Decolav 1802-CHL User manual

© DECO LAV, INC. 2016
1
PLEASE CONTACT 1-866-DECOLAV (332-6528) FOR FURTHER ASSISTANCE
DECOLAV.COM
THANK YOU FOR CHOOSING DECOLAV
CARE AND CLEANING
RECOMMENDED TOOLS
PRE-INSTALLATION
USE AND CARE GUIDE
1802-CHL
Item # 1802-CHL
NOTE: It is recommended that a professional contractor be retained
for the installation of this product.
NOTE: All natural materials are prone to variations in color, pattern
and density adding a unique beauty to the material.
PRODUCT DIMENSIONS AND PARTS LIST
Item # 1802-CHL
Screwdriver
Tape measure Drill Level PencilSilicone sealant or caulk Jigsaw
B
Item Description Qty
A Lavatory 1
B Wooden Body 1
A
We appreciate the trust and condence you have placed in DECOLAV® through the purchase of our products. We strive to continually
create and manufacture quality products designed to enhance your home. Visit us online at decolav.com for our full line of products, and follow
us on Facebook, Twitter, Instagram and Pinterest for the most up-to-date information, product care tips and trends.
• Do not overtighten drain. Overtightening of the drain can damage your DECOLAV®product
• Do not clean the product with detergents, acid, abrasives, harsh cleaners or a cloth with a coarse surface (S.O.S.®pads, Scotch Brite®pads)
• Do not leave any cleaning agents other than water on your DECOLAV®product
• Do not allow your DECOLAV®product to unnecessarily encounter other solid objects
• Do clean your DECOLAV®product to maintain its new appearance over the years. Wipe with a damp cloth and dry with a soft cloth. If necessary,
a general mild soap and water solution can be used. Use only a mild furniture polish to clean wood frame
• Unpack your new DECOLAV®product and inspect it for damage. Keep the product in its original package until you are ready to install it
• The oor and walls must be square and level
• Shut the water supply off when replacing an existing xture
• Preparation of the oors and walls, including all additional wall supports, may be required
• Observe all local plumbing and building codes

© DECO LAV, INC. 2016
2
PLEASE CONTACT 1-866-DECOLAV (332-6528) FOR FURTHER ASSISTANCE
DECOLAV.COM
ASSEMBLY INSTRUCTIONS
• Prior to installation, unpack your new DECOLAV®product and inspect it.
Keep the product in its original package until you are ready to install it
• The wall must be square, plumb and level
• Shut the water supply off when replacing an existing xture
• Observe all local plumbing and building codes
• It is recommended that this installation be done by a professional contractor
with a minimum of two people. Do not install this xture alone
• To ensure adequate support, DECOLAV®recommends removing
wall board and re-enforcing area with 2” x 4” (5.08 cm x 10.16cm)
wall support crosspiece or 3/4” thick plywood for ease of location
• Measure the desired location of the vanity and mark
mounting hole guidelines on wall
• Check alignment of mounting hole guidelines against vanity base
to ensure product is level
• Drill mounting holes in nished wall through wall support crosspiece
• Connect included power supply to power source
• Screw brackets into support
• Apply sealant to the top edge of the vanity base
• Apply sealant to the back wall of the lavatory
• Gently place the lavatory over the vanity base
• Wipe away any excess sealant
• Allow sealant to set before proceeding to install faucet, drain, and
waste system (not included), ensure that supply lines are secured tightly
NOTE: DO NOT OVER TIGHTEN DRAIN. MAY RESULT IN DAMAGE
• Connect LED light input to touch sensor output
• Turn on water supply to faucet and check for leaks
• Refer to the below gure for nished product
BEFORE YOU BEGIN
INSTALLING WOOD WALL SUPPORT
SECURING THE VANITY BASE TO THE WALL
SECURING THE LAVATORY TO THE VANITY BASE
1
2
3
NOTE: Use DECOLAV®decorative bottle trap item #
9102-CP/SN/PN to complete your new look.
NOTE: Use DECOLAV®drain item # 9290-CP/SN/PN, #
9296-CP/SN/PN or # 9298-CP/SN/PN. DECOLAV®cannot
guarantee against leakage with other manufacturer drains.
Figure 1
Figure 2
Figure 3
1802-CHL
Item # 1802-CHL

© DECO LAV, INC. 2016
3
PLEASE CONTACT 1-866-DECOLAV (332-6528) FOR FURTHER ASSISTANCE
DECOLAV.COM
LIMITED LIFETIME WARRANTY
1802-CHL
Item # 1802-CHL
Any Deco Lav, Inc. (“DECOLAV®”) product(s), sold after April 1, 2014, will
be warranted to the original end consumer to be free of true defects in
material and workmanship during normal residential use for as long as
the consumer owns his or her home subject to the following:
• Proof of purchase (original sales receipt) from the original end
consumer must be made available to DECOLAV®for all warranty
claims.
• The person claiming a warranty issue must be able to establish
original purchase and installation of the product.
• Authorized DECOLAV®personnel have inspected the product(s)
and determined the product(s) to have true manufacturing
defect(s) (unless other arrangements satisfactory to DECOLAV®
have been agreed upon).
• Such product(s) are returned to DECOLAV®(unless other
arrangements satisfactory to DECOLAV®have been agreed upon).
• The product must have been purchased, directly or indirectly,
through an authorized DECOLAV®reseller.
This limited warranty is non-transferable and applies only to the original
end consumer and to the original installation of the product. This limited
warranty is void if the product has been moved from its initial installation
site or if ownership of the product has changed. DECOLAV’s product
are produced from natural raw materials and there may be a slight color
variance from product appearing in catalogs, brochures, web-sites,
or product samples, or prior production. These are not examples of
manufacturing defects and will not be covered under this warranty.
This limited warranty does not cover any mechanical pieces of any
DECOLAV®product. These mechanical pieces will be covered under a
One Year Warranty, with all other terms of this warranty applying except
duration. This limited warranty does not cover the nish, color or plating
of any DECOLAV® product. The nish, color or plating of any product
will be covered under a One Year Warranty, with all other terms of this
warranty applying exception duration.
If this product is used commercially or installed outside of North America,
DECOLAV®warrants the product to be free from defects in material and
workmanship for one (1) year from the date of installation with all other
terms of this warranty applying except duration.
THIS LIMITED WARRANTY DOES NOT COVER ANY DAMAGES
CAUSED BY SHIPPING, MISUSE, ABUSE, ACCIDENTS, NEGLECT,
UNAUTHORIZED REPAIRS OR ALTERATIONS, MODIFICATIONS, USE
OF OTHER THAN GENUINE DECOLAV®REPLACEMENT PARTS, DIRT,
LIME SCALE, AND OTHER MINERALS, SCUFFS AND SCRATCHES,
EXPOSURE TO MARINE AREAS, ABNORMAL USAGE, AND NORMAL
WEAR AND TEAR. ANY IMPROPER INSTALLATION, IMPROPER
MAINTENANCE, IMPROPER HANDLING, IMPROPER AND CONTRARY
USES, IMPROPER CARE AND CLEANING AND ALL ACTS BEYOND
DECOLAV’s CONTROL WILL VOID THIS LIMITED WARRANTY.
This limited warranty does not apply to local building code compliance.
Since local building codes vary considerably, the original end consumer of
the product(s) should check with a local building or plumbing contractor
to ensure local code compliance prior to installation.
If you believe that you have a valid warranty claim, contact your Home
Center, Dealer, Plumbing Contractor or E-tailer. Please be sure to
provide all pertinent information regarding your claim, including a
complete description of the problem, the product, model number, the
date the product was purchased, from whom the product was purchased
and the installation date and location. Also be sure to provide a copy of
your original purchase invoice. For other questions, please write to us
at: Deco Lav, Inc., Attn. Returns Processing, 314 S. Chimney Rock Road,
Greensboro, NC 27409.
Upon satisfaction of each of the foregoing conditions and requirements,
DECOLAV®shall, at its option, either repair or replace the defective
product. DECOLAV®shall return any product repaired or replaced under
this limited warranty to the original end consumer transportation prepaid.
All Closeout/Discontinued product(s), at time of a valid warranty claim,
will either be repaired or replaced with a comparable item. DECOLAV’s
option to repair or replace the product under this limited warranty
does not cover any cost of labor to remove or install the DECOLAV®
product, usage and delay time, or other costs of removal or installation
whatsoever. IN NO EVENT WILL DECOLAV BE LIABLE FOR THE COST
OF REPAIR OR REPLACEMENT OF ANY INSTALLATION MATERIALS,
INCLUDING BUT NOT LIMITED TO, COUNTERTOPS, TILES, MARBLE,
GRANITE, ETC.
THIS LIMITED WARRANTY DOES NOT COVER ANY LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES, ALL OF WHICH ARE
HEREBY EXPRESSLY DISCLAIMED, OR THE EXTENSION BEYOND THE
DURATION OF THIS LIMITED WARRANTY. Some states do not allow
the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
THE WARRANTIES HEREIN:
• ARE EXCLUSIVE AND STATED IN LIEU OF ALL OTHER
WARRANTIES, WHETHER EXPRESS, STATUTORY, OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR AN INTENDED
PURPOSE, ALL OF WHICH ARE HEREBY EXPRESSLY
DISCLAIMED.
• NEITHER ASSUME NOR AUTHORIZE ORIGINAL END
CONSUMER NOR ANY OTHER PARTY TO ASSUME ANY OTHER
LIABILITIES IN CONNECTION WITH THE MANUFACTURE OR
SALE OF THE PRODUCT.
• ARE SUBJECT TO THE LIMITATIONS ON DAMAGES AS SET
FORTH ABOVE.
