Datexel DAT 1111 User manual

Via monte Nero, 40/B – 21049 TRADATE (VA) ITALY
P one: [phone] Fax:[phone] - e-mail:[email protected] - www.datexel.it
Low profile, dip-switch
programmable and linearised
transmitter for Pt100
DAT 1111 DAT 1111
GENE AL DESC IPTION
T e transmitter DAT 1111 is designed to provide on output a 4÷20 mA current loop linearised signal proportional wit t e temperature c aracteristic provided
from t e Pt100 connected to its input.
It is possible to connect on input bot Pt100 3 wires and Pt100 2 wires sensors.
It is possible to program t e input range by t e 4 way DIP-switc es available removing t e protection plastic cap located on t e top of device (see t e section
“Input ranges table”).
T e regulation of t e zero and full-scale value are made using t e ZERO and SPAN potentiometers.
T e DAT 1111 is in compliance wit t e Directive 2004/108/EC on t e Electromagnetic Compatibility.
It is oused in a self-extinguis plastic enclosure suitable for DIN B in- ead mounting.
Moreover ( by proper mounting kit ) it is possible to mount t e DAT 1111 on DIN rail.
FEATU ES
- Input from Pt100
- Input scale in °C or °F
- Zero and Span programmable by DIP-switches
- 4÷20 mA current loop linearised output
- Good accuracy and linearity
- EMC compliant – CE mark
- Suitable for DIN B in-head mounting
- Option for DIN rail mounting in compliance with EN 50022 (DIN AIL Option)
USE INST UCTIONS
T e transmitter DAT 1111 must be powered by a direct voltage between 10 to 32 V applied to t e terminals +V and -V.
T e 4÷20 mA output signal is measurable in t e power loop as s own in t e section “Output/Power supply connections”; Rload is t e input impedance of
instruments on t e current loop; to obtain a correct measure, t e value of Rload will be calculated as function of t e power supply value ( see section “ Load
c aracteristic”).
T e input connections must be made as s own in t e section "Input connections".
T e Pt100 t ree wires must be connected to t e terminals 1 and 3, connecting t e t ird wire to t e terminal 2.
T e Pt100 two wires must be connected to t e terminals 1 and 3, connecting t e terminal 2 and 3.
T e configuration of t e input range must be made by DIP-switc es. To configure t e device refer to t e section “Input ranges table”.
Regulate t e output value by t e ZERO and SPAN regulations.
To calibrate and install t e transmitter refer to sections " DAT1111: configuration and calibration" and “Installation Instructions”.
TECHNICAL SPECIFICATIONS (Typical at 25 °C and in nominal conditions)
Input
Sensor type RTD Pt100 in according to IEC 60751
Minimum input Span 50 °C (122 °F)
Zero programmability From -50 °C (-58 °F) up to + 50 °C (122 °F)
Span programmability From 50 °C (122 °F) up to 650 °C (1202 °F)
Excitation current 1 mA typ.
Line resistance influence 0.05 % of f.s./o m (100 o m max. balanced per wire)
Output
Output type 4 ÷ 20 mA on current loop
Sensor interruption signalling Positive out of scale (> 20 mA)
Maximum output signal 35 mA
Load resistance (Rload) see section “Load c aracteristic”
Response time (from 10 to 90 % of f.s.) 300 ms
Warm-up time 3 min.
Performances
Calibration error ± 0.1 % of f.s.
Linearity error (*) ± 0.15 % of f.s.
T ermal drift 0.03 % of f.s./°C
Power supply voltage (**) 10÷32 Vdc
Electromagnetic Compatibility (EMC)
( for industrial environments ) Immunity: EN 61000-6-2; Emission : EN 61000-6-4.
Operating Temperature -20 ÷ 70 °C
Storage Temperature -40 ÷ 85 °C
Humidity (not condensed) 0 ÷ 90%
Weig t about 35 g.
(*)inclusive of ysteresis, linearisation error and power supply voltage variation
(**)internally protected against reverse polarity.

Datexel s.r.l. reserves its rig ts to modify t e c aracteristics of its products wit out warning at any time .
DAT 1111: CONFIGU ATION AND CALIB ATION
1) Calculate t e difference between t e full-scale and t e begin scale values
(Span).
2) Refer to t e “Input range table” and determine in t e column " SPAN "
w ere t e calculated value is included. Determine in t e column “ZERO”,
t e range of value w ere t e zero scale value is included. In t e line
obtained wit t e combination, is s own t e DIP-switc es configuration.
3) Remove t e protection plastic cap.
4) Set t e switc es as indicated.
5) Connect on input a Pt100 simulator or a fixed resistance value
corresponding to t e resistive value provided from t e Pt100 sensor at t e
selected temperatures.
6) Set t e simulator at t e minimum temperature or connect a fixed
resistance value corresponding to t e zero value.
7) Regulate t e output value at 4 mA by t e “ZERO” potentiometer .
8) Set t e simulator at t e maximum temperature or connect a fixed
resistance value corresponding to t e span value.
9) Regulate t e output value at 20 mA by t e “SPAN” potentiometer .
10) Repeat t e operation from t e step 6 to t e step 9 until t e output
values are accurate ( typical 3 attempts required ).
Example of configuration: -30/200 °C.
Span => 200°C - (-30°C) = 230°C;
Input switc es configuration: Off, Off, Off, Off.
INSTALLATION INST UCTIONS
The device DAT 1111 is suitable for direct DIN B in-head mounting. The
transmitter must be fixed inside the probe by the proper kit.
By apposite stirrup, provided on request, it is possible to mount the device
on DIN rail in compliance with EN-50022. It is necessary to install the
device in a place without vibrations; avoid to routing conductors near
power signal cables .
ED.02.07 EV.02
INPUT ANGE TABLE
DAT1111: CONNECTIONS
INPUT CONNECTIONS
POWE SUPPLY/OUTPUT CONNECTIONS
+
-
load
Iout
10÷32 Vdc
+
Pt100 3 wires
+V
-V
Pt100 2 wires
Pt100
3
2
1
Pt100
2
3
1
Working
Area
0
1K
700
400
10 18 24 32 V
Ohm LOAD CHA ACTE ISTIC
DIMENSIONS (mm) & EGULATIONS
21 -V 3
ZERO SPAN
DIN rail mounting (DIN AIL Option)
Fixing screw
Stirrup
HOW TO O DE
T e DAT1111 is provided as requested on t e Customer's order.
In case of t e configuration is not specified, t e parameters must be set by t e
user.
T e mounting kit for DIN rail is provided only on request wit code DIN RAIL.
O DE CODE EXAMPLE: DAT1111 0÷200 °C/°F – DIN AIL Option
Input range Unit of measure
DIN rail
mounting KIT
Fixing screws
DIN B In-head mounting
Sensor cables
4÷20 mA cables
Dip-switches available removing
protection plastic cap
7
4 3 1 7
3 3
Z E R O S P A N
O N
1
9
= DIP SWITCH : " ON"
SPAN ZE O
SWITCH
INPUT
1 2 34
< 80°C (176°F)
80÷200°C(176÷392°F)
200÷250°C(392÷482°F) - 50÷50°C(-58÷122°F)
- 50 ÷ -15°C(-58÷5°F)
- 15 ÷ 15°C(5÷59°F)
15 ÷ 50°C(59÷122 °F)
< 80°C (176°F)
< 80°C (176°F)
80÷200°C(176÷392°F)
80÷200°C(176÷392°F)
250÷650°C(482÷1202°F) - 50÷50°C(-58÷122°F)
- 50 ÷ -15°C(-58÷5°F)
- 15÷ 15°C(5÷59°F)
15 ÷ 50°C(59÷122 °F)
