DC HP User manual

HIGH POST MODEL: HP
STEP 1
Ensure foot is fully threaded in.
Locate the post and ensure it is visually plumb.
Minimum edge distance: 2” (50 mm)
STEP 2
Remove the lock pin and extend the outer tube
until the head contacts the slab above.
Install the lock pin in the closest hole.
STEP 3
Turn the post counterclockwise until it is tight
and until there is no red showing at the visual
“safe” indicator.
1 2a
2b 3
INSTALLATION
HEAD VISUAL “SAFE”
INDICATOR
INNER TUBE
LOCK PIN
OUTER TUBE
FOOT
Maximum spacing of High Posts not to exceed 9’ (2743 mm)
WEIGHT: 28 lbs / 12.7 kg
HEIGHT: 8’2”–13’6” / 2489–4115 mm
CLOSED HEIGHT: 7’1” / 2159 mm
When all the steps are completed, the High Post is ready for the
Speed Fence or temporary guardrail to be installed
STORAGE PIN HOLE
MIN 2”
(50mm)

ALWAYS REFER TO GENERAL SAFETY NOTES BEFORE INSTALLATION
FOR TECHNICAL ASSISTANCE:
[email protected]
[phone]
dellcore.com
1
3
2
DISMANTLING
STEP 1
Turn the post clockwise until the head is
clear of the slab above.
STEP 2
Remove the lock pin and lower the outer
tube to its lowest position.
STEP 3
Install the lock pin in the “Storage Pin Hole”
and ensure foot is fully threaded in.
