Cooper Lighting Shaper 416 SERIES User manual

Catalog #
Project
Comments
Prepared by
Type
Date
SPECIFICATION FEATURES
08/08/2008 10:02:21 AM
Consult your representative for additional options and finishes.
Specifications and Dimensions subject to change without notice.
ADS042723
ORDERING INFORMATION
DESCRIPTION
416 Luminous Shade Pendant.
Material/Mounting
Solid aluminum or solid copper
materials. Matte white acrylic
diffuser. Supplied with an SJ cord
assembly. SJ Cord (Standard): 4
1/2" x 1/2" canopy for incandescent
or 6 1/4" x 2 7/8" canopy for CFL.
One 3 (INC) or 5 (CFL) conductor
white SJ cord with a standard
overall hang height of 24" (OA),
minimum 18" (OA) with either a 4
1/2" x 1/2" canopy for incandescent
or a 6 1/4" x 2 7/8" canopy for CFL.
Maximum (OA) for CFL is 10'.
Optional clear SJ cord (CSJ).
Finish
Standard: Unlacquered Natural
Aluminum (NA) [Sustainable
Design]. Premium: Matte White
(MW), Lacquered Satin Aluminum
(SAL), Satin Copper (SCP),
Polished Copper (PCP) or Custom
Color (CC).
Optics
Refer to www.shaperlighting.com
for complete photometrics.
Ballast
Integral electronic HPF, multi-volt
120/277V (347V Canada), thermally
protected with end-of-life circuitry
to accommodate the specified
lamp wattage.
Lamp/Socket
One (1) 26W, 32W (GX24q-3) or
42W (GX24q-4) 4-pin triple CFL
lamps or one (1) 100W A-19 lamps.
CFL socket injection molded
plastic. INC socket fired ceramic
rated for 660W-250V. Lamps
furnished by others.
Installation
Supplied with either a circle strap
mounting canopy or bar strap that
mounts to a 4" J-box or plaster
ring. Integral safety cable provided
with option stem.
Options
Sloped Ceiling Adaptor for stem -
Specify up to 45° (SCA), Single
Stem (1S), Perched Single Stem
Two Shade (PSS2SD), Perched
Single Stem Three Shade
(PSS3SD), Perched Single Stem
Four Shade(PSS4SD), Clear SJ
Cord (CSJ). Dimming ballast -
Contact factory for ballast options
(DM), Remote Emergency Battery -
Supplied by others (REM), MRI
Applications (INC) Contact factory,
Regressed Lense - Contact Factory,
Damp Location (DL): All Painted
Finishes only. Energy Star Rating -
Contact Factory.
Labels
U.L. and C.U.L approved for indoor
and damp location. See options
for damp location finishing
requirements.
Modifications
Shaper's skilled craftspeople with
their depth of experience offer the
designer the flexibility to modify
standard pendant luminaires for
project specific solutions. Contact
the factory regarding scale options,
unique finishes, mounting,
additional materials/colors, or
decorative detailing.
416 SERIES
Pendant Luminaire
Starter Collection
Luminous Shade
MAGNETIC
RESONANCE
IMAGING (MRI)
ENERGY
STAR
SUSTAINABLE
DESIGN
Refer to the Icon Legend
Link on shaperlighting.com.
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
Shaper’s exclusive Starter Collection fixtures
are featured throughout the Shaper product
line. The concept of offering highly styled,
affordable fixtures was introduced over
fourteen years ago and has become one of
our fastest growing lines. The design
premise, basic construction, clean lines
and unadorned shapes are highly desirable
in modern architectural environments.
STARTER
COLLECTION
Shaper’s Quick Ship program
features over thirty-four fixtures
with finish options such as Satin
Chrome, Natural Aluminum and
Satin Brass and a wide variety of
lamp selections. All products ship
in five days from receipt of order.
QUICK SHIP (QS)
Sample Number: 416-INC/1/100-120V-PCP-24
Finish
Standard
NA Natural Aluminum=
Premium
CC Custom Color=
MW Matte White=
PCP Polished Copper
=
SAL Lacquered Satin
Aluminum
=
SCP Satin Copper=
Options
1S Single Stem=
CSJ Clear SJ Cord=
PSS2SD Perched Single
Stem Double Shade
=
PSS3SD Perched Single
Stem Triple Shade
=
PSS4SD Perched Single
Stem Four Shade
=
DL Damp Location=
DM CFL Dimming Ballast 2
=
REM Remote Emergency
Battery
3
=
SCA Sloped Ceiling Adapter 4
=
Suspension Height
24"
or specify
Series
416 Luminous
Shade
=
Lamp
CFL/1/26
CFL/1/32
CFL/1/42
INC/1/100
Voltage
120V
277V 1
347V 1
Notes:
1
2
3
4
Available with CFL only.
Consult the factory for available options.
Supplied by others.
For stem mounting only. Specify up to 45°.
shaperlighting.com

Shaper Lighting • 1141 Marina Way South • Richmond, CA 94804 • ph 510.234.2370 • fax [phone]/2008 10:02:21 AM
Specifications and Dimensions subject to change without notice.
ADS042723
416 STANDARD
416 SERIES PENDANT LUMINAIRE
24"
12-1/2"
INC
4-1/2" ø
1/2"
24"
12-1/2"
6-1/4" ø
2-1/8"
CFL
24"
12-1/2"
9" ø
6-1/4" ø
2-1/8"
9" ø
24"
12-1/2"
9" ø
4-1/2" ø
1/2"
Single Sem (1S): 4 1/2" x 1/2" canopy for incandescent or 6 1/4" x 2 7/8" canopy for CFL.
One 1/2" stem with a standard hang height of 24" (OA), minimum 18" (OA). Maximum
overall hang height for one piece stem assembly is 8' (OA). 9' to 30' (OA) stems are supplied
in multiple sections.

Shaper Lighting • 1141 Marina Way South • Richmond, CA 94804 • ph 510.234.2370 • fax [phone]/2008 10:02:21 AM
Specifications and Dimensions subject to change without notice.
ADS042723
416 SUSPENSION OPTIONS
30"
12-1/2"
5" ø
3/4"
2'-6"
PERCHED SINGLE STEM
DOUBLE SHADE (PSS2D)
12-1/2"
30"
5" ø
3/4"
2'-6"
PERCHED SINGLE STEM
FOUR SHADE (PSS4SD)
30"
12-1/2"
5" ø
3/4"
2'-6"
PERCHED SINGLE STEM
TRIPLE SHADE (PSS3SD)
Perched Single Stem Double Shade (PSS2SD): 5” canopy with a
1-1/2”swivel ball. One 5/8” stem with a standard hang height of
30” (OA), minimum. Maximum overall hang height for one piece
stem assembly is 8’ (OA). 9’ to 30’ (OA) stems are supplied in
multiple sections. Supplied with a swivel canopy which will
accommodate up to 45° adjustment.
Perched Single Stem Triple Shade (PSS3SD): 5" canopy with a
1-1/2” swivel ball. One 5/8” stem with a standard hang height of
30” (OA), minimum. Maximum overall hang height for one piece
stem assembly is 8’ (OA). 9’ to 30’ (OA) stems are supplied in
multiple sections. Supplied with a swivel canopy which will
accommodate up to 45° adjustment.
Perched Single Stem Four Shade (PSS4SD): 5" canopy with a 1-1/2"
swivel ball. One 5/8” stem with a standard hang height of 30” (OA),
minimum. Maximum overall hang height for one piece stem
assembly is 8‘ (OA). 9’ to 30’ (OA) stems are supplied in multiple
sections. Supplied with a swivel canopy which will accommodate
up to 45° adjustment.
Installation
Multi-Shade Pendants: Contractor to provide appropriate structural
support for fixture weight. Refer to the installation drawings for
details. Integral safety cable provided.
