Delfin DG 70 EXP Z22 Installation instructions

Industrial vacuum cleaners
Operator’s and maintenance manual
Read this manual carefully before using the vacuum cleaner
Machine complying with the ATEX 2014/34/EU DIRECTIVE intended for dust vacuuming in potentially explosive
atmospheres, classified Z22
DG 70 EXP Z22

Introduction
The manual must be kept with the vacuum cleaner in case of resale!
© Copyright DELFIN S.r.l.
2016
This manual provides all the information needed to use and service your vacuum cleaner. Good operation
and durability depend on proper maintenance and careful use.
Before leaving the factory, this particular model has undergone stringent tests to ensure utmost reliability.
Always check however to make sure the vacuum cleaner has not been damaged during transport in such a
way as to affect operation and safety.
This manual should be considered an integral part of the vacuum cleaner and must be kept together with
the unit until this is scrapped. In case of loss of or damage to the manual, ask DELFIN for a new copy.
The technical details contained in this manual are the property of DELFIN and should be deemed of a
confidential nature.
Even partial reproduction of the graphic project, the text and the illustrations is legally forbidden.
Some details shown in the illustrations in this manual may be different from those of your vacuum cleaner.
Some component parts may have been removed for greater clarity.
For easier reference, this manual is split into sections, identifiable by specific graphic symbols.
The subjects dealt with in this manual are those expressly required by "Machine Directive 2006/42/CE"and
the “ATEX 2014/34/EU Directive”, the technical details shown are those provided by the manufacturer at
the time of compilation.
This manual must be kept in a place accessible to all the personnel charged with operating and servicing the
vacuum cleaner.
In case of any doubts, always immediately phone the After-Sales Service.
The competent Law Court for all disputes is that of TURIN (Italy).

Contents
Information section
1.1 Identification of main parts 1
1.2 Accessories provided 2
1.3 Identification details of manufacturer 3
1.4 Marking plate
1.5 Intended uses 4
1.6 Allowed environmental conditions
1.7 Noise level
1.8 Storage
1.9 Scrapping
1.10 Technical details 5
1.11 Warranty 6
Safety section
2.1 Safety details 7
2.2 Safety warnings 8
2.3 Safety plates and symbols 11
2.4 Outstanding risks 13
2.5 Applied directives
Installation section
3.1 Handling 14
3.2 Installation 15
Operation section
4.1 Description of controls 17
4.2 Work cycle 18
4.3 Releasing and removing the removable container 20
4.4 Using the filter shaking system 22
4.5 Function of the vacuum gauge 23
Maintenance section
5.1 Informative notes 24
5.2 General safety warnings
5.3 Maintenance operations 25
5.4 Replacing the filters 27
5.5 Troubleshooting 29
Spare parts section
6.1 Recommended spare parts 30
