DAYCO 0901 User manual

GENERAL DESCRIPTION
+ C Fold toilet paper dispenser made with
stainless steel 304 S.S and 430 S.S. 0.60 & 0.70 mm
thicknesses.
+ Available in two type of finishes (bright and satine)
+ Useful for the public areas.
+It is mounted with three steel 4 mm screws
(provided in the box) with their 8 mm plastic plugs
(also provided)
+ Metal lock sytem is exist to protect the paper inside
clean and safe.
COMPONENTS AND MATERIAL
+ 0901-Stainless Steel 304 satine finish
+ 0901A-Stainless Steel 430 satine finish
+ 0901P-Stainless Steel 304 bright finish
+ 0901PA-Stainless Steel 430 bright finish
0901
C Fold Toilet Paper Dispenser
0901
1/2
TECHNICAL DATA SHEET
0901
22 cm
8,6614"
11,5 cm
4,5276"
10,5 cm
4,1339"
11,5 cm
4,5276"
Alt Görünüm
10,5 cm
4,1339"
Max 11 cm
C Fold Paper
Max 10 cm

INSTALLATION
+ First measure out
where the lid dispenser
will be placed, mark
four holes and drill
into the wall.
+ Insert the provided
wall plugs and screw
in the top two screws,
leaving a slight gap
for the dispenser
to slot onto.
+ Open the dispenser
lock before mounting
the dispenser to
the wall.
+ Slot the dispenser
onto the two previously
fixed screws and then
screw final one screw.
+ Once the dispenser
is secure, you can
close the lid.
MOUNTING TEMPLATE
Should be minimum 60 cm high from the floor.
DISPENSER REPLACEMENT REQUIREMENTS
AND RECOMMENDATIONS
e following recommendations are intended to
provide guidelines on the best possible placement
of the dispensers. Because every location a dispenser
is to be mounted is different, depending on customer
site, physical size limitations, and available space,
these recommendations may not always be entirely
possible to follow.However, when placing a dispenser
installation must meet ADA requirements and
2/2
TECHNICAL DATA SHEET
should promote ease of use and be in union with its
surroundings.Upon installation, the dispenser should
be level and the job results professional,presentable
and fully functional.
AFTERCARE INSTRUCTIONS
+ Regular cleaning with a soft cloth will keep the
surface of your product looking new. Soapy water
can be used to remove stubborn marks. Dont use
abrasive or chemical cleaners as these may damage
the surface finish over time.
+ Don’t expose to sunlight.
+ Don’t respond to the product with force against
the possibility of damnification, deformation.
+ Don’t throw any cigarettes and flammable materials
into the product.
80
115
0901
Kg Kg
X
Y
Z
X
Y
Z
X
Y
Z
PRODUCT PRODUCT CARTON CARTON INBOX PALLET GROSS PALLET GROSS PALLET
CODE DIMEN. DIMEN. WEIGHT QUANTITY QUANTITY DIMEN. WEIGHT
0901 10,5x11,5x22 cm 36x44x46 cm 12 kg 12 240 80x120x200 cm 255 kg
