Precision 5530
Setup and Specications guide
Regulatory Model: P56F
Regulatory Type: P56F002

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2018 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks
may be trademarks of their respective owners.
2018 - 05
Rev. A01

Set up your computer
1 Connect the power adapter.
2 Press the power button.
3 Follow the instructions on the screen to nish Windows setup:
a Connect to a network.
1
Set up your computer 3

b Sign-in to your Microsoft account or create a new account.
4 Locate Dell apps.
Table 1. Locate Dell apps
Register your computer
Dell Help & Support
SupportAssist — Check and update your computer
4Set up your computer

Chassis
This chapter illustrates the multiple chassis views along with the ports and connectors and also explains the FN hot key combinations.
Topics:
• System Overview
• Hot key combinations
System Overview
Figure 1. Inside View — Back
1WLAN card 2 M.2 PCle SSD
3 heatsink 4 memory modules
5 system fan 6 battery
7 speakers
2
Chassis 5

Figure 2. Front View
1Power button with light indicator / Power button with
ngerprint reader without light indicator (optional)
2 Keyboard
3 Palmrest 4 Touchpad
Figure 3. Front Open View
1Camera-status light 2 Camera
6 Chassis

3 Left speaker 4 Right speaker
Figure 4. Left View
1 Power connector port 2 USB 3.1 Gen 1 port with PowerShare
3 HDMI port 4 Thunderbolt 3 Type-C port
5 Headset port
Figure 5. Right View
1Memory card reader 2 USB 3.1 Gen 1 port with PowerShare
3 Battery-charge status lights 4 Battery-charge status button
5 Noble wedge security slot
Chassis 7

Hot key combinations
Table 2. Hot key combination
Fn key combination Precision 5530
Fn+ESC Fn Toggle
Fn+ F1 Speaker Mute
Fn+ F2 Volume Down
Fn+ F3 Volume Up
Fn+ F4 Rewind
Fn+ F5 Play/Pause
Fn+ F6 Forward
Fn+ F8 Display Toggle (Win + P)
Fn+ F9 Search
Fn+ F10 Increase Keyboard Back light Brightness
Fn+ F11 Panel Brightness Down
Fn+ F12 Panel Brightness Up
Fn+ PrtScr Wireless
8 Chassis

Technical specications
NOTE: Oerings may vary by region. The following specications are only those required by law to ship with your computer. For
more information about the conguration of your computer, go to Help and Support in your Windows operating system and
select the option to view information about your computer.
Topics:
• Physical specications
• System information
• Processor specications
• Operating system specications
• Memory specications
• Port and connector specications
• Communication specications
• Video specications
• Audio specications
• Storage specications
• Display specications
• Keyboard specications
• Camera
• Touchpad specications
• Power supply specications
• Battery
• Power adapter
• Security
• Computer environment
Physical specications
Table 3. Dimensions and weight
Height 17 mm (0.66 in)
Width 357 mm (14.06 in)
Depth 235 mm (9.26 in)
Weight 1.78 kg (3.93 lb) - Non Touch / 2.04 kg (4.5 lb) - Touch
System information
3
Technical specications 9

Table 4. System information
Chipset Intel CM246
DRAM bus width 64-bit wide channels
FLASH EPROM 32 MB
PCIe bus up to Gen3; 8 Gbps
Processor specications
NOTE: Processor numbers are not a measure of performance. Processor availability is subject to change and may vary by region/
country.
Table 5. Processor specications
Type UMA Graphics
Intel Xeon E-2176M (6-core 2.7GHz, 4.4GHz Turbo, 12MB 45W) Intel UHD Graphics P630
Intel 8th generation Intel Core i9-8950HK,(6-core 2.9GHz, 4.8GHz
Turbo, 12MB 45W)
Intel UHD Graphics 630
Intel 8 th generation Intel Core i7-8850H (6-core 2.6GHz, 4.3GHz
Turbo, 9MB 45W)
Intel UHD Graphics 630
Intel 8 th generation Intel Core i5-8300H (4-core 2.3GHz, 4.0GHz
Turbo, 8MB 45W)
Intel UHD Graphics 630
Operating system specications
Table 6. Operating system specications
Operating systems supported • Microsoft 10 Windows Pro 64-bit
• Microsoft Windows 10 Home 64-bit•
• Microsoft Windows 10 Pro National Academic (64-bit)
• Microsoft Windows 10 Home National Academic (64-bit)
• Microsoft Windows 10 Pro for Enterprise
• Microsoft windows 10 Pro for Workstation (64-bit)
• Red Hat Enterprise Linux (RHEL)
• Ubuntu 16.04 LTS SP1 64-bit
Memory specications
Table 7. Memory specications
Minimum memory conguration 8 GB
Maximum memory conguration 32 GB
10 Technical specications

Number of slots 2 SoDIMM
Maximum memory supported per slot 16 GB
Memory options • 8 GB DDR4 2666 MHz (8Gx1)
• 8 GB DDR4 2666 MHz (4Gx2)
• 12 GB DDR4 2666 MHz (8Gx1 + 4Gx1)
• 16 GB DDR4 2666 MHz (8Gx2)
• 16 GB DDR4 2666 MHz (16Gx1)
• 24 GB DDR4 2666 MHz (16Gx1 + 8Gx1)
• 32 GB DDR4 2666 MHz (16Gx2)
NOTE: The memory modules are customer replaceable
units (CRU), and it can be upgraded.
NOTE:
• Memory conguration of 2666 MHz pair with core i5, i7
and i9 CPU
Type DDR4 SDRAM Non-ECC memory
Speed 2666 MHz on Core i5, i7 and i9 processor
Port and connector specications
Table 8. Ports and connectors
USB • Two USB 3.1 Gen 1 ports with PowerShare
• One Thunderbolt 3 port (USB 3.1 Gen 2 Type-C) with power
delivery
Security Noble lock slot
Audio One headset port (headphone and microphone combo)
Video HDMI 2.0 port
Memory Card reader SD 4.0
Communication specications
Table 9. Communication specications
Network adapter Ethernet via USB-to-Ethernet Dongle provided in box.
Wireless • Intel Wireless-AC 9260 2x2 802.11ac + BT5.0 (vPro)
• Qualcomm QCA6174A 2x2 802.11ac + BT5.0
• Bluetooth 5.0
Technical specications 11

Video specications
Table 10. Video
Controller Type CPU
Dependency
Graphics
memory type
Capacity External display
support
Maximum
resolution
Intel UHD
Graphics 630
UMA Intel Core i5 -
8300H
Intel Core i7 -
8850
Intel Core i9 -
8950
Integrated Shared system
memory
HDMI 2.0 HDMI : 1920x1080@
60Hz
Intel UHD
Graphics P630
UMA Intel Xeon
E-2176M
Integrated Shared system
memory
HDMI 2.0 HDMI : 1920x1080@
60Hz
NVIDIA Quadro
P1000
Discrete N/A GDDR5 4 GB HDMI 2.0 HDMI = 1920x1200
(PC Mode),
1920x1080 (TV
mode, 1080p)
NVIDIA Quadro
P2000
Discrete N/A GDDR5 4 GB HDMI 2.0 HDMI = 1920x1200
(PC Mode),
1920x1080 (TV
mode, 1080p)
Audio specications
Table 11. Audio specications
Controller Waves MaxxAudio Pro
Type Integrated
Interface • High-quality speakers
• Dual-array microphones
Storage specications
Table 12. Storage specications
Type Form factor Interface Capacity
Solid-State Drive (SSD) M.2 PCIe SSD PCIe, Up to 8 Gbps 256 GB upto 2 TB SSD
Hard drive (HDD) 2.5 inch SATA HDD SATA , Up to 6 Gbps 500 GB / 1 TB/ 2 TB HDD
12 Technical specications

Display specications
Table 13. Display specications
Type • 15.6-inch UltraSharp FHD IPS (1920x1080) Wide View Anti-
Glare LED-backlit with Premium Panel Guarantee (72% color
gamut)
• 15.6-inch UltraSharp UHD IGZO (3840x2160) Touch Wide View
LED-backlit with Premium Panel Guarantee (100% Minimum
Adobe color gamut)
Luminance/Brightness (typical) • 400 nits (FHD 72% color gamut )
• 360 nits (UHD Adobe 100% color gamut)
Height (Active area) • FHD - 194.5 mm (7.66 inches)
• UHD - 194.5 mm (7.66 inches)
Width (Active area) • FHD - 345.6 mm (13.61 inches)
• UHD - 345.6 mm (13.55 inches)
Diagonal • FHD - 396.52 mm (15.61 inches)
• UHD - 396.52 mm (15.61 inches)
Megapixels • FHD - 2.07
• UHD - 8.29
Pixels Per Inch (PPI) • FHD - 141
• UHD - 282
Contrast ratio • FHD - 1500:1
• UHD - 1500:1
Refresh rate 60 Hz
Horizontal viewing angle (min) +/- 89 degrees
Vertical viewing angle (min) +/- 89 degrees
Pixel pitch • FHD - 0.18 mm
• UHD - 0.09 mm
Power consumption (max) • 4.22 W (FHD 72% color gamut )
• 9.23 W (UHD Adobe 100% color gamut)
Technical specications 13

Keyboard specications
Table 14. Keyboard specications
Number of keys • 80 (U.S. and Canada)
• 81 (Europe)
• 82 (Brazil)
• 84 (Japan)
Size Full sized
• X= 19.05 mm key pitch
• Y= 18.05 mm key pitch
Backlit keyboard Easy enable/disable via hotkey <Fn+F10 Key> variable brightness
levels
Layout QWERTY/AZERTY/Kanji
Camera
Table 15. Camera specications
Resolution HD Camera:
• Still image: 0.92 megapixels
• Video: 1280x720 at 30 fps
Diagonal viewing angle • Camera - 66 degrees
Touchpad specications
Table 16. Touchpad specications
Resolution • Horizontal: 1952
• Vertical: 3220
Dimensions • Width: 4.03 inches (102.40 mm )
• Height: 2.45 inches (62.40 mm)
Multi-touch Support 5 ngers
14 Technical specications

Power supply specications
Table 17. Power supply
Input Voltage 100–240 VAC, 50–60 Hz
Input current (maximum) • 130 W AC Adapter
Battery
Table 18. Battery specications
Type • 56 WHr lithium-ion 3 cell battery
• 97 WHr lithium-ion 6 cell battery
Dimension 1 56 WHr lithium-ion
• Length: 223.2 mm (8.79 inch)
• Width: 71.8 mm (2.83 inch)
• Height: 7.2 mm (0.28 inch)
• Weight: 250.00 g (0.55 lb)
2 97 WHr lithium-ion
• Length: 332 mm (13.07 inch)
• Width: 96.0 mm (3.78 inch)
• Height: 7.7 mm (0.30 inch)
• Weight: 450.00 g (0.992 lb)
Weight (maximum) 450.00 g (0.992 lb)
Voltage • 56 WHr - 11.4 VDC
• 97 WHr - 11.4 VDC
Life span 300 discharge/recharge cycles
Charging time when the computer is o (approximate) 4 hours
Operating time Varies depending on operating conditions and can signicantly
reduce under certain power-intensive conditions
Temperature range: Operating 0°C to 35°C (32°F to 95°F)
Temperature range: Storage -40°C to 65°C (-40°F to 149°F)
Coin-cell battery ML1220
Technical specications 15

Power adapter
Table 19. Power adapter specications
Type 130W adapter
Input Voltage 100 to 240 VAC
Adapter size Height:22 mm (0.86 inches)
Width:66 mm (2.59 inches)
Depth:143 mm (5.62 inches)
Input frequency 50 Hz to 60 Hz
Output current 130 W - 6.67 A (continuous)
Rated output voltage 19.5 VDC
Temperature range (Operating) 0° to 40° C (32° to 104° F)
Temperature range (Non-Operating) 40° to 70° C (-40° to 158° F)
Security
Table 20. Security
Security HW Trusted Platform Module (TPM) 2.0 - Integrated on system board
Computer environment
Airborne contaminant level: G1 as dened by ISA-S71.04-1985
Table 21. Computer environment
Operating Storage
Temperature range 0°C to 40°C (32°F to 104°F) -40°C to 65°C (-40°F to 149°F)
Relative humidity (maximum) 20% to 80% (non-condensing) 5% to 95% (non-condensing)
Vibration (maximum) 2 to 600 Hz at 0.66 Grms 2 to 600 Hz at 1.3 Grms
Shock (maximum) 140 G with pulse duration of 2 msec +/- 5%
(equivalent to 70 in/sec)
160 G with pulse duration of 2 msec +/- 5%
(equivalent to 80 in/sec)
Altitude (maximum) 0 m to 3048 m (0 to 10,000 ft); 0° to 40°C
(32° to 104°F)
0 m to 10668 m (0 to 35,000 ft)
* Measured using a random vibration spectrum that simulates user environment.
† Measured using a 2 ms half-sine pulse when the hard drive is in use.
16 Technical specications

‡ Measured using a 2 ms half-sine pulse when the hard-drive head is in parked position.
Technical specications 17

System Setup
Topics:
• Boot Sequence
• Navigation keys
• System setup options
• System Setup Options
• Updating the BIOS in Windows
• System and setup password
Boot Sequence
Boot Sequence allows you to bypass the System Setup–dened boot device order and boot directly to a specic device (for example:
optical drive or hard drive). During the Power-on Self Test (POST), when the Dell logo appears, you can:
• Access System Setup by pressing F2 key
• Bring up the one-time boot menu by pressing F12 key
The one-time boot menu displays the devices that you can boot from including the diagnostic option. The boot menu options are:
• Removable Drive (if available)
• STXXXX Drive
NOTE: XXX denotes the SATA drive number.
• Optical Drive (if available)
• SATA Hard Drive (if available)
• Diagnostics
NOTE: Choosing Diagnostics, will display the ePSA diagnostics screen.
The boot sequence screen also displays the option to access the System Setup screen.
Navigation keys
NOTE: For most of the System Setup options, changes that you make are recorded but do not take eect until you restart the
system.
Keys Navigation
Up arrow Moves to the previous eld.
Down arrow Moves to the next eld.
Enter Selects a value in the selected eld (if applicable) or follow the link in the eld.
Spacebar Expands or collapses a drop‐down list, if applicable.
Tab Moves to the next focus area.
4
18 System Setup

Keys Navigation
NOTE: For the standard graphics browser only.
Esc Moves to the previous page until you view the main screen. Pressing Esc in the main screen displays a message
that prompts you to save any unsaved changes and restarts the system.
System setup options
NOTE: Depending on the and its installed devices, the items listed in this section may or may not appear.
System Setup Options
NOTE: Depending on your computer and its installed devices, the items listed in this section may or may not appear.
Table 22. Main
Option Description
System Time/Date Allows you to set the date and time.
BIOS Version Displays the BIOS version.
Product Name Displays the product name.
Dell Precision 5530 (Default Setting)
Service Tag Displays the service tag.
Asset Tag Displays the asset tag.
None (Default Setting)
CPU Type Displays the CPU type.
CPU Speed Displays the CPU speed.
CPU ID Displays the CPU ID.
CPU Cache Displays the sizes of the CPU caches.
Fixed HDD Displays the type and size of the HDD.
mSATA Device Displays the type and size of the mSATA device.
AC Adapter Type Displays the type of the AC adapter.
None (Default Setting)
System Memory Displays the size of the system memory.
Extended Memory Displays the size of the extended memory.
Memory Speed Displays the speed of the memory.
Keyboard Type Displays the type of keyboard.
Backlite (Default Setting)
Table 23. Advanced
Option Description
Intel (R) SpeedStep (TM) Allows you to enable or disable the Intel (R)
SpeedStep (TM) feature.
System Setup 19

Option Description
Enabled (Default Setting)
Virtualization This option species whether a Virtual Machine
Monitor (VMM) can utilize the additional hardware
capabilities provided by Intel Virtualization technology.
Allows you to enable or disable the Virtualization
feature.
Enabled (Default Setting)
Multi Core Support Species whether the processor will have one or
more cores enabled. All (Default Setting)
Intel TurboBoost Enables or disables the Intel TurboBoost mode of the
processor. Enabled (Default Setting)
C-States Control This option enables or disables additional processor
sleep states. Enabled (Default Setting)
Audio Enables or disables the integrated audio controller.
Enabled (Default Setting)
Keyboard Illumination This eld lets you choose the operating mode of the
keyboard illumination feature. Disabled (Default
Setting)
USB Conguration Allows you to congure the integrated USB controller.
Default Enabled: Enable Boot Support, Enable
Thunderbolt Ports; Always Allow Dell Docks; Enable
External USB Port
Touchscreen This eld controls whether the touchscreen is enabled
or disabled. Enabled (Default Setting)
AC Behavior Allows the system (if OFF or in Hibernate) to power-
on automatically when AC is inserted.
Wake On LAN Allows the computer to power up from the o state
when triggered by special LAN. Disabled (Default
Setting)
Advanced Battery Charge Conguration Maximizes battery health while still supporting heavy
use during the work day. Disabled (Default Setting)
Block Sleep Lets you to block entering to sleep (S3 state) in OS
environment. Disabled (Default Setting)
Auto On Time Sets the time of day when you would like the system
to turn on automatically. Disabled (Default Setting)
Peak Shift Minimizes AC power usage at times of peak demand.
Disabled (Default Setting)
USB Wake Support Allows you to enable USB devices to wake the system
from Standby. Enabled (Default Setting)
LCD Brightness This options sets the panel brightness independently
for Battery and AC power.
USB Emulation Allows you to enable or disable the USB Emulation
feature.
Enabled (Default Setting)
USB PowerShare Allows you to enable or disable the USB PowerShare
feature.
20 System Setup
