Installation and Operation Guide
January 2011
Revision- January 2021
AM Series
Single Leg Hydraulic Jack: 12,000# Capacity
Installation
Tools Required for Installation
•Ratchet, sockets and wrench set
•Wire cutters / crimpers
•Electric drill and bits
•Screw gun bit
•Welding equipment (if welding jack in place)
Additional Parts Needed for Installation
•# 4 gauge power wire (to connect battery +12V Positive
•to the Pump)
•# 4 gauge ground wire (to connect battery -12V Ground to Pump)
•# 4 gauge ring terminals
•Loom clips (to secure switch and harness to the trailer)
•Self tapping screws or pop rivets (to secure loom clips)
•Wire tie
Jack
Your AM Jack may have been provided with a mounting flange or bracket (depending on the
mounting option ordered for your system). When Bolting the Jack to the trailer we recommend using
Grade 8 bolts. Welding the Jack in place requires sound welding practices.
The Jack should be mounted so that when the trailer is level (while mounted to the tow vehicle) there is
10 inches Minimum of Ground Clearance. This is usually achieved by mounting the jack so that the
foot is slightly below the bottom edge of trailer. The bottom of the footpad should not be lower than
any other Item mounted on the trailer.

Switch Harness and Hydraulic Lines
The AM Jack has been shipped with all necessary Switchgear, Harnesses and Hydraulic Lines.
These items are specifically engineered to operate your System and should not be altered in any
manner. Modification of any factory supplied item may result in the denial of all warranty claims.
Switchgear
The Unit may have been provided with a key switch in the switchgear box (depending on the option
ordered). If unit is not supplied with a key switch, the +12v battery lead must be fed through a power
disconnect switch to fully isolate the system during travel or inactivity. Minimum disconnect switch rating
must be Minimum 100 ampere DC. Switchgear is plugged into the system harness through a weather
resistant connector (shown in Fig.1)
Fig.1-Weather Resistant Connector
Battery Connections
Pumps #’s 2142, 2390, 2532, 3126, 3170:
Battery Lead (+12volts): Attach a # 4 gauge wire between the positive (+12V) terminal on the
battery and the large post on the solenoid opposite the black motor wire on the solenoid. If circuit
protection is required, Install an 80 amp (minimum) circuit breaker.
Battery / Pump Ground (-12volts): Attach a # 4 gauge wire between the negative (-12v) terminal
on the battery and the ground stud located directly in front of the motor. It is not acceptable to allow
the Jack mounting bolts or the weld to be the sole grounding connection.
Pump #’s 3040, 3041, 3200, 3201 and 3201KS see Fig. 2
Attach a minimum # 6 gauge wire between the positive (+12V) terminal on the battery and the plus ( + )
terminal on the contactor. Attach a minimum #6 Gauge wire between battery negative ( - ) and the
negative terminal on the contactor. Note: These units will not ground thru the mounting. The described
ground/negative battery to contactor connection must be made.
Fig. # 2: Pictured
Pump #’s, 3040, 3041,
3200, 3201 and 3201KS
Attach battery negative
(ground) to
contactor here
(6 gage min)
Attach +12V
Positive from Power Supply
(6 gage min)

Reservoir Breather Cap for Pump on units that are shipped assembled and filled with fluid.
With the jack installed in the vertical position, remove the flush mounted fill plug from the top of the
reservoir and discard. Replace with breather cap. Failure to do so will cause the jack to
operate erratically.
Operation
To raise and lower the jack, simply push and hold the rocker switch in the up or down position. The
jack will hold a position by releasing the switch at any time. There is no need to take the weight off
the jack when storing the trailer, as the positive check valves in the system will not allow the jack to
bleed down.
*Note: When the jack is fully retracted, the fluid level in the reservoir should be approximately one
inch below the fill cap. If fluid needs to be added, use Dexron III automatic transmission fluid (the
same as used for a GM automobile).
✷Caution ✷
The keyed switch must be in the off position and the key must be removed when the jack is not in
use and/or when the trailer is in transit. If unit is not supplied with a keyed switch, the +12v
battery lead must be fed through a power disconnect switch to fully isolate the system during
inactivity or travel. The minimum switch rating must be 100 ampere DC.
With any hydraulic application, holding any position on a cylinder must be done with safety in
mind. Failure in the system may cause the jack to retract or extend on its own. When working
under or near the trailer, always use jack stand of appropriate rating to support the weight of the
trailer.
Manual Override –Hand Pump - Pump # 2142 & 3126, 3170
The following procedure gives step-by-step instructions on how to operate the manual override to
either extend or retract the jacks.
Your AM series Single Leg Jack is available with a Manual Override, depending on the specific
unit ordered. If your unit is equipped with the Override Hand Pump, it is operated as follows:
To Extend your Jack:
1. Install a handle in the hand pump. Pump the handle to extend the jack. You may have to
pump 10-20 times before you build enough pressure and the jack begins to extend.
To Retract your Jack:
1. Locate the red knurled knob on the directional valve. Pull it out and turn ¼ turn. The knob
will remain in the “out” position. Do not use anything other than your fingers to manually
shift the directional valve.
2. Install a handle in the hand pump. Pump the handle to retract the jack. You may have to
pump 10-20 times before you build enough pressure and the jack begins to retract. Return
the directional valve to the normal position.
Caution: Following manual override operation, failure to return all valves to normal position
may result in one or more jacks drifting down from their retracted (stowed) position. For
directional valves, rotate the red knob until it “snaps” back to the normal position.

Manual Override –Output Shaft
If your unit is not equipped with the override hand pump, it is operated as
follows: Pump #’s 2390, 2532, 3040, 3041,3043, 3200, 3201, 3201KS
1/4 “ (6mm) Allen Drive Hex Key or 7/16 “ (11mm) Hex Head Socket
Your hydraulic motor is equipped with a manual override output shaft. The drill must be capable
of producing a minimum of 2000 rpm for the pump to develop appropriate pressure output.
To Retract your Jack: Uni-Rotational Pump # 2142, 3126, 3170
1. Locate the red knurled knob on the directional valve; this valve will be on the side of the
manifold. Pull the red knob out and turn 1/4 turn. The knob will remain in the “Out”
position. Do not use anything other than your fingers to manually shift the directional
valve.
2. Remove the black plastic cap / silver seal from the top of the motor. Place the drill with
the proper size hex bit on the manual override shaft located at the top of the motor. Run
drill in a clockwise direction at 2000 rpm (minimum). The jack (s) will retract.
3. When retraction is complete, return the directional valve to the normal position. Reinstall
black plastic cap / silver seal on motor end.
Caution: Following manual override operation, failure to return all valves to normal
position may result in one or more jacks drifting down from their retracted (stowed)
position. For directional valves, rotate the red knob until it “snaps” back to the normal
position.
Note: The normal operating position of the red knob on the directional valve is the “in” position.
The only time the valve should be shifted manually is when attempting to operate jack via manual
override.
To Extend Your Jack:
1. To extend the jack, follow all of the above steps Except Do Not manually shift the
directional valve as described in step #3 above.

To Retract your Jack: Bi Rotational Pump #’s 2390, 2532, 2542, 3040, 3041, 3043, 3200, 3201 and
3201KS 1. Remove the black plastic cap / silver seal (foil) from the end of the motor.
2. Insert drill (capable of minimum 2000rpm) and hex key, 1/4 “ (6mm) Allen drive hex
key or 7/16 “ (11mm) Hex head socket into motor. Rotate counter-clockwise.
To Extend your Jack:
1. Operate the drill in clockwise rotation.
Problem Solving
“The jack runs for a few seconds, then stops”
Your battery is weak or battery capacity is diminished. Charge the battery fully. It may be necessary
to “load test” the battery.
“The jack only runs in one direction”
Verify appropriate battery voltage. Verify that all wires are attached appropriately. The jack may
only run in the extend direction if the battery does not have enough capacity to operate the motor
and shift the directional valve.
“I push the switch and nothing happens”
Ensure both positive and negative 12V have adequate connection. Ensure full charge on your
battery. 9 out of 10 calls we receive are related to a discharged battery. Ensure that battery connections
to the jack (pump assembly) are correct per the installation instructions. Check all associated wiring.
“The jack is jerky when retracting”
This may be caused by air in the system, low fluid level or incorrect hose installation. To purge jack,
add fluid as necessary and run the jack to full extension and retraction at least twice. If problem
persists, call Equalizer Systems for assistance.
If your problem is not listed or persists, call Equalizer Systems at 1-800-846-9659.
Please Gain Prior Authorization for Warranty Service or Repair.

Assembly Wiring, Pump #’s 2390, 2532
Solenoid Wiring Bi-Rot Pump #’s 2390, 2532, 2542
Wiring for Pump # 3040, 3041, 3200, 3201 and 3201KS
