DARDANI ILLIRO User manual
USER MANUAL
ILLIRO
Thank you for purchasing our product.
We are dedicated to making high end technology
that enriches your life by not only sounding great,
but also having a unique and elegant design.
The vision of unifying science and art
is our inspiration
and we hope you enjoy our products
as much as we do.
If you have any questions concerning
our products, feel free to contact us:
With kind regards,
Dardani
Founder & CEO
5
5
Index
Notes
Box Content
Control Elements
LED Status Indicator
Bluetooth Connection
AUX Input
Speakerphone
3D Stereo Mode
Charging
Technical Data
Further Information
Page
06
07
08 - 09
10
11 - 12
12
13
14
15
16
17
6
Notes
1. Please use and store this device at
room temperature.
2. Avoid any external impacts or shocks.
3. Keep the speaker away from Benzine,
liquid chemicals, etc.
4. Keep the speaker away from strong
magnetic or electric fields.
5. Please avoid direct sunlight and heating
appliances.
6. Do not disassemble, repair or refit the
speaker on your own.
7. Please adjust the volume of the speaker
properly to avoid permanent hearing
damages.
8. Do not use the speaker while driving
car or motorcycle to avoid dangerous
accidents.
7
Box Content
1. ILLIRO Loudspeaker
2. Micro USB Cable
3. USB Power Adapter
4. Microfiber Cleaning Cloth
5. User Manual
8
Control Elements
9
Bluetooth Button
Volume Up
Volume Down
Speakerphone Button / Pause Botton
Power Button
LED Status Indicator
AUX Input Port
Micro USB Charging Port
Microphone
10
LED Status Indicator
Blue LED:
- LED blinks blue > pairing mode
- LED stays blue > connected
- LED blinks 2 times > maximum or minimum
volume is reached
Green LED:
- LED stays green > 3D Stereo Mode
Red LED:
- LED blinks slowly > battery is low
- LED stays red > battery is charging
- LED turns off > battery is fully charged
11
Bluetooth Connection
Short Press the POWER BUTTON to turn on or turn off the
speaker.
The LED blinks blue and indicates that the speaker is in pai-
ring mode.
Search for “Dardani ILLIRO“ on your bluetooth device to
connect the speaker. If needed, enter PIN code “0000“.
You hear a sound signal and the LED stays blue when your
device is connected succesfully.
Next time you turn on the speaker, it connects automatically
to the last connected device, if bluetooth is turned on.
Press the BLUETOOTH BUTTON to activate the pairing
mode for connecting a new device.
Press VOLUME UP or VOLUME DOWN to increase or
decrease the volume. You hear a sound signal when maxi-
mum or minimum volume level is reached.
Short press the TELEPHONE BUTTON to pause playback.
Short press again to resume.
12
AUX Input
Connect a device through the AUX input port of the speaker.
While playback, the LED stays blue.
Press VOLUME UP or VOLUME DOWN to increase or
decrease the volume. You hear a sound signal when maxi-
mum or minimum volume is reached.
Short press the TELEPHONE BUTTON to pause playback.
Short press again to resume.
Bluetooth Connection
The speaker turns off automatically, if unconnected through
bluetooth for 10 minutes.
If the speaker is connected to an iPhone, there is a battery
status indicator next to the bluetooth icon. You can also
control the iPhone‘s volume through the speaker and vice
versa.
13
Speakerphone
While in Bluetooth Mode, short press the TELEPHONE
BUTTON to pick up incoming calls.
Short press again to hang up.
Long press the TELEPHONE BUTTON to reject incoming
calls.
Double press the TELEPHONE BUTTON to redial the last
number called.
14
3D Stereo Mode
While playing music, press VOLUME UP and VOLUME
DOWN simultaneously until the music turns off for one
second.
The LED turns green and stays green while in 3D Stereo
Mode.
Press VOLUME UP and VOLUME DOWN simultaneously
to turn off 3D Stereo Mode and switch back to normal
mode.
The LED turns blue again.
15
Charging
The LED blinks red when battery is low.
Connect the speaker to a power outlet via the included
Micro USB cable and the USB power adapter to charge the
battery.
You can also charge the speaker through a power bank or
through a connection to a computer.
The LED stays red while charging.
The LED turns off when battery is fully charged.
Note:
Please charge the speaker during standby mode or in
power off status.
Charging Time: 2 - 4 hours
(depending on cable and adapter)
Playback Time: 8 - 10 hours
(depending on volume level)
16
Technical Data
Input voltage / current: DC 5V / 1000-2000mA
Speaker output: 2 x 10W
Bluetooth version: CSR 4.0
Battery type: Lithium Battery
Battery capacity: 2200mAh / 7.4V
S/N: >85dB
Impedance: 4Ω
Distortion: <2%
Sensibility: 600 ± 50mV
Frequency response: 60Hz - 18kHz
Bluetooth protocol: A2DP1.2 AVRCP1.4
Session protocol: HFPV1.6
Audio interface: Bluetooth, AUX
AUX input: 3.5mm
Charging time: 2 - 4 hours
Playback time: 8 - 10 hours
Working distance: ≥ 10m
Connect a device through the AUX input port of the speaker.
While playback, the LED stays blue.
Press VOLUME UP or VOLUME DOWN to increase or
decrease the volume. You hear a sound signal when maxi-
mum or minimum volume is reached.
Short press the TELEPHONE BUTTON to pause playback.
Short press again to resume.
17
Further Information
Weight: 645g
Size: 170 x 170 x 93 mm
Material: Stainless Steel, plastic
Color: Silver, black
www.dardani.audio
ENJOY TECHNOLOGY IN STYLE
