Dell OptiPlex 360 MT User manual

Dell™
Optiplex™360
Designed with growing businesses and organizations with less complex
IT infrastructures in mind, the OptiPlex 360 is built with practical
features focused on providing essential business value. The OptiPlex
360 delivers reliable, cost-eective business productivity with Intel®Core™2
Duo processors, high-speed memory options, and integrated video support.
Customizable to meet your business needs, the OptiPlex 360 oers
technology that provides basic manageability, security, and energy
eciency. All backed by a choice of smart, desktop-focused services
that provide your IT professionals the tools they need throughout the
technology lifecycle, from acquisition to asset retirement. Essential
business value of the OptiPlex 360 is just one of the reasons Dell is a
leader in business desktops – and why OptiPlex is the easiest choice
you’ll make today.
Optiplex Means Business
The OptiPlex 360 delivers essential performance to help keep your
business running:
• Exceptionalvalueforreliablebusiness-classcomputing,featuringIntelCore2Duo,
Pentium®DualCore,andCeleron®processors
• Planningsupportwithuptoa12-monthlifecycle,stableimages,managedtransitions,and
DellImageWatch™toprovideearlynoticationofupcomingtechnologychanges
• CustomizableGlobalserviceandsupportthroughDellProSupportserviceoptions
• DellClientManagerremotemanagerallowseasysystemmanageability
Optiplex is easy tO Own
The OptiPlex 360 is designed and built to be both flexible and easily scalable to meet your
changing needs:
• Therighttforbasicuserproductivitywithchoiceoftwoformfactors
• Time-savingtool-lessdesignandDellexclusiveDirectDetect™troubleshootingLEDshelp
result in reduced maintenance and service costs
• AddpredictabilitytotheITmanagementprocesswithaminimum60-daytransitionperiod
betweenproducttransitions
• Dellclientmanagerenabling,remoteinventory,diagnosis,andsystemhardwaremanagement
Optiplex security
OptiPlex provides basic security oerings to help protect your critical data:
• SystemandBIOSpasswordstohelppreventunauthorizedaccess
• Chassislooplockprovidesphysicalsystemprotection
• ProactiveDellProSupportserviceshelpreduceriskandprotectyoursensitivedatawith
HardDriveDataRecoveryandCertiedDataDestruction
Optiplex Gets Green
DelliscommittedtobeingthegreenestPCCompanyontheplanet.AndtheOptiPlex
360 delivers smart energy choices so that you can:
• AchieveoutstandingperformancewithlessenergythroughDell’sEnergySmart
powermanagement
• Helpreducepowerconsumption—andcost—withDell'spowersupply,whichisup
to88%ecient(availableafter11/17/2008onselectedmodels)

Optiplex 360 Technical Specifications
Processors
E7000seriesIntel®Core2Duo3M,1066FSB
E2000seriesIntel®PentiumDualCore1M,800FSB
E1000seriesIntel®CeleronDualCore512K,800FSB
400seriesIntel®Celeron512K,800FSB
Chipset Intel®G31(ICH7)ExpressChipset
Operating System Microsoft®WindowsVista®Business(32bit);Microsoft®WindowsVista®HomeBasic(32bit);Microsoft®
Windows®XPProSP3throughVistaBusinessDowngradeRight,NovelSLED(Chinaonly)
Memory Upto2DIMMslots;Non-ECCdual-channel800MHzDDR2SDRAM,supporting512MBto4GB
Networking IntegratedBroadcom®(BCM5784M)10/100/1000Ethernet
OptionalNIC10/100/1000*EthernetwithRemoteWakeUp,PXEsupport
Video1Intel®GraphicsMediaAccelerator3100;256MBATIRadeon™HD2400PROwithDVIandTVOut;256MBATI
RadeonHD3450GraphicsdualDVIorVGAandTVOut
Internal Port TwoSerialATA(7-pin)ontheDT,andThreeSerialATA(7-pin)ontheMTHardDrives
Hard Drives 80GB,160GB7200RPMSATAII,3.0GB/s;2ndharddriveavailableonminitower
Chassis
MINI TOWER DESKTOP
Dimensions (H x W x D) 16.10”x7.36”x17.52” 15.65”x4.59”x14.25”
 40.8cmx18.6cmx44.5cm 39.7cmx11.6cmx36.1cm
Number of Bays 2internal3.5” 1internal3.5”
 1external3.5” 1external3.5”
 2external5.25” 1external5.25”
Expansion Slots 1fullheightPCIex16graphics 1low-prolePCIex16graphics
 2fullheightPCI 2low-prolePCI
(Optional riser converts the
  PCIex16andPCIintofullheightslots)
Power Supply Options  255WStandardPowerSupply, 235WStandardPowerSupply,
 255W88%EcientPowerSupply 255W88%EecientPower
(availableafter11/17/08) Supply
(availableafter11/17/08)
Peripherals
Monitors
Flat Panel Analog:Dell17”E178FPFlatPanel;Dell19”E198FPFlatPanel
Widescreen Flat Panel Analog:Dell16”E1609WWidescreenFlatPanel;Dell17”E1709WWidescreenFlatPanel
(availableafter11/17/08);Dell19”E1909WWidescreenFlatPanel;Dell20”E2009WWidescreenFlatPanel;Dell22”
E2209WWidescreenFlatPanel;Dell17”E178WFPWidescreenFlatPanel;Dell19”E198WFPWidescreenFlatPanel;
Dell20"E207WFPWidescreenFlatPanel;Dell22”E228WFPWidescreenFlatPanel
UltraSharp Digital Flat Panel, Adjustable Stand, VGA/DVI:Dell17”UltraSharp™1708FPFlatPanel;Dell19”
UltraSharp™1908FPFlatPanel
UltraSharp Digital Widescreen Flat Panel, Adjustable Stand, VGA/DVI:Dell19”UltraSharp™1908FPWWidescreen
Keyboards: DellUSBEntryKeyboard,DellQuietKeyboard(availableafter11/17/08)
Mouse: DellOptical2-buttonscrollmouse,USB
Audio Speakers: InternalDellBusinessaudiospeaker,DellAX2102.0Speakers,AX510andAX510PAsound
barsavailablewithselectFPmonitors
Storage OptionalRemovableMediaStorageDevices:DVD-ROM,CDRW/DVD-ROM,DVD+/-RW,FloppyDrive
Security Chassislooplocksupport(withcablelocksavailable),Setup/BIOSPassword,I/OInterfaceSecurity
Systems Management
DellClientManagerStandard:Ano-chargesystemsmanagementconsole;allowsyoutodeploy,manageand
troubleshootDellclientsystemsacrossyourentireorganization.OptionalupgradestoDellClientManagerPlus
ortheManagementSuiteforDellClientsavailable.
Environmental,
Ergonomic, and
Regulatory Standards
Environmental Standards (eco-labels) CECP,JapanEnergyLaw,CES,JapanGreenPC,FEMP,SouthKorea
Eco-label,EURoHS,ChinaRoHS.EnergyStar4.0,TCOandEPEATGoldfrom11/17/2008
Other Environmental Options DellEnergySmartsettings,CarbonO-set,SystemRecycle(AssetRecoveryService)
Warranty21-yearNextBusinessDayOn-SiteServiceafterRemoteDiagnosis;3-yearLimitedHardwareWarrantyand
3-yearNextBusinessDayOn-SiteServiceafterRemoteDiagnosis.
1.Graphics:Signicantsystemmemorymaybeusedtosupportgraphics,dependingonsystemmemorysizeandotherfactors.
2.Availabilityvaries.Otherconditionsapply.RemoteDiagnosisisdeterminationbyonline/phonetechnicianofcauseofissue;mayinvolve
customeraccesstoinsideofsystemandmultipleorextendedsessions.IfissueiscoveredbyLimitedHardwareWarranty[Dell.com/warranty]
andnotresolvedremotely,technicianand/orpartwillbedispatched,usuallywithin1businessdayfollowingcompletionofRemoteDiagnosis.
ForcopyofLtdHardwareWarranty,writeDellUSALP,Attn:Warranties,OneDellWay,RoundRock,TX78682orseewww.dell.com/warranty
IntelandIntelCorearetrademarksorregisteredtrademarksofIntelCorporationintheU.S.andothercountries.Microsoft,MS,Windows,and
WindowsVistaareregisteredtrademarksofMicrosoftCorporation.
SIMPLIFY DESKTOP COMPUTING AT DELL.COM/OptiPlex
