Altronix eBridge100RMT Kit User manual

I.T.E. 43KC
Z1409
eBridge100RMT Kit
IP and PoE+ over
Coax or Extended Ethernet Cable
eBridge100RM Receiver and eBridge100TM Transceiver Kit
Installation Guide
Rev. 111413 More than just power.TM
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
PLUS

- 2 - eBridge100RMT Installation Guide
Overview:
Altronix eBridge100RMT is a versatile dual solution Ethernet adapter/media converter kit which transmits data
at 100Mbps full duplex and power over Coax cable or extended CAT5e cable in a PoE+ compliant format. The
eBridge100RM is powered via a PoE midspan such as the Altronix Netway series or by an endspan. The receiver
passes the PoE(+) compliant power over cable to the eBridge100TM transceiver which in turn passes this power
to an enabled IP Camera/device. These plug and play units facilitate cost effective solutions for IP devices that
need to be installed at distances greater than 100m. They also provide a simple way to replace legacy analog
products with new IP devices over existing coax or structured cable.
Features:
*See note on the bottom of Page 3.
Agency Listings:
• UL/cUL Listed for Information
Technology Equipment (UL 60950-1).
• CE European Conformity.
• C-Tick compliant.
Input eBridge100RM:
• Powered by midspan or endspan.
PoE compliant to IEEE 802.3af (15W) and
PoE+ compliant to IEEE 802.3at (30W).
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5.
• Distance: up to 500m.
• Speed: 10/100BaseT, half/full duplex,
auto negotiation.
PoE compliant to IEEE 802.3af (15W) and
PoE+ compliant to IEEE 802.3at (30W)
Delivered to camera by eBridge100TM.
Power provided byveBridge100RM to
eBridge100TM by PoE protocol.*
• Throughput is rated to pass 100Mbps of data
at distances up to 500m.
Coax Link:
• Distance: Coax 300m (Maximum Length of Coax
Type vs. Camera Power/PoE Class, pg. 4) for
power delivery.
• Connectivity: BNC, RG-59/U or similar.
Coax or CAT5e Link:
• Distance: CAT5e up to 500m, Coax 300m
(Maximum Length of Coax or CAT5 Type vs.Camera
Power/PoE Class, pg. 4) for power delivery.
LED Indicators:
• eBridge100RM and eBridge100TM:
Green - PoE ON (by respective RJ45 jack).
• eBridge100RM and eBridge100TM:
Yellow and Green LED (RJ45) IP Link
status, 10/100Base-T/active.
Environmental:
• Operating Temperature:
eBridge100RM:
– 20ºC to 49ºC (– 4ºF to 120.2ºF).
eBridge100TM:
– 20ºC to 49ºC (– 4ºF to 120.2ºF).
• Storage Temperature:
– 30ºC to 70ºC (– 22ºF to 158ºF).
• Humidity: 20 to 85%, non-condensing.
Functions:
• Auto detection and protection of legacy
non-PoE cameras/devices.
Applications:
• Retrofit digital IP cameras in an analog
CCTV installation.
• Works with Megapixel, HD720, HD1080 and
VGA (SD) cameras (see note, pg. 3).
• Extend Network link distance in an industrial
environment over 700m (see note, pg. 3).
• Upgrade deployed CCTV Coax to a digital network in
Retail, Casinos, Airports, Schools, Hospitals, etc.
Mechanical:
• Dimensions (W x L x H approx.):
eBridge100RM/eBridge100TM:
3.5” x 4.375” x 1” (88.9mm x 111.1mm x 25.4mm).

eBridge100RMT Installation Guide - 3 -
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes
and authorities having jurisdiction. Wiring should be UL Listed and/or Recognized wire suitable for the application.
eBridge100TM and eBridge100RM are not intended to be connected to outside plant leads and should be installed
indoors within the protected premises. eBridge100TM and eBridge100RM are intended for indoor use only.
Note: The eBridge100RM and eBridge100TM are a paired set and must be used together.
1. eBridge100RM installation:
a. Secure unit to desired mounting surface with a proper fastening device utilizing the unit’s mounting hole
(Fig. 2a, pg. 4). Unit should be mounted in proximity to ethernet switch/network, NVR or video server.
Note: When installing more than one (1) eBridge100RM, please allow at least 1” (25mm)
distance between the receivers.
b. Connect structured cable from Ethernet midspan or endspan device to RJ45 jack marked [PoE Input]
(Fig. 2, pg. 4).
c. When connecting to the eBridge100TM use either Coax or CAT5 or higher wiring:
Coax: Connect Coax cable to BNC connector marked [Coax] (Fig. 2, pg. 3).
CAT5 or higher: Connect CAT5 or higher to connector marked [RJ45 OUT] (Fig. 2, pg. 4).
2. eBridge100TM installation:
a. Secure unit to desired mounting surface with a proper fastening device utilizing the case’s mounting hole
(Fig. 2a, pg. 4). Unit should be mounted in proximity of camera/device.
b. Connect structured cable from IP camera/device to RJ45 jack marked [PoE Out] (Fig. 2, pg. 4).
c. Coax: Connect Coax cable to BNC connector marked [Coax] (Fig. 2, pg. 4).
CAT5 or higher: Connect CAT5 or higher to connector marked [RJ45 IN] (Fig. 2, pg. 4).
Note: The eBridge100RMT is designed to accommodate Megapixel, HD720, HD1080 and VGA (SD) cameras.
It is important to note that some high resolution and high frame rate cameras may demand faster headend
processing ability, such as a PC graphics card to present a quality image. If the headend processing equipment
is insufficient in speed, the image may show pixilation and latency. It is advisable to pretest system if unsure.
Alternatively, frame rate and resolution may be reduced to accommodate system equipment.
Technical Specifications:
Parameter Description
Connections BNC for Coax link. RJ45 for extended Ethernet link.
Input Power Requirements Midspan or endspan port connected. PoE compliant to IEEE 802.3af (15W) and
PoE+ compliant to IEEE 802.3at (30W).
Indicators
Yellow (RJ45 connector): On - Link, Off - No Link, Blinking - Activity.
Green (RJ45 connector): On - 100Base-TX, Off - 10Base-T.
Green: PoE Active.
Environmental Conditions
Operating Ambient Temperature (UL60950-1):
eBridge100RM: – 20ºC to 49ºC (– 4ºF to 120.2ºF).
eBridge100TM: – 20ºC to 49ºC (– 4ºF to 120.2ºF).
Storage Temperature: – 30ºC to 70ºC (– 22ºF to 158ºF).
Relative humidity: 85% +/– 5%
Operating Altitude: – 304.8 to 2,000m.
Regulatory Compliance UL/cUL Listed for Information Technology Equipment (UL 60950-1).
CE European Conformity C-Tick compliant.
Weights (approx.) Product: 0.45 lb. (0.2 kg) | Shipping: 0.8 lb. (0.36 kg)
*Note: Caution: once PoE connection is established between eBridge100RM and eBridge100TM, disconnection
from eBridge100TM will not disable the PoE output voltage on the eBridge100RM, although the eBridge100TM
can be reconnected, caution should be taken not to connect the CAT5 or single UTP wiring from eBridge100RM
to any non-PoE device.

- 4 - eBridge100RMT Installation Guide
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Single PoE Camera Connection:
Fig. 2 Fig. 2a
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Maximum Length of Coax/CAT5 Type vs. Camera Power/PoE Class:
Cable Type Total Power Consumption Max Data Distance Max Power Distance
RG59u/23awg 13W 300m 264m
RG59u/23awg 25W 300m 132m
RG59U/22awg 13W 300m 334m
RG59U/22awg 25W 300m 167m
RG59U/20awg 13W 300m 532m
RG59U/20awg 25W 300m 266m
RG59U/18awg 13W 300m 846m
RG59U/18awg 25W 300m 423m
CAT5e 13W 500m 846m
CAT5e 25W 500m 423m
Fig. 1 eBridge100RM eBridge100TM
Structured
Cable from
Midspan/
Endspan
Green LED
indicates
PoE Present
from Midspan/
Endspan
Green LED
indicates
PoE being
transmitted
to eBridge100TM
CAT5 or higher
out to
eBridge100TM
CAT5 or higher
from
eBridge100TM
Coax out to
eBridge100TM
Coax from
eBridge100RM
Structured
Cable to
Camera/Device
Green LED
indicates
PoE transmitted
to Camera/Device
Green LED
indicates
PoE received
from
eBridge100RM
Ethernet Switch
NetWay8M - Front Panel
+ PoE --
SHUTDOWN
Local Area Network (LAN)
or Laptop connection
PoE/PoE+ over Coax
up to 300m max. PoE compliant
100m max.
100m max.
Structured Cable
Legend:
Mounting Hole
PoE Camera
Coax
eBridge100RM eBridge100TM
RJ45
OUT
PoE
LED
PoE
LED
Coax
RJ45 LEDs Yellow - Speed
Green - Activity
Yellow LED Power and PoE
PoE
Input
I.T.E. 43KC www.altronix.com
Z1409
eBridge100RM
EoC Receiver
passes PoE/PoE+
RJ45
IN
PoE
LED
PoE
LED
Coax
RJ45 LEDs Yellow - Speed
Green - Activity
Yellow LED Power and PoE
PoE
OUT
I.T.E. 43KC www.altronix.com
Z1409
eBridge100TM
EoC Transceiver
passes PoE/PoE+
Mounting Hole
RJ45 LEDs Yellow - Speed
Green - Activity
Green LED Power and PoE
I.T.E. 43KC
Z1409
eBridge100RM - Receiver
Passes PoE/PoE+
Brooklyn, NY, U.S.A.
www.altronix.com
RJ45
Link
Output
PoE
LED
Input
PoE
LED
PoE
Input
Coax
Link
RJ45 LEDs Yellow - Speed
Green - Activity
Green LED Power and PoE
Coax
Link
I.T.E. 43KC
Z1409
eBridge100TM - Transceiver
Supports PoE/PoE+
Brooklyn, NY, U.S.A.
www.altronix.com
RJ45
Link
PoE
Out
Output
PoE
LED
Input
PoE
LED
