User’s Manual
Portable Data Terminal
Model: M1000
SHIN CHUAN COMPUTER CO., LTD.
6F-2, 268, LianCheng Rd., ZhongHe Dist, New Taipei City 23553,
Taiwan(R.O.C)
TEL:[phone]. FAX:[phone]. http://www.sccltd.com.tw
NOV/07/2011 Ver:0.2

•Microsoft Windows CE is a registered trademark of Microsoft Corporation in the
United States and/or other countries.
•Wi-Fi is a registered trademark of the Wi-Fi Alliance.
•Bluetooth is a registered trademark of Bluetooth SIG, Inc.
•All other Trade Names referred to are the Servicemark, Trademark or Registered
Trademark of the respective manufacturers.
Information in this document is subject to change without notice. No part of this
document may be reproduced or transmitted in any form or by any means, electronic
or mechanical, for any purpose, without the express consent of SHIN CHUAN
COMPUTER CO., LTD. Copyright ©2011 by SHIN CHUAN COMPUTER CO., LTD.
All rights reserved
Revision History:
Date Description Remark

Table of Contents
Chapter 1. Introduction ..............................................................................1-1
1.1 About this Manual.................................................................1-1
1.2 User and Product Safety......................................................1-2
1.3 Battery Safety.......................................................................1-3
1.4 CE Statement.......................................................................1-4
1.5 FCC Statement.....................................................................1-8
1.5.1 Federal Communication Commission Interference
Statement.....................................................................1-8
1.6 Recycling & disposal instructions.........................................1-9
1.7 Regulatory information.........................................................1-9
1.8 Product Labeling................................................................1-10
1.9 System Specifications ........................................................1-12
1.10 Environment Standard......................................................1-13
1.11 Warranty and after service................................................1-13
Chapter 2. Getting Started .........................................................................2-1
2.1 Check the package...............................................................2-1
2.2 General View of the PDT......................................................2-2
2.2.1 M1000 general view.....................................................2-2
2.3 Charging the Battery Pack ...................................................2-4
2.3.1 Installing the battery pack ............................................2-4
2.3.2 Charging the battery pack with Cradle.........................2-5
2.4. Handling the Device............................................................2-6
2.4.1 Starting the Device.......................................................2-6
2.4.2 Power on / off...............................................................2-7
2.4.3 Calibration of the touch Screen....................................2-7
2.4.4 To mute the Sound for M1000......................................2-8
2.4.5 Using the Stylus...........................................................2-8
2.4.6 Using the M1000 Keypad.............................................2-8
2.4.9 Using the Earphone...................................................2-17
2.5 Navigating the Display........................................................2-17
2.5.1 Setting Time and Date ...............................................2-17
2.5.2 Entering the Data.......................................................2-18
2.5.3 The Command Bar.....................................................2-18
2.5.4 The Task Bar..............................................................2-19

2.5.5 The Soft Keypad........................................................2-19
2.5.6 Setting Up Wireless LAN ...........................................2-19
2.5.7 Reading barcodes, 1D laser version..........................2-25
2.5.8 Installing the MicroSD Card .......................................2-25
2.5.9 Help ...........................................................................2-26
2.6 Power management...........................................................2-26
2.6.1 Suspend Mode...........................................................2-26
2.6.2 Resuming...................................................................2-27
2.7 Resetting the Device..........................................................2-27
2.7.1 Software (Warm) Reset..............................................2-27
2.7.2 Cold Reset.................................................................2-28
Chapter 3. Setting.......................................................................................3-1
3.1 Introduction ..........................................................................3-1
3.2 Control Panel .......................................................................3-1
3.2.1 BarCode Controls ........................................................3-1
3.2.2 Backup/Restore .........................................................3-18
3.2.3 Bluetooth Device Properties ......................................3-20
3.2.4 Certificates.................................................................3-24
3.2.5 Date/Time ..................................................................3-26
3.2.6 Device Information.....................................................3-27
3.2.7 Dialing Properties.......................................................3-27
3.2.8 Display Properties......................................................3-29
3.2.9 Input Panel.................................................................3-31
3.2.10 Internet Options .......................................................3-32
3.2.11 Keyboard..................................................................3-35
3.2.12 Network and Dial-up Connections............................3-35
3.2.13 Owner......................................................................3-40
3.2.14 Password.................................................................3-41
3.2.15 PC Connection.........................................................3-42
3.2.16 Power.......................................................................3-43
3.2.17 Regional Settings.....................................................3-45
3.2.18 Remove Programs...................................................3-47
3.2.19 Storage Manager .....................................................3-47
3.2.20 Stylus.......................................................................3-49
3.2.21 System.....................................................................3-50
3.2.22 USB Function Driver Properties...............................3-52
3.2.23 Volume & Sounds Properties...................................3-52

3.3 Tap Start.............................................................................3-53
3.3.1 Security......................................................................3-53
3.3.2 Bluetooth....................................................................3-54
3.3.3 Boot Manager ............................................................3-55
3.3.4 Brightness..................................................................3-56
3.3.5 Device Power.............................................................3-57
3.3.6 Fn Key Manager ........................................................3-58
3.4 Taskbar and Start Menu .....................................................3-59
Chapter 4. Communication ........................................................................4-1
4.1 Installing & Setting Up Microsoft ActiveSync........................4-1
4.1.1 Installing Microsoft ActiveSync on the Host PC............4-1
4.1.2 Connecting Device to Host PC ....................................4-1
4.2 Using ActiveSync .................................................................4-1
4.2.1 Setting up a Partnership ..............................................4-1
4.2.2 ActiveSync File Synchronization..................................4-2
4.3 Networking...........................................................................4-3
Chapter 5. Software Applications..............................................................5-1
5.1 Introduction ..........................................................................5-1
5.2 Software Applications...........................................................5-1
5.2.1 Internet Explorer ..........................................................5-1
5.2.2 Microsoft WordPad ......................................................5-4
5.2.3 Remote Desktop..........................................................5-9
5.2.4 Windows Explorer......................................................5-10
5.3 Flash Disk ..........................................................................5-12
5.3.1 Saving to Flash..........................................................5-12
5.3.2 FlashDisk Location.....................................................5-12
5.3.3 FlashDisk Size...........................................................5-13

1-1 / 122
Chapter 1.Introduction
Congratulations on purchasing the M1000 Portable Data Terminal, a Microsoft
Windows® CE Rugged Device. Its special combination of features makes it
perfect for using in a wide range of applications. These features as:
Intel® XScaleTM PXA310 624 MHz 32 bits RISC Processor
Windows® CE 6.0 Operating System
128MB SDRAM & 256MB Flash ROM
Open Architecture: User Accessible MicroSD Slot
240 x 320, 2.8” Color TFT Display with Touch Panel
One Numeric-Alpha Keyboards with LED backlight
WLAN 802.11a/b/g Radio Support
Bluetooth V2.0+EDR, Class II Support
Integrated 1D Barcode Scanner or 2D Imager Scanner
1.1 About this Manual
The following chapters contained in this manual are:
Chapter 1 Introduction General information about the Device.
Chapter 2 Getting started Describe the basic use of the Device.
Chapter 3 Setting Provide basic instructions for customizing
the Device.
Chapter 4 Communication Describe how to use all kinds of
communication of the Device.
Chapter 5 Software Application Describe the installed applications on the
Device.

1-2 / 122
1.2 User and Product Safety
zDo not stare into the laser or LED beam directly or shine it into eyes.
zNever use strong pressure onto the screen or subject it to severe impact,
as the LCD panel could become cracked and possibility cause personal
injury. If the LCD panel is broken, never touch the liquid inside because
the liquid irritates the skin.
zAlthough the Device has passed the test of IP65 standard for water and
dust resistance, avoid prolonged exposure to rain or other concentrated
moisture. Such condition exceeds the IP65 standard, and could result in
water or other contaminants entering into the Device.
zUse only the original approved AC Adapter with the Device. Use of an
unapproved AC Adapter could result in electrical problems, or even cause
a fire or electrical shock to the user.
zDo not disassemble the Device. Servicing should be done by supplier only.
If the Device or accessories gets damaged due to wrong handling or
unauthorized repair, warranty is void. In case the warranty seals are
broken, warranty is void too.
zMake regularly back-up of all important data.
zUnder no circumstance will supplier be liable for any direct, indirect,
consequential or incidental damages baring out of the use or inability to
use the hardware and software and/or any data loss, even if supplier has
been informed about the possibility of such damages.
zLASER RADIATION DO NOT STARE INTO BEAM CLASS 2 LASER
PRODUCT

1-3 / 122
1.3 Battery Safety
CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type.
Dispose of Used Batteries According to the Instructions.
Lithium-ion battery packs might get hot, explode, ignite and/or cause serious
injury if exploded by abusive using. Please follow the safety warnings listed as
below:
zDo not throw the battery pack in fire. Do not expose the battery to high
temperatures.
zDo not connect the positive battery pack with negative battery pack to
each other with any metal object (like wire).
zDo not carry or store battery pack together with metal objects.
zDo not pierce the battery pack with nails or drills, strike the battery pack
with a hammer, step on the battery pack or otherwise expose it to strong
impacts, shocks or excessive force.
zDo not solder onto the battery pack.
zDo not expose battery pack to liquid or allow the battery contacts to get
wet.
zDo not disassemble or modify the battery pack. The battery pack contains
safety and protection measures, which, if damaged, may cause the
battery pack to generate heat, explode or ignite.
zDo not discharge the battery pack using any device except for the
specified device. When it is used in devices other than the specified
devices, the battery pack can be damaged or its life expectancy reduced.
If the device causes any abnormal current to flow, it may cause the battery
pack to become hot, explode or ignite and cause serious injury.
zIn the event the battery pack leaks and the fluid gets into one’s eye, do not
rub the eye. Rinse well with water and immediately seek medical care. If
left untreated, the battery fluid could cause damage to the eye.

1-4 / 122
1.4 CE Statement
This device complies with the essential requirements of the R&TTE Directive
1999/5/EC. The following test methods have been applied in order to prove
presumption of conformity with the essential requirements of the R&TTE
Directive 1999/5/EC:
- EN 60950-1: 2006 +A11:2009 +A1:2010
Safety of Information Technology Equipment
- EN 300 440-1 V1.6.1: 2010
- Electromagnetic compatibility and Radio spectrum Matters (ERM); Short
range devices; Radio equipment to be used in the 1 GHz to 40 GHz
frequency range; Part 1: Technical characteristics and test methods
- EN 300 440-2 V1.4.1: 2010
- Electromagnetic compatibility and Radio spectrum Matters (ERM); Short
range devices;Radio equipment to be used in the 1 GHz to 40 GHz
frequency range; Part 2: Harmonized EN covering the essential
requirements of article 3.2 of the R&TTE Directive
- EN 300 328 V1.7.1: 2006
- Electromagnetic compatibility and Radio spectrum Matters (ERM);
Wideband Transmission systems; Data transmission equipment operating
in the 2,4 GHz ISM band and using spread spectrum modulation
techniques; Harmonized EN covering essential requirements under article
3.2 of the R&TTE Directive
- EN 301 893 V1.5.1 (2008-12)
- Broadband Radio Access Networks (BRAN); 5 GHz high performance
RLAN; Harmonized EN covering the essential requirements of article 3.2 of
the R&TTE Directive
- EN 301 511 V9.0.2: 2003
- Global System for Mobile communications (GSM); Harmonized standard
for mobile stations in the GSM 900 and DCS 1800 bands covering essential
requirements under article 3.2 of the R&TTE directive (1999/5/EC)

1-5 / 122
- EN 301 489-1 V1.8.1 (2008-04)
- Electromagnetic compatibility and Radio Spectrum Matters (ERM);
ElectroMagnetic Compatibility (EMC) standard for radio equipment and
services; Part 1: Common technical requirements
- EN 301 489-17 V2.1.1 (2009-05)
- Electromagnetic compatibility and Radio spectrum Matters (ERM);
ElectroMagnetic Compatibility (EMC) standard for radio equipment; Part 17:
Specific conditions for Broadband Data Transmission Systems
- EN 301 489-7 V1.3.1 (2005-11)
- Electromagnetic compatibility and Radio spectrum Matters (ERM);
ElectroMagnetic Compatibility (EMC) standard for radio equipment and
services; Part 7: Specific conditions for mobile and portable radio and
ancillary equipment of digital cellular radio telecommunications systems
(GSM and DCS)
- EN 62209-2: 2010
- Human exposure to radio frequency fields from handheld and
bodymounted wireless communication devices — Human models,
instrumentation, and procedures Part 2: Procedure to determine the
specific absorption rate (SAR) for wireless communication devices used in
close proximity to the human body (frequency range of 30 MHz to 6 GHz)
- EN 62311: 2008
- Assessment of electronic and electrical equipment related to human
exposure restrictions for electromagnetic fields (0 Hz – 300 GHz)
This device is a 2.4 GHz wideband transmission system (transceiver),
intended for use in all EU member states and EFTAcountries, except in France
and Italy where restrictive use applies.
In Italy the end-user should apply for a license at the national spectrum
authorities in order to obtain authorization to use the device for setting up
outdoor radio links and/or for supplying public access to telecommunications
and/or network services.
This device may not be used for setting up outdoor radio links in France and in

1-6 / 122
some areas the RF output power may be limited to 10 mW EIRP in the
frequency range of 2454 – 2483.5 MHz. For detailed information the end-user
should contact the national spectrum authority in France.
0560
Česky
[Czech]
[Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shoděse
základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk
[Danish]
Undertegnede [fabrikantens navn] erklærer herved, at følgende udstyr
[udstyrets typebetegnelse] overholder de væsentlige krav og øvrige relevante
krav i direktiv 1999/5/EF.
Deutsch
[German]
Hiermit erklärt [Name des Herstellers], dass sich das Gerät [Gerätetyp] in
Übereinstimmung mit den grundlegenden Anforderungen und den übrigen
einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
Eesti
[Estonian]
Käesolevaga kinnitab [tootja nimi = name of manufacturer] seadme [seadme
tüüp = type of equipment] vastavust direktiivi 1999/5/EÜ põhinõuetele ja
nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
English Hereby, [name of manufacturer], declares that this [type of equipment] is in
compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
Español
[Spanish]
Por medio de la presente [nombre del fabricante] declara que el [clase de
equipo] cumple con los requisitos esenciales y cualesquiera otras disposiciones
aplicables o exigibles de la Directiva 1999/5/CE.
Ελληνική
[Greek]
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ [name of manufacturer] ΔΗΛΩΝΕΙ ΟΤΙ [type of equipment]
ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ
ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français
[French]
Par la présente [nom du fabricant] déclare que l'appareil [type d'appareil] est
conforme aux exigences essentielles et aux autres dispositions pertinentes de la
directive 1999/5/CE.
Italiano
[Italian]
Con la presente [nome del costruttore] dichiara che questo [tipo di
apparecchio] è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti
stabilite dalla direttiva 1999/5/CE.
Latviski
[Latvian]
Ar šo [name of manufacturer / izgatavotāja nosaukums] deklarē, ka [type of
equipment / iekārtas tips] atbilst Direktīvas 1999/5/EK būtiskajām prasībām un
citiem ar to saistītajiem noteikumiem.
LietuviųŠiuo [manufacturer name] deklaruoja, kad šis [equipment type] atitinka esminius

1-7 / 122
[Lithuanian] reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
Nederlands
[Dutch]
Hierbij verklaart [naam van de fabrikant] dat het toestel [type van toestel] in
overeenstemming is met de essentiële eisen en de andere relevante
bepalingen van richtlijn 1999/5/EG.
Malti
[Maltese]
Hawnhekk, [isem tal-manifattur], jiddikjara li dan [il-mudel tal-prodott]
jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm
fid-Dirrettiva 1999/5/EC.
Magyar
[Hungarian]
Alulírott, [gyártó neve] nyilatkozom, hogy a [... típus] megfelel a vonatkozó
alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym [nazwa producenta] oświadcza, że [nazwa wyrobu] jest zgodny z
zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami
Dyrektywy 1999/5/EC.
Português
[Portuguese
]
[Nome do fabricante] declara que este [tipo de equipamento] está conforme
com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]
[Ime proizvajalca] izjavlja, da je ta [tip opreme] v skladu z bistvenimi zahtevami
in ostalimi relevantnimi določili direktive 1999/5/ES.
Slovensky
[Slovak]
[Meno výrobcu] týmto vyhlasuje, že [typ zariadenia] spĺňa základné požiadavky
a všetky príslušné ustanovenia Smernice 1999/5/ES.
Suomi
[Finnish]
[Valmistaja = manufacturer] vakuuttaa täten että [type of equipment = laitteen
tyyppimerkintä] tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja
sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska
[Swedish]
Härmed intygar [företag] att denna [utrustningstyp] står I överensstämmelse
med de väsentliga egenskapskrav och övriga relevanta bestämmelser som
framgår av direktiv 1999/5/EG.

1-8 / 122
1.5 FCC Statement
1.5.1 Federal Communication Commission Interference
Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Operations in the 5.15-5.25GHz band are restricted to indoor usage only.
Radiation Exposure Statement:
The product comply with the FCC portable RF exposure limit set forth for an

1-9 / 122
uncontrolled environment and are safe for intended operation as described in
this manual. The further RF exposure reduction can be achieved if the product
can be kept as far as possible from the user body or set the device to lower
output power if such function is available.
Note: The country code selection is for non-US model only and is not available
to all US model. Per FCC regulation, all WiFi product marketed in US must
fixed to US operation channels only.
Please use only the specific belt-clips/holsters/accessories supplied by the
SHIN CHUAN COMPUTER CO., LTD. For this product or select a belt-clips,
holsters or similar accessories that have no metallic component in the
assembly and must provide at least 1.5 cm separation distance between the
device and the user's body.
Caution: SCC declares that M1000 ( FCC ID: TQ2-SC900PDT-BWG )is
limited in CH1~CH11 for 2.4GHz by specified firmware controlled
in U.S.A.
The FCC ID of M1000 is TQ2-SC900PDT-BWG
LED AND LASER SAFETY INFORMATION
zClass II LED/Laser Product
zDo not stare at the LED/Laser or shine into eyes
zDo not allow young children to use the product without adult supervision
zDo not replace/repair the LED/Laser, these are not user replaceable
zDo not shine the LED/Laser on a shiny reflective surface
zLASER RADIATION DO NOT STARE INTO BEAM CLASS 2 LASER
PRODUCT
1.6 Recycling & disposal instructions.
Do not throw this product in the home waste bin.
1.7 Regulatory information.
For CE, FCC, RoHS and other Document of Conformities, consult
the Contact Window of Shin Chuan Computer.

1-10 / 122
1.8 Product Labeling
The Device has several labels as shown in Figure 1-1 to 1-2.
A. M1000
Figure 1-1 Product Labeling (Front side view)
Label nr. Description
1 LCD panel protection film
Table 1-1 Front labeling

1-11 / 122
Figure 1-2 Product Labeling (Back side view)
Label nr. Description
2Laser radiation warning label
3 System and regulatory label
4 Serial / Configuration number
5 Warranty seal
6 Windows CE .NET label
7 FCC Statement
Table 1-2 Rear labeling

1-12 / 122
1.9 System Specifications
The M1000 detailed specifications as follows. Unless otherwise noted, all the
specifications are subject to change without prior notification.
Table 1-3 System Specification
M1000
Processor - Intel PXA310 624MHz 32 bits RISC CPU
Memory - 256MB Flash ROM
- 128MB SDRAM
Display - 240 x 320 2.8” TFT 256K Color LCD with LED
backlight
Audio - One mono speaker for system voice(on lower case)
Expansion Slot - One Micro SD slot
LED - One Dual-Color LED for Charger Indicator
- One Dual-Color LED for Scanner, Bluetooth and
WLAN Indicator
Radio Support - Wireless LAN: 802.11a/b/g
- Bluetooth: V2.0+EDR, Class II
Scan Engine - Opticon Laser (1D) Engine.
Communication
Ports - USB: Support USB v2.0 client. (Device and Cradle)
Power System
- Standard Li-Ion Battery Pack, 3.7VDC/1840mAh
- Advanced Smart Battery
- Built-in Battery Charger
- 3.7VDC/75mAh rechargeable backup battery
- One Battery Cover Magnet Sensor Switch
- Power Adapter: 100~240VAC, 50/60Hz Input ;
5VDC/1A Output
Keypad / Buttons
M1000
- One Power Button
- Three Barcode Scanner Buttons
- Four Navigation Buttons
- Four Application Buttons
- One 12-key Numeric Keypad

1-13 / 122
M1000
Dimensions and
Weight
- Dimensions:
L: 144 x 62 x 26.2~35.8 mm
- Weight: 240g with Standard Battery Pack(Approx.)
Color - Gray
Peripherals and
Accessories
- Optional: High-Capacity Li-Ion Battery Pack
(3.7VDC/2760mAh)
- Single Dock
Software - Microsoft Windows 6.0 Professional
1.10 Environment Standard
Table 1-4 Environment Standards
Operating Temperature 14oF ~ 122oF( -10oC ~ 50oC)
Storage Temperature -4oF ~ 158oF (-20oC ~ 60oC)
Humidity 5% ~ 95% (non-condensing)
Drop 4ft (1.2m) Drop onto Concrete
Water & Dust proof IP65 Certificated
Vibration MIL STD 810F
1.11 Warranty and after service
Should this Device be malfunctioned, please contact your original retailer
providing information about the product name, the serial number, and the details
about the problem.

2-1 / 122
Chapter 2.Getting Started
2.1 Check the package
Open the package and check all the parts are inside without shortage and
damage:
A. M1000
Figure 2-1 Inside the package
1. M1000 Terminal
2. Hand Strip
3. Stylus Cord.
4. Standard Battery Pack(3.7VDC/1840mAh)
5. Earphone
6. Stylus(Inserted onto Lowercase)

2-2 / 122
2.2 General View of the PDT
2.2.1 M1000 general view
Figure 2-2 M1000 front side view
Figure 2-3 M1000 back side view
