Delfield F18SC39A User manual

PROJECT
ITEM #
QUANTITY DATE
APPROVAL
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
Short Form Specifications
Exterior top is constructed of one-piece 16-gauge stainless steel, with
integral 2.12” (5.4cm) square nosing at the front, and 4.00” (10.2cm) high
by 2” (5.1cm) deep backsplash at the rear. Top has an opening for use
with 1/6 size pans. Pans and adapter bars supplied by others. Pans are
recessed 3” (7.6cm), or 2” (5.1cm) and rest on adjustable pan supports.
Pan opening has a 20-gauge stainless steel removable cover. Temperature
in top opening to maintain 33°F (1°C) to 41°F (5°C), with pans recessed 3”
(7.6cm), at 86°F ambient room temperature, meeting NSF7 requirements.
Unit has a stainless steel plate shelf 8.4” [21.3cm] above the doors.
Exterior back and bottom to be 24-gauge galvanized steel. Exterior ends
are 18-gauge galvanized steel.
Base interior has a 22-gauge stainless steel back and bottom. Interior
ends and door frames are thermoformed ABS plastic. Base is insulated
with 1.5” (3.8cm) of high-density foamed-in-place polyurethane.
Door(s) have a 22-gauge stainless steel exterior front, with a thermo-
formed ABS plastic interior liner. Door(s) have a black recessed handle and
a snap-in magnetic gasket which is easily replaceable.
Base has a machine compartment, standard on the right, with condens-
ing unit, condensate evaporator and an electrical junction box installed.
Machine compartment has a louver for access to condensing unit. Blower
coil(s) are located behind the door mullions and refrigerate the cabinet.
HFC-404A refrigerant and maintains 36°F (2°C) to 40°F (4°C) interior cabi-
net temperature in the base.
Unit is mounted on 6.13” (15.6cm) high adjustable stainless steel legs.
Electrical connections are 115 volts, 60 Hertz, single phase. Unit has an 8’
(2.4m) long cord and plug.
Optional Accessories & Modifications
906A Stainless steel end
505H Stainless steel back
505F Laminate facing (full front)
906E Laminate end
905A Laminate back
1030A Cutting board (Sanalite or composite)
107F Tray rack
102 Drawers
A-(2) 19” in lieu of one door
B-(2) 27” in lieu of one door
C-(2) 32” in lieu of one door
108 Locks
120F Cold pan drain
213 *220V/50 cycle
1027A Casters
* Inclusion of this option will alter the
electrical specifications of the unit
Model F18SC60A
31.5” (80cm) Deep Self-Contained Refrigerated Salad Top Tables
F18SC

The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
39" [99.1cm] 39" [99.1cm]
52" [132.1cm] 52" [132.1cm]
52" [132.1cm]
60" [152.4cm]
31.5"
[80cm]
31.5"
[80cm]
31.5"
[80cm]
31.5"
[80cm]
31.5"
[80cm]
52" [132.1cm]
31.5"
[80cm]
13.82" x 21.00" NSF-7 STYLE COLD
PAN SIZED TO ACCOMMODATE (6)
1/6 SIZE PANS 6" DP. WITH HINGED
REMOVABLE COVER. (PANS AND
ADAPTER BARS BY OTHERS)
13.82" x 21.00" NSF-7 STYLE COLD
PAN SIZED TO ACCOMMODATE (6)
1/6 SIZE PANS 6" DP. WITH HINGED
REMOVABLE COVER. (PANS AND
ADAPTER BARS BY OTHERS)
13.82" x 21.00" NSF-7 STYLE COLD
PAN SIZED TO ACCOMMODATE (6)
1/6 SIZE PANS 6" DP. WITH HINGED
REMOVABLE COVER. (PANS AND
ADAPTER BARS BY OTHERS)
13.82" x 28.00" NSF-7 STYLE COLD
PAN SIZED TO ACCOMMODATE (8)
1/6 SIZE PANS 6" DP. WITH HINGED
REMOVABLE COVER. (PANS AND
ADAPTER BARS BY OTHERS)
13.82" x 28.00" NSF-7 STYLE COLD
PAN SIZED TO ACCOMMODATE (8)
1/6 SIZE PANS 6" DP. WITH HINGED
REMOVABLE COVER. (PANS AND
ADAPTER BARS BY OTHERS)
13.82" x 28.00" NSF-7 STYLE COLD
PAN SIZED TO ACCOMMODATE (8)
1/6 SIZE PANS 6" DP. WITH HINGED
REMOVABLE COVER. (PANS AND
ADAPTER BARS BY OTHERS)
13.82" x 35.00" NSF-7 STYLE COLD
PAN SIZED TO ACCOMMODATE (10)
1/6 SIZE PANS 6" DP. WITH HINGED
REMOVABLE COVER. (PANS AND
ADAPTER BARS BY OTHERS)
13.82" x 35.00" NSF-7 STYLE COLD
PAN SIZED TO ACCOMMODATE (10)
1/6 SIZE PANS 6" DP. WITH HINGED
REMOVABLE COVER. (PANS AND
ADAPTER BARS BY OTHERS)
13.82" x 42.00" NSF-7 STYLE COLD
PAN SIZED TO ACCOMMODATE (12)
1/6 SIZE PANS 6" DP. WITH HINGED
REMOVABLE COVER. (PANS AND
ADAPTER BARS BY OTHERS)
31.5"
[80cm]
60" [152.4cm]
31.5"
[80cm]
60" [152.4cm]
31.5"
[80cm]
60" [152.4cm]
31.5"
[80cm]
13.82" x 42.00" NSF-7 STYLE COLD
PAN SIZED TO ACCOMMODATE (12)
1/6 SIZE PANS 6" DP. WITH HINGED
REMOVABLE COVER. (PANS AND
ADAPTER BARS BY OTHERS)
PLAN VIEW
18SC39A
PLAN VIEW
18SC39B
PLAN VIEW
18SC52A
PLAN VIEW
18SC60A
PLAN VIEW
18SC60B
PLAN VIEW
18SC60C PLAN VIEW
18SC60D
PLAN VIEW
18SC52B
PLAN VIEW
18SC52C
PLAN VIEW
18SC52D
F18SC
31.5” (80cm) Deep Self-Contained Refrigerated Salad Top Tables

25"
[63.5cm]
CLEARANCE
17"
[43.1cm]
CLEARANCE
END VIEW
ALL MODELS
19" [48.3cm]
DOOR 27" [68.6cm]
DOOR
ELEVATION VIEW
F18SC39A,
F18SC39B
ELEVATION VIEW
F18SC52A,
F18SC52B,
F18SC52C,
F18SC52D
ELEVATION VIEW
F18SC60A,
F18SC60B,
F18SC60C,
F18SC60D
19" [48.3cm]
REF'G
24" [61cm]
PLATE SHELF
19" [48.3cm]
REF'G
19" [48.3cm]
REF'G
19" [48.3cm]
REF'G
27" [68.6cm]
REF'G
45" [115cm]
PLATE SHELF
37" [94cm]
PLATE SHELF
1/4 HP 115V-60C-1PH
1/4 HP 115V-60C-1PH
1/4 HP 115V-60C-1PH
16.31"
[41.4cm]
14.8"
[37.6CM]
36"
[91.44cm]
7.62"
[19.4cm]
6.13"
[15.6cm]
31.5"
[80cm]
PROBE
LINE
PAN COVER WHEN OPEN EXTENDS TO A HEIGHT OF 12" (30.5cm)
40"
[101.6cm]
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
F18SC
31.5” (80cm) Deep Self-Contained Refrigerated Salad Top Tables

MODEL NUMBER OF # 0F STORAGE VOLTS/HERTZ/ SHIP WEIGHT BTU DESIGN BTU SYSTEM CAP.
NUMBER DOORS PANS CU. FT. H.P. PHASE AMPS NEMA LBS / KG BASE/RAIL BASE/RAIL
F18SC39A (1) 19” 6 4.11 1/4 115/60/1 10.0 5-15P 400/181 280/265 1903/745
F18SC39B (1) 19” 8 4.11 1/4 115/60/1 10.0 5-15P 390/177 280/353 1903/867
F18SC52A (2) 19” 6 6.94 1/4 115/60/1 10.0 5-15P 460/208 444/265 1903/745
F18SC52B (2) 19” 8 6.94 1/4 115/60/1 10.0 5-15P 450/204 444/353 1903/867
F18SC52C (2) 19” 10 6.94 1/4 115/60/1 10.0 5-15P 440/199 444/441 1903/971
F18SC52D (2) 19” 12 6.94 1/4 115/60/1 10.0 5-15P 480/195 444/529 1903/1061
F18SC60A (2) 19” & 27” 6 8.69 1/4 115/60/1 10.0 5-15P 500/227 515/265 2314/667
F18SC60B (2) 19” & 27” 8 8.69 1/4 115/60/1 10.0 5-15P 490/222 515/353 2314/798
F18SC60C (2) 19” & 27” 10 8.69 1/4 115/60/1 10.0 5-15P 480/217 515/441 2314/916
F18SC60D (2) 19” & 27” 12 8.69 1/4 115/60/1 10.0 5-15P 470/213 515/529 2314/1023
Mechanical Data–Standard Unit
14"
[35.6cm]
39" [99.1cm]
52" [132.1cm]
60" [152.4cm]
31.5"
[80cm]
AND PLUG
J = JUNCTION BOX
C = CONDENSING UNIT
W/8FT (2.4M) CORD
J
C
NOTE; UNOBSTRUCTED AIRFLOW MUST BE MAINTAINED TO
INSURE UNIT PERFORMANCE AND MAINTAIN WARRANTY.
The Delfield Company, 980 S. Isabella Rd., Mt. Pleasant, MI 48858, U.S.A. • [phone] • Fax [phone] • www.delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice. ©2002 The Delfield Company. All rights reserved. Printed in U.S.A.
DSF18SC 04/02
F18SC
31.5” (80cm) Deep Self-Contained Refrigerated Salad Top Tables
