DARRELL HARP LAND-SPAN F/300 METAL User manual

FERTILIZER SPREADER OPERATOR’S MANUAL
F/300 METAL –F/500 METAL –F/500 POLY
DARRELL HARP ENTERPRISES,INC.
PO Box 140 / 819 4th Street NW
Red Bay, AL 35582
phone: [phone] •fax: [phone] •email: [e-mail] •www.darrellharp.com

INTRODUCTION
In this manual you will find the instructions for the operation
and maintenance of the Spreader –Seeder machine, as well
as the spreading tables designed as a guideline for spreading
various types of fertilizer and seeds.
ASSEMBLING
In the case that the spreader has been supplied unassembled
(Fig. A), it is necessary to follow these simple steps:
Join the two tubular parts of the frame and fit the proper bolts
without tightening them. Next, attach the lower part of the
frame and the spreading assembly, then fit the proper bolts
(Fig. A1). Finally, tighten all bolts.
Mount the hopper on the frame and make sure that the five
holes of the hopper are lined up with those of the frame. Place
the bolts and tighten them up, make sure that the hopper is
centered.
Connect the levers to the shutters and adjust them by placing
both levers on “0” position. In this position both shutters should
be completely closed.
Insert the agitator spindle in the vertical gear box shaft inside
the hopper (Fig. B).
In order to obtain the total spreading width of the fertilizer or
seeds, it is enough to move both levers 1 and 2 linked together
by a special pin (Fig. C).
To spread to the left side of the driver, simply remove the
linking pin from the two levers, lower lever 1 and leave lever 2
in “0” position (Fig. D).
To spread to the right side of the driver, simply remove the
linking pin from the two levers, lower lever 2 and leave lever 1
in the “0” position (Fig. E).
ADJUSTMENT OF THE SPREADER VANES
To obtain maximum uniformity of the spreading, regardless of
the different specific gravities of the fertilizer to be spread, it is
possible to adjust the spreading vanes on disc by moving
them into the most appropriate position (Fig. F).

MAINTENANCE AND LUBRICATION OF THE MACHINE
It is necessary to wash the equipment with water after use. Dry
and oil the shutters and slides. It is necessary to perform the
a.m. operations immediately after us. Replace the oil or grease
in the gearbox after the first 30 working hours and afterwards
do it every 250 hours of service. For replacing the oil, unscrew
the drain plug and wait until oil has drained completely. Turn
equipment upside down (as shown Fig. G) and refill gearbox
with about 0.25 kgs. of clean oil. Periodically grease the
universal joint shaft as well as the sliding parts.
HIGH STANDARDIZATION OF PARTS
All the components of the Land-Span spreader line are
interchangeable except the hoppers.
RECOMMENDATIONS
We recommend that this manual accompanies the machine if
it is resold a 2nd time.
WARNING
Before setting the machine into operation, make sure that all
the mechanisms run freely. Grease the cardan shaft and check
the oil level in the transmission housing. It is important to engage
PTO slowly.
END OF WORK PERIOD
At the end of the work day, empty the hopper and completely
wash all the mechanisms and hopper until all fertilizer particles
are completely removed.
To ensure a longer life of your spreader, at the end of the
season,
completely dismount the hopper and the distributor disc, wash
with hot water and soda and protect all non-painted parts
using protective grease or oil.
SAFETY PRECAUTIONS
All spreaders are especially dangerous to children and persons
who are not acquainted with the operation. We recommend
that no one without a full understanding of how the unit
operates be allowed use of the machine. The spreader should
be used only by responsible people who have carefully read
the Operator’s Manual and are entrusted to use the machine.
Before operating the machine be sure to understand this
manual. In case there is any part you do not understand well, or
a phase of the machines operation you do not understand,
please contact your local dealer or distributor.

SPREADING CHART FOR SEEDS
Seed
PTO Speed
(RPM)
Spreading
Width
in yards
Feed
MPH AND SPREADING RATES BY LBS. PER ACRE
1
2.5
5
7.5
10
Wheat
540
17.5
2
273
109
55
36
26
2.5
442
176
88
58
43
3
604
241
121
79
60
3.5
741
316
159
106
79
Oats
540
8.7
1.5
209
83
41
27
20
2
347
139
69
46
34
2.5
518
206
103
69
50
3
693
277
139
92
69
Rye
540
17.5
2
353
139
72
46
35
2.5
549
216
109
73
55
3
752
300
149
99
77
3.5
915
366
183
121
91
Barley
540
13.1
2.5
362
144
71
47
36
3
439
176
87
57
44
3.5
607
244
121
82
59
4
747
298
148
98
73
Rye Grass
540
5.5
1.5
50
20
11
7
6
2
142
57
30
20
14
2.5
299
120
61
40
30
Rape Seed
540
7.1
1.5
41
16
8
6
4
2
214
86
42
29
22
2.5
427
172
86
57
42
Red Clover
540
7.1
1.5
57
22
11
7
6
2
196
78
39
26
21
2.5
481
194
96
65
48

SPREADING CHART FOR FERTILIZERS
Fertilizer
Type
PTO
Speed
RPM
Spreading
width in
yards
MPH
Quantity to be spread in lb. per acre
at the forward speed indicated in the mph column
Feed
1.5
2
2.5
3
3.5
4
4.5
5
5.5
6
6.5
7
Coarse
Grain
Fertilizers
540
24
1
201
335
617
1016
1299
1602
1941
2372
2579
2900
3176
3574
2.5
95
145
247
415
518
642
791
937
1031
1164
1294
1453
5
52
70
129
205
261
321
394
473
523
602
662
745
7.5
35
54
86
139
176
219
261
324
344
402
433
493
10
21
35
64
107
134
171
201
241
259
299
329
375
Medium
Grain
Fertilizers
540
19.7
1
-
467
799
1141
1459
1807
2015
2341
2582
2827
2991
3289
2.5
-
176
330
468
599
741
827
948
1041
1143
1205
1334
5
-
105
171
237
303
377
419
479
526
582
610
672
7.5
-
73
113
163
199
253
287
326
355
401
415
457
10
-
54
82
116
155
189
207
246
268
295
312
341
Fine
Grain
Fertilizers
540
13.1
1
177
289
491
826
1066
1345
1576
1896
2134
2447
2659
2959
2.5
85
122
204
341
441
552
649
773
866
1001
1086
1188
5
46
61
108
179
225
281
325
397
443
500
542
604
7.5
30
41
94
122
153
194
221
264
298
341
370
405
10
17
30
53
88
114
137
169
200
235
257
283
299
Medium
Crystal
Fertilizers
540
8.75
1
335
553
1021
1655
2047
2624
3066
3563
4089
4538
4976
5482
2.5
117
222
418
670
827
1068
1238
1466
1644
1827
2000
2204
5
69
113
212
334
422
542
623
740
832
920
1003
1107
7.5
45
77
142
226
284
369
421
497
554
615
674
738
10
30
54
102
173
211
278
322
369
414
461
503
557
Calcium
Cyanamide
& Similar
540
11
1
278
760
1120
1659
2048
2672
2908
3391
4349
-
-
-
2.5
111
304
457
671
820
1008
1174
1362
1529
-
-
-
5
59
151
232
301
412
502
592
682
766
-
-
-
7.5
37
101
150
221
276
337
394
455
509
-
-
-
10
26
74
113
169
207
254
293
341
381
-
-
-
Ammonium
Sulphate
540
11
1
144
573
937
1411
1804
2230
2644
3103
3401
3820
4095
4584
2.5
62
227
378
565
726
899
1055
1245
1366
1533
1644
1835
5
29
116
191
285
367
450
526
639
680
767
820
922
7.5
23
74
124
192
244
299
353
424
458
515
551
616
10
15
59
95
145
182
225
266
312
341
383
416
460
Thomas
Meal
540
6.6
1
-
-
-
-
2294
5107
6763
7025
-
-
-
-
3.5
-
-
-
-
580
1295
1709
1760
-
-
-
-
7.5
-
-
-
-
293
544
855
882
-
-
-
-
12
-
-
-
-
198
433
562
591
-
-
-
-

Number
Description
Note
Code
1
Wheel for articulated agitator
Option
CZ_001228
2
Washer M8
CG_001009
3
Split Pin D.3 x 35
CV_001435
4
Wheel Holder for articulated agitator
Option
AS_001290
5
Screw TE M8 x 55
CV_001054
6
Self-Locking Nut M8
CD_001091
7
Agitator
CZ_001150
8
Screw M10 x 70
Option
CV_001065
9
Bushing
CZ_001134
10
Hopper
AS_001032 (F150)
AS_001031 (F250)
AS_001030 (F300)
AS_001028 (F400)
AS_001027 (F500)
GM_001168 (F500PVC)
11
Washer M10
CG_001010
12
Nut M10
CD_001004
13
Screw TTQST M10 x 25
CV_001350
14
L.H. Connecting Rod Guard
For Italy ONLY
SM_003004
15
R.H. Connecting Rod Guard
For Italy ONLY
SM_003005
16
Screw TE 8 x 20
CV_001002
17
Galvanized Washer 8 x 24
CG_001001
18
Nut M8
CD_001003
19
Seeger
CV_001439
20
R.H. Shutter
SM_001122
21
L.H. Shutter
SM_001123
22
Fan
SM_001117
23
Carter Disc
For Italy ONLY
AC_F10
24
Fan Holder Disc
AS_001019
25
Wingnut M8
CD_001050
26
Split Pin 8 x 40
CV_001411
27
Nut M10
CD_001004
28
Screw TE M10 x 110
CV_001069
29
Gearbox
CT_001007
30
Flat Guard
For EC ONLY
AC_F09
31
Self-Locking Nut M10
CD_001092
32
Screw TE M10 x 30
CV_001010
33
Screw TE M8 x 30
CV_001004
34
Handle
CZ_001219
35
L.H. Lever
SM_001090
36
Washer M12
CG_001011
37
Self-Locking Nut M12
CD_001093
38
Split Pin diam. 3 x 35
CV_001435
39
L.H. Connecting Rod
AS_001256
40
PTO Shaft
CA_001001 (EC)
CA_001002 (USA)
41
R.H. Lever
SM_001091
42
Lever Return
CZ_001045
43
R.H. Connecting Rod
AS_001219
44
Screw TE M8 x 40
CV_001006
45
Screw TE M12 x 80
CV_001078
46
Frame
AS_001033
47
Guard
SM_001038
48
Articulated Agitator
Option
AC_F04
49
Washer M10 x 30
Option
CG_001002
50
Filtering Net
Option
AC_F05
51
Filtering Net
Option
SM_003006
52
Hook
Option
SM_001032
53
Spring
CM_001016
