Delfield Shelleyspeed SPM-28W User manual

SPM-W SHELLEYSPEED™ UTILITY (MERCHANDISING) MODULE, 34”HEIGHT, 35” DEPTH
Project __________________________
Item ____________________________
Quantity _________________________
CSI Section 11400
SPM-W
Utility (Merchandising) Module, 34” height, 35” depth
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
Approval _________________
Date ____________________
SPECIFICATIONS
MODELS
❑ SPM-28W 28” length, merchandising module, 34” height, 35” depth
❑ SPM-36W 36” length, merchandising module, 34” height, 35” depth
❑ SPM-50W 50” length, merchandising module, 34” height, 35” depth
SPM-50W
❑ SPM-60W 60” length, merchandising module, 34” height, 35” depth
❑ SPM-74W 74” length, merchandising module, 34” height, 35” depth
STANDARD FEATURES
• 14-gauge stainless steel tops standard
• 34” counter height, 35” depth
• 18-gauge stainless steel exterior body
• Units have a single or double door dry compartment
for storage
• Standard on 5” diameter polyurethane swivel casters
• Stainless steel fully retractable interlock provided as
standard
• A wide selection of laminate colors available at no
additional charge
• Laminate selection has 18-gauge galvanized base,
16-gauge coved corner supports to protect laminate
• Meets NSF standards
• One-year parts and 90 day labor standard warranty.
Additional warranties available.
OPTIONS AND ACCESSORIES
❑ Single tier merchandiser (Unheated)
❑ Double tier merchandiser (Unheated)
❑ 16”x35” Stainless steel drop tray shelf
❑ Stainless steel cash shelf
❑ Tray slides
• V-style
• Tubular bar
❑ Decal package
❑ Canopy
❑ Basket storage rack for base of unit
❑ Lid storage rack for base of unit
Exterior: Exterior body is constructed of 18-gauge
stainless steel side panels or 18-gauge galvanized
reinforced laminate panels. 14-gauge galvanized
bottom. All exterior side panels are reinforced with
overlapping corners and are welded in place. All
insert cutouts are reinforced with 14-gauge galvanized
channel supports.
Exterior top is constructed of 14-gauge stainless steel,
welded, ground and polished into one integral unit.
Top is fabricated with square exterior corners with
fully hemmed nosing on all sides. Stainless steel fully
retractable interlocks are installed on opposing corners
and locks units into a complete serving system.
Units have a one or two door dry compartment(s)
constructed of 18-gauge stainless steel. All doors have
recessed black ABS door handle as standard. Door(s)
are double-wall construction, with stainless steel front
panel.
Casters: Unit is mounted on 5” (12.7cm) diameter
swivel polyurethane casters with non-marking tires
and plate brakes. Casters are bolted directly to the
14-gauge bottom of the base. Overall height of caster
assembly is 6.00” (15.2cm).
Styling: Units are standard with 18-gauge stainless
steel exterior sides. Laminate is an option available at
no additional charge. Decal packages and canopies are
also available.












Model #__________
CSI Section 11400
Printed in the USA.
06/05
SSSPMW
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: [phone]
Fax: [phone]
Email: info@delfield.com
MODEL
NUMBER TYPE L D H
NUMBER
OF
DOORS
BASKET CAPACITY
(BASE OF UNIT)*
LID STORAGE
CAPACITY
(BASE OF UNIT)*
SHIP
WEIGHT
SPM-28W UTILITY MODULE 28 35 34 1
8 (13.25X26.13X2.5)
4 (13.25X26.13X4.75) NA 165
SPM-36W UTILITY MODULE 36 35 34 1
8 (13.25X26.13X2.5)
4 (13.25X26.13X4.75) NA 185
SPM-50W UTILITY MODULE 50 35 34 2
16 (13.25X26.13X2.5)
8 (13.25X26.13X4.75) 14 205
SPM-60W UTILITY MODULE 60 35 34 2
24 (13.25X26.13X2.5)
12 (13.25X26.13X4.75) 14 250
SPM-74W UTILITY MODULE 74 35 34 2
24 (13.25X26.13X2.5)
12 (13.25X26.13X4.75) 14 270
SPM-W - Utility Merchandising Module, 34” height, 35” depth
Plan View SPM-36W Plan View SPM-50W Plan View SPM-60W
Elevation View SPM-74W
Plan View SPM-28W
MECHANICAL DATA:
Elevation View SPM-28W
34.00”
86.36cm
Elevation View SPM-36
34.00”
86.36cm
Elevation View SPM-50W
34.00”
86.36cm
Elevation View SPM-60W
34.00”
86.36cm
34.00”
86.36cm
35.00”
88.9cm
35.00”
88.9cm
35.00”
88.9cm
35.00”
88.9cm
28.00”
71.12cm
36.00”
91.44cm
50.00”
127cm
60.00”
152.4cm
35.00”
88.9cm
74.00”
187.96cm
Right End View
All Models
28.75”
73.03cm
24.00”
60.96cm
Delfield reserves the right to make changes in design or specifications without prior notice.
Plan View SPM-74W
*If ordering optional basket or lid storage module.
