ODU MINI-SNAP K Series User manual

SERIES K
www.odu-usa.com
A PERFECT ALLIANCE.
ODU MINISNAP®
Miniature circular connectors
with Push-Pull locking.
ODU MINISNAP®K
ODU MINI-SNAP® L ODU MINI-SNAP® B ODU MINI-SNAP® F ODU AMC® ODU MEDI-SNAP® ODU MINI-SNAP® PC

ODU MINI-SNAP® K
APPLICATIONS
•Medical
•Industrial
•Test and measurement
•Military and security
•Energy
•eMobility
FEATURES
•Quick and easy mating and demating
• Blind mating and demating in difficult-to-reach places
•Low space requirements on the receptacles
•Definite and secure locking conditions
• Robotic mating and demating possible
• Easy cleaning of the connector plug housing possible
• High connector density
• Low power requirement
All shown connectors are according to IEC 61984:2008
(VDE 0627:2009); connectors without breaking capacity (COC).
ODU MINI-SNAP is UL-approved under file E110586.
MIL specification: Tests carried out (see page 170).
All dimensions are in mm.
Some figures are for illustrative purposes only.
Subject to change without notice. Errors and omissions excepted.
We reserve the right to change our products and their technical
specifications at any time in the interest of technical improvement.
This publication supersedes all prior publications.
This publication is also available as a PDF file that can be down-
loaded from www.odu-connectors.com.
Issue: 2018-05
Data transmission protocols
These ODU specific connectors can transmit common data transmission protocols
such as USB® 2.0, USB® 3.1 Gen1, CAT 5, CAT 6A and Ethernet , but they are not
USB®-, CAT- and Ethernet-standard connectors.
2

3
TABLE OF CONTENTS
4THE ODU CORPORATE GROUP
PRODUCT INFORMATION 10
12
13
14
Push-Pull connector series at a glance
Specific attributes of series L, K and B
Functional principle of the Push-Pull locking
Facts & figures 15
CONFIGURATION GUIDELINE 16
Correct configuring – step by step 18
ODU MINI-SNAP® SERIES K 74
76
78
80
88
90
108
Summary ODU MINI-SNAP® series K
The LP locking principle
Styles
Keyings
Contact inserts and PCB layouts
Cable collet system
Accessories 110
TOOLS, CRIMP INFORMATION, PROCESSING INSTRUCTIONS, ACCESSORIES 154
156
158
158
Crimping tools /assembly tools
Spanner wrench
Nutdriver for slotted mounting nut
Removal tools for crimp-clip-contacts 159
TECHNICAL INFORMATION 160
162
163
164
165
166
167
168
169
170
170
International protection classes acc. IEC 60529:2013 (VDE 0470-1:2014)
Principle of watertightness
Housing materials and insulator materials
Termination technologies
Conversions / AWG
Current load of turned contacts
Operating voltage
Electro magnetic compatibility (EMC)
Autoclaving
Test standard
Technical terms 171
For assembly instructions, please refer to our website: www.odu-connectors.com/downloads/assembly-instructions
Clickable page
numbers

A PERFECT
ALLIANCE.
CREATING CONNECTIONS, BUILDING ALLIANCES, COLLABO-
RATING INTO THE FUTURE: WHETHER TWO TECHNICAL COM-
PONENTS COME TOGETHER TO FORM A UNIT OR PEOPLE COME
TOGETHER TO STRIVE FOR GREAT RESULTS – THE KEY IS TO
ASPIRE IN ACHIEVING SUPERB RESULTS. THIS GOAL DRIVES OUR
WORK. PERFECT CONNECTIONS THAT INSPIRE AND DELIVER
ON THE PROMISES.

ODU WORLDWIDE
ODU GROUP OVERVIEW
• More than 75 years of experience in connector technology
• A turnover of 170 million Euro
• Over 1,900 employees worldwide
• 9 sales subsidiaries in China, Denmark, France, Germany,
Italy, Japan, Sweden, the UK and the US as well as
5 production and logistics sites
• All technologies under one roof: Design and development,
machine tool and special machine construction, injection,
stamping, turning, surface technology, assembly and
cable assembly
As of February 2018
CERTIFIED QUALITY
• DIN EN ISO 9001
• IATF 16949
• DIN EN ISO 14001
• ISO 13485
• Wide range of UL, CSA, VG and DVA licenses
• UL certifi ed cable assembly
For a complete list of our certifi cations, please visit our website.
ODU Scandinavia AB
ODU Denmark ApS
ODU Mexico
Manufacturing S.R.L. de C.V.
ODU GmbH & Co. KG
Headquarters
ODU-USA, Inc.
ODU North American Logistics
ODU Romania Manufacturing S.R.L.
ODU Italia S.R.L.
ODU France SARL
ODU-UK Ltd.
ODU (Shanghai)
International Trading Co., Ltd.
ODU (Shanghai)
Connectors Manufacturing Co.L
td
ODU Japan K.K.

PERFECT SOLUTIONS
INGENIOUS IDEAS
ODU’S PRODUCT PORTFOLIO.
THE ODU GROUP
• Circular connector series in robust
metal or plastic housing
• Contacts for soldering, crimping and
PCB termination
• Optional selectable Push-Pull locking ensuring
a secure connection at all times as well as
easy to release Break-Away function
• 2 up to 55 contacts
• IP 50 to IP 69
• Autoclavable for medical applications
• Hybrid inserts for combined transmission
• Application-specifi c hybrid interface
• For manual mating and automatic docking
• The highest packing density
• Flexible modular construction
• Multitude of data transmission modules
• Variety of locking options available
• For the transmission of signals, power, high
current, high voltage, coax, high-speed data,
fi ber optics and other media such as air or fl uid.
• Mating cycles scalable as required
from 10,000 to over 100,000 (1 million)
• Versatile connector technologies
• Outstanding reliability, lifetime and durability
• Up to 1 million mating cycles
• Current-carrying capacity of up to
2,400 amperes and more
• Rugged contact systems, suitable even
for harsh environments
• Economical solutions for automatic processing
PUSH-PULL CIRCULAR CONNECTORS ELECTRICAL CONTACTSCOMPACT MODULAR CONNECTOR SOLUTIONS

Versatile connector solutions for transmission of power, signals, data,
or media – ODU never fails to o er the right interface when quality and
absolute reliability are the top priorities.
• Complete systems from a single source based
on years of assembly expertise
• State-of-the-art production facilities with 100%
end testing, high-voltage testing, component
testing and pressure testing up to 100 bar
• Cleanroom production
• Hot-melt and high-pressure injection molding
• Customer-specifi c labeling
• Rapid prototyping of samples
• Extremely durable even under extreme / harsh
environments
• Interference-free and secure connection,
even under vibration
• Up to 500 A (higher currents upon request)
• High contact security due to the springwire
technology
• High pin density due to a minimum contact
diameter
• Low contact resistance
• Contacts, connectors and assemblies for
the highest technical requirements as well
as special applications
• First-class implementation expertise
• High level of vertical manufacturing –
all competences and key technologies
under one roof
• Expert advice based on mutual partnership
• Fast development and production
CABLE ASSEMBLY
APPLICATION AND
CUSTOMER-SPECIFIC SOLUTIONS
HEAVY-DUTY & DOCKING
AND ROBOTIC CONNECTOR SOLUTIONS

APPLICATION-SPECIFIC SOLUTIONS
Demands that can’t be pigeon-holed call for cre-
ative specialists who think outside the box. ODU
o ers the type of expertise that focuses solely
on the specifi c requirements of our customers.
For every development order we get, we not only
perform a thorough check to make sure it’s feasi-
ble, we intensively incorporate our customers in
the ongoing design process. This guarantees an
impressive, custom-fi t fi nal result. Our solutions
are frequently based on the modifi cations of our
products, especially for the ODU MINI-SNAP and
ODU-MAC connectors.
MORE
THAN A CONNECTION
OUR KNOW-HOW FOR YOUR SUCCESS.
HIGH PERFORMANCE CONNECTOR TECHNOLOGY FOR DEMANDING KEY MARKETS
Customers rely on ODU technology wherever fi rst-class, high-performance con-
nector solutions are required. All our skills go into our products to ensure your
success. In addition to the top quality, reliable stability and maximum fl exibility
in customer-specifi c requirements, our products also stand for dynamics,
reliability, safety, precision, effi ciency and sustainability. And they guarantee
unrestricted functionality for the fi nal product due to our high quality connectors.
ODU – A PERFECT ALLIANCE.
THE ODU GROUP

HIGH LEVEL OF VERTICAL INTEGRATION
ODU combines all the competences and key technologies for the connector
manufacturing. These include design and development, machine tool and
special machine construction, injection, stamping, turning, surface tech-
nology, assembly and cable assembly and our own test laboratory.
INDIVIDUAL CABLE ASSEMBLY
Our production skills together with our cutting
edge production facilities from Europe, China
and the USA enable us to deliver to our customers
locally tested assemblies and also global ones.
INDUSTRIAL
ENERGY
MEDICAL
TEST AND MEASUREMENT
MILITARY AND SECURITY
EMOBILITY

ODU MINI-SNAP®
Table of Contents

PRODUCT INFORMATION
Push-Pull connector series at a glance 12
Specific attributes of the series L, K and B 13
Functional principle of the Push-Pull locking 14
Facts & figures 15
PRODUCT INFORMATION
Table of Contents

12
PRODUCT INFORMATION
THE COMPLETE SERIES OF ODU PUSH-PULL
CONNECTORS AT A GLANCE
Keying Size No. of possible me- chanical keyings Plug diameter in mm Max. cable diameter in mm Number of max. contacts Solder Crimp PCB IP protection degree IEC 60529:2013 in mated condition IP protection degree IEC 60529:2013 in unmated condition From page
Pin and groove
00 46.4 3.5 04
• • • IP 50 Up to
IP 68 22
0 8 9 5.6 10
1 8 11.5 7.7 16
2 8 14.5 9.9 26
3 8 17.5 11.9 30
4 8 25 16 40
Pin and groove
0 8 11 5 10
••• Up to
IP 68
Up to
IP 68 74
1 8 13 716
2 8 16 926
3 8 19 10.5 30
4 8 25 14 40
Pin and groove
0 8 9.4 5 10
• • • IP 68 Up to
IP 68 114
1 9 12 7 16
2 10 15 926
313 18 10.5 30
FURTHER PRODUCTS OF THE ODU PUSH-PULL CONNECTOR SERIES.
ODU MINI-SNAP® L
ODU MINI-SNAP® K
ODU MINI-SNAP® B
• Keying over half-shell
• 2–27 contacts
• Low weight
• IP 67
• 3 sizes
• Plastic connector plug
housing
ODU MINI-SNAP® PCODU MEDI-SNAP® ODU MINI-SNAP® S
• Keying over insulator
• 2–10 contacts /
mixed inserts
• 3 sizes
• IP 50 and IP 68 with same
outer diameter possible
• Contacts for solder, crimp
and PCB termination
• Keying over half-shell
• 2–27 contacts /
mixed inserts
• 5 sizes
• IP 50 and IP 68 with same
outer diameter possible
• Contacts for solder, crimp
and PCB termination
ODU MINI-SNAP® F
• Push-Pull and
Break-Away version
• 3–55 contacts
• 6 sizes
• Watertight – IP 68
• Easy-Clean and
High-Density version
• Tested acc. MIL
• Low weight
(aluminium connector
plug housing)
ODU AMC®
• Push-Pull locking
• Break-Away functionality
• Distinctive coding options
– by colors and mechanics
• Lightweight
• 2 to 26 positions
• IP 50, IP 64 and IP 67
• Sterilizable versions
• 2,000 mating cycles
Table of Contents

13
PRODUCT INFORMATION
PRODUCT INFORMATION
CIRCULAR CONNECTORS WITH PUSH-PULL LOCKING
IN METAL CONNECTOR PLUG HOUSING
ODU MINI-SNAP is the ideal self-locking circular connector for a wide range
of applications. Whether used for transmitting power, signals, data or other
media, this circular connector in its robust metal connector plug housing
impresses customers with its exceptional quality, high reliability and ideal
handling characteristics.
The Push-Pull principle reliably ensures that the connector will not come
loose during application in practice: Once plugged in, the ODU MINI-SNAP
locks itself into the receptacle automatically. It cannot be separated by
pulling on the cable. Instead, the connector can easily be separated from the
receptacle by pulling on the outer housing.
The ODU MINI-SNAP is available in a wide range of sizes and models. In addi-
tion, you can choose between three base codings.
VERSATILE CONFIGURATION OPTIONS
There are 6 sizes, 3 termination types and
a great variety of various contact inserts to
choose from.
Table of Contents

14
PRODUCT INFORMATION
FUNCTIONAL PRINCIPLE OF
THE PUSH-PULL LOCKING
Push-Pull locking systems have a highly user-friendly locking mechanism.
When the connector is mated with the receptacle, the connector’s locking fi -
gers (1) will lock into place in the receptacle and form a dependable connec-
tion between both parts. It cannot be separated by pulling on the connector’s
cable (2). Instead, the connector can easily be separated from the receptacle
by pulling on the outer housing (3). Push-pull connectors from ODU are avail-
able in 6 dierent standard sizes with diameters from 6.4 mm to 25 mm.
You can read about the precise functioning of
the locking mechanism in the relevant series.
Connector
in mated condition
Pulling on the cable or back
nut will lock the “fi gers”
firm y in place in the recep-
tacle’s locking groove. This
prevents the connector
from being disconnected.
But pulling on the outer
housing will cause the
fi gers to emerge from the
locking groove, making
it easy to disconnect the
connector.
RECEPTACLE PLUG
1
2
3
Table of Contents

15
PRODUCT INFORMATION
PRODUCT INFORMATION
Turned contacts are available in diameter 0.5 mm to 2 mm
in the following termination types:
Solder, crimp and PCB
Mating cycles > 5.000
Material Brass
Plating Ni and Au
IMPORTANT ISSUES
AT A GLANCE
TURNED CONTACTS
VARIOUS SIZES
• Metal connector plug housing deliverable in 6 sizes
• Outer diameter 6.4 mm to 25 mm
• Number of contacts 2 to 40 contacts, mixed inserts
• IP 50 and IP 68 are deliverable.
APPLICATIONS AND MATERIALS
The ODU MINI-SNAP uses PEEK insulator material as a stand-
ard feature. Other materials are available upon request. ODU
MINI-SNAP connector plug housings are made of brass, nickel
plated and then matt chrome plated. Nickel and black chrome
plated connector plug housings are available upon request as
special materials. The internal parts are made of nickel-plated
brass.
Thanks to its versatility and autoclavability, the ODU MINI-SNAP
is used in a wide range of fields, such as medical technology,
measurement and testing technology, military and security
technology, industrial electronics and energy technology.
The temperature of ODU MINI-SNAP range under general condi-
tions of use runs from –40 °C to +120 °C, while autoclavable
connectors can even be used at temperatures up to +134 °C
(see page 170 ).
Information on diameters, terminal types and current-
carrying capacity can be found in the relevant series after
the inserts.
STANDARD PIN CONTACTS
Solder
termination
Clip-contact with
crimp termination
Plug Receptacle
Crimp termination • •
Solder termination • •
PCB termination • •
TERMINATION TECHNOLOGIES
PCB
termination
Table of Contents

ODU MINI-SNAP®
Table of Contents

CONFIGURATION GUIDELINE
Correct configuring – step by step
CONFIGURATION
Table of Contents

ODU oers you high-quality connectors and comprehensive service for the complete assembly.
From connectors to watertight grouting, we provide the complete system from a single source.
BIT BY BIT TO THE
PERFECT CONNECTION
Back nut
Cable collet
Half-shells
Insulator with contacts
Connector plug housing
Receptacle
Hex nut

YOUR WAY TO AN INDIVIDUAL CONNECTION:
HOW TO CONFIGURE WITH THE PART NUMBER KEY
12345678910 11 12 13 14 15 16 17 18 19
C – P – 0
Type
A = Break-Away connector / panel-mounted plug
G = Receptacle
K = In-line receptacle
S = Plug
W = Right-angled plug
1
Cable collet system
Style
1 – 9, A – Z
2
Insulator material1
(PEEK = standard)
8
Back nut
(Cable bend
relief)
19
Series
L, K, or B
4
Contact type /
surface
11
Keying
5
Size
00 – 4
3
Housing
material
matt chromate
(C)
Standard2
6
1 Other insulation materials on request. 2 Black chrome plated on request.
Connector plug housing
Series L from page 28, series K from page 80,
series B from page 120
Cable entry
Series L from page 64, series K from
page 108, series B from page 144
Contact insert
Series L from page 40, series K from page 90,
series B from page 126
Contact insert
e. g. 18 contacts = 18
910
17
16
Contact diameter /
termination cross-section
13 1412
This shows you how ODU’s part number key is composed. In the fir t part of the configuration, select the connector plug
housing (such as style and size) of the connector. In the middle part of the part number key, you configure the contact
insert and then the cable entry.
CONFIGURATION

Connector in style 2 / size 2 / series L / keying 0° / connector plug housing Ms matt chrome plated / insulator PEEK /
16 contacts / pin (solder) Au / termination cross-section AWG 22 / cable diameter 6–7.2 mm / back nut for silicone
cable bend relief (silicone cable bend relief has to be ordered separately)
SERIES L
SIZE 2
KEYING 0°
SAMPLE CONFIGURATION STEP BY STEP
The perfect product for you in just a few steps. These step-
by-step instructions show you how to configure your own
individual product with the ODU part number key based on
a sample configuration.
12345678910 11 12 13 14 15 16 17 18 19
L C – P – 0
12345678910 11 12 13 14 15 16 17 18 19
S 2 2 L C – P – 0 S
12345678910 11 12 13 14 15 16 17 18 19
S 2 2 L 0 C – P – 0 S
12345678910 11 12 13 14 15 16 17 18 19
S 2 L C – P – 0 S
STYLE S 2 WITH BACK NUT
FOR CABLE BEND RELIEF
CR
matt
12345678910 11 12 13 14 15 16 17 18 19
S 2 2 L 0C – P – 0 S
SURFACE MATT CHROMATE
(OTHERS UPON REQUEST)
STEP 1: SERIES (SEE POSITION 4)
STEP 2: STYLE (SEE POSITIONS 1,2 AND 19)
STEP 3: SIZE (SEE POSITION 3)
STEP 4: KEYING (SEE POSITION 5)
STEP 5: HOUSING MATERIAL (SEE POSITION 6)
CONFIGURATION
14.5
Page 28–38 (Series L), 80–87 (Series K), 120–124 (Series B)
Page 28–38 (Series L), 80–87 (Series K), 120–124 (Series B)
Page 39 (Series L), 88 (Series K), 125 (Series B)
Page 39 (Series L), 88 (Series K), 125 (Series B)
