Defy Gemini CP Series User manual

GEMINI & SLIMLINE
SOLID PLATE HOBS
Cooking
Instruction manual
Part number: 073873

Please register your product at
www.defy.co.za
Introduction
Congratulations on the purchase of this
quality hob.
We, the manufacturer, trust that you will
enjoy many years of trouble free use.
Please read these instructions carefully
before using the hob.
This book will provide you with information
on how to operate and care for your hob in
order that you gain the maximum benefit
from it.
Unpacking
 Please ensure that packaging material is
disposed of in a responsible manner.
 Plastic bags should be cut up to prevent
children playing with them and
accidentally suffocating.
 Some models feature a protective film
over the stainless steel. This film must be
carefully removed before using the hob.
 If the appliance is damaged in any way,
do not use it. Report the damage to your
dealer, who will take the necessary
corrective action.
Index
2 Introduction.
2 Unpacking.
3 Important safety instructions
6 Package information
6 Future transportation
7 Know your product
7 Cupboard design
8 Aperture sizes
9 Installation for solid plate hobs
9 Hobs with control panels
9 Hobs without control panels
10 Plate controls
10 Solid plate care guide.
11 Solid plates.
12 Care guide for stainless steel models.
13 Technical specifications.
14 Problem check.
14 Owner’s responsibility
15 Branches.
16 Warranty.

Important safety instructions
This section contains safety
instructions that will help you
avoid risk of injury and damage.
All warranties will become void if
you do not follow these
instructions.
General safety
 This appliance is not intended
for use by persons (including
children) with reduced
physical, sensory or mental
capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction
concerning the use of the
appliance by a person
responsible for their safety.
 Young children should be
supervised to ensure that they
do not play with the appliance.
 Installation and repair
procedures must always be
performed by Authorized
Service Agents. The
manufacturer shall not be held
responsible for damages
arising from procedures
carried out by unauthorized
persons which may also void
the warranty. Before
installation, read the
instructions carefully.
 Do not operate the product if it
is defective or has any visible
damage.
 Ensure that the product
function knobs are switched off
after every use.
Electrical safety
 If the product has a failure, it
should not be operated unless
it is repaired by the Authorized
Service Agent. There is the risk
of electric shock!
 Only connect the product to a
grounded outlet/line with the
voltage and protection as
specified in the “Technical
specifications”. Have the
grounding installation made by
a qualified electrician while
using the product with or
without a transformer. Defy
shall not be liable for any
problems arising due to the
product not being earthed in
accordance with local
regulations.
 Never wash the product by
spreading or pouring water
onto it! There is the risk of
electric shock!
 The product must be
disconnected from the mains
supply during installation,
maintenance, cleaning and
repairing procedures.
 If the electrical supply is
restricted, means of all-pole
disconnection must be
accessible and incorporated in
the fixed wiring in accordance
with the regulations.

 Never use the product when
your judgment or coordination
is impaired by the use of
alcohol and/or drugs.
 Be careful when using
alcoholic drinks in your dishes.
Alcohol evaporates at high
temperatures and may cause
fire since it can ignite when it
comes into contact with hot
surfaces.
 Do not place any flammable
materials close to the product
as the sides may become hot
during use.
 Keep all ventilation slots clear
of obstructions.
 Do not use steam cleaners to
clean the appliance as this
may cause an electric shock.
 Do not use or store flammable
products (alcohol, petrol,
benzene etc.) near the
appliance as these pose a fire
risk.
 Danger of fire: Do not store
items on the cooking surfaces.
 Unattended cooking on a hob
with fat or oil can be
dangerous and may result in
fire. NEVER try to extinguish a
fire with water, but switch off
the appliance and then cover
flame e.g. with a lid or a fire
blanket.
 If the power connection cable
for the product is damaged, it
must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.
 The appliance must be
installed so that it can be
completely disconnected from
the network. The separation
must be provided either by a
mains plug, or a switch built
into the fixed electrical
installation, according to
construction regulations.
 Any work on electrical
equipment and systems should
only be carried out by
authorized and qualified
persons.
 In case of any damage, switch
off the product and disconnect
it from the mains. To do this,
turn off the fuse at home.
 Make sure that fuse rating is
compatible with the product.
Product safety
 The appliance and its
accessible parts become hot
during use. Care should be
taken to avoid touching
heating elements. Children
less than 8 years of age shall
be kept away unless
continuously supervised.

Intended use
 This product is designed for
domestic use. Commercial
use will void the guarantee.
 This appliance is for cooking
purposes only. It must not be
used for other purposes, for
example room heating.
 The manufacturer shall not be
liable for any damage caused
by improper use or handling
errors.
Safety for children
 Accessible parts may become
hot during use. Young children
should be kept away.
 The packaging materials will
be dangerous for children.
Keep the packaging materials
away from children. Please
dispose of all parts of the
packaging according to
environmental standards.
 Electrical and/or gas products
are dangerous to children.
Keep children away from the
product when it is operating
and do not allow them to play
with the product.
 Do not place any items above
the appliance that children
may reach for.
 Do not spray aerosols in the
vicinity of this appliance while
it is in operation.
 Do not modify this appliance
 Where this appliance is
installed in a marine craft or in
caravans, it shall not be used
as a space heater.
 Do not use the appliance for
heating closed tins and glass
jars. The pressure that would
build up in the tin/jar may
cause it to burst.
 Always keep children and
infirm persons away from the
appliance when it is in use.
 Use a deep pan, large enough
to cover the appropriate
cooking zones.
 Always dry food thoroughly
before placing it in hot oil or
fat. Frozen food in particular
will spit and splatter if added
too quickly.
 Never fill the pan more than
one third full of fat or oil.
 Never heat fat or fry with a lid
on the pan.
 Do not fry too much food at
once. This lowers the
temperature of the oil or fat
and results in fatty foods.
 Do not leave hot fat or oil
unattended. If overheating
occurs, these could catch fire.
 Do not modify this appliance
 This appliance is not intended
to be operated by means of
external timer or separate
remote control system

Danger of fire: Do not
store items on the
cooking surface.
CAUTION: The cooking
process has to be
supervised. A short term
cooking process has to
be supervised
continuously.
WARNING: Unattended
cooking on a hob with fat
or oil can be dangerous
and may result in a fire.
Package information
 Packaging materials of the
hob are manufactured from
recyclable materials in
accordance with
Environmental Regulations.
 Do not dispose of the
packaging materials together
with domestic or other wastes.
Take them to collection points
designated by the local
authorities.
Future Transportation
 Keep the product's original
carton and transport the
product in it. Follow the
instructions on the carton. If
you do not have the original
carton, pack the product in
bubble wrap or thick
cardboard and tape it
securely.

Know your product
 Defy Solid plate hobs are available in
two model sizes.:
 Gemini CP model with a control panel
in black enamel
 Gemini NCP model without a control
panel in black enamel
 Slimline CP model with a control panel
in black enamel
 Slimline CP model with a control panel
in stainless steel
 Slimline NCP model without a control
panel in black enamel
 Slimline NCP model without a control
panel in stainless steel
 Hobs with control panels may be used
on their own or with an eye –level oven.
 Hobs without control panels may only
be used when connected to a Defy under-
counter oven. The hob controls in this
instance, are located on the oven fascia.
Please determine the type of hob you
have purchased and read only the
instructions pertaining to that model.
Cupboard design
 Cooking appliances generate
considerable heat. The layout and
materials of the mounting cabinet should
take account of these characteristics.
 Surfaces and surrounding edges
immediately adjacent to the hob should be
able to withstand temperatures of up to
100°C without delaminating or
discolouring.

Gemini black enamel hobs
WITHOUT a control panelWITH a control panel
Slimline black enamel hobs
WITH and WITHOUT a control panel
Slimline stainless steel hobs
WITHOUT a control panelWITH a control panel
803
470
70
+ 3
- 0
+ 3
- 0
686
466
70
+ 3
- 0
+ 3
- 0
570
480
80
+ 3
- 0
+ 3
- 0
570
480
80
+ 3
- 0
+ 3
- 0
560
485
80
+ 3
- 0
+ 3
Aperture sizes

Installation for Solid plate hobs
Installation is the buyer’s responsibility. The
manufacturer accepts no liability for this
service. Any action that the manufacturer
has to take as a result of an erroneous
installation will not be covered by the
warranty.
 The hob should be installed in a ventilated
cupboard fitted with a sturdy worktop and
must be secured using the fixing brackets
provided. (see sketch below)
 Hobs without control panels should be
installed directly above the oven.
 Allow an unrestricted air space of at least
75mm underneath the underside of the
hob for ventilation and cooling purposes.
 To avoid liquid spills penetrating between
the hob and the worktop, please attach
the rubber ‘U’ seal to the perimeter of the
hob. Do not use a silicone sealer.
 Invert the hob on the worktop adjacent to
the aperture before making the electrical
connection. This will ensure sufficient
cable length for subsequent servicing.
Fixing method
Electrical installation
This appliance must be earthed and the
manufacturer and the seller do not
accept responsibility for any damage
due to incorrect installation or electrical
connection.
Hobs with control panels
Earth leakage
This hob should not be connected through
an earth leakage system.
Refer to S.A.N.S.10142
Connection to the power supply must be
carried out by a licensed electrician, who will
ensure that the hob is correctly connected
and safely earthed. The rated current is
printed on the serial number label attached
to the base cover.
The hob must be connected to the mains
through a double pole isolating switch which
has a minimum clearance between the
contacts of 3 mm. in both poles.
A means for disconnection must be provided
in the fixed wiring.
Note:
The appliance is not intended to be operated
by means of an external timer or separate
remote-control system.
Hobs without control panels
Electrical connection is via connector blocks
to the oven below the hob.
Please see the section pertaining to
electrical connection as described in the
oven manual.
Suitable for Gemini Black Enamel hobs,
Slimline Black Enamel hobs and Slimline
Stainless steel hobs.
SECURING BRACKET
AND SCREW
HOB
THICKER
COUNTER TOP
STANDARD
COUNTER TOP
HOB
SECURING BRACKET
AND SCREW
SECURING BRACKET
AND SCREW
HOB
THICKER
COUNTER TOP
STANDARD
COUNTER TOP
HOB
SECURING BRACKET
AND SCREW

The controls
The plate controls for hobs without a control
panel are located on the oven fascia.
SWITCH THE PLATE ON FOR A
SHORT PERIOD TO DRY
TO CLEAN THE PLATE - WIPE IT WITH A DAMP
CLOTH OR NYLON SCOURING PAD
DO NOT USE ONE POT ON TWO PLATES
USE POTS THAT ARE SLIGHTLY
BIGGER THAN THE PLATE
AND THAT HAVE A SMOOTH FLAT BASE
DO NOT USE A POT WITH AN UNEVEN BASE
BEFORE USING THE PLATES FOR THE FIRST TIME
SWITCH THEM ON FOR FOUR MINUTES
AT THE HIGHEST SETTING
THIS ALLOWS THE PROTECTIVE COATING
TO BURN IN
TO INHIBIT CORROSION, PERIODICALLY APPLY
SALT-FREE VEGETABLE OIL,
SEWING MACHINE OIL OR
ELECTRICAL HOT-PLATE POLISH,
(AVAILABLE FROM DEFY SERVICE CENTRES)
DO NOT USE A POT WITH A DIRTY OR WET BASE
DO NOT USE A POT ON AN UNMATCHED PLATE
TO CONSERVE ENERGYAND AVOID SPILLS
WE RECOMMEND
YOU KEEP A LID ON THE POT.
Plate controls
1. Left front
2. Left back
3. Right back
4. Right front
Ringer timer on Gemini hobs with a
control panel only (Depends on model)
 The ringer timer may be used for timing a
cooking period of up to 60 minutes.
 First wind the timer by turning the knob
fully clockwise.
 Return the knob to the desired time
period.
 At the end of the this period the bell will
ring.
 Note: If the timer is not first fully wound
the bell may not ring.
1 2 3 4
DO DO NOT
Solid plate care guide
4
3
2
1

Red dot plates
 Plates featuring a red dot in the centre are
thermal protection plates for increased
performance.
 For your safety these plates are fitted with
thermal limiters. Should a plate be
accidentally switched on and left
unattended, the limiter will reduce the
power output of the plate and minimise
the risk of overheating and the possibility
of fire.
Solid plates
Recommendations
 Use only pots with a solid level base. An
uneven base can prolong cooking times
and waste energy.
 Use pots with a base diameter slightly
larger than the plate. This will ensure
even heat distribution and prevent
spillage from dripping onto and staining
the hot plate.
 Always cover the pot with a lid. This will
conserve energy and minimise spillage.
 Thermal shock could damage the plates.
Do not put cold pots on very hot plates.
Plate controls
 Select the heat level by turning the
relevant plate control knob to the required
setting.
 The higher the number selected, the
hotter the temperature of the plate will be.
 The plate indicator light will glow when a
plate is switched on.
NOTE: THE WARRANTY DOES NOT
COVER THE REPLACEMENT
OR REPAIR OF RUSTED OR CORRODED
PLATES.
Caring for Solid Plates
 Before using the plates for the first time,
switch them on for about 4 minutes at the
highest setting. This allows the factory
applied protective coating to burn in.
 To prevent blotchy discolouration and
corrosion, moisture from spatters and
spills should be cleaned off immediately.
 To clean the plates, wipe them with a
damp cloth or nylon pad. A little liquid
detergent may be used. Do not use metal
scourers or sharp metal objects to clean
the plates.
 DO NOT USE A STEAM CLEANER.
 After cleaning, dry the plates by switching
them on for a short while.
 To prevent rust, periodically apply some,
sewing machine oil or electrical hotplate
polish available from Defy Service
Centres. Extra attention is required in
areas of high humidity or in close
proximity to the sea.

CONDITION ACTION NOTES AND COMMENTS
Requires routine cleaning. Mild detergent solution applied
with soft sponge or cloth.
Rinse and wipe dry.
If possible use warm to hand-
hot water. A 5% addition of
ammonia is beneficial.
Finger prints. Pre-treat finger marks with
alcohol or an organic solvent.
Follow immediately with
routine cleaning.
Minimize re-occurrence by
applying a wax or silicone
based household polish to the
clean dry surface.
Wipe with a little baby oil and
a soft lint free cloth.
Buff to shine.
Apply whenever necessary.
Stubborn stains and
Discolouration.
Use only stainless steel sink
cleaner and polish that has
been approved by Defy
appliances. (Available from
Defy Service Departments).
Repeat several times rather
than resorting to a single
aggressive cleaning method.
Grease and fat splatter. Wipe off excess with a soft
cloth or paper towel. Use a
water borne degreasing agent
( dishwashing liquid ).Follow
up by routine cleaning.
Scratches on the brushed
finish.
For slight scratches, use a
nylon pad loaded with an iron-
free abrasive polishing
compound. Follow the
direction of the original
texture. Follow up with routine
cleaning. For deep scratches
use a coarser abrasive initially
and follow up as for light
scratches.
Deep scratches will be difficult
to remove completely. Do not
use steel wool or metal
scourers unless they are
made from stainless steel.
Care guide for Slimline Stainless Steel models
SOME OF THE SUGGESTED
PROCEDURES WILL ALTER
THE SURFACE APPEARANCE
OF THE TREATED AREA. THEY
SHOULD THEREFORE BE
APPLIED WITH DUE
CONSIDERATION AND CARE.

Technical Specifications
The Manufacturer strives for continuous improvements. For this reason,
the text and illustrations in this book are subject to change without notice.
Model GEMINI
SOLID PLATE
SLIMLINE
SOLID PLATE
Volts 230V –250V 50Hz~ 230V –250V 50Hz~
Amperes 22 22
Plate power rating (W)
Large plate front 1500 1500
Small plate front 1000 1000
Small plate back 1000 1000
Large plate back 1500 1500
Hobs with control panels
Integrated Yes Yes
6 Heat switches 44
Indicator lights 11
Available in:
Black enamel Yes Yes
Stainless steel No Yes

Before calling the customer care line:
PROBLEM
The plates do not work -
Solid plates are rusting -
The timer on Gemini hobs make a
clicking noise -
Remember that you may be charged for a
service call even during the warranty period
if the fault is due to or caused by any of the
above.
Problem check
SOLUTION
Check there is power to the wall switch.
Clean plates with a nylon brush, wipe off and
dry. Apply a thin coating of salt free
vegetable oil or hotplate polish available
from Defy Service Centres
This is normal. Timers do make a clicking
noise.
Since the following are not factory faults,
they are the owner’s responsibility.
 Damage to exterior finish.
 Breakage of glass and other components.
 Damage through improper use or
installation of the appliance.
 Damage caused by moving the appliance.
 Rusted or corroded solid plates.
Purchase details for future reference,
record the listed information in the space
below.
The Serial number may be found on the
label attached to the hob base.
Serial
No:________________________________
Date of
purchase:___________________________
Purchased
from:_______________________________
Owner’s responsibility

Branches
If you have followed the instructions and still have a problem, contact the customer care line on
086 100 3339. They will be able to advise you on any aspect of the appliance.
South African Branches:
BLOEMFONTEIN
Unit Number 5
Monument Business Park
50 Monument Road
Oranjesig
Bloemfontein
[e-mail]
CAPE TOWN
5A Marconi Rd. Montague Gardens, 7441
[e-mail]
DURBAN
135 Teakwood Road, Jacobs,
Durban, 4052
[e-mail]
EAST LONDON
Robbie de Lange Road, Wilsonia,
East London, 5201
EastLondon.Se[email protected]a
GAUTENG, MIDRAND
127 15th Road, Cnr Pharmaceutical &15th Rd,
Midrand, Gauteng
Gauteng.Servi[email protected]o.za
POLOKWANE
87 Nelson Mandela Drive, Superbia 0699
[e-mail]
PORT ELIZABETH
112 Patterson Road, North End, Port Elizabeth
6001
[e-mail]
Sub-Saharan Africa Branches:
ZAMBIA: SOUTHGATE INVESTMENTS LTD
Plot 1606, Sheki Sheki Road
P.O. Box 33681
Lusaka, 10101, Zambia
Tel: [phone]
Fax: [phone]
[e-mail]
NAMIBIA: ATLANTIC DISTRIBUTORS (PTY)
LTD
10 Tienie Louw Street, Northern Industrial Area
P.O. Box 21158, Windhoek, Namibia
Tel: [phone]
Fax: [phone]
[email protected]
ZIMBABWE: TRADECOMAFRICA
Trade Com Africa, 183 Loreley Crescent
Msasa, Harare, Zimbabwe
Tel: [phone]
Cell: [phone]
Cell: [phone]
BOTSWANA: RAY MORGAN AGENCIES
RMA Service Centre, Plot 48, East Gate
Gaborone International Commerce Park
Kgale View, Gaborone
Botswana
Tel: [phone]
Fax: [phone]
Cell: [phone]
[email protected]; [e-mail]
SWAZILAND: LYNDS DISTRIBUTORS
P.O Box 716, Mbabane, Swaziland, H100
Tel: [phone]
Fax: [phone]
MOZAMBIQUE: COOL WORLD. LDA
Rua da Resistencia No. 97B R/C
Cell: [phone]
coolw[email protected]
Nosso Show Room
Av: da Industrias, Parcela No.735 * 735A
Machava, Maputo

This certificate is issued by DEFY APPLIANCES (PTY) LTD manufacturers of Defy and Ocean
products, hereinafter the Company, to the original purchaser only, of the appliance described on the
certificate and shall constitute the only warranty given in respect of this appliance.
The Company warrants to the original purchaser that for a period of TWO YEARS from date of
purchase the appliance is free from defect under normal domestic use, both in workmanship and
material, subject to the following conditions.
1. Repair or replacement of any part of this appliance, found by the Company to be defective, shall be at
the election of the Company. The Company reserves the right to effect such service through any of its
Service Divisions or Authorised Service Dealers. The cost of such service shall be borne by the
Company in full, provided that the appliance is located no further than 50 km from a Company
Service Centre or an Authorised Service Dealer. Where the appliance is located beyond the 50 km
radius, the purchaser shall be liable for the standard travelling charges, as determined by the Company.
CARRY IN SERVICE Microwave ovens, Compact cookers and small appliances are repaired in our
service centres and are not collected from the customers home. Faulty units should be delivered to the
purchasing dealer or to the nearest Company Service Centre for warranty repairs.
2. Rusted or corroded plates, vitreous enamelware, fuses and lamps are specifically excluded from these
warranties. It is an express condition of these warranties that the purchaser takes due care and attention
in the use and maintenance of the appliance. Abuse, misuse in conflict with operating instructions,
connection to incorrect voltages and subjection to commercial use shall release the Company from its
obligations.
3. This warranty shall become void and cease to operate if the appliance is dismantled by, or any repairs
to the appliance are effected by any persons not duly authorised by the Company, or if substitute parts
not approved by the Company are used in the appliance, or if the serial number of the appliance is
removed.
4. The Company shall not be responsible for damages resulting from fire, flood, civil disturbances or
any Act of God. The Company shall not, in terms of these warranties be responsible nor held liable for
any consequential loss or damage of any kind caused by or due to the failure or malfunction of the
appliance. The Company shall not be responsible for damages caused by insect and/or animal
infestation.
5. The Company shall not be responsible for transportation or other costs other than those incurred
within the provisions of Point 1 of this Certificate.
6. For warranties in the Republic of South Africa and Sub-Saharan Africa, please contact the
customer care line. Please refer to the previous page for respective South African branches and
Sub-Saharan Africa branches.
7. Where service is requested under warranty and no fault or defect can be found by the Company, all
costs incurred will be for the purchaser's account.
8. This Certificate as well as your invoice will serve as proof of purchase. For the purpose of warranty,
it will be essential to produce this Certificate and invoice. Failure to do so, will render the purchaser
liable for service costs.
KEEP THIS CERTIFICATE AND SALES INVOICE AS PROOF OF PURCHASE FOR WARRANTY PURPOSES.
Warranty
