MetalTech JOBSITE I-IDS1830 User manual

1YEAR
WARRANTY
Picture may differ from actual product
OPERATIONAL SAFETY
AND ASSEMBLY INSTRUCTIONS
THE STILTS ARE FOR PROFESSIONAL USE ONLY!
WE WILL NOT BE HELD RESPONSIBLE FOR ANY ACCIDENT
RESULTING FROM IMPROPER USE, IRRESPONSIBLE USE, OR
FAILURE TO INSPECT AND ADEQUATELY MAINTAIN ACCORD-
INGLY. THIS IS THE SOLE RESPONSIBILITY OF THE USER.
This manual gives imperative information on appropriate
operations and maintenance. Each exertion has been made to
guarantee the precision of this manual.These guidelines are
not intended to cover each conceivable condition and
circumstance that may happen.We reserve the right to change
this product at any time without prior notice.
IT IS VITAL THAT STILTS BE ASSEMBLED PROPERLY AND
ADJUSTED ACCORDING TO PERSONAL SIZE AND PREFER-
ENCE. ADDITIONALLY, IT IS CRITICAL TO PROPERLY KEEP
UP THE GOOD CONDITION OF YOUR STILTS AND TO FULLY
EXAMINE YOUR STILTS BEFORE EVERY USE, ENSURING ALL
FASTENERS; BOLTS, NUTS, WING NUTS AND SCREWS ARE
TIGHT. IT IS YOUR RESPONSIBILITY TO READ, UNDERSTAND
AND FOLLOW THESE INSTRUCTIONS, AND TO ALWAYS
PRACTICE CAUTION UTILIZING STILTS. STILTS OUGHT TO BE
USED ONLY IF WORKING ON A LEVEL FLOOR, CLEAR OF ANY
OBSTRUCTIONS OR DEBRIS.
IF THERE’S ANY QUESTION ABOUT CONDITIONS BEING
SAFE OR UNSAFE, DON’T USE THIS PRODUCT!
WARNING!
READ ALL INSTRUCTIONS, WARNINGS IN THIS MAN-
UAL AND LABELS ON THE PRODUCT BEFORE USING
STILTS. IT IS YOUR RESPONSIBILITY TO READ,
UNDERSTAND AND FOLLOW THESE INSTRUCTIONS.
BROKEN OR MISSING PARTS?
DO NOT RETURN THE PRODUCT TO THE RETAILER FROM
WHICH IT WAS PURCHASED – PLEASE CONTACT OUR
CONSUMER SERVICE DEPARTMENT.
If you experience a problem, have any questions concerning
the assembly or use of this product or need replacement
parts, please contact our customer service:
1 800 363-7587 / 450-681-6440 / [e-mail]
MODELS:
I-IDS1830
I-IDS1830QP
I-IDS2440
FRANÇAISESPAÑOL ENGLISH

2
METAL CONDUCTS ELECTRICITY:
Do not use this equipment where contact may be made with power lines or other live electrical circuits.
DO NOT OVERLOAD:
These stilts are designed to support a maximum load of 225 lb (102 kg).
FAILURE TO UNDERSTAND AND FOLLOW ALL SAFETY RULES AND ASSEMBLY INSTRUCTIONS
COULD RESULT IN SERIOUS INJURY OR DEATH.
READ BEFORE BEGINNING ASSEMBLY.
OPERATION AND SAFETY
1. The operator must read and understand all
instructions before using.
2. Do not use this equipment if you are in poor health,
taking medications, drugs, or have been consuming
alcohol, all of which may impair your ability to work
safely on this product.
3. Always use these stilts in conformity with local or
national legislation which applies.
4. Inspect before use. Do not use if damaged or parts
are missing. Replace any damaged or excessively worn
components before using the stilts. Stilts must be
maintained and cleaned daily.
5. Stilts must not be modified. Never make temporary
repairs of damaged or missing parts.
6. Examine thoroughly to make sure stilts are properly
set up.
7. Stilts must be assembled and adjusted properly
following this manual.
8. Fasten the calf strap first when putting on stilts.
9. Keep all strap tightness comfortable, always fastened
and secure. Over-tightening can cause loss of
circulation and numbness in legs.
10. Do not wear stilts without having had pertinent
instruction on how to wear and use them. Make sure
stilts are comfortable and adjusted properly. Practice
using Stilts with a handhold or wall close-by to break
or prevent falls.
11. Stilts must be removed to make adjustments.
12. Work area must be free of debris, clear of any
obstructions and level.
13. Only use on a hard surface and level floor.
14. Always be careful when working around furniture,
fixtures, pipes, rails and grates.
15. Never work close to open stairs, doors, windows, floor
openings or other hazards.
16. Always cover or block floor openings, staircases
and drop-offs.
17. Avoid walking on oily, wet or otherwise slippery
surfaces.
18. Always think about safety and use extreme care
when using stilts.
19. Always look ahead before you step. Always warn fellow
workers of your movements.
20. Take short, firm steps, making sure that the Stilts is
raised clear of the floor at each step. Do not drag
Stilts as you move or walk.
21. Avoid working over other workers or their equipment
while on Stilts.
22. Walk forward only. Never walk backwards.
Make a “U-turn” to change direction.
23. Never walk on raised surfaces, for example, planks,
scaffolding, ladders or stand on benches or stools, etc.
24. Do not climb or descend stairway while wearing Stilts.
25. Ask for other workers assistance when retrieving
objects from the floor.
26. Disconnect upper leg strap last when removing Stilts.
27. This product is not intended or designed
for entertainment purposes.
OPERATIONAL SAFETY
FRANÇAIS ESPAÑOL
ENGLISH

3
RULES FOR USE AND NON-USE OF STILTS
STILTS SHOULD ONLY BE USED FOR LIGHT DUTY TASKS SUCH AS:
placing of insulation batts;
installing furring channels;
screwing sheets to furring channels, trusses, underside of floor joists and walls;
patching, touching up and stopping of joints using a trowel;
fixing cornices; and
minor hand sanding.
STILTS SHOULD NOT BE USED WHEN:
the work site is not “Plaster Ready”;
observing or experiencing fatigue;
they are poorly maintained;
lifting or supporting plaster sheets;
handling long, heavy or cumbersome objects or items, such as decorative cornices;
employees have not been properly trained in their use:
walking on stairs;
the floor level is not solid, changes height or slopes;
stepping into or over baths or other obstructions;
placed on a non-floor surface (such as tables, trestles, etc.);
the springs are fully compressed (caused when lifting heavy objects or exerting
high upward force, such as drilling through overhead structures);
picking up items from below knee level;
standing on void covers that bend from the weight;
using inappropriate equipment such as trowel boxes, tools with power leads or hoses;
there is an absence of a suitable mounting / dismounting platform;
the ceiling height is greater than 10 feet (3 m); or
the task requires frequent bending of the torso or over-reaching.
FRANÇAISESPAÑOL ENGLISH

4
STILTS ASSEMBLY
TOOLS NEEDED:
7/16” Wrench
7/16” Socket and Ratchet
#2 Phillips Screwdriver
SIDE POLES ASSEMBLY
1. Loosen Upper Side Pole Clamp bolt.
2. Loosen Lower Side Pole Bracket and remove bolt SidePole.
3. Insert Lower Side Pole through the Upper Side PoleBracket,
then insert it into the Lower Side Pole Bracket. Lining
PoleClamp up the hole, carefully reinsert the bolt with
washer through both the bracket and pole. Add the second
washer and tighten the nut. Lift the pole to make sure
it is attached properly.
4. Slide the Upper Side Pole over the Lower Side Pole and
through the Upper Side Pole Clamp. Tighten the bolt so the
pole will not fall but can be moved and twisted.
HEEL CUP ASSEMBLY AND ADJUSTING
1. Install Heel Cup using the included screws, nuts
and washers. Leave Heel Cup loose for now.
2. Adjust Heel Cup on Foot plate to fit shoe. Slide Heel Cup
in or out to adjust length of Foot Plate so your leg
is aligned with the Upper Side Pole.
3. Make sure Heel Cup screws are fastened securely.
HEIGHT ADJUSTMENT
1. Stand or sit in a comfortable position to try
on the assembled stilt.
2. Remove Height Adjustment Knobs and pull Upper Legs
to the required length.
3. Place Leg Support Cuff on or above the calf muscle, below
the knee joint. Make sure the knee can flex properly.
4. Adjust the Upper Side Pole height by pulling up or pushing
down.
5. Remove stilt and tighten Upper Side Pole Clamp bolt
to secure height. NOTE: Do not over-tighten the clamp
as doing so can bend the tube and weaken the stilt.
SIDEWAYS ADJUSTMENT
1. Loosen Upper Side Pole Bracket bolt. This adjusts distance
between Foot Plate and Upper Side Pole.
2. While sitting, put stilt on.
3. Push or pull Side Pole so that knee is aligned over foot,
making sure leg is straight (knees not turned out).
4. Tighten the Upper Side Pole Bracket bolt.
LEG CUFF
ANKLE STRAP
UPPER SIDE
POLE CLAMP
HEEL CUP
TOE STRAP
FOOT PLATE
UPPER
ADJUSTER
DISK
LOWER
ADJUSTER
DISK
FLOOR SOLE
HEIGHT
ADJUSTMENT
KNOB
CALF STRAP
UPPER SIDE POLE
UPPER SIDE
POLE BRACKET
LOWER SIDE
POLE
LOWER
SIDE POLE
BRACKET
UPPER LEG
FRANÇAIS ESPAÑOL
ENGLISH

5
STILTS ADJUSTMENT AND MAINTENANCE
FASTEN STRAPS
CAUTION: Always attach the Calf Strap before fastening the Foot Straps.
1. Put on stilt, keeping one foot firmly on the ground. Fasten the Calf Strap, followed by the Ankle and Toe Strap.
2. With help from a skilled stilt co-worker, lift yourself onto the second stilt, keeping legs comfortably apart and your weight balanced.
Fasten the Calf Strap, then Ankle and Toe Straps.
3. Make sure all straps are tight and secure.
NOTE: When mounting stilts, it is best to start from a sitting position using a bench, ladder or scaffold. Have a skilled stilt co-worker
help you mount and balance from a sitting position.
FORWARD-BACKWARD STABILITY
If you feel your weight shifting forward or backward while wearing the stilts,
try the following settings:
1. Make sure your Heel Cup fits properly your shoe and your leg is aligned with
the Upper Side Pole.
2. Adjust the Leg Cuff. To move your balance forward, loosen the Upper Side Pole Clamp
and rotate the Leg Cuff a little to the back of your calf. To move your balance backward,
rotate the Leg Cuff a little to the front of the calf. Retighten Clamp. Make sure Clamp
is tight to prevent twisting.
NOTE: Do not shape the aluminum Leg Cuff to fit your leg, as this may
cause it to crack or break.
3. Adjust the Springs – for most users, the Springs factory setting is adequate to maintain
stability. If needed, adjust the Springs by turning the Spring Adjuster Disk (clockwise
to tighten).
a. Forward Stability: Tighten the Upper Spring (light grey) to shift your weight back.
b. Backward Stability: Tighten the Lower Spring (dark grey) to shift your weight
forward. Turn the Adjuster Disk slightly (1/2 turn) and test walking, repeating
until comfortable.
NOTE: Over-tightening the Springs may limit walking action and damage the stilts.
SIDEWAYS ADJUSTMENT
When correctly balanced the Leg Cuffs should apply moderate support to the calf.
If the Leg Cuff forces the leg inward or pulls the knee outward, revise the Upper
Side Pole Bracket sideways adjustment:
1. While sitting or balancing on the stilt with the help of a co-worker, loosen the Sideways
Adjusting bolt on the Upper Side Pole Bracket.
2. Move the Side Pole inward until the Leg Cuff is comfortably resting against your leg.
Securely tighten the bolt.
3. Test the change by walking with the co-worker. If you still feel knee pressure, continue
to move the Leg Cuff until you feel balanced without pressure on your knee joints.
CAUTION: It is important to adjust the stilts to feel comfortable. Improper
tuning may cause fatigue and injury. If you feel any pain or
discomfort, re-adjust the fit.
90˚
90˚
