DB GROUP HERRAJES Snack User guide

TECHNICAL DRAWINGS
MOUNTING INSTRUCTION
SNACK
P. 1

THE PACKAGING INCLUDES:
M6x40 SELF THREADING SCREW (x12)
A - SLIDES ASSEMBLY (x2)
B - 2348 mm SPAR (x2) FOR 411-78.1281.22
- 1748 mm SPAR (X2) FOR 411-78.1282.22
C - 709 mm SPAR (x1)
D -
P. 2
3.5x14 WOODEN SCREW (x10)
E -
F - BLOCKING PIN (x2)
G - 3.5x9.5 SELF THREADING SCREW (x8)

CABINET REQUIRED INTERNAL DIMENSIONS
P. 3
WIDTH: 2508 mm (2458 minimum if first slide is inserted in the cabinet side) FOR 411-78.1281.22
WIDTH: 1908 mm (1858 minimum if first slide is inserted in the cabinet side) FOR 411-78.1282.22
DEPTH: min. 800 mm
HEIGHT: min. 80 mm
TABLE PLANE THICKNESS: 19 mm
TOTAL LENGTH OUTSIDE THE CABINET: 640 mm
WIDTH: 2508-2457 / 1908-1857 mm
DEPTH: 800
HEIGTH: min 80
640

2458
800
25
55
765
5
min.
TOP
EXTERNAL SLIDE
(FIXED TO THE CABINET SIDE)
INTERNAL SLIDE
(FIXED TO THE TOP)
P. 4
INSERT A SPACER OVER THE
INTERNAL SLIDE

1
2
3
SLIDES DISMOUNTING
TO DISASSEMBLY THE INTERNAL SLIDE, PUSH IT TO THE LEFT
TILL IT STOPS (SEE FIG."1").
USING THE INDICATED HOLE, UNSCREW
THE FIXING GRAINS OF THE BALL BEARING SLEDGE
MOUNTED ON THE CENTRAL SLIDE (SEE FIG. "2").
TO DO THIS USE A #2.5 ALLEN KEY.
AFTER UNSCREWING THE TWO GRAINS, PUSH THE INTERNAL
SLIDE TO THE RIGHT AND DISMOUNT IT (AND THE SLEDGE) FROM
THE OTHER TWO SLIDES (FIG. "3").
INTERNAL SLIDE
INSERT IN THIS HOLE
THE 2.5 ALLEN KEY
BALL BEARINGS SLEDGE
GRAIN
P.5
INTERNAL SLIDE CENTRAL
SLIDE
BALL BEARINGS SLEDGE

INTERNAL FRAME ASSEMBLY
P.6
E - M6x40 (x12)
B -
C -
E
E
E
E
90°
BUTTON SIDE
(WITH COUNTERSINKED AND BIGGER
HOLES)
UPPER SIDE
B -
TO ASSEMBLY THE INTERNAL FRAME, USE THE INCLUDED
M6x40 SCREWS. ATTENTION TO THE "B" BARS, THEY HAVE
AN UPPER SIDE AND A BUTTON ONE.
INTERNAL SLIDE
DISMOUNTED AS SHOWN
ON PAGE 4
INTERNAL SLIDE
DISMOUNTED AS SHOWN
ON PAGE 4
INTERNAL SLIDE
DISMOUNTED AS SHOWN
ON PAGE 4

AA
A
MECHANISM FINAL ASSEMBLY
RUBBER PART
LOOK AT THE DOT
302
GRAIN
SLIDE
TO ASSEMBLY THE FRAME ON THE SLIDES,
INSERT IT FROM THE BACK OF THE SLIDES
AS SHOWN AND THEN REPOSITION THE TWO
BALL BEARINGS SLEDGES.
THE BALL BEARINGS SLEDGES MUST BE POSITIONED
AS SHOWN TO THE RIGHT AT 302 mm FROM THE
END OF THE SLIDES AND THE FIXED USING
A 2.5 ALLEN KEY REVERSING THE PROCEDURE
SHOW ON PAGE 3.
P. 7
FRAME
ASSEMBLED AS SHOWN ON PAGE 5
SLEDGE
SLEDGE
SLEDGE

55
25
CLEARANCEBETWEENSLIDES
ANDBOTTOMOFTHETOP
FURNITURE CROSS_SECTION
55
765
19
41
62,5
55
222,5 320
320 320
n
5
P. 8
800
ASSEMBLY TO THE CABINET SIDE
TO ASSEMBLY THE MECHANISM ON THE CABINET,
USE THE "D" WOODEN SCREWS INSERTED IN THE
FIVE HOLES IN THE EXTERNAL SLIDES.
EXTERNAL SLIDE
D - (x5)

P.9
TABLE TOP
TO FIX THE TABLE TOP, USE THE 8 DIAM. 6 HOLES (TWO IN EACH INTERNAL SLIDE AND
FOUR IN EACH SPAR). THESE HOLES ARE INDICATED AS "A" ON THE FIGURE.
ON EACH SPAR THERE ARE TWO ADDITIONAL M6 HOLES AT YOUR DISPOSAL FOR FITTNIG
PROPER SPACER TO BE INSERTED BETWEEN THE FRAME AND THE TOP.
THESE HOLES ARE INDICATED AS "B" ON THE FIGURE.
IT IS SUGGESTED TO KEEP SOME CLEARANCE (MINIMUM 2 mm) BETWEEN THE TOP OF THE
SLIDES AND THE BOTTOM OF THE TOP (SEE SECTION ON PAGE 4 AND 7).
A
A
AB

AA
A
BLOCKING PINS
P.10
F -
G -
IF NECESARY, MOUNT THE TWO BLOCKIN
PINS (F), ONE FOR EACH SIDE.
USE THE 3.5 SCREWS (G) TO FIX THEM
THIS PART MUST GO UP WHEN YOU
WANT TO MOVE THE TOP. IT SHOULD
ENTER IN A HOLE DRILLED IN THE TOP
THIS END OF THE PIN GOES DOWN WHEN
THE MECHANISM IS OPENED AND
MUST ENTER IN A HOLE DRILLED
ON THE CABINET
