Tsun TSOL-MT-F User manual

TSOL-MT-F
TSOL-MT-M
TSOL-MP-F
TSOL-MP-M
TSOL-MC200-G2
TSUNESS Co., Ltd
STORE THE FUTURE
User Manual

Accessories Instruction
www.tsun-ess.com
CONTENT
Read Me First 1
2
Warning 1
Contact 1
Female AC Connector (TSOL-MT-F)
Accessory Size 2
2
Connection Diagram
Technical Data 3
Male AC Connector (TSOL-MT-M) 4
Accessory Size
4
Connection Diagram 4
Technical Data 5
Female Protection Cap (TSOL-MP-F) 6
Accessory Size 6
Connection Diagram 6
Technical Data 7
Male Protection Cap (TSOL-MP-M) 8
Connection Diagram 8
Accessory Size 8
Technical Data 9
Technical Data 11
Connection Diagram 10
Connector Assembly 12
Instructions of Operation 14
AC Extension Cable (TSOL-MC200-G2) 10

Accessories Instruction
www.tsun-ess.com
1
Warning
Contact
Dear customer, thank you for choosing the TSOL micro inverter from TSUN. We hope
you will find our products meet your needs for renewable energy. Meantime, we appre-
ciate your feedbacks regarding our products.
This manual contains important instructions for the accessories of TSOL-M350 / M400 /
M800 / M1600 micro inverter and must be read in its entirety before installing or
commissioning the equipment. For safety, only qualified technician, who has received
training or has demonstrated skills can install and maintain these optional accessories
under the guide of this document.
If you have technical problems about our products, contact the TSUN Service line.
Read Me First
Only qualified personnel should install, troubleshoot, or replace these accesso-
ries.
Before installation, check the unit to ensure absence of any transport or
handling damage, which could affect insulation integrity or safety clearances.
All repairs should be carried out using only qualified spare parts, which must be
installed in accordance with their intended use and by a licensed contractor or
authorized TSUN service representative.
Please ensure the inverter system is not under working conditions firstly when
installing connectors, the human body cannot simultaneously contact the
connector’s positive and negative pole, in order to avoid electric shock
accidents.
Tel: [phone]
E-mail:[email protected] | www.tsun-ess.com
Add: Building E1, No. 555, Chuangye Road, Dayun Town, Jiashan County,
Jiaxing City, Zhejiang Province, China
TSUNESS Co., Ltd

2
www.tsun-ess.com
AC connectors are used to connect the micro-inverter in terrestrial PV systems to the
distribution box. The connection of pin and wire is screw type which is easy for field
installation.
For each project the usage quantity of AC connectors is depended on the system design
and at least 1 pcs. TSUN recommend the use of female AC connector.
Female AC Connector (TSOL-MT-F)
Accessory Size
Connection Diagram
TSOL-MT-F
Distribution Box
Male Connector
Microinverter
Recommended
Accessories Instruction

3
www.tsun-ess.com
Item Parameter
Type TSOL-MT-F
-40℃～+85℃
≤95%
2P+PE
TUV: 250V AC
25A (4mm²)
Copper alloy &silver plated
≤1mΩ
UL94-V0
III
Screw type
≥100MΩ
4000V AC
IP68（1.5m,24h）
10～50N
2.5/4.0 mm2
10～13mm
UL6703A,EN 61535,PPP 59015A:2013
2
Applicable environment temperature
Relative humidity
Electrode number
Nominal voltage
Nominal current
Material of pin
Contact resistance
Pollution degree
Enclosure flame class
Insulation resistance
Rated impulse withstand voltage
Degree of protection
Insertion and withdraw force(unlocked)
Applicable wire gauge
Outer cable diameter
Standards
Over-voltage category
Wiring Connection
Technical Data
Accessories Instruction

4
www.tsun-ess.com
Male AC Connector (TSOL-MT-M)
AC connectors are used to connect the micro-inverter in terrestrial PV systems to the
distribution box. The connection of pin and wire is screw type which is easy for field
installation.
For each project the usage quantity of AC connectors is depended on the system design
and at least 1 pcs.
Accessory Size
Connection Diagram
Microinverter
Female Connector
TSOL-MT-M
Distribution Box
Accessories Instruction

5
www.tsun-ess.com
Item Parameter
Type TSOL-MT-M
-40℃～+85℃
≤95%
2P+PE
TUV: 250V AC
25A (4mm²)
Copper alloy &silver plated
≤1mΩ
UL94-V0
III
Screw type
≥100MΩ
4000V AC
IP68（1.5m,24h）
10～50N
2.5/4.0 mm2
10～13mm
UL6703A,EN 61535,PPP 59015A:2013
2
Applicable environment temperature
Relative humidity
Electrode number
Nominal voltage
Nominal current
Material of pin
Contact resistance
Pollution degree
Enclosure flame class
Insulation resistance
Rated impulse withstand voltage
Degree of protection
Insertion and withdraw force(unlocked)
Applicable wire gauge
Outer cable diameter
Standards
Over-voltage category
Wiring Connection
Technical Data
Accessories Instruction

6
www.tsun-ess.com
Female Protection Cap (TSOL-MP-F)
Protection Cap are used to give the unused AC connector an IP67 protection from water
and dust.
For each project the usage quantity of protection caps is depended on the system design
and at least 1 pcs. TSUN recommend the use of female protection caps.
Accessory Size
Connection Diagram
Microinverter
Female Connector
TSOL-MP-F
Recommended
Accessories Instruction

7
www.tsun-ess.com
Technical Data
Item
Type
Material
Degree of protection
Flame retardant rating
Standards
silicone rubber
TSOL-MP-F
IP67
UL94-V0
ROHS
Parameter
Accessories Instruction

8
www.tsun-ess.com
Protection Cap are used to give the unused AC connector an IP67 protection from water
and dust.
For each project the usage quantity of protection caps is depended on the system design
and at least 1 pcs.
Male Protection Cap (TSOL-MP-M)
Accessory Size
Connection Diagram
TSOL-MP-M
Male Connector
Microinverter
Accessories Instruction

9
www.tsun-ess.com
Item
Type
Material
Degree of protection
Flame retardant rating
Standards
silicone rubber
TSOL-MP-M
IP67
UL94-V0
ROHS
Parameter
Technical Data
Accessories Instruction

10
www.tsun-ess.com
AC Extension Cable (TSOL-MC200-G2)
Connection Diagram
AC connectors are used to connect the micro-inverter in terrestrial PV systems to the
distribution box. The connection of pin and wire is screw type which is easy for field
installation.
TSOL-MC200-G2
MicroinverterMicroinverter
TSOL-MC200-G2
012345678912032156
012345678912032156 012345678912032156 012345678912032156
012345678912032156012345678912032156
Accessories Instruction

11
www.tsun-ess.com
Technical Data
Item
Type
Connector type
Nominal voltage for connector
Nominal current
Wire gauge
Length
UV resistant
Fire performance of cable
Operating Temperature
Product Standard of cable
TSOL-MT-F * 1 pcs
TSOL-MC200-G2
TSOL-MT-M * 1 pcs
250V AC
25A (4mm²)
4.0 mm2
2m
UL1581
Vertical-Tray flame test UL1277
-40 to +90
UL44 UL1277 UL1581 ROHS
Parameter
Accessories Instruction

12
www.tsun-ess.com
Connector Assembly
Only multiple strands of copper wire can be used. Please cut and strip the wire according
to the requirements, and the ground wire needs to be 5mm longer than live and naught
wire, and the applicable stripping length is 7 ~ 8mm.
Screwing off the tail parts (End Locker, Wire Sealing Claw and Wire Sealing) from male
or female cable connector, and then pulling the wire which was cut and stripped through
them in turn.
Inserting the stripped wires correctly into the corresponding pin holes according to the
identification and then tightening all screws firmly, Screw twisting torque 0.4±0.1N•m.
after it , giving a reverse pull force lightly ( about 10N ) by manual to test crimping result.
Please pay attention to avoiding damage of pins and pin-holder.
Wire sealing
Housin
g
Bod
y
Wire Sealing Claw
Cable
Endlocker
Accessories Instruction

13
www.tsun-ess.com
Push the sealing body and sealing craw into the housing body, and then tighten the
end locker, torque 4.0±0.5N•m.
After crimping, the tensile strength shall meet the requirements listed in the following
table：
Push the male or female cable body into housing body correctly according to the position
of the clamping groove , and will hear a crisp “click” sound in place.
click
click
Accessories Instruction

14
www.tsun-ess.com
Please switch off the system power and ensure the male and female connector are of the
same type before using;
When mating connectors, align mate-locker on the male connector with grooves on the
female connector, and insert gradually .Connected in place, there will be a sound of
"click";
Wire Sealing claw
Housing Body
Wire Sealing
Cable
End Locker
Instructions of Operation
Accessories Instruction

15
If the connectors are separated, choose a corresponding flat screwdriver to push mate-lock-
er step slightly out of position, and then give a force along the axial direction until separa-
tion.
If the connector to be disassembly for rewire, please according to the following
steps:
1) Loosen tail parts (End Locker, Wire Sealing Claw and Wire Sealing body);
2) Use a suitable flat screwdriver to press the elastic tongue on the male or female
cable body inward and push forward slightly, and when the tongue comes off a
little, use the same method to the tongue on other side. Give a force along the
axial direction until separation.
www.tsun-ess.com
Click
Accessories Instruction

©2018 TSUNESS. All rights reserved. All specifications are subject to change without prior notice.
