Dell™Vostro™330
Regulatory Information
Regulatory Compliance
Regulatory Model: W02C
Regulatory Type: W02C001
Last revised: 7 June 2011
PDF
HTML
Setup and Features Information Tech Sheet
View
Download
Owner's Manual
View
Download

Back to Contents Page
Dell Vostro 330 Owner's Manual
Speaker Cover
Installing The Speaker Cover
Removing The Speaker Cover

Back to Contents Page
Dell Vostro 330 Owner's Manual
Heat Sink
Removing The Processor Heat Sink
Removing The Processor Heat Sink

Back to Contents Page
Dell Vostro 330 Owner's Manual
Front Bezel
Removing The Front Bezel
Installing The Front Bezel

Back to Contents Page
Dell Vostro 330 Owner's Manual
Removing The Back Stand Cover
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Remove the front stand.
4. Push the back stand to its maximum extent.
5. Slide the stand cover through the stand and remove the back stand cover from the computer.
Related tasks
Installing The Back Stand Cover

Back to Contents Page
Dell Vostro 330 Owner's Manual
Installing The Speakers
1. Place the speakers on the system board.
2. Replace the screws that secure the speakers to the system board.
3. Connect the speaker cable to the system board.
4. Replace the system board shield.
5. Replace the front stand.
6. Replace the cover.
7. Follow the procedures in After Working Inside Your Computer.
Related tasks
Removing the Speakers

Back to Contents Page
Dell Vostro 330 Owner's Manual
Removing The Front Stand
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the cover.
3. Remove the screws that secure the front stand to the computer.
4. Fold the back stand as far as it will go and then lift the front stand out of the computer.
5. Remove the screws securing the I/O bracket to the front stand.

6. Remove the I/O panel.
Related tasks
Installing The Front Stand

Back to Contents Page
Dell Vostro 330 Owner's Manual
System Board Shield
Removing The System Board Shield
Installing The System Board Shield

Back to Contents Page
Dell Vostro 330 Owner's Manual
Removing The Processor Heat Sink
1. Place the heat sink on the computer and replace the screws that secure the heat sink to the system board.
2. Replace the screws that secure the heat sink to the computer.
3. Replace the processor fan.
4. Replace the video card fan.
5. Replace the video card and heat sink assembly.
6. Replace the system board shield.
7. Replace the front stand.
8. Replace the cover.
9. Follow the procedures in After Working Inside Your Computer.
Related tasks
Removing the Processor Heat Sink
