Daxten MONITOR SPLITTER User manual

f
Monitor Splitter - VGA Splitter
Images say more
than words!
The Daxten Monitor Splitter, sometimes known as a VGA splitter or video
splitter, allows a user to display their video image over multiple monitors.
This is an ideal product for training, exhibitions, demonstrations and class-
room situations. A variety of models are available for every use, including
distance applications up to 250 feet from the CPU. Premium models offer
maximum video clarity across all resolutions.
Available in 2, 4, and 8 port versions
Plug & Play
Operating system and software independent
Also available as a Micro Splitter with a 1 GHz bandwidth for a high
resolution up to 1600 x 1200
www.daxten.com

Monitor Splitter - VGA Splitter
Daxten Limited
5 Manhattan Business Park
Westgate
London W5 1UP
Tel: [phone]
Fax: [phone]
[email protected]
Part No.
1020-02M Micro Splitter 2 Port 1 GHz
1020-02EK Monitor Splitter E 2 Port
1020-04EK Monitor Splitter E 4 Port
1020-08EK Monitor Splitter E 8 Port
www.daxten.com
Technical specification Monitor Splitter:
Dimensions (HxWxD):
• 2 and 4 port: 156 x 80 x 32 mm
• 8 port: 185 x 132 x 55 mm
Supports resolution up to 1280 x 1024
Video bandwidth: 400 MHz
Support all operating systems incl. DOS,
UNIX (Linux), Windows 95, 98, NT, OS/2
Max. distance from Splitter to PC: 7,5 m (25ft)
cable included
No external power supply for 2 and 4 port
versions
Technical specification Micro Splitter:
Dimensions (HxWxD):
100 x 60 x24 mm
Supports resolution up to 1600 x 1200
Video bandwidth: 1 GHz
Configuration Monitor Splitter 2-Port Configuration Micro Splitter Splitter 2-Port
