Dell EMC PowerEdge XR11 Manual

Dell EMC PowerEdge XR11
Installation and Service Manual
Part Number: E72S
Regulatory Type: E72S001
September 2021
Rev. A01

Notlar, dikkat edilecek noktalar ve uyarılar
NOT: NOT, ürününüzü daha iyikullanmanıza yardımcı olacak önemlibilgiler sağlar.
DİKKAT: DİKKAT, donanım hasarı veya verikaybı olasılığını gösterir ve sorunu nasıl önleyeceğinizibildirir.
UYARI: UYARI, mülk hasarı, kişisel yaralanma veya ölüm potansiyeline işaret eder.
© 2021 Dell Inc. veya yan kuruluşları. Tüm hakları saklıdır. Dell, EMC ve diğer ticarimarkalar, Dell Inc. veya bağlı kuruluşlarının ticarimarkalarıdır.
Diğer ticarimarkalar ilgilisahiplerinin ticarimarkaları olabilir.

Chapter 1: Bu belge hakkında.........................................................................................................7
Chapter 2: PowerEdge XR11 sistem overview.................................................................................8
Front view of the system...................................................................................................................................................8
Rear view of the system................................................................................................................................................... 11
Durum LED'ikontrol paneli...............................................................................................................................................13
Power button control panel.............................................................................................................................................13
Sistemin İçi...........................................................................................................................................................................15
Locating the Express Service Code and Service Tag............................................................................................... 16
Sistem bilgilerietiketi.........................................................................................................................................................17
Ray boyutlandırma ve raf uyumluluğu matrisi..............................................................................................................19
Chapter 3: Başlangıç sistem kurulumu ve yapılandırması.............................................................. 21
Sistemikurma......................................................................................................................................................................21
iDRAC yapılandırması.........................................................................................................................................................21
Options to set up iDRAC IP address........................................................................................................................21
Options to log in to iDRAC........................................................................................................................................ 22
Resources to install operating system......................................................................................................................... 23
Ürün yazılımını indirme seçenekleri..........................................................................................................................23
Options to download and install OS drivers .........................................................................................................23
Sürücü ve ürün yazılımı indirme................................................................................................................................24
Chapter 4: POST ve sistem yönetimiyapılandırma doğrulaması için gereken minimum.................25
Minimum configuration to POST ..................................................................................................................................25
Yapılandırma doğrulaması................................................................................................................................................ 25
Hata iletileri................................................................................................................................................................... 26
Chapter 5: Sistem bileşenlerinitakma ve çıkarma........................................................................ 27
Safety instructions............................................................................................................................................................ 27
Sisteminizin içinde çalışmaya başlamadan önce.........................................................................................................28
sistem içinde çalıştıktan sonra........................................................................................................................................28
Recommended tools......................................................................................................................................................... 28
İsteğe bağlı ön çerçeve.................................................................................................................................................... 29
Ön çerçeveyiçıkarma................................................................................................................................................. 29
Ön çerçeveyitakma.................................................................................................................................................... 29
Çerçeve filtresi...................................................................................................................................................................30
Removing the bezel filter for Rear Accessed configuration............................................................................. 30
Installing the bezel filter for Rear Accessed configuration................................................................................ 31
Sistem kapağı...................................................................................................................................................................... 31
Removing the system cover...................................................................................................................................... 31
Installing the system cover....................................................................................................................................... 33
Hava örtüleri....................................................................................................................................................................... 35
Removing the air shrouds..........................................................................................................................................35
Installing the air shrouds............................................................................................................................................36
Contents
Contents 3

Soğutma fanları..................................................................................................................................................................38
Soğutma fanını çıkarma..............................................................................................................................................38
Soğutma fanını takma.................................................................................................................................................38
Intrusion switch module...................................................................................................................................................39
Removing the intrusion switch module.................................................................................................................. 39
Installing the intrusion switch module.................................................................................................................... 40
Sürücüler.............................................................................................................................................................................. 41
Removing a drive blank...............................................................................................................................................41
Sürücü kasasını takma................................................................................................................................................ 42
Sürücü taşıyıcısını çıkarma.........................................................................................................................................42
Sürücü taşıyıcısını takma............................................................................................................................................43
Removing the drive from the drive carrier............................................................................................................ 44
Installing the drive into the drive carrier................................................................................................................45
Drive backplane..................................................................................................................................................................47
Sürücü arka paneli....................................................................................................................................................... 47
Removing the drive backplane................................................................................................................................. 47
Installing the drive backplane .................................................................................................................................. 48
XR11 için dahilidepolama yapılandırması matrisi.........................................................................................................49
Kablo yerleşimi................................................................................................................................................................... 50
Sistem belleği..................................................................................................................................................................... 53
System memory guidelines........................................................................................................................................53
Genel bellek modülü montaj yönergeleri................................................................................................................ 55
Intel Optane PMem 200 Series installation guidelines ...................................................................................... 55
Bellek modülünü çıkarma........................................................................................................................................... 56
Bellek modülünü takma...............................................................................................................................................57
Processor and heat sink module....................................................................................................................................58
Removing the processor and heat sink module................................................................................................... 58
Removing the processor from the processor heat sink module ..................................................................... 60
İşlemciyibir işlemciısı emicisimodülüne takma.....................................................................................................61
Installing the processor and heat sink module..................................................................................................... 65
Genişletme kartları ve genişletme kartı yükselticileri................................................................................................ 67
Genişletme kartı takma yönergeleri.........................................................................................................................68
Removing the expansion card risers........................................................................................................................ 71
Installing the expansion card risers......................................................................................................................... 72
Removing an expansion card from the expansion card riser............................................................................ 73
Installing an expansion card into the expansion card riser................................................................................ 76
İsteğe bağlı BOSS S1 kartı............................................................................................................................................... 79
Removing the BOSS S1 card.....................................................................................................................................79
BOSS S1 kartını takma................................................................................................................................................80
Removing M.2 SSD module....................................................................................................................................... 81
Installing M.2 SSD module......................................................................................................................................... 81
System battery ................................................................................................................................................................. 82
Sistem pilinideğiştirme...............................................................................................................................................82
Internal USB memory key................................................................................................................................................84
DahiliUSB anahtarını çıkarma...................................................................................................................................84
Installing internal USB key.........................................................................................................................................84
Power supply unit..............................................................................................................................................................85
Sıcak yedek özelliği..................................................................................................................................................... 85
Güç kaynağı ünitesidolgu ekiniçıkarma.................................................................................................................85
Güç kaynağı ünitesidolgu ekinitakma....................................................................................................................86
4Contents

Bir güç kaynağı ünitesiniçıkarma............................................................................................................................. 87
Bir güç kaynağı ünitesinitakma................................................................................................................................88
Power interposer board...................................................................................................................................................90
Removing power interposer board (PIB)...............................................................................................................90
Installing the power interposer board (PIB).......................................................................................................... 91
System board..................................................................................................................................................................... 92
Removing the system board..................................................................................................................................... 92
Installing system board...............................................................................................................................................93
Trusted Platform Module................................................................................................................................................ 95
Upgrading the Trusted Platform Module...............................................................................................................95
Kullanıcılar için TPM başlatma.................................................................................................................................. 96
Kullanıcıları için TPM 1.2'ı başlatma......................................................................................................................... 96
Kullanıcıları için TPM 2.0'ı başlatma........................................................................................................................ 96
Control panel...................................................................................................................................................................... 97
Removing the status LED control panel for Rear Accessed configuration................................................... 97
Installing the status LED control panel for Rear Accessed configuration ....................................................98
Removing the power button control panel for Rear Accessed configuration.............................................. 99
Installing the power button control panel for Rear Accessed configuration................................................101
Removing the status LED control panel for Front Accessed configuration................................................ 102
Installing the status LED control panel for Front Accessed configuration .................................................103
Removing the power button control panel for Front Accessed configuration........................................... 104
Installing the power button control panel for Front Accessed configuration............................................. 105
MIL 901E ve MIL 461G güçlendirilmiş kiti...................................................................................................................106
Installing the MIL 901E and MIL 461G rugged kit...............................................................................................107
Chapter 6: Upgrade Kits............................................................................................................ 109
Chapter 7: Atlama Tellerive konnektörler................................................................................... 110
System board connectors.............................................................................................................................................. 110
Sistem Kartı Anahtar Ayarları......................................................................................................................................... 111
Unutulan parolayı devre dışı bırakma............................................................................................................................ 111
Chapter 8: Sistem tanılamaları ve gösterge kodları..................................................................... 113
Status LED indicators......................................................................................................................................................113
System health and system ID indicator codes...........................................................................................................114
iDRAC Direct LED gösterge kodları..............................................................................................................................115
NIC gösterge kodları........................................................................................................................................................ 115
Güç kaynağı ünitesigösterge kodları........................................................................................................................... 116
Drive indicator codes.......................................................................................................................................................118
Sistem Tanılamayı Kullanma........................................................................................................................................... 119
Dell Tümleşik Sistem Tanılama.................................................................................................................................119
Chapter 9: Yardım alma.............................................................................................................. 121
GeriDönüşüm veya Kullanım Ömrü Sonu servis bilgileri......................................................................................... 121
Dell Technologies’e Bağlanma....................................................................................................................................... 121
Accessing system information by using QRL.............................................................................................................121
PowerEdge XR11 sistem için Hızlı Kaynak Bulucu.............................................................................................. 122
SupportAssist ile otomatik destek alma..................................................................................................................... 122
Contents 5

Chapter 10: Dokümantasyon kaynakları...................................................................................... 123
6 Contents

Bu belge hakkında
Bu belge, sisteme genel bir bakış; bileşenleritakma ve değiştirme, tanılama araçları hakkında bilgiler ve belirlibileşenlerikurarken
izlenecek yönergeler sağlar.
1
Bu belge hakkında 7

PowerEdge XR11 sistem overview
The PowerEdge XR11 sistem is a 1U server that supports:
●Rear Accessed configuration or Front Accessed configuration
●One 3rd Generation Intel Xeon Scalable processor with up to 36 cores
●Eight DIMM slots
●Two redundant AC or DC power supply units
●Up to 4 x 2.5-inch SAS/SATA/NVMe SSD drives
NOTE: All instances of SAS, SATA and NVMe drives are referred to as drives in this document, unless specified otherwise.
NOTE: The Rear Accessed and Front Accessed configurations cannot be modified into the other configuration.
CAUTION: Do not install GPUs, network cards, or other PCIe devices on your system that are not validated
and tested by Dell. Damage caused by unauthorized and invalidated hardware installation will null and void the
system warranty.
NOTE: For more information, see the Dell EMC PowerEdge XR11 Technical Specifications on the product documentation
page.
Topics:
•Front view of the system
•Rear view of the system
•Durum LED'i kontrol paneli
•Power button control panel
•Sistemin İçi
•Locating the Express Service Code and Service Tag
•Sistem bilgileri etiketi
•Ray boyutlandırma ve raf uyumluluğu matrisi
Front view of the system
Figure 1. Front view of Rear Accessed configuration
Table 1. Features available on the front view of Rear Accessed configuration
Item Ports, panels, and slots Icon Description
1 Status LED control panel N/A Contains the system health,
system ID, status LED.
●Status LED: Enables you
to identify any failed
2
8 PowerEdge XR11 sistem overview

Table 1. Features available on the front view of Rear Accessed configuration (continued)
Item Ports, panels, and slots Icon Description
hardware components.
There are up to five
status LEDs and an
overall system health
LED (Chassis health and
system ID) bar. For
more information, see
the Status LED indicators
section.
2 Drives N/A Enables you to install up to 4
x 2.5-inch SAS/SATA/NVMe
SSD drives.
3 Power button control panel N/A Contains the power button,
USB port, iDRAC Direct micro
port, and the iDRAC Direct
status LED.
4 Information tag N/A The Information tag is a slide-
out label panel that contains
Service Tag, iDRAC MAC
address and LOM 1 MAC
address.
Figure 2. Front view of Front Accessed configuration
Table 2. Features available on the front view of Front Accessed configuration
Item Ports, panels, or slots Icon Description
1 PCIe expansion card riser 1
(slot 1)
N/A Enables you to connect PCIe
expansion card installed on
riser 1.
2 Serial port Enables you to connect a
serial device to the system.
3 iDRAC dedicated port It is an RJ-45 port.
iDRAC'e uzaktan erişmenize
olanak tanır. Daha fazla
bilgi için www.dell.com/
poweredgemanuals
adresindeki iDRAC Kullanıcı
Kılavuzu'na bakın.
4 PCIe expansion card riser 2
and 3 (slot 2 and 3)
N/A Enables you to connect PCIe
expansion card installed on
riser 2 and 3.
5 Power supply unit (PSU2) Indicates the PSU2 or
redundant PSU.
PowerEdge XR11 sistem overview 9

Table 2. Features available on the front view of Front Accessed configuration (continued)
Item Ports, panels, or slots Icon Description
6Power supply unit (PSU1) Indicates the PSU1 or primary
PSU.
7USB 2.0 port This port is USB 2.0-
compliant.
8 USB 3.0 port This port is USB 3.0-
compliant.
9 VGA port Enables you to connect a
display device to the system.
10 4 x 25 GbE LOM ports Provides network connectivity
and can also be shared with
iDRAC when iDRAC network
settings is set to shared
mode.
11 System identification button Press the system ID button:
●To locate a particular
system within a rack.
●To turn the system ID on
or off.
To reset iDRAC, press and
hold the button for more than
16 seconds.
NOTE:
●To reset iDRAC using
system ID, ensure that
the system ID button is
enabled in the iDRAC
setup.
●If the system stops
responding during
POST, press and hold
the system ID button
(for more than 5
seconds) to enter the
BIOS progress mode.
12 Power button control panel N/A Contains the power button,
iDRAC Direct micro port, and
the iDRAC Direct status LED.
NOTE: For more information, see the Dell EMC PowerEdge XR11 Technical Specifications on the product documentation
page.
10 PowerEdge XR11 sistem overview

Rear view of the system
Figure 3. Rear view of Rear Accessed configuration
Table 3. Features available on the rear view of Rear Accessed configuration
Item Ports, panels, or slots Icon Description
1 PCIe expansion card riser 1
(slot 1)
N/A Enables you to connect PCIe
expansion card installed on
riser 1 in the system.
2 Serial port Enables you to connect a
serial device to the system.
3 iDRAC dedicated port iDRAC'e uzaktan erişmenize
olanak tanır. Daha fazla
bilgi için www.dell.com/
poweredgemanuals
adresindeki iDRAC Kullanıcı
Kılavuzu'na bakın.
4 PCIe expansion card riser 2
and 3 (slot 2 and 3)
N/A Enables you to connect PCIe
expansion card installed on
riser 2 and 3 in the system.
5 Power supply unit (PSU2) Indicates the PSU2 or
redundant PSU.
6Power supply unit (PSU1) Indicates the PSU1 or primary
PSU.
7USB 2.0 port This port is USB 2.0-
compliant.
8 USB 3.0 port This port is USB 3.0-
compliant.
9 VGA port Enables you to connect a
display device to the system.
10 4 x 25 GbE LOM ports Provides network connectivity
and can also be shared with
iDRAC when iDRAC network
settings is set to shared
mode.
11 System identification button Press the system ID button:
●To locate a particular
system within a rack.
●To turn the system ID on
or off.
To reset iDRAC, press and
hold the button for more than
16 seconds.
PowerEdge XR11 sistem overview 11

Table 3. Features available on the rear view of Rear Accessed configuration (continued)
Item Ports, panels, or slots Icon Description
NOTE:
●To reset iDRAC using
system ID, ensure that
the system ID button is
enabled in the iDRAC
setup.
●If the system stops
responding during
POST, press and hold
the system ID button
(for more than 5
seconds) to enter the
BIOS progress mode.
Figure 4. Rear view of Front Accessed configuration
Table 4. Features available on the rear view of Front Accessed configuration
Item Ports, panels, and slots Icon Description
1 Status LED control panel N/A Contains the system health,
system ID, status LED.
●Status LED: Enables you
to identify any failed
hardware components.
There are up to five
status LEDs and an
overall system health
LED (Chassis health and
system ID) bar. For
more information, see
the Status LED indicators
section.
2 Drives N/A Enables you to install up to
4x 2.5-inch SAS/SATA/NVMe
SSD drives.
3 Information tag N/A The Information tag is a slide-
out label panel that contains
Service Tag, iDRAC MAC
address and LOM 1 MAC
address.
NOTE: For more information, see the Dell EMC PowerEdge XR11 Technical Specifications on the product documentation
page.
12 PowerEdge XR11 sistem overview

Durum LED'ikontrol paneli
Rakam 5. Durum LED'ikontrol paneli
Tablo 5. Durum LED'ikontrol paneli
Öğe Gösterge, düğme veya
konnektör Simge Açıklama
1 Durum LED'igöstergeleriYok Sistemin durumunu gösterir. Daha fazla bilgiiçin Durum LED
göstergeleribölümüne bakın.
2 Sistem sağlığı ve sistem
kimliğigöstergesiSistem sağlığını gösterir. Daha fazla bilgiiçin Sistem sağlığı ve sistem
kimliğigösterge kodları bölümüne bakın.
NOT: Gösterge kodları hakkında daha fazla bilgiiçin Sistem tanılamaları ve gösterge kodları bölümüne bakın.
Power button control panel
Figure 6. Power button control panel for Front Accessed configuration
Table 6. Power button control panel
Item Indicator or button Icon Description
1 Power button Sistemin açık veya kapalı durumunu gösterir. Sistemin gücünü manuel
olarak açmak veya kapatmak için güç düğmesine basın.
NOTE: ACPI uyumlu bir işletim sistemini düzgün kapatmak için güç
düğmesine basın.
2USB 2.0-compliant port The USB port is a 2.0-compliant. This port enables you to connect USB
devices to the system.
NOTE: The USB 2.0 port is not available on Front Accessed
configuration.
PowerEdge XR11 sistem overview 13

Table 6. Power button control panel (continued)
Item Indicator or button Icon Description
3 iDRAC Direct LED
indicator
N/A The iDRAC Direct LED indicator lights up to indicate that the iDRAC Direct
port is actively connected to a device.
4iDRAC Direct port (Micro-
AB USB)
The iDRAC Direct port (Micro-AB USB) enables you to access the iDRAC
direct features. For more information, see the https://www.dell.com/
idracmanuals.
NOTE: You can configure iDRAC Direct by using a USB to micro USB
(type AB) cable, which you can connect to your laptop or tablet. Cable
length should not exceed 3 feet (0.91 meters). Performance could be
affected by cable quality.
NOTE: For more information, see the Dell EMC PowerEdge XR11 Technical Specifications on the product documentation
page.
Figure 7. Power button control panel for Rear Accessed configuration
Table 7. Power button control panel
Item Indicator or button Icon Description
1 Power button Sistemin açık veya kapalı durumunu gösterir. Sistemin gücünü manuel
olarak açmak veya kapatmak için güç düğmesine basın.
NOTE: ACPI uyumlu bir işletim sistemini düzgün kapatmak için güç
düğmesine basın.
2iDRAC Direct LED
indicator
N/A The iDRAC Direct LED indicator lights up to indicate that the iDRAC Direct
port is actively connected to a device.
3iDRAC Direct port (Micro-
AB USB)
The iDRAC Direct port (Micro-AB USB) enables you to access the iDRAC
direct features. For more information, see the https://www.dell.com/
idracmanuals.
NOTE: You can configure iDRAC Direct by using a USB to micro USB
(type AB) cable, which you can connect to your laptop or tablet. Cable
length should not exceed 3 feet (0.91 meters). Performance could be
affected by cable quality.
NOTE: For more information, see the Dell EMC PowerEdge XR11 Technical Specifications on the product documentation
page.
14 PowerEdge XR11 sistem overview

Sistemin İçi
Rakam 8. Sistemin içinde - Arkadan Erişilen yapılandırma
1. Yükseltici1 2. Sistem kartı
3. BOSS-S1 kartı (isteğe bağlı) 4. İşlemcive ısı emicimodülü
5. Bellek modülü yuvaları (8) 6. İşlemcihava örtüsü
7. Soğutma fanları (6) 8. Bilgietiketi
9. Sürücü kafesi10. Arka panel
11. PCI hava örtüsü 12. Güç Ayırıcı Kartı (PIB)
13. Yükseltici2 ve 3 14. Güç kaynağı üniteleri
PowerEdge XR11 sistem overview 15

Rakam 9. Sistemin içinde - Önden Erişilen yapılandırma
1. Yükseltici1 2. Sistem kartı
3. BOSS-S1 kartı (isteğe bağlı) 4. İşlemcive ısı emicimodülü
5. Bellek modülü yuvaları (8) 6. İşlemcihava örtüsü
7. Soğutma fanları (6) 8. Bilgietiketi
9. Sürücü kafesi10. Arka panel
11. PCI hava örtüsü 12. Güç Ayırıcı Kartı (PIB)
13. Yükseltici2 ve 3 14. Güç kaynağı üniteleri
Locating the Express Service Code and Service Tag
The unique Express Service Code and Service Tag are used to identify the system.
The information tag is located on the front of the Rear Accessed configuration and rear of the Front Accessed configuration.
The information tag includes system information such as the Service Tag, Express Service Code, Manufacture date, NIC, MAC
address, QRL label, and so on.
Figure 10. Locating the Service Tag of your system
1. Information tag (front view)
2. Express Service Tag label
16 PowerEdge XR11 sistem overview

3. Information tag (back view)
4. iDRAC MAC address information label
5. Network MAC address information label
The Mini Enterprise Service Tag (MEST) label is located on the rear of the Rear Accessed configuration and on the front
of the Front Accessed configurations. The MEST includes the Service Tag (ST), Express Service Code (Exp Svc Code), and
Manufacture Date (Mfg. Date). The Exp Svc Code is used by Dell EMC to route support calls to the appropriate personnel.
Alternatively, the Service Tag information is located on a label on the left wall of Rear Accessed configuration and right wall of
the Front Accessed configuration.
Sistem bilgilerietiketi
Sistem bilgilerietiketi, sistem kapağının arkasında yer alır.
PowerEdge XR11 sistem overview 17

Rakam 11. Servis bilgileri
18 PowerEdge XR11 sistem overview

Rakam 12. Servis bilgileri(devamı)
Rakam 13. Sistem görevleri
Rakam 14. Simge göstergesi
Ray boyutlandırma ve raf uyumluluğu matrisi
Sisteminizle uyumlu ray çözümlerihakkında bilgiiçin https://i.dell.com/sites/csdocuments/Business_solutions_engineering-
Docs_Documents/en/rail-rack-matrix.pdf adresindekiDell EMC Kurumsal Sistemler Ray Boyutlandırma ve Raf Uyumluluğu
Matrisi'ne bakın.
Belgede aşağıda listelenen bilgiler sağlanır:
●Ray tiplerive bunların işlevleriile ilgilibelirliayrıntılar.
PowerEdge XR11 sistem overview 19

●Çeşitlirafa montaj flanşlar için ray ayarlanabilirlik aralığı.
●Kablo yönetim aksesuarları ile veya olmadan ray derinliği.
●Çeşitlitürlerde rafa montaj flanşlar için desteklenen raf tipleri.
20 PowerEdge XR11 sistem overview
