DaVinci Category 1 User manual

Category 1
Owner’s Manual
WARNING:
If the information in these instructions is not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas
Tested and Listed by
Report # 100884872PRT-001
ANSI Z21.50b-2014 /
CSA 2.22b-2014
Gas-Fired Domestic and Commercial Heating
Equipment “Vented Gas Fireplace”
This appliance may be installed in an aftermarket, permanently located, manufactured home
(USA only) or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This
appliance is not convertible for use with other gases, unless a certified kit is used.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Travis Industries, Inc. 12521 Harbour Reach Dr., Mukilteo, WA 98275 www.travisproducts.com
Copyright 2015, T.I. $10.00 4150210 100-01384

2 Introduction
© Travis Industries 4140805 100-01384
Overview
This manual details the DaVinci category 1
fireplace.
Listing Details
This appliance was listed by Intertek (Warnock
Hersey) to ANSI Z21.50b-2014 / CSA 2.22b-2014.
The listing label is chained to the appliance near
the glass frame. A copy is shown to the right.
Massachusetts Approval
This manual has been submitted to the
Massachusetts Board of State Examiners of
Plumbers and Gas Fitters
National Fireplace Institute
Dealer Information
Please record your dealer information here for
future reference:
Dealer Name: ____________________
Dealer Address: ____________________
Dealer E-Mail: ____________________
Dealer Phone #: ____________________
Report No. 100884872PRT-001
Control No. 4000515 Vented Gas Fireplace Heater
DaVinci L.P. DaVinci N.G.
Tested to: ANSI Z21.50-2014/CSA 2.22-2014 Gas-Fired Domestic and Commercial Heating Equipment “Vented Gas Fireplace” This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA54, or Natural Gas and Propane Installation Codes, CSA B149.1. This appliance must be installed in accordance with the Standard for Manufactured Homes, CAN/CSA Z240 MH Series, or with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or when such a standard is not applicable, the Standard for Fire Safety Criteria for Manufactured Home Installations, Sites and Communities, NFPA 501A This vented gas fireplace heater is equipped at the factory for use with gas fuel marked above. No conversion is allowed. This appliance is only for use with the type of gas indicated on the rating plate and may be installed in an aftermarket,permanently located,manufactured home (USAonly)or mobilehome, where notprohibited bylocal codes. See owner’s manual for details. This appliance is not convertible for use with other gases, unless a certified kit is used. This vented gas fireplace heater is not for use with air filters. Keep burner and control compartment clean. See installation and operating instructions accompanying appliance. This appliance must be properly connected to a venting system in accordance with the manufacturer’s installation instructions. See owner’s manual for approved brands of venting. WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to the owner’s information manual provided with this appliance. For assistance or additional information consult a qualified installer, service agency or the gas supplier. VENTED GAS FIREPLACE HEATER - NOT FOR USE WITH SOLID FUEL
Minimum Clearances to Combustibles
Fireplace to Adjacent Wall Wood Floor Beneath Fireplace Back to Enclosure
1” (26mm)
0” (0mm) 0” (0mm)
Top to Enclosure Sides to Enclosure Base of Fireplace to a Mantel
5.5” (140mm)
0” (0mm)
See Owner’s Manual
Electrical Rating: 120V., 60 Hz., Less than 7.0Amps
DANGER! Risk of Electric Shock. Disconnect power before servicing unit.
Minimum Inlet Pressure (inches W.C.) Maximum Inlet Pressure (inches W.C.) Manifold Pressure on “HI” (inches W.C.)
L.P.
11”
13” 10”
N.G.
5.5”
7”
3.5”
This appliance is equipped for use only at altitudes 0-2,000 feet (0-610m) in the USA. In Canada, 0-4,500 feet (0-1370m). For altitudes above 2,000 feet, the vent configuration, orifice, or combination of both may need to be changed. See owner’s manual for information on making these changes.
Input Rate on “HI” (BTU/Hr) Orifice Sizes - (DMS)
L.P.
#56
N.G.
#49
2015 2016 2014
Feb. Mar. Jan.
May Jun. Apr.
Aug. Sep. Jul.
Nov. Dec. Oct.
MANUFACTURE DATE:
WARNING: Failure to install this appliance per the manufacturer’s instructions or failure to use only parts specifically approved with this appliance may result in property damage or personal injury.
12521 Harbour Reach Drive
Mukilteo, WA 98275
Manufactured by:
www.travisproducts.com
CAUTION:
Do not operate this appliance with glass removed, cracked or broken. Replacement of the panel(s) should be done by a licensed or qualified service person.
XXXX

Table of Contents 3
© Travis Industries 4140805 100-01384
Overview .........................................................................2
Listing Details.................................................................. 2
Installation Options..........................................................6
BTU Specifications..........................................................6
Decimal Conversions ......................................................6
Dimensions – Single Sided or See Through Configurations7
Horizontal Dimensions ................................................7
Dimensions – Pier Configuration.....................................8
Horizontal Dimensions ................................................8
Dimensions – Island Configuration.................................. 9
Horizontal Dimensions ................................................9
Dimensions – Full Bay Configuration..............................10
Horizontal Dimensions ................................................10
Dimensions – Right Side Configuration...........................11
Horizontal Dimensions ................................................11
Dimensions – Left Side Configuration............................. 12
Horizontal Dimensions ................................................12
Packing List.....................................................................13
Recommended Installation Procedure............................14
Massachusetts Requirements......................................... 15
Requirements for the Commonwealth of Massachusetts 15
MANUFACTURER REQUIREMENTS........................ 15
Fireplace Placement Requirements................................16
Clearances..................................................................16
Raised Fireplaces .......................................................16
Typical Framing Dims. – One Sided Configuration.........17
Minimum Framing Dimensions....................................17
Typical Framing Dims. – See Through Configuration .....18
Minimum Framing Dimensions....................................18
Typical Framing Dims. – Pier Configuration....................19
Minimum Framing Dimensions....................................19
Typical Framing Dims. – Island Configuration.................20
Minimum Framing Dimensions....................................20
Typical Framing Dims. – Full Bay Configuration.............21
Minimum Framing Dimensions....................................21
Typical Framing Dims – Right-Sided Corner...................22
Minimum Framing Dimensions....................................22
Typical Framing Dims – Left-Sided Corner.....................23
Minimum Framing Dimensions....................................23
Nailing Brackets .............................................................. 24
Accessing Internal Components......................................25
Internal Shut Off Valve Access ...................................25
Burner Removal..........................................................26
Gas Line Requirements...................................................27
Fuel ............................................................................. 27
Gas Line Connection...................................................27
Gas Inlet Pressure ......................................................27
Directions for Connecting a Gas Pressure Test Gauge 27
Gas Inlet Location.......................................................28
Electrical Input Connection..............................................29
Connecting the Power Exhaust Damper Harness to the
Fireplace.......................................................................... 30
Connecting the Power Exhaust Lead to the Fireplace....31
Wiring the Power Exhaust Assembly ..............................32
Wiring the Power Exhaust Assembly (continued) ........... 33
Connecting the On-Off LED Harness to the Fireplace....34
Installing the On-Off Switch and LED Controller.............35
Air Intake Requirements..................................................36
Air Intake Ducts...........................................................36
Intake Dampers...........................................................37
Air intakes in Warm Environments..............................37
Air Intake Installation – Horizontal with Termination .......38
Air Intake Installation (continued)....................................39
Air Intake Dampers (for Hori. or Vert. Termination).........40
Vent Requirements.......................................................... 41
Vent Clearances..........................................................41
Altitude Considerations................................................41
Approved Vent.............................................................41
Vent Installation...........................................................41
Approved Vent Configurations.........................................42
Maximum Vent Run and Rise......................................42
Rheostat Adjustment ...................................................43
Restrictor Installation...................................................43
Termination Requirements ..........................................44
Power Vent – Dimensions and Framing ..........................45
Power Exhaust Dimensions – Low Volume 9440090345
Power Exhaust Dimensions – High Volume 94400904 46
Framing For Exhaust Box............................................47
Hearth Requirements.......................................................48
Facing Requirements.......................................................48
Do Not Drill or Screw Zone..........................................49
Mantel Requirements.......................................................49
Fireback Installation.........................................................50
Fireback Quantity Needed – Category 1 Fireplaces....50
Fireback Installation Order...........................................50
Identifying the Firebacks..............................................51
Installing the 12” Firebacks..........................................52
Installing the Bay Firebacks.........................................52
Installing the Divider and End Firebacks .....................53
Glass Pane Installation and Removal..............................54
Suction Cups ...............................................................54
When to Install the Glass Panes..................................54
Overview of Glass Panes – Category 1 Fireplaces.....54
Attaching the Suction Cups to the Glass Panes..........55
Installing the Glass Panes Into the Fireplace ..............56
Steps for Finalizing the Installation..................................57
Air Shutter Adjustment.................................................57
Crushed Glass Installation...............................................58
Placing Crushed Glass on the Burner and Center Media
Trays............................................................................58
Placing Crushed Glass in the Intake Channel (Between
Panes of Glass) - OPTIONAL......................................59
Wiring Diagram................................................................60
Before You Begin.............................................................61
Starting the Heater for the First Time ..........................61
Location of Controls.........................................................61
Fireplace On/Off Operation..............................................61
LED Operation.................................................................61
Yearly Service Procedure................................................62
Glass Cleaning.................................................................62
Replacement Parts ..........................................................62
CONDITIONS & EXCLUSIONS.......................................63
IF WARRANTY SERVICE IS NEEDED:..........................63

4 Safety Precautions
© Travis Industries 4140805 100-01384
Safety Warnings:
Failure to follow all of the requirements may result in property damage, bodily injury, or even death.
Young children should be carefully supervised when they are in the same room
as the appliance. Toddlers, young children and others may be susceptible to
accidental contact burns. A physical barrier is recommended if there are at-risk
individuals in the house. To restrict access to a fireplace or stove, install an
adjustable safety gate to keep toddlers, young children and other at-risk
individuals out of the room and away from hot surfaces.
Children and adults should be alerted to the hazards of high surface temperature
and should stay away to avoid burns or clothing ignition. Do not touch the hot
surfaces of the heater. Educate all children of the danger of a high-temperature
heater.
Due to the high temperature, the heater should be located out of traffic and away
from furniture and draperies.
This unit must be installed by a qualified installer to prevent the possibility of an explosion.
This appliance must be installed in accordance with all local codes, if any; if not, in U.S.A. follow ANSI
Z223.1 and NFPA 54(88), in Canada follow CSA B149.1.
A manufactured home (USA only) or mobile home OEM installation must conform with the
Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or, when such a
standard is not applicable, the Standard for Manufactured Home Installations, ANSI/NCSBCS
A225.1, or Standard for Gas Equipped Recreational Vehicles and Mobile Housing, CSA Z240.4. This
appliance may be installed in Manufactured Housing only after the home is site located.
All exhaust gases must be vented outside the structure of the living-area. Combustion air is drawn
from outside the living-area structure. The venting must not be connected to a chimney flue serving a
separate solid-fuel burning appliance.
Notify your insurance company before hooking up this fireplace.
The instructions in this manual must be strictly adhered to. Do not use makeshift methods or
compromise in the installation. Improper installation will void the warranty and safety listing.
This heater is approved for use with natural gas (NG) or propane (LP). Burning the incorrect fuel will
void the warranty and safety listing and may cause an extreme safety hazard. Direct questions about
the type of fuel used to your dealer.
Contact your local building officials to obtain a permit and information on any installation restrictions
or inspection requirements in your area.
If the flame becomes sooty, dark orange in color, or extremely tall, do not operate the heater. Call
your dealer and arrange for proper servicing.
It is imperative that control compartments, screens, or circulating air passageways of the heater be
kept clean and free of obstructions. These areas provide the air necessary for safe operation.
Do not operate the heater if it is not operating properly in any fashion or if you are uncertain. Call
your dealer for a full explanation of your heater and what to expect.
Do not store or use gasoline or other flammable liquids in the vicinity of this heater.
Do not operate if any portion of the heater was submerged in water or if any corrosion occurs.
Immediately call a qualified service technician to inspect the appliance and to replace any part of the
control system and any gas control which has been under water.

Safety Precautions 5
© Travis Industries 4140805 100-01384
Safety Warnings (continued)
Because this heater can be controlled by a thermostat there is a possibility of the heater turning on
and igniting any items placed on or near the appliance.
Light the heater using the built-in igniter. Do not use matches or any other external device to light
your heater.
Never remove, replace, modify or substitute any part of the heater unless instructions are given in this
manual. All other work must be done by a trained technician. Don't modify or replace orifices.
The viewing glass should be opened only for conducting service.
Allow the heater to cool before carrying out any maintenance or cleaning.
Operate the heater according to the instructions included in this manual.
If the main burners do not start correctly turn the gas off and call your dealer for service.
This unit is not for use with solid fuel.
Do not place anything inside the firebox (except the optional artwork).
Warning: Do not operate appliance with the glass front removed, cracked or broken. Replacement
of the glass should be done by a licensed or qualified service person.
Do not throw this manual away. This manual has important operating and maintenance instructions
that you will need at a later time. Always follow the instructions in this manual.
Instruct everyone in the house how to shut gas off to the appliance and at the gas main shutoff valve.
The gas main shutoff valve is usually next to the gas meter or propane tank and requires a wrench to
shut off.
Clothing or other flammable material should not be placed on or near the appliance.
Any safety screen, guard, or barrier removed for servicing an appliance must be replaced prior to
operating the appliance.
Installation and repair should be done by a qualified service person. The appliance should be
inspected before use and at least annually by a professional service person. More frequent cleaning
might be required due to excessive lint from carpeting, bedding material, et cetera. It is imperative
that control compartments, burners, and circulating air passageways of the appliance be kept clean.
Travis Industries, Inc. grants no warranty, implied or stated, for the installation or
maintenance of your heater, and assumes no responsibility of any consequential damage(s).
Proposition 65 Warning: Fuels used in gas, woodburning or oil fired appliances, and the products of combustion of such
fuels, contain chemicals known to the State of California to cause cancer, birth defects and other reproductive harm.
California Health & Safety Code Sec. 25249.6

6 Features and Specifications
© Travis Industries 4140805 100-01384
Installation Options
Residential or Commercial Installations
Raised or Floor Placement
Internal or External Chase

Horizontal or Vertical Vent
Bedroom Approved
BTU Specifications
Natural Gas Propane
3’ Burner - BTU Input Per Hour 43,500 43,500
4’ Burner - BTU Input Per Hour 58,000 58,000
5’ Burner - BTU Input Per Hour 72,500 72,500
Decimal Conversions
0.125” 1/8”
0.25” 1/4"
0.375” 3/8”
0.5” 1/2"
0.625” 5/8”
0.75” 3/4"
0.875” 7/8”

Features and Specifications 7
© Travis Industries 4140805 100-01384
Dimensions – Single Sided or See Through Configurations
(a) Air Intake - 6” Diameter, Centered on Fireplace, Left or Right Side (determined at time of order)
(b) Exhaust - 10” or 8” Diameter B-Vent (determined by exhaust blower type), Centered on Fireplace
(c) Gas Inlet – Location is determined at time of order (can be relocated)
(d) Electrical Junction Box – On both sides (location determined at time of order – can be relocated), includes
120v input, exhaust vent power/harness, on-off LED harness
(e) Gas Control Valve
Horizontal Dimensions
Version Overall Width (x) Exhaust Location (y) BTUs
36” Single Sided / See Through 38” (966mm) 19” (483mm) 43,500
48” Single Sided / See Through 50” (1270mm) 25” (635mm) 58,000
60” Single Sided / See Through 62” (1575mm) 31” (788mm) 72,500
20" 508mm (Single)
19.75" 502mm (See-Through)
Front
avant
Right
droit
Rear
arrie're
Left
a' gauche
b
10.375"
264mm
11"
280mm
c
x
y
a
e
d
c


Version
Length
d
a
10.375"
264mm
12" Glass
41.125" (1045mm)
20" Glass
49.125" (1286mm)
30" Glass
59.125" (1502mm)
36" Glass
65.125 (1655mm)
12" (305mm)
20" (508mm)
30" (762mm)
36" (915mm)

8 Features and Specifications
© Travis Industries 4140805 100-01384
Dimensions – Pier Configuration
(a) Air Intake - 6” Diameter, Centered on Fireplace, Left or Right Side (determined at time of order)
(b) Exhaust - 10” or 8” Diameter B-Vent (determined by exhaust blower type), Centered on Fireplace
(c) Gas Inlet – Location is determined at time of order (can be relocated)
(d) Electrical Junction Box – On both sides (location determined at time of order – can be relocated), includes
120v input, exhaust vent power/harness, on-off LED harness
(e) Gas Control Valve
NOTE: When using a 2-sided fireplace, the front is determined by the gas control valve (it is to the front).
Horizontal Dimensions
Version Overall Width (x) Exhaust Location (y) BTUs
42” Pier 43” (1093mm) 24” (610mm) 43,500
54” Pier 55” (1397mm) 30” (762mm) 58,000
66” Pier 67” (1702mm) 36” (915mm) 72,500
19.75"
502mm
Front
avant
Right
droit
Rear
arrie're
Left
a' gauche
b
11"
280mm
1" (25mm) 16.375"
416mm
x
y
a
e
12" Glass
41.125" (1045mm)
-------------------------
20" Glass
49.125" (1248m)
12" (305mm)
------- or -------
20" (508mm)
Version
Length


d
c
c
d
a
10.375"
264mm

Features and Specifications 9
© Travis Industries 4140805 100-01384
Dimensions – Island Configuration
(a) Air Intake - 6” Diameter, Centered on Fireplace, Left or Right Side (determined at time of order)
(b) Exhaust - 10” or 8” Diameter B-Vent (determined by exhaust blower type), Centered on Fireplace
(c) Gas Inlet – Location is determined at time of order (can be relocated)
(d) Electrical Junction Box – On both sides (location determined at time of order – can be relocated), includes
120v input, exhaust vent power/harness, on-off LED harness
NOTE: When using an island fireplace, the harnesses will need to be long (typically 50’ to 150’)
(e) Gas Control Valve
NOTE: When using a 2-sided fireplace, the front is determined by the gas control valve (it is to the front).
Horizontal Dimensions
Version Overall Width (x) Exhaust Location (y) BTUs
48” Island 48.125” (1223mm) 24” (610mm) 43,500
60” Island 60.125” (1528mm) 30” (762mm) 58,000
72” Island 72.125” (1832mm) 36” (915mm) 72,500
19.75"
502mm
Front
avant
Right
droit
Rear
arrie're
Left
a' gauche
b
11"
280mm
e
x
y
a
16.375"
416mm

d
c
d
c
Version
Length
a
16.375"
416mm
12" Glass
41.125" (1045mm)
20" Glass
49.125" (1286mm)
30" Glass
59.125" (1502mm)
36" Glass
65.125 (1655mm)
12" (305mm)
20" (508mm)
30" (762mm)
36" (915mm)

10 Features and Specifications
© Travis Industries 4140805 100-01384
Dimensions – Full Bay Configuration
(a) Air Intake - 6” Diameter, Centered on Fireplace, Left or Right Side (determined at time of order)
(b) Exhaust - 10” or 8” Diameter B-Vent (determined by exhaust blower type), Centered on Fireplace
(c) Gas Inlet – Location is determined at time of order (can be relocated)
(d) Electrical Junction Box – On both sides (location determined at time of order – can be relocated), includes
120v input, exhaust vent power/harness, on-off LED harness
(e) Gas Control Valve
Horizontal Dimensions
Version Overall Width (x) Exhaust Location (y) BTUs
48” Full Bay 48.125” (1223mm) 24” (610mm) 43,500
60” Full Bay 60.125” (1528mm) 30” (762mm) 58,000
72” Full Bay 72.125” (1832mm) 36” (915mm) 72,500
20"
508mm
Front
avant
Right
droit
Rear
arrie're
Left
a' gauche
b
11"
280mm 5.75"
(147mm)
16.375"
416mm
x
y
a
e

d
c
d
c
Version
Length
a
16.375"
416mm
12" Glass
41.125" (1045mm)
20" Glass
49.125" (1286mm)
30" Glass
59.125" (1502mm)
36" Glass
65.125 (1655mm)
12" (305mm)
20" (508mm)
30" (762mm)
36" (915mm)

Features and Specifications 11
© Travis Industries 4140805 100-01384
Dimensions – Right Side Configuration
(a) Air Intake - 6” Diameter, Centered on Fireplace, Left or Right Side (determined at time of order)
(b) Exhaust - 10” or 8” Diameter B-Vent (determined by exhaust blower type), Centered on Fireplace
(c) Gas Inlet – Location is determined at time of order (can be relocated)
(d) Electrical Junction Box – On both sides (location determined at time of order – can be relocated), includes
120v input, exhaust vent power/harness, on-off LED harness
(e) Gas Control Valve
Horizontal Dimensions
Version Overall Width (x) Exhaust Location (y) BTUs
42” Left or Right Side 43” (1093mm) 24” (610mm) 43,500
54” Left or Right Side 55” (1397mm) 30” (762mm) 58,000
66” Left or Right Side 67” (1702mm) 36” (915mm) 72,500
20"
508mm
Front
avant
Right
droit
Rear
arrie're
Left
a' gauche
b
11"
280mm 5.75"
(147mm)
16.375"
416mm
x
y
a
Version
Length
e

d
c
c
d
a
10.375"
264mm
12" Glass
41.125" (1045mm)
20" Glass
49.125" (1286mm)
30" Glass
59.125" (1502mm)
36" Glass
65.125 (1655mm)
12" (305mm)
20" (508mm)
30" (762mm)
36" (915mm)

12 Features and Specifications
© Travis Industries 4140805 100-01384
Dimensions – Left Side Configuration
(a) Air Intake - 6” Diameter, Centered on Fireplace, Left or Right Side (determined at time of order)
(b) Exhaust - 10” or 8” Diameter B-Vent (determined by exhaust blower type), Centered on Fireplace
(c) Gas Inlet – Location is determined at time of order (can be relocated)
(d) Electrical Junction Box – On both sides (location determined at time of order – can be relocated), includes
120v input, exhaust vent power/harness, on-off LED harness
(e) Gas Control Valve
Horizontal Dimensions
Version Overall Width (x) Exhaust Location (y) BTUs
42” Left or Right Side 43” (1093mm) 24” (610mm) 43,500
54” Left or Right Side 55” (1397mm) 30” (762mm) 58,000
66” Left or Right Side 67” (1702mm) 36” (915mm) 72,500
Front
avant
Right
droit
Rear
arrie're
Left
a' gauche
20"
508mm
b
11"
280mm
5.75"
(147mm)
16.375"
416mm
x
y
a
Version
Length
e

d
c
c
d
a
10.375"
264mm
12" Glass
41.125" (1045mm)
20" Glass
49.125" (1286mm)
30" Glass
59.125" (1502mm)
36" Glass
65.125 (1655mm)
12" (305mm)
20" (508mm)
30" (762mm)
36" (915mm)

Installation (for qualified installers only) 13
© Travis Industries 4140805 100-01384
Packing List
Included Hardware (for Set & Vent)
ITEM Qty Location Notes
Manual 1 You’re looking at it baby!
On-Off LED Harness (8
wires) 1 Hardware Box 10, 25, or 50 Length
On/Off Switch 1 Hardware Box
LED Controller 1 Hardware Box Labeled “Elemental LED”
Double-Gang Junction
Box 1 Hardware Box
Double-Gang Cover
Plate 1 Hardware Box
Exhaust Blower
Assembly (B) 1 On its own pallet Low Volume 94400903 (B)
High Volume 94400904 (B)
Addtitional Equipment Required (for Set & Vent)
ITEM REQUIRED WHERE SHIPPED SKU
Suction Cups For
Glass Yes Ordered separately 94400914 (includes 2 suction cups)
Fireback Liners
(see “Firebacks” on
page 50 for qty.)
Yes In its own box Gloss Black Enamel
Silver Painted
Matte Black Painted
Exhaust Damper
Wiring Harness Yes ? 50 Foot 94700887
150 Foot 94700888
250 Foot 94700889
10” B-Vent Yes In its own box(s) 36” Section 98900060
18” Section 98900061
90° Elbow 98900062
45° Elbow 98900063
12” Adjustable Section 98900064
Wall Strap 98900065
Fire Stop 98900066
Optional Intake
Damper(s) (A) Hardware Box
Hori w Term 6” (98900093)
Hori w Term 8” (98900094)
Inline Dmpr 6” (98900078)
Inline Dmpr 8” (98900079)
Air Intakes (6” or 8” Dia.) (A)
Intake Wiring Harness (if
using intake damper) (A) Hardware Box 25’ Length (Black and White Wire)
(A) Category 1 Fireplaces have 1 intake. Category 2 Fireplaces have up to 3 intakes. Refer to the
configuration of your appliance to determine the number of intakes required.
(B) Category 1 Fireplaces use the smaller exhaust blower.
Category 2 Fireplaces use the larger exhaust blower.
Finalization Hardware (install after fireplace is in place – you may hold at dealership)
ITEM Location Notes
Crushed Glass Hardware Box Center Channel uses 1.5 Lbs.
(cups) per foot
Outer Channel uses 1 Lbs.
(cups) per foot

14 Installation (for qualified installers only)
© Travis Industries 4140805 100-01384
Recommended Installation Procedure
Important Notes Regarding Framing
We strongly suggest framing around the fireplace after it is in place. Because this fireplace is
especially large and requires hookups from the side (or bottom), framing is best installed after the
fireplace and vent are in place.. The header and framing above the fireplace is best installed after the
vent is installed (this allows for proper framing placement to ensure all clearances are met).
1. Prepare the installation location. If placing the fireplace on a platform, build the platform, making
sure to accommodate the weight of the fireplace and venting. Verify the platform is level ande
plumb.
2. Install the periphery components:
a) Install the power exhaust vent (and power exhaust blower assembly).
b) Install the air intake(s).
c) Install the gas line.
d) Install the electrical line, on/off switch, and LED controller.
3. Test operation of the fireplace before attaching facing or drywall (this can be done with no
crushed glass and the outer glass panes removed). This allows the installer to verify all
connections and diagnose issues with the fireplace exterior accessible.
4. Frame the area around the fireplace.
5. Install the drywall and/or facing.
6. Install the hearth (if applicable).
7. Install the mantel (if applicable).
8. Finalize the installation (see page 57).

Installation (for qualified installers only) 15
© Travis Industries 4140805 100-01384
Massachusetts Requirements
NOTE: The following requirements reference various Massachusetts and national codes not contained in this document.
Requirements for the Commonwealth of Massachusetts
For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in
part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent
termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and
porches, the following requirements shall be satisfied:
Installation of Carbon Monoxide Detectors
At the time of installation of the side wall horizontal vented gas fueled equipment, the installing plumber or gasfitter shall
observe that a hard wired carbon monoxide detector with an alarm and battery back-up is installed on the floor level where the
gas equipment is to be installed. In addition, the installing plumber or gasfitter shall observe that a battery operated or hard
wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure served
by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the
services of qualified licensed professionals for the installation of hard wired carbon monoxide detectors.
In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired
carbon monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall
have a period of thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day
period, a battery operated carbon monoxide detector with an alarm shall be installed.
Approved Carbon Monoxide Detectors
Each carbon monoxide detector as required in accordance with the above provisions shall comply with NFPA 720 and be
ANSI/UL 2034 listed and IAS certified.
Signage
A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of eight
(8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or
equipment. The sign shall read, in print size no less than one-half (1/2) inch in size, “GAS VENT DIRECTLY BELOW. KEEP
CLEAR OF ALL OBSTRUCTIONS”.
Inspection
The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the
provisions of 248 CMR 5.08(2)(a)1 through 4.
Exemptions
The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
• The equipment listed in Chapter 10 entitled “Equipment Not Required To Be Vented” in the most current edition of NFPA 54
as adopted by the Board; and
• Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the
dwelling, building or structure used in whole or in part for residential purposes.
MANUFACTURER REQUIREMENTS
Gas Equipment Venting System Provided
When the manufacturer of Product Approved side wall horizontally vented gas equipment provides a venting system design or
venting system components with the equipment, the instructions provided by the manufacturer for installation of the equipment
and the venting system shall include:
• Detailed instructions for the installation of the venting system design or the venting system components; and
• A complete parts list for the venting system design or venting system.
Gas Equipment Venting System NOT Provided
When the manufacturer of a Product Approved side wall horizontally vented gas fueled equipment does not provide the parts
for venting the flue gases, but identifies “special venting systems”, the following requirements shall be satisfied by the
manufacturer:
• The referenced “special venting system” instructions shall be included with the appliance or equipment installation
instructions; and
• The “special venting systems” shall be Product Approved by the Board, and the instructions for that system shall include a
parts list and detailed installation instructions.
A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting
instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or
equipment at the completion of the installation.
See Gas Connection section for additional Commonwealth of Massachusetts requirements.

16 Installation (for qualified installers only)
© Travis Industries 4140805 100-01384
Fireplace Placement Requirements
This appliance may be installed into a residential or commercial/public space.
Fireplace must be installed on a level surface capable of supporting the fireplace and vent
Fireplace must be placed directly on wood or non-combustible surface (not on linoleum or carpet)
Fireplace should be located out of traffic and away from furniture and draperies.
Fireplace may be placed in a bedroom.
Clearances
(a) Clearance to Sides of Fireplace: 0”.
(b) Clearance to Back of Fireplace: 0”.
(c) Clearance to Front of Fireplace: 0”.
NOTE: do not cover the glass opening with any material.
NOTE: Side walls may be placed directly to the side of the fireplace.
(d) Clearance to Top of Fireplace: 0”
(e) Clearance to Bottom of Fireplace: 0” (may be placed directly on subfloor).
(f) Clearance to Vent 1” (25mm)
Raised Fireplaces
The fireplace (and hearth, if desired) may be placed on a platform designed to support the fireplace
and vent.
The base of the platform must be a minimum ¾” plywood (or equivalent). This provides the
necessary support for the fireplace runners.
HINT: We typically have displayed this fireplace on a 24” to 36” raised platform. Keep in mind that the
firebox opening (base of the flames) is 12” above the base. Desired position may vary depending
upon room size, typical viewing angle, and aesthetic intent.







b




a
c
Top of
Fireplace Side of
Fireplace


e
f
d

Installation (for qualified installers only) 17
© Travis Industries 4140805 100-01384
Typical Framing Dims. – One Sided Configuration
Important Notes Regarding Framing
We strongly suggest framing around the fireplace after it is in place. If you do frame before
fireplace placement, add 6” to each side to allow for fireplace access.
Minimum Framing Dimensions
Version Width (x) Height (y) –
12” Glass Height (y) – 20” Glass Height (y) – 30” Glass Height (y) – 36” Glass
36” Single Sided 38.5” (978mm) 46.625”
(1185mm) 54.625” (1388mm) 64.625” (1642mm) 70.625” (1794mm)
48” Single Sided 50.5” (1283mm)
60” Single Sided 62.5” (1588mm)
20"
508mm
xy
3" (77mm) Maximum for vent clearance.
Do not place vertical framing directly in the
center above the fireplace - it will infringe
upon the vent clearance requirements.

18 Installation (for qualified installers only)
© Travis Industries 4140805 100-01384
Typical Framing Dims. – See Through Configuration
Important Notes Regarding Framing
We strongly suggest framing around the fireplace after it is in place. If you do frame before
fireplace placement, add 6” to each side to allow for fireplace access.
Minimum Framing Dimensions
Version Width (x) Height (y) –
12” Glass Height (y) – 20” Glass Height (y) – 30” Glass Height (y) – 36” Glass
36” See Through 38.5” (978mm) 46.625”
(1185mm) 54.625” (1388mm) 64.625” (1642mm) 70.625” (1794mm)
48” See Through 50.5” (1283mm)
60” See Through 62.5” (1588mm)
19.625"
499mm
When using a top plate, you may need to notch it at
the center to provide adequate vent clearance.
3" (77mm) Maximum for vent clearance.
Do not place vertical framing directly in the
center above the fireplace - it will infringe
upon the vent clearance requirements.
x
y

Installation (for qualified installers only) 19
© Travis Industries 4140805 100-01384
Typical Framing Dims. – Pier Configuration
Minimum Framing Dimensions
Version Width (x) Height (y) –
12” Glass Height (y) – 20” Glass Height (y) – 30” Glass Height (y) – 36” Glass
42” Pier 43.5” (1105mm) 46.625”
(1185mm) 54.625” (1388mm) 64.625” (1642mm) 70.625” (1794mm)
54” Pier 55.5” (1410mm)
66” Pier 67.5” (1715mm)
19.625"
499mm
x
y
The framing above the fireplace
must be self-supporting (the
fireplace is not load-bearing).
When using a top plate, you may need to notch it at
the center to provide adequate vent clearance.
3" (77mm) Maximum for vent clearance.
Do not place vertical framing directly in the
center above the fireplace - it will infringe
upon the vent clearance requirements.

20 Installation (for qualified installers only)
© Travis Industries 4140805 100-01384
Typical Framing Dims. – Island Configuration
Minimum Framing Dimensions
Version Width (x) Height (y) –
12” Glass Height (y) – 20” Glass Height (y) – 30” Glass Height (y) – 36” Glass
48” Island 48.125” (1223mm) 46.625”
(1185mm) 54.625” (1388mm) 64.625” (1642mm) 70.625” (1794mm)
60” Island 60.125” (1528mm)
72” Island 72.125” (1832mm)
19.625"
499mm
x
y
The framing above the fireplace
must be self-supporting (the
fireplace is not load-bearing).
When using a top plate, you may need to notch it at
the center to provide adequate vent clearance.
3" (77mm) Maximum for vent clearance.
Do not place vertical framing directly in the
center above the fireplace - it will infringe
upon the vent clearance requirements.
