Dell Dimension 5150 Manual

Power Button
NetworkModem
AC Adapter
1. S-video TV-out connector
2. AC adapter connector
3. AC adapter
4. USB connectors
5. IEEE 1394 connector
6. network connector
7. PC Card slot
8. hard drive bay
9. audio connectors
10. CD or DVD drive
11. display latch
12. power button
13. touch pad
14. touch pad buttons
15. battery bay
16. modem connector
Setting Up Your Computer
CAUTION:
Before you set up and operate your Dell™ computer, see the safety instructions
in the Owner's Manual. Also, see your Owner's Manual for a complete list of features.
www.dell.com |support.dell.com
|
0J1415A00
1
2
3
5
46
7
8
9
10
13
12
11
14
15
16
1234

Information in this document is subject to change without notice.
© 2002–2003 Dell Computer Corporation. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Computer Corporation is strictly forbidden.
Dell and the DELL logo are trademarks of Dell Computer Corporation.
Dell disclaims proprietary interest in the marks and names of others.
May 2003
Printed in Malaysia
What’s Next? |
Finding Answers
See your Owner's Manual for information on setting up
devices like printers.
See the Dell Tell Me How help file for information on
using your computer and operating system.
To access the Tell Me How:
1. Click the Start button and click Help and Support.
2. Click User and system guides and click User’s guides.
3. Click Tell Me How.
Battery
To remove the battery, slide and hold the latch, and pull
the battery out of the bay.
