Hardware Manual
MIL-STD-1553 Tester/Simulator
PCI Interface Card
MN-65572iX-001
The information provided in this User’s Guide is believed to be accurate; however,
no responsibility is assumed by Data Device Corporation for its use, and no license
or rights are granted by implication or otherwise in connection therewith.
Specifications are subject to change without notice.
Please visit our web site at www.ddc-web.com for the latest information.
105 Wilbur Place, Bohemia, New York 11716-2482
For Technical Support - 1-800-DDC-5757 ext. 7382 or 7234
Headquarters, N.Y., U.S.A. - Tel: (631) 567-5600, Fax: (631) 567-7358
West Coast, U.S.A. - Tel: (714) 895-9777, Fax: (714) 895-4988
Southeast, U.S.A. - Tel: (703) 450-7900, Fax: (703) 450-6610
United Kingdom - Tel: +44-(0)1635-811140, Fax: +44-(0)1635-32264
Ireland - Tel: +353-21-341065, Fax: +353-21-341568
France - Tel: +33-(0)1-41-16-3424, Fax: +33-(0)1-41-16-3425
Germany - Tel: +49-(0)8141-349-087, Fax: +49-(0)8141-349-089
Japan - Tel: +81-(0)3-3814-7688, Fax: +81-(0)3-3814-7689
World Wide Web - http://www.ddc-web.com
REV D February, 2003
© 2000 Data Device Corp.
All rights reserved. No part of this User’s Guide may
be reproduced or transmitted in any form or by any
means, electronic, mechanical, photocopying,
recording, or otherwise, without the prior written
permission of Data Device Corporation.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Data Device Corporation BU-65570/2i Manual
ii
RECORD OF CHANGE
Revision Date Pages Description
A Jan., 2000 All Original Issue
B Oct., 2000 62-142 Function Definitions corrected
C Aug, 2002 All Software section removed, Fig 13 modified
D Feb, 2003 6 New Figure 1, and Table 1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Data Device Corporation BU-65570/2i Manual
iii
TABLE OF CONTENTS
TABLE OF CONTENTS.................................................................................................III
LIST OF FIGURES......................................................................................................... V
LIST OF TABLES ......................................................................................................... VI
HOW TO USE THIS MANUAL..................................................................................... VII
TEXT USAGE.........................................................................................................................................VII
SYMBOLS AND ICONS.........................................................................................................................VII
SPECIAL HANDLING AND CAUTIONS...............................................................................................VIII
TRADEMARKS .....................................................................................................................................VIII
INTRODUCTION.............................................................................................................1
WHAT IS INCLUDED IN THIS MANUAL?............................................................................................... 1
SYSTEM REQUIREMENTS..................................................................................................................... 2
TECHNICAL SUPPORT........................................................................................................................... 2
SOFTWARE LICENSE AND POLICIES.................................................................................................. 2
UPDATE POLICY..................................................................................................................................... 4
HARDWARE INSTALLATION........................................................................................ 5
DISCRETE I/O CONNECTOR “J1” PINOUTS ...............................................................6
CARD PINOUT ...............................................................................................................7
DRIVER INSTALLATION................................................................................................ 9
WINDOWS 95/98..................................................................................................................................... 9
WINDOWS NT 4.0 ................................................................................................................................. 14
WINDOWS 2000.................................................................................................................................... 15
HARDWARE CONFIGURATION........................................................................................................... 19
HARDWARE OPERATION........................................................................................... 20
GENERAL .............................................................................................................................................. 20
BUS CONTROLLER MODE................................................................................................................... 20
Minor And Major Frames ................................................................................................................................. 20
BC Error Injection............................................................................................................................................. 21
Inserting Asynchronous Messages .................................................................................................................... 21
BC Intermessage Routines ................................................................................................................................ 22
Response Timeout............................................................................................................................................. 22
RT MODE............................................................................................................................................... 23
RT Error Injection ............................................................................................................................................. 23
RT Intermessage Routines ................................................................................................................................ 24
BC/RT DATA TABLES........................................................................................................................... 24
MONITOR MODE................................................................................................................................... 25
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Data Device Corporation BU-65570/2i Manual
iv
INTERRUPTS ........................................................................................................................................ 25
BC Interrupt Generation.................................................................................................................................... 26
RT Interrupt Generation.................................................................................................................................... 26
Monitor Interrupts ............................................................................................................................................. 26
OTHER FEATURES............................................................................................................................... 27
Variable Amplitude Transceiver ....................................................................................................................... 27
IRIG-B support ................................................................................................................................................. 27
IRIG-B Specifications....................................................................................................................................... 28
Monitor DMA to Host Buffer ........................................................................................................................... 29
Software Control Of Bus Configuration ........................................................................................................... 29
Discrete Outputs................................................................................................................................................ 30
APPENDIX A ................................................................................................................ 31
INDEX ...........................................................................................................................32
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Data Device Corporation BU-65570/2i Manual
v
LIST OF FIGURES
Figure 1. 25-Pin “J1” Discrete I/O Connector (As viewed from BU-65570/72i Card Edge)6
Figure 2. Found New Hardware ....................................................................................9
Figure 3. Search for Driver..........................................................................................10
Figure 4. Specify Driver Location.................................................................................10
Figure 5. Found Driver.................................................................................................11
Figure 6. Finished Install of Driver...............................................................................12
Figure 7. Confirm Driver Installation............................................................................12
Figure 8. Found New Hardware ..................................................................................15
Figure 9. Search for Driver..........................................................................................16
Figure 10. Specify Driver Location...............................................................................16
Figure 11. Found Driver.................................................................................................17
Figure 12. Finished Install of Driver...............................................................................17
Figure 13. Sample IRIG Signal Timing..........................................................................28
Figure 14. Bus Configuration.........................................................................................31
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Data Device Corporation BU-65570/2i Manual
vi
LIST OFTABLES
Table 1. Supplied I/O Connector Components................................................................6
Table 2. J2: 1553 Bus 'D' Connector...............................................................................7
Table 3. J1: Discrete I/O..................................................................................................8
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Data Device Corporation BU-65570/2i Manual
vii
HOWTO USETHIS MANUAL
This manual uses typographical and iconic conventions to assist the reader in
understanding the content. This section will define the text formatting and icons used in
the rest of the manual. This manual is formatted with a ‘Scholar Margin’ where many tips,
symbols or icons will be located.
For the full text of this manual, BU-65572iX will be used to identify both the BU-65572iX
and the BU-65570iX. In those cases where there is a difference, the appropriate part
number will be identified.
TEXT USAGE
• BOLD– text that is written in bold letters indicates important information and
table, figure, and chapter references.
• BOLD ITALIC– will designate DDC Part Numbers.
• Courier New– is used to indicate code examples.
• <…> - Indicates user entered text or commands.
SYMBOLS AND ICONS
The Idea/Tip icon will be used to identify a handy bit of supplementary
information that may be useful to the user.
The Note icon signifies important supplementary information that will be
useful to the user.
The Caution icon identifies important information that presents a
possibility of damage to the product if not heeded.
Much stronger than a Caution, the Warning icon presents information
pertaining to hazards that will cause damage to the product and possible
injury to the user.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

HOW TO USE THIS MANUAL
Data Device Corporation BU-65570/2i Manual
viii
The Reference icon indicates that there is related material in this
manual or in another specified document.
The Disk Icon describes information that is related to software.
SPECIAL HANDLING AND CAUTIONS
The BU-65572iX-300 uses state-of-the-art components, and proper care should be used
to ensure that the device will not be damaged by Electrical Static Discharge (ESD),
physical shock, or improper power surges and that precautions are taken to avoid
electrocution.
• Turn off power to the PC and unplug from wall.
• NEVER insert or remove card with power turned on.
• Ensure that standard ESD precautions are followed. As a minimum,
one hand should be grounded to the power supply in order to
equalize the static potential.
• Do not store disks in environments exposed to excessive heat,
magnetic fields or radiation.
TRADEMARKS
All trademarks are the property of their respective owners.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Data Device Corporation BU-65570/2i Manual
1
INTRODUCTION
The BU-65572iX provides full, intelligent interfacing between one or two
MIL-STD-1553 Data Buses and a PCI Bus. The BU-65572iX is
packaged on a half-size IBM PC/AT printed circuit board with a PCI bus
interface. Features of the board include:
• Plug-and-Play (PnP) compatible for easy installation
• Onboard processor operating at 40MHz
• 64 Kbytes of on-board Program RAM
• 64 Kbytes of shared static RAM per installed channel
• DMA transfer of monitored data to host data buffer
• IRIG-B time tagging combined with 32-bit onboard time tag counter
• Software configuration of bus connection
• Software configuration of bus loading
• Variable output transceivers, 0 – 28 volts with 4096 incremental
steps (Only the BU-65572i model)
Application software has the capability to simulate Bus Controller, all 31
Remote Terminals, and Monitor simultaneously on each of the installed
buses. There is additional capability to synchronize the onboard time
tags of all of the operating cards with one command. Included with each
BU-65572iX PCI Card is the DDC Menu and the Runtime Library with
example source. The library supports ‘C’ and LabVIEWprogramming.
All software and updates are posted on the DDC web site.
WHAT IS INCLUDED IN THIS MANUAL?
This manual contains a detailed installation guide for the BU-65572iX
PCI Card and a complete listing of the software supplied with the card.
The RTL Library, DLL, and Driver installations for Windows®95, 98,
Windows NT®, and Windows 2000 will be covered in this manual.
The library software provides a level of abstraction such that it is not
necessary to understand the operation of the chip set.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INTRODUCTION
Data Device Corporation BU-65570/2i Manual
2
SYSTEM REQUIREMENTS
An IBM compatible PC with an Pentium 233 MHz processor or better.
Windows 95, 98, NT, or 2000 operating system.
One available PCI slot in the main board.
TECHNICAL SUPPORT
In the event that problems arise beyond the scope of this manual, you
can visit the DDC web site and review the FAQ page. If you still have
questions you can get in touch with DDC by calling:
U.S.A. toll free: 1-800-DDC-5757, ext. 7234
Outside U.S.A.: (631) 567-5600, ext. 7234
Regional Technical Support:
Northeast and Mid-West, U.S.A.:
(631) 567-5600 Fax: (631) 567-5758
West Coast, U.S.A.:
(714) 895-9777 Fax: (714) 895-4988
Southeast, U.S.A.:
(703) 450-7900 Fax: (703) 450-6610
Europe:
44 (1635) 811140 Fax: 44 (1635) 32264
Asia/Pacific:
81 (3) 3814-7688 Fax: 81 (3) 3814-7689
DDC also has an Internet World Wide Web site, which allows customers
to easily download new revisions of software and documentation. The
Internet address is www.ddc-web.com.
SOFTWARE LICENSE AND POLICIES
This program license agreement is displayed conspicuously on the
package so that you can read it before opening the package. Retaining
possession of the package and using the programs and materials
contained in it indicates that you have agreed to the terms and
conditions of this agreement. If you do not agree with them, you should
promptly return the package unopened to Data Device Corporation,
(“DDC”) and your money will be refunded.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INTRODUCTION
Data Device Corporation BU-65570/2i Manual
3
LICENSE. DDC grants a license to the individual and/of corporate
licensee to use the Program Product (the set of computer programs and
machine readable and printed materials supplied with this package for a
term beginning on the date you accept this Agreement and continuing
until termination. This license agreement is automatically terminated if
you violate any of the terms and conditions of this License Agreement.
You may terminate this agreement at any time by destroying all copies,
modifications, and original materials supplied with the Program Product
and destroying any portions of the DDC Program Product merged in any
form.
USE OF THE PROGRAM PRODUCT. You may use the Program
Product only on the Card with which the product was purchased. You
may copy the program for backup or transfer to any machine. Reverse
compiling and disassembling of programs in object format are prohibited.
Title to the program is not transferred to you by this license. Any
attempted sublicense, assignment, or other transfer of the programs or
the rights and obligations of this Agreement without the prior written
consent of DDC shall be void.
RESTRICTIONS. You may not use, copy, modify, merge, or transfer the
Program Product or any portion or modification thereof in whole or in
part, except as expressly provided in this Agreement.
LIMITED WARRANTY. DDC warrants the distribution diskette(s) upon
which the Program Product is provided to be free from defects in
materials and workmanship under normal use for a period of one year
from the date of purchase by the original purchaser. FOR BREACH OF
ANY WRITTEN OR IMPLIED WARRANTY ON THIS PRODUCT, THE
CONSUMER IS LIMITED TO THE REPLACEMENT OF THE
DEFECTIVE DISKETTE(S).
NOTE: some states do not allow the exclusion or limitation of incidental
or consequential damages so the above limitation or exclusion may not
apply to you.
DDC makes no other warranty of any kind, either expressed or implied,
and no warranty that the program product is free of errors. DDC and its
authorized dealers shall not be liable for the cost of any repair of
correction required for defective DDC program product material except
as stated in this paragraph.
GENERAL TERMS. This is the only agreement between User and DDC
regarding this Program Product and it may be modified only by a written
agreement between those parties. This agreement cannot be modified
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INTRODUCTION
Data Device Corporation BU-65570/2i Manual
4
by purchase orders, advertising or other representation by any person.
If any provision of this agreement shall be held invalid, illegal, or
unenforceable, then the validity, legality and enforceability of the
remaining provisions shall not be affected or impaired thereby. The laws
of the State of New York shall govern this agreement. By opening or
keeping the package, you acknowledge that you have read this
agreement, understand it and agree to be bound by its terms and
conditions, you acknowledge that you have read this agreement,
understand it and agree to be bound by its terms and conditions.
UPDATE POLICY
We will update the product as new functions are developed or major
bugs are fixed, to the extent of the warranty period. These updates will
be made available on our web site from time to time. Prior to calling
DDC for updated material, please visit our web site for the latest
versions.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Data Device Corporation BU-65570/2i Manual
5
HARDWARE INSTALLATION
The BU-65572iX card is a PCI Target device and may be inserted into
any PCI 2.1, or higher, compatible slot. When installing the card, the
following should be observed:
NEVER insert or remove the card with the power turned on.
ALWAYS take proper precautions to guard against static damage. Use
a wrist strap if available, or ensure proper static grounding by touching
the power supply cover WITH POWER OFF.
Insert the card at a slight angle so that the connectors first protrude from
the rear opening and then gently press the card into the motherboard
connector. Secure with proper hardware.
Make sure that adjacent cabling and wiring do no hinder the airflow
around the card.
The BU-65572iX does not contain any configuration jumpers for
selection of bus connection. Selection of direct or transformer coupling is
performed by way of functions provided in the RTL. In addition to this,
there are no jumpers needed for card installation, as the BU-65572iX is
a true Plug and Play design. Interrupts and memory selections will be
performed by the operating system as the boot system progresses.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

HARDWARE INSTALLATION
Data Device Corporation BU-65570/2i Manual
6
DISCRETE I/O CONNECTOR “J1” PINOUTS
This connector (Soldered on the board) is a 25-pin “Subminiature D Connector” (Amp P/N
747846-4). Pin numbering designations for “J1” are shown below.
Figure 1. 25-Pin “J1” Discrete I/O Connector (As viewed from BU-65570/72i Card
Edge)
Models BU-65570/72i are shipped with “J1” mating connector and backshell kit as listed
in table below.
Table 1. Supplied I/O Connector Components
Description AMP # Quantities
SHIELDING ENCLOSURE
KIT, PLUG, SIZE 3, 25 POSN,
AMPLIMITE HDE-20 747948-5 1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

HARDWARE INSTALLATION
Data Device Corporation BU-65570/2i Manual
7
CARD PINOUT
This section describes pinouts for the card. The card has two
connectors, a DB-9 that is used for 1553 Bus I/O and a DB-25 that is
used for discrete, power and IRIG. The pinouts for these connectors are
shown in following figures.
NOTE: All ground returns are connected to the chassis ground.
Pin Description
1 CH1_TXA_L
2 CH1_TXA
3 CH1_TXB
4 CH1_TXB_L
5 GND (connected to shell)
6 CH2_TXA_L
7 CH2_TXA
8 CH2_TXB
9 CH2_TXB_L
Table 2. J2: 1553 Bus 'D' Connector
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

HARDWARE INSTALLATION
Data Device Corporation BU-65570/2i Manual
8
Pin Description
1 N/C
2 Chassis Ground
3 Chassis Ground
4 Chassis Ground
5 IRIG Mod
6 Channel 1 Discrete Out 1
7 Channel 1 Discrete Out 2
8 Channel 1 Discrete Out 3
9 Channel 1 Discrete Out 4
10 Channel 2 Discrete Out 1
11 Channel 2 Discrete Out 2
12 Channel 2 Discrete Out 3
13 Channel 2 Discrete Out 4
14 Chassis Ground
15 +5 Volts
16 +5 Volts
17 IRIG In
18 Channel 1 Monitor Trigger In
19 Channel 1 Monitor Trigger Out
20 Channel 1 BC Trigger In
21 Channel 1 BC Trigger Out
22 Channel 2 Monitor Trigger In
23 Channel 2 Monitor Trigger Out
24 Channel 2 BC Trigger In
25 Channel 2 BC Trigger Out
Table 3. J1: Discrete I/O
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Data Device Corporation BU-65570/2i Manual
9
DRIVER INSTALLATION
WINDOWS 95/98
For a Windows 95/98 installation continue with the following installation
instructions. If using another operating system, skip to the relevant
installation section.
1) Install the card as described in the beginning of the HARDWARE
INSTALLATION section.
2) Turn on the computer.
3) The Add New Hardware Wizard window will appear after boot-up:
Figure 2. Found New Hardware
4) Click on the Next button.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

DRIVER INSTALLATION
Data Device Corporation BU-65570/2i Manual
10
Figure 3. Search for Driver
5) Highlight Search for the best driver for your device (Recommended)
radio button.
6) Click on the Next button.
Figure 4. Specify Driver Location
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

DRIVER INSTALLATION
Data Device Corporation BU-65570/2i Manual
11
7) Insert the BUS-69068 Installation Disk.
Select the Floppy disk drives option.
NOTE: If you are installing the software from a CD, highlight CD-ROM
drive check box and uncheck the Floppy disk drives check box.
9) Click on the Next button to locate the BU-65572iX-300 device
driver.
Figure 5. Found Driver
10) Click on the Next button to install the device driver.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table of contents
Other DDC PCI Card manuals
Popular PCI Card manuals by other brands

ADLINK Technology
ADLINK Technology PCI-8102 user manual

Contec
Contec DIO-1616B-LPE user guide

ICP DAS USA
ICP DAS USA PCI-TMC12AU quick start

Airlink101
Airlink101 AWLH6045 Quick installation guide

SMC Networks
SMC Networks SMC EZ Connect Turbo SMC2402W user manual

ORiNG
ORiNG PCard-E1041L-SI-D4 Quick installation guide
