DAVIS FLA Series User manual

Installation Instructions
FLA Series
LUMINAIRE DIMENSION:
TRUNNION ARM DIMENSION:
CAUTIONS:
Installation is to be completed by a competent licensed electrician, in accordance with these instructions and relevant
local regulations.
Electronic control equipment must not be subjected to high voltages, DO NOT MEGGER between Live and Neutral.
All cable/conduit terminations must be installed in accordance with the designated IP rating of this product.
Suitable installation fastening methods should be employed to ensure the mounting points are not damaged when
subjected to vibration and or movement.
As is the case with all electronic components, it is advisable to fit appropriate surge protection to final sub circuits.
Choose an installation place capable to withstand 10 times the weight of the product to ensure safety.
Model
Dimension
FLA10G1xK03
124 (W) x 115 (H) x 32 (D)
FLA20G1xK03
151 (W) x 179 (H) x 35 (D)
FLA30G1xK03
151 (W) x 179 (H) x 35 (D)
FLA50G1xK03
197 (W) x 179 (H) x 35 (D)
FLA100G1xK03
254 (W) x 234 (H) x 42 (D)
FLA150G1xK03
348 (W) x 324 (H) x 47 (D)
FLA200G1xK03
348 (W) x 324 (H) x 47 (D)
Model
Dimension (mm)
A
B
C
D
FLA10G1xK03
72
32
8
8
FLA20G1xK03
92
52
8
8
FLA30G1xK03
92
52
8
8
FLA50G1xK03
122
72
8
8
FLA100G1xK03
170
110
10
10
FLA150G1xK03
220
140
10
10
FLA200G1xK03
220
140
10
10
Read all instructions to prevent injury, electric shock or damage
due to fire & mechanical hazard

INSTALLATION:
1. Loosen trunnion arm bolts, adjust to desired angle and fasten the bolt using hex key.
Key Size Model
5mm 10W / 20W / 30W / 50W
6mm 100W
8mm 150W / 200W
2. Mount the fitting to wall or ground and connect to power supply.
3. Turn on power.
MAINTENANCE:
The supply must be isolated before opening or accessing the luminaire. Product maintenance is critical to the product designed
performance. The product is to be maintained in accordance with the manufacturer’s instructions. For the latest product
maintenance guides please go to www.davislighting.com. Davis Lighting is not responsible for any product not maintained in
accordance with the recommended procedure or intervals. The light source of this luminaire is non-replaceable; if the light
source should become faulty or expire then the entire luminaire will need to be replaced. Products supplied with visors or covers
must not be operated with a damaged visor or cover; it is recommended damaged visors or covers be replaced by a competent
person immediately.
Warning: Maximum loading of earth leakage and circuit protection device.
Note
The maximum number of ballasts/drivers connected to earth leakage circuit protection device shall not be greater than 6
units for fixed output on MCB 16A or that as recommended by the protective device supplier/manufacturer whichever is the
smaller number.
The maximum loading of automatic circuit breakers shall not be greater than those shown in the table supplied by the
control gear manufacturer or that as recommended by the protective device supplied/manufacturer whichever is the
smaller number.
