Philco PHS 604 DC User manual

CERAMIC HOB
OWNER’S MANUAL
PHS 604 DC

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all
the instructions in this user’s manual.
Copyright © 2019, Fast ČR, a. s. Revision 10/2021

Copyright © 2019, Fast ČR, a. s. Revision 10/2021
EN - 1
CONTENTS
PART 1: SAFETY PRECAUTIONS......................................................................................................................2
PART 2. PRODUCT INTRODUCTION ...............................................................................................................5
2.2 Control Panel ................................................................................................................................................................................5
2.3 Product Information...................................................................................................................................................................5
2.4 Working Principle........................................................................................................................................................................6
2.5 Before using your New Ceramic Hob...................................................................................................................................6
2.6 Technical Specication..............................................................................................................................................................6
PART 3. OPERATION OF PRODUCT.................................................................................................................7
3.1 Touch Controls ............................................................................................................................................................................. 7
3.2 Choosing the right Cookware.................................................................................................................................................7
3.3 How to use.....................................................................................................................................................................................8
PART 4. COOKING GUIDELINES ....................................................................................................................15
4.1 Cooking Tips................................................................................................................................................................................15
PART 5. HEAT SETTINGS ................................................................................................................................16
PART 6. CARE AND CLEANING ......................................................................................................................17
PART 7. HINTS AND TIPS ...............................................................................................................................18
PART 8. INSTALLATION..................................................................................................................................19
8.1 Selection of installation equipment...................................................................................................................................19
8.2 Before locating the xing brackets.....................................................................................................................................21
8.3 Cautions........................................................................................................................................................................................22
8.4 Connecting the hob to the mains power supply...........................................................................................................22

Copyright © 2019, Fast ČR, a. s. Revision 10/2021
EN - 2
PART 1: SAFETY PRECAUTIONS
THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 8
YEARS AND ABOVE AND BY PERSONS WITH REDUCED PHYSICAL,
SENSORY OR MENTAL CAPABILITIES OR LACK OF EXPERIENCE
AND KNOWLEDGE IF THEY HAVE BEEN GIVEN SUPERVISION OR
INSTRUCTIONS CONCERNING USE OF THE APPLIANCE IN A SAFE
WAY AND IF THEY UNDERSTAND THE HAZARDS INVOLVED.
CHILDREN MUST NOT PLAY WITH THE APPLIANCE.
CLEANING AND USER MAINTENANCE CANNOT BE PERFORMED
BY CHILDREN WITHOUT SUPERVISION.
IF THE SUPPLY CABLE GETS DAMAGED, HAVE IT REPLACED BY A
SPECIALIZED SERVICE CENTRE IN ORDER TO AVOID DANGEROUS
SITUATION.
IT IS PROHIBITED TO USE THE APPLIANCE WHEN THE SUPPLY
CABLE IS DAMAGED.

CAUTION, HOT SURFACE
CAUTION: IF THE SURFACE IS CRACKED, TURN THE APPLIANCE
OFF TO PREVENT RISK OF ELECTRIC SHOCK.
CAUTION: THE APPLIANCE AND ITS ACCESSIBLE PARTS GET HOT
DURING USE.

Copyright © 2019, Fast ČR, a. s. Revision 10/2021
EN - 3
PLEASE MAKE SURE TO REFRAIN FROM TOUCHING THE HEATING
ELEMENTS.
KEEP CHILDREN BELOW 8 YEARS OF AGE AWAY FROM THE
APPLIANCE IF THEY ARE NOT UNDER CONSTANT SUPERVISION.
WHEN CLEANING THE OVEN DOOR GLASS / COOKING HOB GLASS
HINGED COVERS, DO NOT USE HARSH ABRASIVE CLEANING
AGENTS OR SHARP METAL SCRAPERS AS THE SURFACE MIGHT
BECOME SCRATCHED WHICH COULD RESULT IN THE GLASS
BREAKING.
STEAM CLEANERS MUST NOT BE USED TO CLEAN COOKING HOBS.
METAL OBJECTS SUCH AS KNIVES, FORKS, SPOONS AND POT LIDS
MUST NOT BE PLACED ON THE COOKING HOB AS THEY MIGHT GET
HOT.
THIS APPLIANCE IS NOT INTENDED TO BE USED WITH EXTERNAL
TIME SWITCH OR SEPARATE REMOTE CONTROL SYSTEM.
CAUTION: COOKING ON THE COOKING HOB USING FAT OR OIL
WITHOUT SUPERVISION CAN BE DANGEROUS AND CAN CAUSE
FIRE.
NEVER TRY TO EXTINGUISH FIRE USING WATER; YOU SHOULD
RATHER TURN THE APPLIANCE OFF AND THEN COVER THE FLAMES
E.G. USING A LID OR A FIRE-STOPPING COVER.

Copyright © 2019, Fast ČR, a. s. Revision 10/2021
EN - 4
NOTICE: COOKING PROCESS MUST BE UNDER SUPERVISION.
SHORT-TIME COOKING PROCESS MUST BE UNDER SUPERVISION
CONSTANTLY.
CAUTION: FIRE HAZARD: DO NOT PLACE ANY OBJECTS ON THE
COOKING SURFACE.
CAUTION: USE ONLY COOKING HOB PROTECTIVE COVERS MADE
BY THE MANUFACTURER OF THE COOKING APPLIANCE OR STATED
BY THE MANUFACTURER OF THE APPLIANCE AS SUITABLE IN THE
RESPECTIVE USER’S MANUAL OR COOKING HOB PROTECTIVE
COVERS BUILT-IN IN THE APPLIANCE. USING INCORRECT
PROTECTIVE COVERS CAN CAUSE ACCIDENTS.

Copyright © 2019, Fast ČR, a. s. Revision 10/2021
EN - 5
PART 2. PRODUCT INTRODUCTION
2.1 Top View
1. Max. 1000/2200 W zone
2. Max. 1200 W zone
3. Max. 1100/2000 W zone
4. Max. 1200 W zone
5. Glass plate
6. Control panel
1. Heating zone selection controls
2. Power slider touch control
3. Dual zone control
4. Keylock control
5. ON/OFF control
6. Timer control
7. Timer regulating controls
2.2 Control Panel
2.3 Product Information
The microcomputer ceramic cooker hob can meet dierent kinds of cuisine demands because of resistance
wire heating, micro-computerized control and multi-power selection, really the optimal choice for modern
families.
The ceramic cooker hob centers on customers and adopts personalized design. The hob has safe and reliable
performances, making your life comfortable and enabling to fully enjoy the pleasure from life.












Copyright © 2019, Fast ČR, a. s. Revision 10/2021
EN - 6
2.4 Working Principle
This ceramic cooker hob directly employs resistance wire heating, and adjust the output power by the power
regulation with the touch controls.
2.5 Before using your New Ceramic Hob
• Readthisguide,takingspecialnoteofthe‘SafetyWarnings’section.
• RemoveanyprotectivelmthatmaystillbeonyourCeramichob.
2.6 Technical Specification
Cooking Hob PHS 604 DC
Cooking Zones 4 Zones
Supply Voltage 220-240V~ 50Hz/60Hz
Installed Electric Power 6000 - 7200W
Product Size L×W×H (mm) 590 x 520 x 55
Building-in Dimensions A×B (mm) 560 x 490
Weight and Dimensions are approximate. Because we continually strive to improve our products we may
change specications and designs without prior notice.

Copyright © 2019, Fast ČR, a. s. Revision 10/2021
EN - 7
PART 3. OPERATION OF PRODUCT
3.1 Touch Controls
• Thecontrolsrespondtotouch,soyoudon’tneedtoapplyanypressure.
• Usetheballofyournger,notitstip.
• Youwillhearabeepeachtimeatouchisregistered.
• Makesurethecontrolsarealwaysclean,dry,andthatthereisnoobject(e.g.autensiloracloth)covering
them. Even a thin lm of water may make the controls dicult to operate.
3.2 Choosing the right Cookware
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits at against the glass, and is the same size as the cooking
zone. Always centre your pan on the cooking zone.

Copyright © 2019, Fast ČR, a. s. Revision 10/2021
EN - 8
Always lift pans o the Ceramic hob – do not slide, or they may scratch the glass.
3.3 How to use
3.3.1 Start cooking
After power on, the buzzer beeps once, all the indicators light up for 1 second then go out, indicating that the
ceramic hob has entered the stat of standby mode.
Touch the ON/OFF

control. All the indicators show“-”
Place a suitable pan on the cooking zone that you wish to use.
• Makesurethebottomofthepanandthesurfaceofthe
cooking zone are clean and dry.
Touching the heating zone selection control, and a indicator
next to the key will ash.
Adjust heat setting by touching the slider control.
• Ifyoudon’tchooseaheatsettingwithin1minute,theceramic
hob will automatically switch o. You will need to start again
at step 1.
• Youcanmodifytheheatsettingatanytimeduringcooking.
• Youcanmodifythepowerlevelfrom0to9Bytheslide
control.

power up
power down
