DAVIS Lucid Series User manual

2401 South College Dr. | High Point, NC | 27261-2065 | P.336.889.2009 | www.davisfurniture.com
Lucid Chair Series
Designed by Burkhard Vogtherr

Seat Depth
Adjustment
Knob
Seat Height Lever
Pull up to raise
and lower seat
Forward Position
Lock Lever
Pull lever forward to
stop back tilt. Push
lever back for full tilt.
Synchro-Tilt Option
Active Seat Option
Allows seat to rock in
synchronous movement
with back, which is determined
by the user’s body positions,
not the chair mechanism.
Tilt Tension
Adjustment Knob
Sitting in chair,
to increase tension
turn knob right (clockwise),
to decrease tension
turn knob left (counter
clockwise).
Seat Depth Adjustment Knob
A round control knob is located at
the back underside of the seat.
Adjust the depth of the seat
by loosening the knob and
sliding the seat forward or
backward to the desired
position. Seat will adjust 2” in
depth. Once desired
position is achieved
tighten knob.
Synchro-Tilt Option
Mechanisms may be specified with a
Synchro-Tilt option. This mechanism has a
synchron ratio of 2 to 1 that is, for 1
degree of seat tilt, the back moves 2
degrees.
Seat Depth
Adjustment
Knob
Seat Height Lever
Pull up to raise
and lower seat
Forward Position
Lock Lever
Pull lever forward to
stop back tilt. Push
lever back for full tilt.
Synchro-Tilt Option
Active Seat Option
Allows seat to rock in
synchronous movement
with back, which is determined
by the user’s body positions,
not the chair mechanism.
Tilt Tension
Adjustment Knob
Sitting in chair,
to increase tension
turn knob right (clockwise),
to decrease tension
turn knob left (counter
clockwise).
Seat Depth
Adjustment
Knob
Seat Height Lever
Pull up to raise
and lower seat
Forward Position
Lock Lever
Pull lever forward to
stop back tilt. Push
lever back for full tilt.
Synchro-Tilt Option
Active Seat Option
Allows seat to rock in
synchronous movement
with back, which is determined
by the user’s body positions,
not the chair mechanism.
Tilt Tension
Adjustment Knob
Sitting in chair,
to increase tension
turn knob right (clockwise),
to decrease tension
turn knob left (counter
clockwise).
Seat Depth
Adjustment
Knob
Seat Height Lever
Pull up to raise
and lower seat
Forward Position
Lock Lever
Pull lever forward to
stop back tilt. Push
lever back for full tilt.
Synchro-Tilt Option
Active Seat Option
Allows seat to rock in
synchronous movement
with back, which is determined
by the user’s body positions,
not the chair mechanism.
Tilt Tension
Adjustment Knob
Sitting in chair,
to increase tension
turn knob right (clockwise),
to decrease tension
turn knob left (counter
clockwise).
Lucid Chair Series Adjustments
Height Adjustment
The right-hand lever (sitting in chair)
actuates the gas lift mechanism.
 •Toraise height: Lift the lever while
lifting your weight from the chair. The
chair will follow your body up. Release
the lever and the new height position
will be held.
 •Tolower height: Lift the same lever
while sitting in the chair. Let the chair
move down with your weight and
release the lever at the height desired.
Tips regarding height adjustment:
Find the height at which your feet are flat
on the floor and the back of your thighs
are comfortably supported by the seat
cushion. Too much pressure on the back of
your thighs means the chair is too high; too
little pressure
means it is too low.
Forward Position Lock Feature
The position lock is intended to hold the
back in an upright position while the user is
seated in the chair.
The left-hand lever (sitting in chair) locks
and unlocks the rear tilt mechanism.
 • Toengage the lock, pull lever forward
to stop back tilt.
 • Torelease the lock, push the lever
back for full tilt.
Tips regarding rear tilt lock:
The lever should be moved either com-
pletely back to disengage or completely
forward to engage lock.
Tilt Tension Adjustment Knob
A round control knob is located under the
front of the seat. It provides a fine
adjustment of the tilt tension, so it may
take many turns before any difference is
felt.
 • Checktheadjustmenttoensureit
effectively balances your body weight
while moving backward and forward.
If the back moves too easily, turn the
knob clockwise to increase the tension.
 • Ifitistoodifculttoleanbackward,
turn the knob counter-clockwise to
decrease the balancing force.
Tips regarding tilt tension adjustment:
Find the tension setting which allows you to
relax as you move back and forth. After the
initial adjustment, your chair should follow
you comfortably as you move.
Seat Depth
Adjustment
Knob
Seat Height Lever
Pull up to raise
and lower seat
Forward Position
Lock Lever
Pull lever forward to
stop back tilt. Push
lever back for full tilt.
Synchro-Tilt Option
Active Seat Option
Allows seat to rock in
synchronous movement
with back, which is determined
by the user’s body positions,
not the chair mechanism.
Tilt Tension
Adjustment Knob
Sitting in chair,
to increase tension
turn knob right (clockwise),
to decrease tension
turn knob left (counter
clockwise).
