuously supervised.
• If the surface is cracked, switch off the appliance to avoid the possibility of electric shock.
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervision.
• During use, the appliance becomes very hot. Care should be taken to avoid touching heating
elements inside the oven.
• Do not allow children to go near the oven when it is operating, especially when the grill is on.
• Ensure that the appliance is switched off before replacing the oven lamp to avoid the
possibility of electric shock.
• The means for disconnection must be incorporated in the fixed wiring in accordance with the
wiring specifications.
• Children should be supervised to ensure that they do not play with the appliance.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by person responsible for
their safety.

PAGE 3
P I 02 9604 1226 E [e-mail] W| danielaappliances.com.au
• Accessible parts may become hot during use. Young children should be kept away.
• An all-pole disconnection means must be incorporated in the fixed wiring in accordance with
the wiring rules.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
• Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass
since they can scratch the surface, which may result in shattering of the glass.
• Only use the temperature probe recommended for this oven.
• A steam cleaner is not to be used.
• The appliances are not intended to be operated by means of an external timer or separate
remote-control system.
• Appliance must not be installed behind a decorative door in order to avoid overheating.

PAGE 4
P I02 9604 1226 E I [e-mail] W| danielaappliances.com.au
SAFETY HINTS
• Do not use the oven unless you are wearing something on your feet. Do not touch the oven
with wet or damp hands or feet.
• For oven: Oven door should not be opened often during the cooking period.
• The appliance must be installed by an authorized technician and put into use. The producer
is not responsible for any damage that might be caused by defective placement, and
installation by unauthorized personnel.
• When the door or drawer of oven is open do not leave anything on it, you may unbalance
your appliance or break the door.
• Some parts of appliance may keep its heat for a long time; it is required to wait for it to cool
down before touching onto the points that are exposed to the heat directly.
• If you will not use the appliance for a long time, it is advised to plug it off.
FITTING THE OVEN INTO THE KITCHEN UNIT
Fit the oven into the space provided in the kitchen unit; it may be fitted underneath a work top
or into an upright cupboard. Fix the oven in position by screwing into place, using the two fixing
holes in the frame. To locate the fixing holes, open the oven door and look inside. To allow
adequate ventilation, the measurements and distances adhered to when fixing the oven.
IMPORTANT
If the oven is to work properly, the kitchen housing must be suitable. The panels of the kitchen
unit that are next to the oven must be made of a heat resistant material. Ensure that the glues of
units that are made of veneered wood can withstand temperatures of at least 120 ºC. Plastics or
glues that cannot withstand such temperatures will melt and deform the unit, once the oven has
been lodged inside the units, electrical parts must be completely insulated. This is a legal safety
requirement. All guards must be firmly fixed into place so that it is impossible to remove them
without using special tools. Remove the back of the kitchen unit to ensure an adequate current of
air circulates around the oven. The hob must have a rear gap of at least 45 mm.
DECLARATION OF COMPLIANCE
When you have unpacked the oven, make sure that it has not been
damaged in any way. If you have any doubts at all, do not use it: contact
a professionally qualified person. Keep packing materials such as plastic
bags, polystyrene, or nails out of the reach of children because these are
dangerous to children.

PAGE 5
P I 02 9604 1226 E [e-mail] W| danielaappliances.com.au
PRODUCT DESCRIPTION
K1Remind buttonK2
Stop button
Time button
Start button
Symbol Function description
Oven Lamp
Which enables the user to observe the progress of cooking without opening the door.
Oven lamp will light for all cooking functions. (except pyrolytic function and ECO function)
Defrost
The circulation of air at room temperature enables quicker thawing of frozen food, (without
the use of any heat). It's a gentle but quick way to speed up the defrosting time and
thawing of ready-made dishes and cream filled produce etc.
Bottom heater
A concealed element in the bottom of the oven provides heat. It is mainly used for
keeping food warm.
The temperature can be set within the range of 60-120°C. The default temperature is
60°C.
Conventional cooking
The top and bottom work together to provide convectional cooking. The temperature can
be set within the range of 50-250°C. The default temperature is 220°C.
Convention with fan
Combination of the fan and both heating element provides more even heat penetration,
saving up to 30-40% of energy. Dishes are lightly browned on the outside and still moist
on the inside. Note: This function is suitable for grilling or roasting big pieces of meat at
a higher temperature. The temperature can be set within the range of 50-250°C. The
default temperature is 220°C.

PAGE 6
P I02 9604 1226 E I [e-mail] W| danielaappliances.com.au
Radiant grilling
The inner grill element switches on and off to maintain temperature.
The temperature can be set within the range of 150-240°C. The default temperature is
210°C
Double grilling
The inside radiant element and top element are working.
The temperature can be set within the range of 150-240°C. The default temperature is
210°C
Double grilling with fan
The inside radiant element and top element are working with fan
The temperature can be set within the range of 150-240°C. The default temperature is
210°C
Convection
An element around the convection fan provides an additional source of heat for
convection style cooking. In convenction mode the fan automatically comes on to improve
air circulation within the oven and creates an even heat for cooking.
The temperature can be set within the range of 50-240°C. The default temperature is
180°C.
Pyrolytic function
When the function set to prolytic mode, LED display " PyR ".
The default temperature is 450°C . The timer can be set 1:30 or 2:00 hours.
For energy-saved cooking.
Cooking the selected ingredients in a gentle manner, and the
heat comes from the top and the bottom.

PAGE 7
P I 02 9604 1226 E [e-mail] W| danielaappliances.com.au
OPERATION INSTRUCTIONS
Clock Setting
After connecting the unit to the power, the symbols " 0:00 " will be visible on the display.
1. Press " ", the hour figures will flash.
2. Rotate " K2 " to adjust the hour figures, (time should be within 0--23).
3. Press " ", the minutes will flash.
4. Rotate " K2 " to adjust the minutes setting, (time should be within 0--59).
5. Press " " to finish the clock settings. " : " will flash, and the time will be illuminated.
Note:
The clock is 24 hours. After power on, if not set, the clock will show " 0:00 ".
Function Setting
1. Rotate " K1 " to choose the cooking function you require. The related symbol will illuminated.
2. Rotate " K2 " to adjust the temperature.
3. Press " " to confirm the start of cooking.
4. If step 2 is ignored, Press " " to confirm the start of cooking and the default time is 9 hours,
the default temperature will display on the LED.
NOTE:
1. The step quantities for the adjustment time of the knobs are as follow:
0--0:30min: step 1 minute 0:30--9:00hour: step 5 minutes
2. The step quantities for the adjustment of temperature is 5 C, and " " " " can not adjust
the temperature.
3. Rotate " K1 " to adjust the cooking time when cooking begins. Then press " " to confirm.
If " " not pressed within 3 seconds, the oven will revert back to the previous time to
continue cooking.
4. Rotate" K2 " to adjust the temperature when cooking begins. The related indicator will be
illuminated. Then press" " to start cooking. If " " not pressed in 3seconds, the oven will
revert back to the previous temperatrue to continue cooking.
Lamp Setting
1. Rotate " K1 " to select the relevant function, then the corresponding icon will be on.
2. Press " " button to start, " 0:00 " and lamp icon" " will light up, " : " will flash.

PAGE 8
P I02 9604 1226 E I [e-mail] W| danielaappliances.com.au
Inquiring Function
In the following states, you can use inquiring function, after 3 seconds return to the current state.
1. During working state, if the clock was set, press " " button to see the current time; if the
reminder function was set, press " " button to see the time of reminder.
2. In reminding state, if the clock was set, press " " button to see the current time.
3. In clock display state, if the reservation function was set, press " " button to see the time
of reservation.
Child lock Function
• To Lock: press " " and " " simultaneously for 3 seconds, there will be a long " beeping "
sound and the " " will be illuminated.
• Lock quitting: press " " and " " simultaneously for 3 seconds, there will be a long
" beeping " sound indicating the child-lock is released.
Note:
During working mode, if you want to stop cooking, press stop button quickly. Do not need to long
pressing on stop button, it is invalid.
Reminder Function
This function will help to remind you to start cooking in a certain time from 0:01 to 9:59. Only
when oven in standby mode, the reminder can be set. Follow below to set the reminder:
1. Press reminder setting button " ";
2. Rotate " K2 " to set the hour time of reminder. (Time should be within 0--9).
3. Press reminder setting button " " again;
4. Rotate " K2 " to set minute time of reminder. (Time should be within 0--59).
5. Press " " to confirm setting. The time will count down.
Note:
The oven buzzer will sound for 10 times after the time back to the zero hour.
You can cancel the reminder during setting by pressing the stop button; After the reminder has
been set, you can cancel it by pressing stop button twice.
Start/Pause/Cancel Function
1. If the cooking time has been set, press " " to start cooking. If the cooking is paused, press
" " to resume cooking.

PAGE 9
P I 02 9604 1226 E [e-mail] W| danielaappliances.com.au
2. During cooking process, press " " once to pause the cooking. Press " " twice to cancel
the cooking.
Energy-Saving Function
1. In waiting state and reminding state, press " " for three seconds, the LED display will go off
and set to energy-saving mode.
2. If no operation in 10 minutes under waiting state, the LED display will go off and go into
energy-saving mode.
3. Under the energy-saving mode, press any key or rotate any knob can quit the energy-saving
mode.
Pyrolytic Function
This function allows you to clean thoroughly the oven cavity.
1. Rotate " K1 " to select the pyrolytic function. LED will display " PyR ".
2. Press " " to confirm the cooking. And the default time is 2 hours, " PyR " will display on the
LED.
3. Rotate " K1 " to change the pyrolytic time. The timer can be set 1:30 or 2:00 hours.
Note:
1. When the oven door is not closed, pressing start button will be invalid, LED display " door ",
" PyR ".
2. When the oven's center temperature is highter than 320°C, pressing start button will be
invalid. The LED will display " CooL " and " PyR ". When the oven's center temperature is
lower than 200°C, press cancel button once , it will pause; press again, it will return to waiting
state. If highter than 200°C, press cancel button once, it will return to waiting state directly.
3. Open the door when the oven is working, the LED will display " door " and the buzzer will
sound continuously until the door was closed or press cancel button.
4. Before activating the pyrolytic cleaning function, remove any excessive spillage and make
sure that oven is empty. Do not leave anything inside it (e.g. pans, baking tray, dripping pan,
slider bracket etc.) as this could heavily damage them.
5. When finished pyrolytic cleaning, don't interrupt the power in an hour.

PAGE 10
P I02 9604 1226 E I [e-mail] W| danielaappliances.com.au
Reservation Function
1. To use reservation function, clock must be set in advance. Then, in the way of setting the
clock, reserved time that oven starts to cook must be set (a> Press reservation setting
button " "; b> Rotate " K2 " to set the hour time of reservation. Time should be within
0-23. c> Press reservation setting button " " again; d> Rotate " K2 " to set minute time of
reservation. Time should be within 0-59.), but don't press clock this time. Next, turn knob
" K1 " to chosse function.
2. Press " " button to set cooking time and temperature. Then turn knob " K1 " to adjust time,
and " K2 " to adjust temperature.
3. Press the " " button to finish cooking setting, and the clock will be on the screen
with reservation sign " " always lighting. But no other function signals are presented.
Reservation time can be checked by pressing " ". 3 seconds later the screen will show
clock again.
4. At the time of reservation, cooking will start automatically after a buzzing sound. The
reservation symbol " " will Put out, and other indicating signs will work normally.
Note:
1. Lamp, defrost, probe can't be reserved.
2. During the status of reservation, press cancel button once, time and temperature of
reservation menu will be shown with menu icon lighting constantly. Press again, screen
returns to clock, or press start button to return to reservation status.
3. Reminder function is invalid during reservation status.
Note
1. The oven lamp will be on for all functions. except pyrolytic function and ECO function.
2. Once the cooking programme has been set and the" " button is not pressed within 5
minutes, the current time will be displayed or turn back to waitting state. The setting program
will be invalid.
3. The buzzer will sound once when effectively pressed, if not effectively pressed there will be
no response.
4. The buzzer will sound five times to remind you when cooking has finished.

PAGE 11
P I 02 9604 1226 E [e-mail] W| danielaappliances.com.au
ACCESSORIES
Wire shelf
For grill, dishes, cake pan with items for roasting and grilling.
Slider bracket :
For cooking larger size food, these shelf support rails on the right and left
sides of the oven can be removed, dishes and tray can be put on the oven
floor, using functions as Radiant grilling, Double grilling, Double grill with fan.
NOTE: When placing dishes on the oven floor, please DO NOT use functions
with bottom heater to prevent heat gathering at bottom.
(only for specific models)
Universal pan:
For cooking large quantities of food such as moist cakes, pastries, frozen
food etc, or for collecting fat/ spillage and meat juices.
Telescopic runner:
Some models might with telescopic runners to facilitate the use of oven.
These telescopic runners and slider brackets could be disassembled by
unscrewing the screws used to fix it. After disassembled, dishes and tray can
be put on the oven floor, using funcstions as Radiant grilling, Double grilling,
Double grill with fan.
NOTE: When placing dishes on the oven floor, please DO NOT use functions
with bottom heater to prevent heat gathering at bottom.
(only for specific models)

PAGE 12
P I02 9604 1226 E I [e-mail] W| danielaappliances.com.au
SHELF PLACEMENT WARNING:
To ensure the oven shelves operate safely, correct placement of the shelves between the side rail
is imperative. Shelves and the pan only can be used between the first and fifth layers.
The shelves should use with the right direction, it will ensure that during careful removal of the
shelf or tray, hot food items should not slide out.
OR
USE OF ROTISSERIE ACCESSORIES
The rotisserie works in combination with the grill element to heat the food equally. At the same
time, it can guarantee the nutrition of the food.
12
OR

PAGE 13
P I 02 9604 1226 E [e-mail] W| danielaappliances.com.au
BULB REPLACEMENT
For replacement, process as follows:
1. Disconnect power from the mains outlet or switch off the circuit breaker of the unit's mains
outlet.
2. Unscrew the glass lamp cover by turning it counter-clockwise (note, it may be stiff) and
replace the bulb with a new one of the same type.
3. Screw the glass lamp cover back in place.
NOTE:
Only use 25-40W/220V-240V, T300°C halogen lamps.
SECURING THE OVEN TO THE CABINET
1. Fit oven into the cabinet recess.
2. Open the oven door.
3. Secure the oven to the kitchen cabinet with two distance holders " A " which fit the holes in
the oven frame and fit the two screws " B ".
VENTILATING OPENINGS
When cooking is finished or in pause state or in waiting state, if the oven's center temperature is
over 75 degree, the cooling fan will continue working for 15 minutes. Or when the oven's center
temperature becomes lower than 75 degree, the cooling fan will stop in advance.

PAGE 14
P I02 9604 1226 E I [e-mail] W| danielaappliances.com.au
CONNECTION OF THE OVEN
INSTALLATION
20
555
595
595
560
570
min. 560
606
600
80 250
100
Remark:
1. Only plus deviations are admissible for all dimension.
2. The cabinet is not include the power switch or socket.
NOTE:
The number of accessories included depends on the particular appliance purchased.

PAGE 15
P I 02 9604 1226 E [e-mail] W| danielaappliances.com.au
REMOVING THE DOOR FROM OVEN (OPTIONAL)
Disassembly of oven door components
1. To remove the door, open the door to the maximum angle. Then
pull the buckle at the door hinge backward.
2. Close the door to an angle approximately 30°. Hold the door with
one hand on each side.
Lift up and slowly pull the door out from the oven.
3. Open the door rotation bracket assembly, refer the action in the
following picture.
4. Lift up the door outer glass and pull it out, then take the door
middle glass out in the same way.
WARNING:
Don't forcibly pulled out the door and prevent the glass breakage
during the dismantling process.

PAGE 16
P I02 9604 1226 E I [e-mail] W| danielaappliances.com.au
WARNING:
The hinge springs could loose, causing personal injury.
WARNING:
Do not lift or carry the oven door by the door handle.
Recipes for ECO mode
Recipes Temperature (°C) Level Time (min) Pre-heat
Potato
Cheese
Gratin 180 1 90-100 No
Cheese
Cake 160 1 100-150 No
Meatloaf 190 1 110-130 No

PAGE 17
P I 02 9604 1226 E [e-mail] W| danielaappliances.com.au
CLEANING AND MAINTENANCE
For the sake of a good appearance and reliability, keep the unit clean. The modern design of the
unit facilitates maintenance to a minimum. The parts of the unit which come into contact with food
have to be cleaned regularly.
• Before any maintenance and cleaning, disconnect the power.
• Set all controls in the OFF position.
• Wait until the inside of the unit is not hot but only slightly warm-cleaning is easier than when
warm.
• Clean the surface of the unit with a damp cloth, soft brush or fine sponge and then wipe dry.
In case of heavy soiling, use hot water with non-abrasive cleaning product.
• For cleaning the glass of the oven door, do not use abrasive cleaners or sharp metal scrapers,
these can scratch the surface or lead to the glass being damaged.
• Never leave acidic substances (lemon juice, vinegar) on stainless steel parts.
• Do not use a high pressure cleaner for cleaning the unit. The baking pans may be washed in
mild detergent.
This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and
Electronic Equipment (WEEE).
By ensuring this product is disposed correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The symbol on the product indicates that this
product may not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must be carried
out in accordance with local environmental regulations for waste disposal. For more detailed
information about treatment, recovery and recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you purchased the product.

danielaappliances.com.au
P I02 9604 1226 E I[email protected] A I6/9 Hume Road, Smithfield NSW 2164
