SPHM SHELLEYSPEED™ HEATED MERCHANDISING MODULE, 34”HEIGHT, 30” DEPTH
Project __________________________
Item ____________________________
Quantity _________________________
CSI Section 11400
SPHM
Heated Merchandising Module, 34” counter height, 30” depth
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
Approval _________________
Date ____________________
MODELS
❑ SPHM-50 50” length, heated merchandising module, 34” counter height, 30” depth
❑ SPHM-64 64” length, heated merchandising module, 34” counter height, 30” depth
SPHM-50
SPECIFICATIONS
STANDARD FEATURES
Base Section
• 14-gauge stainless steel top standard
• 34” counter height, 30” depth
• 18-gauge stainless steel exterior body
• Base of unit has dry storage; lid rack or basket rack optional
• Hinged door(s) with black ABS recessed door handle standard
• Standard on 5” diameter polyurethane swivel casters
• Stainless steel fully retractable interlock provided as standard
• Laminate section has 18-gauge galvanized base and 16-gauge coved
corner supports to protect laminate
• A wide selection of laminate colors available at no additional charge
• One-year parts and 90 day labor standard warranty. Additional
warranties available.
Display Section
• 9’ long cord and plug are supplied standard
• Top heated cabinet maintains NSF4 requirements; holds product
temperatures at 140 degrees
• Two sliding doors standard, easily removable for serving period
• Cabinet interior has lighting to enhance merchandising
• Heated merchandiser accommodates 13.25”x20.5”x2.5” or
13.25”x20.5”x4.75” size baskets
• Sloped peak of heated cabinet accommodates baskets for added
merchandising
• Meets UL, NSF2, NSF4 and CEC standards
OPTIONS AND ACCESSORIES
❑ Lid storage rack
❑ Basket storage rack
❑ 16”x30” Stainless steel drop tray shelf
❑ Stainless steel cash shelf
❑ Tray slides
• V-style
• Tubular bar
❑ 2” Wire basket (13.25”x20.5”x2.5”)
❑ 4” Wire basket (13.25”x20.5”x4.75”)
❑ Decal package
❑ Canopy
Exterior: Exterior body is constructed of 18-gauge
stainless steel side panels or 18-gauge galvanized
reinforced laminate panels. 14-gauge galvanized bottom.
All exterior side panels are reinforced with overlapping
corners and are welded in place. All insert cutouts are
reinforced with 14-gauge galvanized channel supports.
Exterior top is constructed of 14-gauge stainless steel,
welded, ground and polished into one integral unit. Top is
fabricated with square exterior corners with fully hemmed
nosing on all sides. Stainless steel fully retractable
interlocks are installed on opposing corners and locks units
into a complete serving system.
Interior Heated Merchandiser: The heated
merchandiser is constructed with a stainless steel tubing
frame, 18-gauge slanted top and Plexiglas ends and
sliding doors. It contains a heat lamp and incandescent
light along with a heating element with a circulating fan.
The merchandiser is heated by a 120 volt food warmer,
mounted under the center shelf. The temperature control
(infinite switch) for the food warmer is located behind the
right hand hinged door of the operator side. There is a
circulating fan for the lower work surface, this allows for
even temperatures across the lower area. The circulating
fan assembly incorporates a 700 watt 120 volt heating
element. The merchandiser is designed to hold product
above 140˚F.
The upper shelf has a 120 volt incandescent light located
directly above.
Interior Base: The base contains a stainless steel dry
hinged storage insert. Stainless steel hinged doors have
black ABS recessed handles and welded stainless steel flag
hinges. Heated merchandiser controls are contained inside
storage area and on/off power switch is behind self closing
stainless steel cover for tamper resistance.
Electrical: Electrical connections shall be 120 volt, 60
Hertz, single phase. Unit shall have a 9’ long electrical
cord and NEMA 5-20P plug. Cord is standard on the
operator right side of equipment. Double cord hook is
located on the bottom of the unit.
Casters: Unit is mounted on 5” (12.7cm) diameter swivel
polyurethane casters with non-marking tires and plate
brakes. Casters are bolted directly to the 14-gauge bottom
of the base. Overall height of caster assembly is 6.00”
(15.2cm).
Styling: Units are standard with 18-gauge stainless steel
exterior sides. Laminate is an option available at no
additional charge. Decal packages and canopies are also
available.

Model #__________
CSI Section 11400
Printed in the USA.
06/05
DSSPHM
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
SPHM - Heated Merchandising Module, 34” height, 30” depth
Right End View
All Models
Plan View SPHM-50


 

Plan View SPHM-64




 

30.00”
76.2cm
30.00”
76.2cm
50.00”
127cm 64.00”
162.56cm
Elevation View SPHM-50


 

34.00”
86.36cm
30.89”
78.5cm
Elevation View SPHM-64


34.00”
86.36cm
30.89”
78.5cm
MODEL
NUMBER TYPE
BASKET CAPACITY
(HEATED SECTION)
BASE STORAGE
CAPACITY
CU. FT. AMPS VOLTAGE WATTS
NEMA
PLUG
SHIP
WEIGHT
SPHM-50
HEATED DISPLAY
MODULE
6(13.25X20.5X2.5)
3 (13.25X20.5X4.75) 13.63 14.7 120 1770 5-20P 440
SPHM-64
HEATED DISPLAY
MODULE
8 (13.25X20.5X2.5)
4 (13.25X20.5X4.75) 18.17 16.3 120 1960 5-20P 490
MECHANICAL DATA:
48.10”
122.2cm
62.10”
157.7cm
Delfield reserves the right to make changes in design or specifications without prior notice.
26.50”
67.3cm
48.10”, 122.2cm
26.50”
67.3cm
62.10”, 157.7cm
