Data Video DAC-8PA User manual

DAC-8PA

2
Table of Contents
FCC COMPLIANCE STATEMENT..............................................4
WARNINGS AND PRECAUTIONS ............................................4
WARRANTY ...........................................................................5
STANDARD WARRANTY ............................................................5
THREE YEAR WARRANTY ..........................................................6
DISPOSAL ..............................................................................6
1. INTRODUCTION .................................................................8
2. CONNECTION AND CONTROLS...........................................9
2.1 FRONT PANEL...................................................................9
2.2 REAR PANEL ..................................................................10
3. HOW TO SET THE SMPTE/EBU STANDARD FOR THE AUDIO
LEVEL...................................................................................12
4. DIMENSIONS ...................................................................13
5. SPECIFICATIONS...............................................................14
SERVICE & SUPPORT............................................................16

3
Disclaimer of Product & Services
The information offered in this instruction manual is intended as a guide only. At all times, Datavideo
Technologies will try to give correct, complete and suitable information. However, Datavideo
Technologies cannot exclude that some information in this manual, from time to time, may not be
correct or may be incomplete. This manual may contain typing errors, omissions or incorrect
information. Datavideo Technologies always recommend that you double check the information in this
document for accuracy before making any purchase decision or using the product. Datavideo
Technologies is not responsible for any omissions or errors, or for any subsequent loss or damage
caused by using the information contained within this manual. Further advice on the content of this
manual or on the product can be obtained by contacting your local Datavideo Office or dealer.

4
FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Warnings and Precautions
1. Read all of these warnings and save them for later reference.
2. Follow all warnings and instructions marked on this unit.
3. Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this unit in or near water.
5. Do not place this unit on an unstable cart, stand, or table. The unit may fall, causing
serious damage.
6. Slots and openings on the cabinet top, back, and bottom are provided for
ventilation. To ensure safe and reliable operation of this unit, and to protect it
from overheating, do not block or cover these openings. Do not place this unit on a
bed, sofa, rug, or similar surface, as the ventilation openings on the bottom of the
cabinet will be blocked. This unit should never be placed near or over a heat
register or radiator. This unit should not be placed in a built-in installation unless
proper ventilation is provided.
7. This product should only be operated from the type of power source indicated on
the marking label of the AC adapter. If you are not sure of the type of power
available, consult your Datavideo dealer or your local power company.
8. Do not allow anything to rest on the power cord. Do not locate this unit where the
power cord will be walked on, rolled over, or otherwise stressed.
9. If an extension cord must be used with this unit, make sure that the total of the
ampere ratings on the products plugged into the extension cord do not exceed the
extension cord rating.
10. Make sure that the total amperes of all the units that are plugged into a single wall
outlet do not exceed 15 amperes.
11. Never push objects of any kind into this unit through the cabinet ventilation slots, as
they may touch dangerous voltage points or short out parts that could result in risk
of fire or electric shock. Never spill liquid of any kind onto or into this unit.
12. Except as specifically explained elsewhere in this manual, do not attempt to service
this product yourself. Opening or removing covers that are marked “Do Not
Remove” may expose you to dangerous voltage points or other risks, and will void
your warranty. Refer all service issues to qualified service personnel.

5
13. Unplug this product from the wall outlet and refer to qualified service personnel
under the following conditions:
a. When the power cord is damaged or frayed;
b. When liquid has spilled into the unit;
c. When the product has been exposed to rain or water;
d. When the product does not operate normally under normal operating
conditions. Adjust only those controls that are covered by the operating
instructions in this manual; improper adjustment of other controls may result in
damage to the unit and may often require extensive work by a qualified
technician to restore the unit to normal operation;
e. When the product has been dropped or the cabinet has been damaged;
f. When the product exhibits a distinct change in performance, indicating a need
for service.
Warranty
Standard Warranty
Datavideo equipment is guaranteed against any manufacturing defects for
one year from the date of purchase.
The original purchase invoice or other documentary evidence should be
supplied at the time of any request for repair under warranty.
The product warranty period beings on the purchase date. If the purchase
date is unknown, the product warranty period begins on the thirtieth day
after shipment from a Datavideo office.
All non-Datavideo manufactured products (product without Datavideo logo)
have only one year warranty from the date of purchase.
Damage caused by accident, misuse, unauthorized repairs, sand, grit or
water is not covered under warranty.
Viruses and malware infections on the computer systems are not covered
under warranty.
Any errors that are caused by unauthorized third-party software installations,
which are not required by our computer systems, are not covered under
warranty.
All mail or transportation costs including insurance are at the expense of the
owner.
All other claims of any nature are not covered.

6
All accessories including headphones, cables, batteries, metal parts, housing,
cable reel and consumable parts are not covered under warranty.
Warranty only valid in the country or region of purchase.
Your statutory rights are not affected.
Three Year Warranty
All Datavideo products purchased after July
1st, 2017 qualify for a free two years
extension to the standard warranty,
providing the product is registered with Datavideo within 30 days of
purchase.
Certain parts with limited lifetime expectancy such as LCD panels, DVD
drives, Hard Drive, Solid State Drive, SD Card, USB Thumb Drive, Lighting,
Non-PCIe Card and third party provided PC components are covered for 1
year.
The three-year warranty must be registered on Datavideo's official website
or with your local Datavideo office or one of its authorized distributors
within 30 days of purchase.
Disposal
For EU Customers only - WEEE Marking
This symbol on the product or on its packaging indicates that this
product must not be disposed of with your other household waste.
Instead, it is your responsibility to dispose of your waste
equipment by handing it over to a designated collection point for
the recycling of waste electrical and electronic equipment. The
separate collection and recycling of your waste equipment at the
time of disposal will help to conserve natural resources and
ensure that it is recycled in a manner that protects human health and the environment.
For more information about where you can drop off your waste equipment for recycling,
please contact your local city office, your household waste disposal service or the shop
where you purchased the product.

7
CE Marking is the symbol as shown on the left of this page. The
letters "CE" are the abbreviation of French phrase "Conformité
Européene" which literally means "European Conformity". The
term initially used was "EC Mark" and it was officially replaced by
"CE Marking" in the Directive 93/68/EEC in 1993. "CE Marking" is
now used in all EU official documents.

8
1. Introduction
The DAC-8PA SDI to HDMI Converter allows users to convert the SDI signal up
to 1080p50/60 to the HDMI signal for easy connecting to the devices with
HDMI signal and the professional SDI video devices.
The DAC-8PA provides one SDI input, one SDI output and one HDMI output.
Moreover, the audio signal can be de-embedded from the SDI input signal for
the audio source of the analog audio outputs.
The DAC-8PA HD/SD-SDI to HDMI converter is suitable for many broadcasting
and professional AV applications.
Features
Supports 1080p50/60 Input Signal
Supports Re-Clocking Function
Supports Automatic Input Signal Detection
Supports HDMI Deep Color
Provides one SDI loop-thru Output and one HDMI Output Interface
Supports Stereo Audio Output
Aluminum appearance design which is rugged and durable

9
2. Connection and Controls
2.1 Front Panel
HD/SD - SDI Input and Output (bypass)
The SDI technology is suitable for long-distance video
signal transmission in professional applications.
The BNC connector on the left side: HD/SD-SDI Input.
The BNC connector on the right side: Loop Through
Output.
F/W UPGRADE
This USB interface is used for firmware update only.

10
2.2 Rear Panel
DC Power Connector
This connector allows users to connect a 12V/500mA
power adapter to the DC power interface.
The connection can be secured by screwing the outer
fastening ring of the DC In plug to the socket.
HDMI OUT
HDMI Output Interface

11
RCA Output
Unbalanced left and right channel audio outputs.
The audio signal can be de-embedded from the SDI
input signal and then can be output from this AUDIO
OUT interface.

12
3. How to set the SMPTE/EBU Standard for the
Audio Level
The DAC-8PA allows users to set the SMPTE/EUB standard of the audio output
signal from Audio OUT. Please follow following steps for further setting.
1. Please install the software “DAC-8PA FW TOOL.exe” in your PC. After the
installation is finished, please open the software.
2. Please use a USB cable to connect from your PC to the MINI USB interface
of the DAC-8PA.
3. Please connect the DAC-8PA to the power source.
4. Please press the “Read” key and then the software version will be shown.
5. Please press the SMPTE or EUB key to set your desired Audio Level standard.

13
4. Dimensions
All measurements in millimeters (mm)

14
5. Specifications
Input
3G/HD/SD-SDI x 1
Output
HDMI 1.3 x 1, 3G/HD/SD-SDI x 1 (Loop-Thru)
RCA x 2 (Unbalanced Audio L/R)
Supported HDMI
Output Formats
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
525i59.94 NTSC, 625i50 PAL
Video Processing
SDI : YUV4:2:2
HDMI : YUV4:4:4
Video Bandwidth
[SDI][2.97Gpbs & 2.975/1.001Gbps]
[HDMI] [6.75Gbps]
Supported HDMI
Standard
HDMI 1.3
Automatic 3G/HD/SD-
SDI Signal Detection
Available
Output Impedance
(SDI)
75
Eye Pattern
Characteristics
Extra low alignment jitter 0.05UI at HD

15
Audio Extracting
Supported
Supports 2 channel only.
SDI Re-clock
Supported
Operating Temp.
Range
0°C to 40°C (32°F to 104°F)
Storage Humidity
10% to 80% (Non-condensing)
Dimensions(mm)
111.8 x 85 x 45.2
Weight
0.35kg
Power
DC 7 ~ 17V

https://www.datavideo.com/product/DAC-8PA
Sept.-16.2019 Ver:E1
Datavideo Technologies Co., Ltd. All rights reserved 2020
