ADF Web HD67E00-2-A1 User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 1 of 31
User Manual
Revision 1.001
En lish
EtherCAT / Serial - Converter
(Order Code: HD67E00-2-A1, HD67E00-5-A1 )
For Website information:
www.adfweb.com?Product=HD67E00
For Price information:
www.adfweb.com?Price=HD67E00-2-A1
www.adfweb.com?Price=HD67E00-5-A1
Benefits and Main Features:
Very easy to confi ure
Triple Electrical isolation
Temperature ran e: -40°C/+85°C (-40°F/+185°F)
For other EtherCAT Slave products see also the followin link:
Converter EtherCAT Slave to
www.adfweb.com?Product=HD67E01 (Modbus Master)
www.adfweb.com?Product=HD67E02 (Modbus Slave)
www.adfweb.com?Product=HD67E03 (Modbus TCP Master)
www.adfweb.com?Product=HD67E04 (Modbus TCP Slave)
www.adfweb.com?Product=HD67E05 (BACnet Master)
www.adfweb.com?Product=HD67E06 (BACnet Slave)
www.adfweb.com?Product=HD67E07 (CAN)
www.adfweb.com?Product=HD67E08 (CANo en)
www.adfweb.com?Product=HD67E09 (DeviceNet Master)
www.adfweb.com?Product=HD67E10 (DeviceNet Slave)
www.adfweb.com?Product=HD67E11 (DMX)
www.adfweb.com?Product=HD67E12 (Ethernet)
www.adfweb.com?Product=HD67E14 (IEC61850 Client)
www.adfweb.com?Product=HD67E15 (IEC61850 Server)
www.adfweb.com?Product=HD67E16 (J1939)
www.adfweb.com?Product=HD67E17 (MQTT)
www.adfweb.com?Product=HD67E18 (NMEA0183)
www.adfweb.com?Product=HD67E19 (NMEA2000)
www.adfweb.com?Product=HD67E20 (OPC UA Client)
www.adfweb.com?Product=HD67E21 (OPC UA Server)
www.adfweb.com?Product=HD67E22 (PROFINET Master)
www.adfweb.com?Product=HD67E23 (PROFINET Slave)
www.adfweb.com?Product=HD67E24 (SNMP Manager)
www.adfweb.com?Product=HD67E25 (SNMP Agent)
www.adfweb.com?Product=HD67E26 (EtherNet/IP Master)
www.adfweb.com?Product=HD67E27 (EtherNet/IP Slave)
www.adfweb.com?Product=HD67E28 (S7comm Client)
www.adfweb.com?Product=HD67879 (IO-Link Master)
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 2 of 31
INDEX:
Pa e
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 7
CONFIGURATION 7
POWER SUPPLY 8
FUNCTION MODES 9
LEDS 10
ETHERCAT 11
RS232 12
RS485 13
ETHERNET 14
USE OF COMPOSITOR SW67E00 15
NEW CONFIGURATION / OPEN CONFIGURATION 16
SOFTWARE OPTIONS 17
SET COMMUNICATION 19
ETHERCAT SET ACCESS 21
ETHERCAT ESI FILE 23
UPDATE DEVICE 24
SERIAL PROTOCOL 26
MECHANICAL DIMENSIONS 28
ORDERING INFORMATIONS 29
ACCESSORIES 29
DISCLAIMER 30
OTHER REGULATIONS AND STANDARDS 30
WARRANTIES AND TECHNICAL SUPPORT 31
RETURN POLICY 31
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the followin document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top ri ht-hand corner of each pa e of this document.
With this “Document Code” o to web pa e www.adfweb.com/download/
and search for the correspondin code on the pa e. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
WARNING:
ADFweb.com reserves the ri ht to chan e information in this manual about
our product without warnin .
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belon to their respective
owners.
Revision Date Author Cha ter Descri tion
1.000 20/09/2021 Ff All First Release
1.001 23/06/2023 Ff All Revision

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 3 of 31
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated accordin to the instructions in the manual. When usin the device, le al and
safety re ulation are required for each individual application. The same applies also when usin accessories.
I NTENDED U SE
Machines and systems must be desi ned so the faulty conditions do not lead to a dan erous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissionin and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the followin symbol:
This symbol indicates that non-observance of the safety instructions is a dan er for people that could lead to serious injury or
death and / or the possibility of dama e.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or ive us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 4 of 31
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 5 of 31
CONNECTION SCHEME:
Figure 1a: Connection scheme for HD67E00 2 A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 6 of 31
Figure 1b: Connection scheme for HD67E00 5 A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 7 of 31
CHARACTERISTICS:
The HD67E00-x-A1 are EtherCAT / Serial - Converters.
It allows for the followin characteristics:
Isolation between EtherCAT – Serial – Power Supply;
Two-directional information between EtherCAT bus and Serial bus;
Mountable on 35mm Rail DIN;
Wide power supply input ran e: 8…24V AC or 12…35V DC;
Wide temperature ran e: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67E00 software on your PC in order to perform the followin :
Define the parameters of EtherCAT line;
Define the parameters of Serial line;
Define EtherCAT variables to read and write;
Define Modbus re isters to read and write from/to the Slaves;;
Export the ESI file for confi uration of EtherCAT Master;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 8 of 31
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consum tion [W/VA]
HD67E00-x-A1 3.5
HD67E00-x-A1
Caution:
Do n
ot reverse the olarity ower

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 9 of 31
FUNCTION MODES:
The device has ot two function modes dependin on the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal workin of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for uploadin the Project and/or Firmware.
For the operations to follow for the updatin , see ‘UPDATE DEVICE’ section.
Accordin to the functionin mode, the LEDs will have specific functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 10 of 31
LEDS:
The device has ot seven LEDs that are used to ive information about the functionin status.
The various meanin s of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device State ( reen) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in pro ress
2: EtherCAT comm. ( reen) It blinks when EtherCAT communication is runnin Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in pro ress
3: Serial comm. ( reen) It blinks when a Serial request is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in pro ress
4: Error state ( reen) ON: An error in the communication busses occurs
OFF: No errors are present
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in pro ress
5: EtherCAT state ( reen)
OFF: EtherCAT Master not connected
Blinking: EtherCAT Master is connectin
ON: EtherCAT Master is connected
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in pro ress
6: Ethernet1 link ( reen) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 11 of 31
ETHERCAT
EtherCAT (Ethernet for Control Automation Technolo y) is an Ethernet-based fieldbus system, invented by Beckhoff Automation.
The protocol is standardized in IEC 61158 and is suitable for both hard and soft real-time computin requirements in automation technolo y.
With EtherCAT, the standard Ethernet packet or frame (accordin to IEEE 802.3) is no lon er received, interpreted, and copied as process
data at every node. The EtherCAT slave devices read the data addressed to them while the tele ram passes throu h the device, processin
data "on the fly". In other words, real-time data and messa es are prioritized over more eneral, less time-sensitive or heavy load data.
The converter has two EtherCAT ports, one is used as Input port (Connector6) and it will receive the incomin messa es from the Master,
the other is used as Output port (Connector7) and i twill forward the messa es to the others nodes of the network.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 12 of 31
RS232:
The connection from RS232 socket to a serial port (example one from a personal computer) must be made with a NULL MODEM cable (a
serial cable where the pins 2 and 3 are crossed).
It is recommended that the RS232 cable not exceed 15 meters.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 13 of 31
RS485:
For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in fi ure.
The maximum len th of the cable should be 1200m (4000 feet).
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 14 of 31
ETHERNET:
The updatin of the converter must be made usin Connector8 of the HD67E00-x-A1 with at least a Cate ory 5E cable. The maximum len th
of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To
connect the device to an Hub/Switch is recommended the use of a strai ht cable, to connect the device to a PC/PLC/other is recommended
the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 15 of 31
USE OF COMPOSITOR SW67E00:
To confi ure the Converter, use the available software that runs with Windows called SW67E00. It is downloadable on the site
www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (XP, Vista, Seven, 8, 10, 11; 32/64bit).
When launchin the SW67E00, the window below appears (Fi . 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure 2: Main window for SW67E00

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 16 of 31
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s confi uration.
A device’s confi uration can also be imported or exported:
To clone the confi urations of a pro rammable “EtherCAT Slave / Serial - Converter” in
order to confi ure another device in the same manner, it is necessary to maintain the
folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “O en Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 17 of 31
SOFTWARE OPTIONS:
By pressin the “Settings” ( ) button there is the possibility to chan e the lan ua e of the software and check the updatin s for the
compositor.
In the section “Lan ua e” it is possible to chan e the lan ua e of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatin s of the software compositor in ADFweb.com website.
Checkin the option “Check Software U date at Start of Program”, the
SW67E00 checks automatically if there are updatin s when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 18 of 31
In the section “Software Settin s”, it is possible to enable/disable some
keyboard’s commands for an easier navi ation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 19 of 31
SET COMMUNICATION:
This section define the fundamental communication parameters of two buses, EtherCAT and
Serial.
By Pressin the “Set Communication” button from the main window for SW67E00 (Fi . 2)
the window “Set Communication” appears (Fi . 3).
The means of the fields for “Ethernet Connection” are:
In the field “Device Name (Hostname)” the Hostname to assi n to the converter is
defined;
If the field “Obtain an IP Address Automatically (DHCP for Cable Connection)”
is checked, DHCP for LAN connection is enabled;
If the field “Enable DNS” is checked, DNS protocol is enabled;
In the field “Primary DNS” the IP Address of the primary DNS server is defined;
In the field “Secondary DNS” the IP Address of the secondary DNS server is defined;
If the field “Clear Data on EtherCAT fault” is checked, the data on Serial are set to
‘0’ if the EtherCAT communication is in error.
The means of the fields for “EtherCAT Slave” are:
In the field “Revision Number” the revision number of the converter is defined;
In the field “Slave Name” the name of the converter is defined;
In the field “Node Address” the ID of the converter is defined.
The means for the fields for the “Serial” are:
In the field “Serial” the serial port to use is defined (RS232 or RS485);
In the field “Baudrate” the baudrate for the serial line is defined;
In the field “Parity” the parity of the serial line is defined;
In the field “Sto Bits” the number of Stop Bits of the serial line is defined
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manua
l
EtherCAT Slave / Serial
Document code: MN67E00_ENG Revision 1.001 Pa e 20 of 31
The means of the fields for “Ethernet” are:
In the fields “IP Address” the IP address for Ethernet side of the converter is defined;
In the fields “SubNet Mask” the SubNet Mask for Ethernet side of the converter is defined;
In the fields “Gateway” the default ateway of the net is defined. This feature can be enabled or disabled pressin the Check Box
field. This feature is used for oin out of the net.
